CIRCUIT BREAKERS

A circuit breaker panel(s) is located at the helm.
Most electrical equipment is controlled with circuit
breakers. These breakers will activate if
PUSH TO R ESET – PUSH TO INTERRUPT
PORT ST BD
I G N I G N
PORT ST BD
WIP ER WI PER
LI GHTS WND LS
Your Formula has additional circuit breaker
panels. For location of these panels, refer to
Specifications, in Section 3, for your specific
model.

STEERING

Your Formula boat is equipped with a tilt steering
wheel. Adjust the tilt position by grasping the top
of the steering wheel and depressing the release
lever with your thumb. Release the lever to lock
the steering wheel when achieving a comfortable
position.
! WARNING
Do not adjust the steering wheel tilt
position while the boat is moving. Sudden
boat movement may cause loss of balance
resulting in loss of control and/or injury.
FORMULA
CONTROLS AND INDICATORS
FUME
DETCTR
HORN B LOW E RS
BILG E E NG INE 1 2 VOLT
PUM P HATCH O UTL ET
CABIN
BILG E
ACC ACC
Typical Circuit Breaker Panel
overloaded and cut power to the switch. To
restore power, push the button in and release. If a
circuit continuously overloads under normal
operating conditions, have your boat inspected by
your Formula dealer immediately.
P U S H TO RE S E T – P US H TO I N TE R RU P T
AUTO E NGI NE
P I LOT S Y NC
V H F
RA DI O G P S
ACC ACC
Figure 4-19
1. Release Lever
Tilt Steering Wheel
FASTECH
DE P T H
S OUND E R P LOTT E R RA DA R
H I G H
S P OT TR IM WATE R
LI GH T TA B
A LA R M
ACC ACC AC C
1
FOR059
Figure 4-20
FOR011
4-7
