OPERATING INSTRUCTIONS

PACKET INTERCOM SYSTEM
N-8000 SERIES
Thank you for purchasing TOA's Packet Intercom system.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N-8000 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toa N-8000 series

Summary of Contents for Toa N-8000 series

  • Page 1: Operating Instructions

    OPERATING INSTRUCTIONS PACKET INTERCOM SYSTEM N-8000 SERIES Thank you for purchasing TOA's Packet Intercom system. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY PRECAUTIONS FOR N-8000EX/8010EX/8000RS/8010RS/8400RS/8000MI /8000DI/8000AF/8000CO/8000AL ............14 2. OPERATING INSTRUCTIONS CONFIGURATION ....16 Chapter 1 : GENERAL DESCRIPTION 1. GENERAL DESCRIPTION ............... 1-2 2. FEATURES ......................1-3 3. HANDLING PRECAUTIONS ..............1-3 4. SPECIFICATIONS ..................1-4 5.
  • Page 3 11. OTHER FUNCTION OUTLINE ............1-87 11.1. Tie-line Connection ..................1-87 11.2. PBX Interface (E and M Interface) ..............1-87 11.3. BGM ....................... 1-88 11.4. Contact Input and Output Functions ............... 1-89 11.5. Time Signal ..................... 1-92 11.6. Audio Trigger ....................
  • Page 4 5.5. Outside Line Connection (only when the N-8000CO is used) ......2-58 5.6. Tie-Line Connection (only when the N-8000MI is used) ........ 2-67 5.7. BGM (only when the N-8000MI is used) ............2-69 5.8. External Equipment Control (only when the N-8000MI/8000DI/8000AF /8050DS/8540DS/8640DS/8650DS is used) ..........
  • Page 5 7.5. Multi-Operation Activation ................2-112 8. OTHER FUNCTIONS ................2-115 8.1. Using the Shift Key ..................2-115 8.2. Using the Microphone Indicator Function ............2-115 9. REMOTE MICROPHONE STATION OPERATION TABLE ................2-116 DOOR STATION'S FUNCTIONS AND OPERATION 1. CALLING FROM A DOOR STATION ..........
  • Page 6 5.2. Resetting the Privacy Mode ................2-129 6. CALL BUTTON RESTRICTION (Only when the system is used to "Sequential Response" mode) ....2-130 6.1. Stations to Which the Call Button Restriction Function can be Programmed ..2-130 6.2. Function Description ..................
  • Page 7 3.3. External Equipment Control (only when the N-8000MI/8000DI/8000AF /8050DS/8540DS/8640DS/8650DS is used) ..........2-173 4. OUTSIDE LINE TELEPHONE OPERATION TABLE ... 2-176 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 1. PRIORITIES ....................2-177 1.1. Call Priority (available only when in "Selective Response" mode) ....2-177 1.2.
  • Page 8 17.1. Line status diagnosis ..................2-190 17.2. Network status diagnosis ................2-190 18. TIME SIGNAL .................... 2-191 19. TIME CORRECTION ................2-191 20. AUTOMATIC DAYLIGHT SAVING TIME (SUMMER TIME) CORRECTION ................... 2-191 21. NTP CLIENT FUNCTION (only when the N-8000AF is used) ..

  • Page 9: Installation Of Option Handset

    8. INSTALLATION OF REMOTE MICROPHONE STATION ..3-31 8.1. Desk-Top Installation ..................3-31 8.2. Wall Hanging ....................3-32 8.3. Creating Remote Microphone Name Labels ..........3-34 9. INSTALLATION OF DOOR STATIONS ......... 3-38 9.1. Flush Mounting ....................3-38 9.2. Wall Surface Mounting ..................

  • Page 10: System Setting Function

    5.4. Sub Stations ..................... 4-10 5.5. IP Stations ......................4-11 5.6. Stations ......................4-14 5.7. C/O Interface ....................4-16 5.8. Telephone Interface ..................4-17 5.9. Audio Interface ....................4-19 5.10. Direct Select ....................4-21 5.11. Gateway ......................4-22 5.12. Paging ......................

