The ignition safety switch and lanyard will stop an
engine in case of an emergency. Attach the
lanyards to the boat operator whenever the
engines are running but be aware there will be a
loss of boat control if the switches are activated. If
the operator is thrown from the seat or moves too
far from the helm, the lanyards will become
disconnected from the ignition safety switches,
shutting off the engines.
5
1. Ignition Safety Switch Button
2. Fork
3. Center Prong covers Safety Switch Button
4. Lanyard
5. Clothing Hook
Installing Lanyard to Ignition Safety Switch
Figure 4-15
To attach a lanyard, connect the clip to the ignition
safety switch and the hook to a strong piece of
clothing on the operator, such as a belt loop.
!
WARNING
Attach the ignition safety switches'
lanyards to the operator before starting the
engines. This will prevent the boat from
becoming a runaway if the operator is
accidentally thrown away from the helm.
FORMULA

CONTROLS AND INDICATORS

1
2
3
4
FOR124
CRUISER/SUPERSPORT
!
WARNING
The ignition safety switches can only be
effective when they are in good working
condition. Observe the following:
Do not remove or modify an ignition
●
safety switch and/or its lanyard.
The lanyard must be free from
●
obstructions that could interfere with its
operation.
Drive Unit Trim Switch—Labeled "Drives," these
switches activate the drive units' power trim
feature for those formula models outfitted with
stern drive power. Push and hold the top of the
switch to raise the drive unit. Push and hold the
bottom of the switch to lower the drive unit. Use
this switch in combination with the trim gauge to
maximize your boat performance.
1
OUT
D
R
I
V
E
S
IN
OUT
TRAILER
1. Trim Switches
Trim Switches
Figure 4-16
On some remote controls, a combination port and
starboard drive unit trim switch is located in the
throttle handle of the remote control. Push and
hold the switch until both drive units are at the
desired angle.
UP
T
A
B
S
DOWN
FOR045
4-5
