Description of the BionX Propulsion System

Your electric bicycle is an EPAC (Electrically Power Assisted Cycle) in accordance with EN 15194 and differs
from a bicycle that isn't electrically assisted.

BionX Propulsion System Components

Battery
1
• Lithium Manganese (LiMn),
48V, 6.6Ah, 317Wh
• Removable, lockable
• Fully charged in: 3-4h
4
Motor
2
• DC rear hub motor
• Black, nom. 250W,
nom. 9Nm / max. 40Nm,
4.7kg
• Brushless, gearless
• Generate mode for energy
recuperation
• Integrated torque sensor
Console
3
• Removable
• Illuminated LCD display with
battery state of charge
• 4 assistance levels
• 4 generate levels
• B acklight controls
• O ffers cycle computer
functions (speed, odometer,
average speed, total distance)