  • Page 11: System Clock Settings

    6. WHEN SETTINGS ARE COMPLETED ........5-126 6.1. Saving Setting Contents to Files ..............5-126 6.2. Uploading Settings ..................5-126 6.3. Downloading Settings ..................5-126 6.4. Printing Settings ..................... 5-127 7. SYSTEM CLOCK SETTINGS .............. 5-128 8. MESSAGE PAGING SETTINGS ............

  • Page 12: Keys Used For Menu Screen Operation

    10.1. Changing System Names and Passwords ............ 6-39 10.2. Uploading Setting File ................... 6-39 10.3. Downloading Setting File ................6-40 10.4. Updating Firmware ..................6-41 10.5. Clock Settings ....................6-42 Chapter 7 : MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) 1.
  • Page 13 5.1. N-8000EX IP Intercom Exchange ..............8-15 5.2. N-8010EX IP Intercom Exchange ..............8-16 5.3. N-8000MS Multifunctional Master Station ............8-17 5.4. N-8010MS Standard Master Station ..............8-18 5.5. N-8011MS Standard Hands-Free Master Station ..........8-19 5.6. N-8020MS Industrial-Use Master Station ............
  • Page 14 5.56. E-7000TB Terminal Board ................8-50 5.57. AD-1210P AC Adapter ..................8-51 5.58. AD-1215P AC Adapter ..................8-51...

  • Page 15: Safety Precautions

    • Should the following irregularity be found during use, immediately disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit...
  • Page 16 · To mount the unit on the TOA equipment rack, use the rack mounting hardware supplied with the unit. · When connecting the unit's power cord to an AC outlet, use the AC outlet with current capacity allowable to the unit.

  • Page 17: Operating Instructions Configuration

    2. OPERATING INSTRUCTIONS CONFIGURATION This operating instruction consists of Chapter 1 – 8 as follows. Please read the necessary chapter as required. Chapter 1 • System Configuration General Description • Nomenclature and Functions To all users • System Function Chapter 2 •...

  • Page 18: Chapter 1 : General Description

    Chapter 1 GENERAL DESCRIPTION This chapter describes the N-8000 Series Packet Intercom System's basic equipment configurations (exchanges, stations and various interface units), component functions and operations, and two types of conversation methods.

  • Page 19: General Description

    GENERAL DESCRIPTION Chapter 1 1. GENERAL DESCRIPTION The N-8000 Series is a packet intercom system (IP network compatible intercom) employing packet audio technology* . By connecting IP intercom exchanges (which can connect up to 16 stations per exchange), IP stations, and various kinds of interface units to a network (LAN or WAN*...

  • Page 20: Features

    GENERAL DESCRIPTION Chapter 1 2. FEATuRES • Exchanges, IP stations, and various kinds of interface units can be connected over a data communications network. • Can be connected to an existing local area network (LAN) or wide-area network (WAN). The system can also be easily connected to fiber-optic networks without restrictions on operating distance. • The dedicated software program enables centralized control with a personal computer. • System maintenance (verifying operation log and Line supervision) can also be performed with a personal computer and Internet browser. • 3 types of exchanges differ in the following points. (1) 2-wire system N-8000EX: Internal 4 links*, external 8 links*, with PA paging output N-8010EX: Internal 1 link*, external 2 links*, without PA paging output (2) 2-core shielded system N-8000RS: External 2 links* N-8010RS: External 1 link*...

