KOBE INX2930SQBF-500-1 Installation Instructions And Operation Manual

Brillia series inx29 sqbf-500-1 series
Hide thumbs Also See for INX2930SQBF-500-1:
Table of Contents

Advertisement

Quick Links

Brillia Series
INX29 SQBF-500-1 Series
Model No.:
KOBE Range Hoods
INX2930SQBF-500-1 (30")
INX2936SQBF-500-1 (36")
INSTALLATION INSTRUCTIONS
AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INX2930SQBF-500-1 and is the answer not in the manual?

Questions and answers

ferris ayoub
July 28, 2025

hi i neded new swich controal

0

Related Manuals for KOBE INX2930SQBF-500-1

Summary of Contents for KOBE INX2930SQBF-500-1

  • Page 1 KOBE Range Hoods Brillia Series INX29 SQBF-500-1 Series Model No.: INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
  • Page 2 IMPORTANT READ THIS FIRST READ BEFORE INSTALLATION 1. Carefully check all contents of packages. 2. Thoroughly inspect the unit for any shipping damages, cosmetic damages or defects. 3. Have a certified contractor/ electrician test the unit before installation. IF THERE IS ANY PROBLEM: 1.

  • Page 3: Table Of Contents

    [ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE ....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS ....................7 MAINTENANCE .......................... 8 SPECIFICATIONS ........................9 MEASUREMENTS & DIAGRAMS ..................... 10 PARTS LIST ..........................11 CIRCUIT DIAGRAM ........................

  • Page 4: Important Safety Instructions

    KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.
  • Page 5 What to Do In The Event Of a Range Top Grease Fire  SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.

  • Page 6: Components Of Package

    COMPONENTS OF PACKAGE (Must keep all material for returns or refunds) Range Hood Box {A} KOBE Range Hood {B} Warranty Registration Card {C} Quick Reference Guide {D} Baffle Filter – 2pcs for 30” – 3pcs for 36” {E} Aluminum Filter – 2pcs for 30”...

  • Page 7: Installation

    1. Read any provided document(s). 2. Test the range hood by temporarily connecting it to an outlet and turning the fan and lights ON. 3. If you run into any problems, contact KOBE Range Hoods. Venting Requirements 4. This range hood has a top 6” Round exhaust (default).
  • Page 8 6. It is recommended to use metal/aluminum duct/pipe with a uniform size (ex. 6” round pipe from range hood to the outside.) 7. If an elbow is necessary, a minimum of 12” straight run is necessary before the elbow. Clearance 8.
  • Page 9 Finish 22. Remove any protective film from the hood. 23. Before using, make sure that any accessories such as baffle filters are properly installed where applicable. 24. Test the range hood to see if it is working properly. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND LOCAL ELECTRICAL CODES.

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS 3-Speed Mechanical Control Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. Button Control Turns the range hood OFF. Lowest fan speed (QuietMode™) Middle fan speed (Low) Highest fan speed (High) Turns the lights ON/OFF Power Control...

  • Page 11: Maintenance

    MAINTENANCE For optimal performance, clean the range hood surface and filters regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. ***Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2.

  • Page 12: Specifications

    SPECIFICATIONS MODEL / SIZE INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”) COLOR 20-Gauge Commercial Grade Stainless Steel CONSUMPTION / AMPERE 240W / 2.0A NUMBER OF BLOWERS DESIGN Seamless / Satin Finish BLOWER TYPE Single Horizontal Squirrel Cage EXHAUST Top 6” Round CONTROLS Mechanical Push Button...

  • Page 13: Measurements & Diagrams

    MEASUREMENTS & DIAGRAMS ***All inch measurements are converted from millimeters. Inch measurements are estimated. ***All measurements in ( ) are millimeters. MODEL NO.: INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”)

  • Page 14: Parts List

    PARTS LIST MODEL NO.: INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”) DESCRIPTION MODEL / SIZE PART NO. 6” Exhaust Vent 02-003 LED Light Driver 02-001 Capacitor (12uF, 250 VAC) 02-004 LED Lights (3W) x 2 02-005 Control Switch 02-006 Blower System 02-012 Aluminum Filter...
  • Page 15 MODEL NO.: INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”)

  • Page 16: Circuit Diagram

    CIRCUIT DIAGRAM MODEL NO.: INX2930SQBF-500-1 (30”) INX2936SQBF-500-1 (36”)

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the Installation, unit’s power is ON. Use a voltage meter to both motors check the power supply. and lights are The wire connection is not secure. Check and tighten wire connection.

  • Page 18: Warranty

    ONE-YEAR LIMITED LABOR WARRANTY ON KOBE BRILLIA SERIES: For one year from the date of your original invoice from a KOBE authorized dealer, we will repair any parts or components free of charge that failed due to manufacturing defects. KOBE reserves the right to replace, rather than repair the product free of charge at our sole discretion.
  • Page 19 THIS WARRANTY WILL BE VOIDED BY: 1. Improper installation and failure to follow installation instructions. 2. Any repair, alteration, modification not authorized by KOBE. 3. Duct alteration, modification and connection. 4. Incorrect electric current, voltage or wiring. 5. Improper usage of the product such as commercial, outdoor or other usage other than residential indoor usage.

  • Page 20: Warranty Information Form

    3. Serial No. :_______________________________ For warranty service or spare parts purchase in US, contact: KOBE Service Center Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880 Toll Free: 1-877-BUY-KOBE (289-5623) For warranty service or spare parts purchase in Canada, contact: Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880...
  • Page 21 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
