CARBON MONOXIDE
DETECTOR
TEST
MONTHLY
DO NOT PAINT
READ OWNER"S MANUAL
Carbon Monoxide Detector
Figure 4-29
Air Conditioning Controller—Displays
information and controls certain aspects relative to
the associated air conditioning system (optional).
Controller (Figure 4-29) for each unit is located
centrally, relative to the area being cooled/heated.
Refer to the air conditioning owner's manual in
your Owner Information Binder for operating
instructions.
Air Conditioning Controller
Figure 4-30
FORMULA
CONTROLS AND INDICATORS
Waste Tank Level Indicator—Displays the level
of waste water in the waste tank. The indicator is
located in the head compartment. Refer to Waste
POWER
Water System, in Section 5, for additional
information.
1. Green Light—Empty
2. Yellow Light—Low
FOR069
3. Orange Light—Mid
4. Red Light—Full
VacuFlush
down on the pedal at the base of the toilet. Lifting
up on the pedal will raise the water level in the
bowl, if needed. NOTE: Once the waste holding
tank is "FULL," the head pump is automatically
disabled to prevent further flushing of the toilet
until the tank has been evacuated.
Please refer to the head unit's operator manual
located in your Owner's Information Binder for
additional information.
FOR016
FASTECH
1 2 3
EMPTY LOW MID FULL
Waste Tank Level Indicator
Figure 4-31
—Flushing is controlled by pushing
®
4
FOR018
