- Page 1 KOBE Range Hoods Brillia Series Model No. INX2730SQB-700-1 INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL PACKAGING MATERIAL. 2. Have your original invoice as proof of purchase and product serial number ready. 3. Call 1-877-BUY-KOBE (289-5623); or e-mail to info@koberangehoods.com to report the problem. NO RETURN, NO REFUND, NO EXCHANGE IF: 1.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................... 2 COMPONENTS OF PACKAGE ....................4 INSTALLATION ......................... 5 OPERATING INSTRUCTIONS ....................9 MAINTENANCE ........................10 SPECIFICATIONS ........................11 MEASUREMENTS & DIAGRAMS ................... 12 PARTS LIST ..........................14 CIRCUIT DIAGRAM ........................ -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
{E} 6” Round Plastic Collar – 1 {F} Liner (Sold Separately) Liner (Sold Separately) For the operation manual, please refer to our website: KOBERangehoods.com FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.KOBERangeHoods.com CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36") C = Height of Counter Top to Wood Frame Bottom (Recommended 26"... - Page 8 - For Insert installation - Preparation Before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. • Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. •...
- Page 9 Wiring to Power Supply Figure 4 SAFETY WARNING RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL LOCAL ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT POWER...
- Page 10 Hood Installation Figure 7 19. Slide the hood to the opening where it will be installed. Two hooks will lock to temporarily hold the hoods’ weight. Figure 7 20. Locate the screw holes (4) on each side of the insert. Adjust the level of the hood casing support according to the thickness of the base (1/2 thickness plywood recommended –...
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS This KOBE hood is equipped with five electronic push buttons with LED indicator, double powerful centrifugal squirrel cage with baffle filters, two bright 3-watt LED lights. The five control buttons are Power Control (On/Off), Speed Control (High, Low, & QuietMode™), Light Control, and Change Filter Indicator. -
Page 12: Maintenance
The indication under symbol will indicate when baffle filter needs cleaning. Remove to clean the baffle filter. (To purchase replacement filters, please contact your local KOBE dealer or call 626-775-8880) MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. -
Page 13: Specifications
SPECIFICATIONS MODEL / SIZE INX2730SQB-700-1 COLOR 18-Gauge Commercial Stainless Steel CONSUMPTION / AMPERE 120W / 3.3A VOLTAGE 120V 60Hz NUMBER OF MOTORS FAN TYPE: CENTRIFUGAL Double Horizontal Squirrel Cage EXHAUST Top 6” Round CONTROLS 5 / Mechanic Push Button - 3-Minute Delay Shutoff HALOGEN LIGHTS 3W-LED x 2 HOOD DIMENSION... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS All ( ) are in millimeter. All inch measurements are converted from millimeters. Inch measurements are estimated. MODEL NO: INX2730SQB-700-1 Bottom View 27-1/2” (699) Front View... - Page 15 Stainless Steel Liner (Sold Separately) Model No. INL36211A...
-
Page 16: Parts List
PARTS LIST MODEL NO: INX2730SQB-700-1 *Liner Sold Separately... - Page 17 INX2730SQB-700-1 Liner (Sold Separately)
-
Page 18: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: INX2730SQB-700-1... -
Page 19: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution Make sure the circuit breaker and the unit’s The power is not on. power is ON. Use a voltage meter to check After the power supply. Installation, The wire connection is not secure. Check and tighten wire connection. both motors The control panel and processor Check wire continuity from control panel to... -
Page 20: Disclaimer
2. PLEASE INSPECT CONTENTS OF PACKAGE(S) CAREFULLY UPON RECEIVING! We must be notified in writing of any damages and/or missing parts within the allocated days upon your receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit. -
Page 21: Warranty
TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE PREMIUM / BRILLIA SERIES: For two years from the date of your original invoice from a KOBE authorized dealer, we will, at our sole discretion, choose to repair or replace the product free of charge that failed due to manufacturing defects. - Page 22 3. Have the model number 4. Have the serial number 5. Have a description of the nature of any defect in the product or part TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS SERVICE CENTER: KOBE SERVICE CENTER (USA ONLY)
-
Page 23: Warranty Information Form
1. Date of purchase 2. Model No. 3. Serial No. For warranty service or spare parts purchase contact: KOBE Service Center (USA ONLY) Toll Free: 1-855-800-KOBE (5623) Email: kobe@adcoservice.com For service in Canada and to report a problem, please... - Page 24 Arcadia, CA 91006 USA www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
