1.4 FRONT VIEW

1.4.1 LED Indicators

Power — This LED will emit a
when the Elite Pro Dual is on. During drive activ-
ity the LED will
rebuild the LED will
HDD1/HDD2 — These LEDs represent the two
hard disk drives (HDDs) inside the enclosure. Dur-
ing normal activity, these LEDs will remain off. If
one of the hard drives inside the enclosure fails,
or if one of the drives is removed without the
RAID mode being reset, the corresponding LED
blink red.
will

1.5 REAR VIEW

1
OWC DIGITAL - MERCURY ELITE PRO DUAL
solid blue
blink blue
steadily, and during a
pulse blue
slowly.
2
3
light
Power
6
5
4
2
HDD1 HDD2