  • Page 21: Specifications

    GENERAL DESCRIPTION Chapter 1 4. SPECIFICATIONS Number of Units Connectable to LAN: Maximum 192 (a total of Exchanges, IP stations, and various kinds of interface units) Line Capacity: Maximum 3072 (192 Exchanges x 16 stations per Exchange) Speech Link Capacity: Maximum 768 (192 N-8000EX Exchanges) Single exchange N-8000EX:...
  • Page 22 GENERAL DESCRIPTION Chapter 1 BGM: Maximum 8 channels (Number of channels selectable at the station) PBX Interface: Maximum 384 (When 192 Multi interface units are connected) Tie-line Interface: Maximum 384 (When 192 Multi interface units are connected) C/O Interface: Maximum 192 (When 192 C/O interface units are connected) Telephone Interface: Maximum 384 (When 192 Telephone interface units are connected) External Contact Output:...

  • Page 23: System Configuration

    GENERAL DESCRIPTION Chapter 1 5. SySTEm CONFIGuRATION 5.1. System Configuration Example This system consists of the following equipment. 2-wire type exchange N-8000EX/8010EX 2-wire type station N-8000MS N-8010MS RS-191 N-8031MS N-8033MS N-8011MS N-8020MS N-8050DS 2-core shielded type exchange N-8000RS/8010RS 2-core shielded type station Network RS-150 RS-160/170...
  • Page 24 GENERAL DESCRIPTION Chapter 1 IP type station Audio interface unit N-8000AF Telephone interface unit N-8000AL Network N-8500MS/8600MS C/O interface unit N-8000CO IP interface module SX-200IP N-8510MS N-8610RM Network N-8540DS N-8640DS N-8650DS Multi interface unit N-8000MI Direct select unit N-8000DI...
  • Page 25 GENERAL DESCRIPTION Chapter 1 5.1.1. Exchange 5.1.3. Peripheral components [2-wire type exchange] N-8000MI: Multi Interface Unit N-8000EX: IP Intercom Exchange N-8000DI: Direct Select Unit N-8010EX: IP Intercom Exchange N-8000AF: Audio Interface Unit N-8000CO: C/O Interface Unit [2-core shielded type exchange] N-8000AL: Telephone Interface Unit N-8000RS: Substation Interface Unit...

  • Page 26: Component Description

    GENERAL DESCRIPTION Chapter 1 5.2. Component Description 5.2.1. Exchange [2-wire type exchange] • N-8000EX IP Intercom Exchange The Exchange permits connection of up to sixteen 2-wire type stations and features two outputs for public address paging. The speech links consist of 4 internal links and 8 external links. The exchange is equipped with a networking interface, allowing connection with IP stations, various kinds of interface units, and other IP intercom exchanges.
  • Page 27 GENERAL DESCRIPTION Chapter 1 5.2.2. Stations [IP station] Specification Speech Method Installation Method Type of Stations Auto- External Control Control Wall cascade- Power Hands- Wall Flush- Display dialing speaker output input surface Handset Headset Desk top connection free hanging mounting mounting N-8500MS: IP Multifunctional...
  • Page 28 GENERAL DESCRIPTION Chapter 1 [2-wire type station] Specification Speech Method Installation Method Type of Stations Auto- External Control External Wall Display dialing speaker output dial input Handset Hands- Wall Flush- surface Headset Desk top free hanging mounting mounting N-8000MS: Multifunctional Master Station N-8010MS: Standard Master Station...
  • Page 29 GENERAL DESCRIPTION Chapter 1 [2-core shielded station] Specification Type of Stations Speech Method Installation Method External speaker Control output Handset Hands-free Flush-mounting Wall surface mounting RS-150: Sub Station RS-160: Sub Station RS-170: *2, *3 Sub Station RS-180: *2, *3 Sub Station RS-140: Switch Panel RS-143:...
  • Page 30 GENERAL DESCRIPTION Chapter 1 5.2.3. Peripheral components [N-8000MI Multi Interface Unit] Having 2 channels each for audio input and output, and 16 contacts each for control input and output, the N-8000MI performs the following interface functions*. • Tie-line interface for connection with the EXES-2000 and EXES-6000 systems. • PBX interface for connection with the PBX via the analog E&M interface. • PA paging interface for connection with PA equipment • E xternal input broadcast interface for connection with a music player (chime unit) or paging microphone irrespective of with or without remote control function. • I nterface function that enables external broadcast by connecting a paging microphone or a playing device without a Remote Control function.
  • Page 31 GENERAL DESCRIPTION Chapter 1 [N-8000DI Direct Select Unit] Having 32 contacts each for control input and output, the N-8000DI performs the following interface functions. • Interface to control an indicator or external equipment such as a CCTV's switcher using relay contacts. • I nterface function that enables Direct Select, Calling Station Display and Remote Dialing functions for designated Master Stations using contact input and output. • I nterface function that uses contact output to diagnose system line and network statuses and transmits the diagnosed result. The N-8000DI also features Network interface for connection with IP stations, IP intercom exchanges, and various kinds of interface units.

