O-View Software Suite. This unit, when matched with the OVIEW Bluetooth or
GSM modules, enables remote control and management of the gate control-
ler. Remote control functions include all programming functions that are avail-
able at the front panel LCD on the control board as well as software updates.
OVBT: Bluetooth module for OVIEW and the "O-View Software Suite" appli-
cation for PC, PDA, or Smartphone for localized wireless control of the gate
controller.
OVBTGSM: GSM module that plugs into the OVIEW and provides cellular
phone access through the "O-View Software Suite" application for PC, PDA,
or Smartphone, for wireless local, national, and international controller of the
gate controller.
O-VIEW Software Suite: Provides desktop or Smartphone level control of
wirelessly as new versions of software are made available.
BLUEBUS ACCESSORIES
MOTB: Moon Touch programmable keypad with secure codes (up to 9 digits
per code if required) to control gate opening and closing. Connects to the
2-wire BlueBUS connector with inexpensive unshielded twisted-pair wire.
MOMB: Proximity card access control with capacity for up to 255 MOCARD
or MOCARDP transponder cards. Connects to the 2-wire BlueBUS connec-
tor with inexpensive unshielded twisted-pair wire.
FT210B: Photocell transmitter and receiver pair that connects to the 2-wire
BlueBUS connector with inexpensive unshielded twisted-pair wire and is a
31.1 "General Entrapment Protection Provisions".
MASTER/SLAVE
The gate operator includes a two-pin connector designed to link two sepa-
uration is enabled by connecting two gate operators with simple, unshielded
twisted-pair wire (Max.100 ft.). All entrapment sensors, switch inputs, receiver
controls, and outputs must be wired to the gate operator designated as the
Master/Slave pair.
for each operator. See the "Programming Quick Start" procedures in this
manual for a description of the gate learning process.
On the Master operator, select Function -> Adv. Settings -> Remote Mst. Slv.
Then select On -> Master. The red LED associated with the Master/Slave
connector will illuminate.
On the Slave operator, select Function -> Adv. Settings -> Remote Mst. Slv.
Then select On -> Slave. The red LED associated with the Master/Slave con-
nector will illuminate.
identical open/close/stop functions in tandem with the Master gate operator.

8.4 - Programming the plug-in receiver and remote controls

SMXI/A Plugin Receiver: The SMXI/A 433Plug-In Receiver provides up
includes built-in programming functions for adding or removing Nice FloR/A
wireless remote controls to/from a gate installation. The following procedures
detail the steps to assign a remote control, add a new remote control, delete a
single remote control, or remove all remote controls from the receiver memory.
Programming the FloR/A 2-Button or 4-Button Remote Control with
the SMXI/A Plug-In Receiver.
These procedures apply to the FloR/A wireless remote control. These pro-
cedures assign factory default controls automatically to the remote control.
1. Have a functioning Nice FloR/A 2-button or 4-button remote control with a
battery installed prior to programming the remote control.
2. Press and hold the button on the side of the SMXI/A receiver until the led
illuminates green on the SMXI/A receiver, then release the button.
3. Within 10 seconds, press and hold any key on the FloR/A remote control
until the led in the SMXI/A receiver blinks green 3 times, indicating that the
FloR/A is programmed to control the receiver.
4. After the led on the SMXI/A receiver blinks green 3 times, another 10 sec-
ond interval is started to program another FloR/A remote control if desired.
Repeat step 3 to program the additional FloR/A remote control. Step 3 may
be repeated as many times as necessary to program all available FloR/A
remote controls.
5. Verify that the FloR/A remote control(s) can control the gate by pressing
one or more buttons individually on the remote control(s).
Wirelessly add new remote control to the SMXI/A Plug-In Receiver
A FloR/A remote control that has been programmed to control a SMXI/A
receiver may be used to create other FloR/A remote controls for the same
receiver. This procedure needs to be performed within 10 to 20m (30 to 60
feet) of the SMXI/A receiver, but the SMXI/A receiver does not need to be
physically accessed.
1. Press and hold any button on the un-programmed FloR/A remote control
for at least 5 seconds, then release the button, taking note of the button
that was pressed.
2. Press the same button on the programmed FloR/A remote control three
times.
3. Press the same button in step 1 on the un-programmed FloR/A remote
control and release.
4. It is recommended to test the new copy of the FloR/A remote control with
the assigned gate controller.
NOTE: This procedure will affect all SMXI/A receivers within radio
range.
Deleting a Single FloR/A Remote Control from the SMXI/A Plug-In
Receiver Memory
A FloR/A remote control that has been programmed to control a SMXI/A
receiver may be removed from the SMXI/A receiver memory without affecting
other assigned remote controls. This procedure needs to be performed at the
-
SMXI/A Plug-In Receiver with the affected FloR/A remote control.
1. Press and hold the button on the side of the SMXI/A receiver until the led
on the SMXI/A receiver illuminates green and keep the button pressed. The
led will illuminate after approximately 4 seconds.
2. Press and hold any button on the FloR/A remote control until the led on the
3. Release the button on the side of the SMXI/A receiver.
4. It is recommended to verify that the de-programmed FloR/A remote control
no longer controls the gate.
Deleting All FloR/A Remote Controls from the SMXI/A Plug-In Receiver
Memory.
All programmed remote controls may be removed from the SMXI/A plug in
receiver memory . This procedures need to be performed at the gate controller.
1. Press and hold the button on the side of the SMXI/A receiver until the led
on the SMXI/A receiver illuminates green and keep the button pressed.
2. Watch the led and on the receiver and verify the following sequence in the
led.
3. Within 4 seconds after pressing the button (approx.) the green led illumi-
nates.
4. Within 8 seconds after pressing the button (approx.) the green led turns off.
5. With 12 second after pressing the button (approx.) the green led starts
6.
7. It is recommended to test the FloR/A remote controls, if available, with
SMXI/A plug in receiver to verify that it no longer affects the gate controller.
the 5 TH
11
