- Page 1 KOBE Range Hoods Brillia Series INX28 SQ-700-1 Series Model No.: INX2830SQB-700-1 (30”) INX2830SQH-700-1 (30”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 IMPORTANT READ THIS FIRST READ BEFORE INSTALLATION 1. Carefully check all contents of packages. 2. Thoroughly inspect the unit for any shipping damages, cosmetic damages or defects 3. Have a certified contractor/electrician test the unit before installation. IF THERE ARE ANY PROBLEMS: 1.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS – CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................ 1 COMPONENTS OF PACKAGE ..................3 INSTALLATION ....................... 4 OPERATING INSTRUCTIONS ..................8 MAINTENANCE ......................9 SPECIFICATIONS ......................10 MEASUREMENTS & DIAGRAMS................. 11 PARTS LIST ........................14 CIRCUIT DIAGRAM ...................... -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the hood. - Page 5 What to Do In the Event Of a Range Top Grease Fire SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
COMPONENTS OF PACKAGE (Must keep all material for returns or refunds) Range Hood Box {A} KOBE Range Hood {B} Warranty Registration Card {C} Quick Reference Guide {D} 6” Round Plastic Collar x1 {E} Twist on wire Connector {F} Screw Package {G} Filter a. -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches). - FOR BUILT-IN / INSERT - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Height of Counter Top to Wood Frame Bottom (Recommended 26”... - Page 8 INSERT INSTALLATION Figure 1 Preparation Before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. A straight, short vent run will allow the hood to perform more efficiently.
- Page 9 Liner Installation Figure 4 6. The custom hood frame must have a sturdy base to accommodate the cut-out for the insert. The base must be recessed to accommodate the height of the liner (See liner dimension on Page 13). 7. Secure the liner to the bottom of the base using screws (not included) appropriate for the size and material of your wood frame.
- Page 10 Duct Work Installation Figure 7 14. Use 6” steel pipe (follow building codes in your area) to connect the ducting on the hood to the ductwork above. Use duct tape to seal and secure joints as shown in Figure 5. 15.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. To operate the fan function Press button to choose the speed. o Q = QuietMode™ speed o L = Low speed o H = High speed ... -
Page 12: Maintenance
MAINTENANCE For optimal appearance, clean the range hood surface and filters regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. ***Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 13: Specifications
SPECIFICATIONS MODEL / SIZE INX2830SQB-700-1 (30”) INX2830SQH-700-1 (30”) COLOR 18-gauge commercial grade stainless steel CONSUMPTION / AMPERE 300W / 2.5A VOLTAGE 120V 60hZ NUMBER OF BLOWER FAN TYPE: CENTRIFUGAL Single Horizontal Squirrel Cage EXHAUST Top 6” Round CONTROLS Mechanical Push Button... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All ( ) are in millimeter. ***All inch measurements are converted from millimeters. Inch measurements are estimated. MODEL NO.: INX2830SQB-700-1 (30”) Side View Bottom View Front View... - Page 15 ***All ( ) are in millimeter. ***All inch measurements are converted from millimeters. Inch measurements are estimated. MODEL NO.: INX2830SQH-700-1 (30”) Side View Bottom View Front View...
- Page 16 Stainless Steel Liner (Sold Separately) Model No.: INL36211A...
-
Page 17: Parts List
PARTS LIST MODEL NO.: INX2830SQB-700-1 (30”) INX2830SQH-700-1 (30”) DESCRIPTION MODEL / SIZE PART NO. 6” Round Plastic Exhaust L1-0505-0003 Wiring Box L1-0231-2730 Blower System L1-0302-0120-802RO Electronic Component Box L1-0524-0003 LED Light Driver L1-0402-0303 Capacitor x 1PCS L1-0401-0120-24 L1-0405-0301 Control Switch... - Page 18 MODEL NO.: INX2830SQB-700-1 (30”)
- Page 19 MODEL NO.: INX2830SQH-700-1 (30”)
-
Page 20: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: INX2830SQB-700-1 INX2830SQH-700-1... -
Page 21: Troubleshooting
TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the Installation, unit’s power is ON. Use a voltage meter both motors to check the power supply. and lights are The wire connection is not secure. Check and tighten wire connection. -
Page 22: Warranty
ONE-YEAR LIMITED LABOR WARRANTY ON KOBE BRILLIA SERIES: For one year from the date of your original invoice from a KOBE authorized dealer, we will repair any parts or components free of charge that failed due to manufacturing defects. KOBE reserves the right to replace, rather than repair the product free of charge at our sole discretion. - Page 23 THIS WARRANTY WILL BE VOIDED BY: 1. Improper installation and failure to follow installation instructions. 2. Any repair, alteration, modification not authorized by KOBE. 3. Duct alteration, modification and connection. 4. Incorrect electric current, voltage or wiring. 5. Improper usage of the product such as commercial, outdoor or other use besides residential indoor usage.
-
Page 24: Warranty Information Form
3. Serial No. : _____________________________ For warranty service or spare parts purchase in US, contact: KOBE Service Center Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880 Toll Free: 1-877-BUY-KOBE (289-5623) For warranty service or spare parts purchase in Canada, contact: Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880... - Page 25 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