  • Page 32: Rack Mounting Examples For Exchanges

    GENERAL DESCRIPTION Chapter 1 5.3. Rack mounting Examples for Exchanges Note The Exchange N-8000EX in these examples can be replaced with the N-8010EX/8000RS/8010RS/8400RS. 5.3.1. A 128-line exchange system 5.3.2. A 192-line exchange system 5.3.3. A 256-line exchange system One CR-273 Equipment Rack is One CR-413 Equipment Rack is Two CR-273 Equipment Racks are used.
  • Page 33 GENERAL DESCRIPTION Chapter 1 5.3.4. A 3072-line exchange system Sixteen CR-413 Equipment Racks are used. Blower unit (BU-412) Rack No. 1 No. 8 No. 9 No. 15 No. 16 Exchange (N-8000EX) Exchange (N-8000EX) Blank panel (2U) Blank panel (2U) Blank panel (2U) Exchange (N-8000EX) Exchange (N-8000EX) Perforated panel Perforated panel...

  • Page 34: Nomenclature And Functions

    GENERAL DESCRIPTION Chapter 1 6. NOmENCLATuRE AND FuNCTIONS 6.1. IP Intercom Exchanges and Their Connected Equipment 6.1.1. N-8000EX IP Intercom Exchange [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the exchange. Lights when power is supplied to the exchange. 2. LNK/ACT indicator [LNK/ACT] (green) 5.
  • Page 35 GENERAL DESCRIPTION Chapter 1 6.1.2. N-8010EX IP Intercom Exchange [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the exchange. Lights when power is supplied to the exchange. 2. LNK/ACT indicator [LNK/ACT] (green) 5. mAC address Lights when connected to a network, and flashes This is the MAC address* for the unit. Since the while transmitting or receiving data.
  • Page 36 GENERAL DESCRIPTION Chapter 1 6.1.3. N-8000MS Multifunctional Master Station [Top] 15 16 1. Handset 5. Speaker Lift the handset for handset conversation. Lifting Outputs call tones and used for hands-free the handset disconnects both the hands-free conversations. microphone and the speaker. 6. Liquid crystal display 2.
  • Page 37 GENERAL DESCRIPTION Chapter 1 9. Redial key [REDIAL] 14. Arrow keys [ ][ ][ ][ ] Permits the last called number to be dialed. (Refer Use these keys to perform auto-dial registration 2-8.) (refer to 2-11) or system settings (refer to Chapter 1 0. Function key [FUNCTION] Use this key to perform function settings such as...
  • Page 38 GENERAL DESCRIPTION Chapter 1 [Bottom] 2 2. Speaker selector switch [INT.SP/EXT.SP] 2 4. Wall bracket mounting slots Used to select either an internal (INT.SP) or an Hang the mounting bracket hooks to these slots external (EXT.SP) speaker. when using the YC-280 Wall Mounting Bracket. (Refer to 3-19, 3-23.) 23.
  • Page 39 GENERAL DESCRIPTION Chapter 1 6.1.4. N-8010MS Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-15.) microphone and the speaker. 8. Push-to-talk key [PTT] 2.
  • Page 40 GENERAL DESCRIPTION Chapter 1 [Rear] 14. Line connection terminal [LINE] Connects to the exchange. (RJ-11 modular jack) [Bottom] 15. microphone 1 6. Wall bracket mounting slots Used for hands-free conversation. Hang the hooks of the mounting bracket to these slots when using the YC-280 Wall Mounting Note Bracket.
