PERFORMANCE CRUISER/SUPER SPORT
S HO REPOW ER
The two shore power inlet breakers, one for shore
power No. 1 circuit and one for shore power No. 2
circuit, protect the AC circuits from the boat's
shore power connectors to the AC control panel.
Refer to Specifications, in Section 3, for shore
power inlet breakers' location.
5-6
MAI N #1
ON
1 20 VAC
6 0 HZ
Shore Power Inlet Breakers
CRUISER/SUPERSPORT
S HOREP OWE R
Figure 5-5

Using Only Shore 1 Power Cord

Shore 1 cord powers the left column of circuit
breakers on the AC control panel. Any of these
circuit breakers may be used with only shore 1
plugged in.
M AIN #2
ON
120 VAC
60 HZ
FOR017