  • Page 41 GENERAL DESCRIPTION Chapter 1 6.1.5. N-8011MS Standard Hands-free Master Station [Top] 1. Paging response key [RESP.] 7. Redial key [REDIAL] Responds to a paging. (Refer to 2-31.) Permits the last called number to be dialed. (Refer 2-8.) 2. Paging key [CALL] 8. Transfer key [TRANSFER] Makes a paging. (Refer to 2-25.) Used to transfer the current conversation to 3.
  • Page 42 GENERAL DESCRIPTION Chapter 1 [Rear] 12. Line connection terminal [LINE] Connects to the exchange. (RJ-11 modular jack) [Bottom] 13. microphone 1 4. Wall bracket mounting slots Used for hands-free conversation. Hang the mounting bracket hooks to these slots when using the YC-290 Wall mounting bracket. Note (Refer to 3-21,...
  • Page 43 GENERAL DESCRIPTION Chapter 1 6.1.6. N-8020MS Industrial-Use Master Station [Top] 1. Handset 7. Redial key [REDIAL] Lift the handset for handset conversation. Lifting Permits the last called number to be dialed. (Refer the handset disconnects both the hands-free 2-8.) microphone and the speaker. 8. Transfer key [TRANSFER] 2. Status indicator (red) Used to transfer the current conversation to Flashes when a call is received, continuously lights another station.
  • Page 44 GENERAL DESCRIPTION Chapter 1 [Rear] Protection cover 14 15 1 3. Line connection cable [LINE] Shift the Speaker selector switch (16) located Connects to the exchange. (3 m-length cable with on the bottom surface of the unit to the EXT.SP position when using the external speaker. RJ-11 modular plug) Note: Do not remove the protection cover.
  • Page 45 GENERAL DESCRIPTION Chapter 1 6.1.7. N-8031MS Flush-Mount Master Station [Front] [Rear] 1. Status indicator (red) 7. Function key [FUNCTION] Flashes when a call is received, continuously lights Use this key to perform function settings such as during a conversation, and is off while in standby assigning call transfer recipients or programming mode.
  • Page 46 GENERAL DESCRIPTION Chapter 1 1 4. Handset connection terminals [CN302] 1 5. External dial input terminals [CN306] A dedicated RS-191 Option Handset can be An external switch such as a footswitch can be connected. (Refer to 3-58.) connected. (Refer to 3-59.) One-touch dial function needs be programmed when using the external switch. (Refer to 2-12.) 6.1.8. RS-191 Indoor Option Handset [Front]...
  • Page 47 The front protective sheet is a wear-and-tear item. It is highly recommended to replace it every 100,000 times of operations (approx. 3 years) for any key. Part code: 115-51-304-00 For replacement, please contact your nearest TOA dealer. 1. Status indicator (red) 8. Redial key [RE.] Flashes when a call is received, continuously lights Permits the last called number to be dialed.
  • Page 48 GENERAL DESCRIPTION Chapter 1 6.1.10. N-8050DS Door Station [Front] [Rear] 1. Speaker 4. microphone Outputs call tones and used for hands-free Used for hands-free conversation. conversations. 5. Line connection terminal [LINE] 2. Status indicator (red) Connects to the exchange. (Terminal block) Flashes when a call is received, continuously lights (Refer to 3-56.) during a conversation, and is off while in standby...

  • Page 49: Ip Station

    GENERAL DESCRIPTION Chapter 1 6.2. IP Station 6.2.1. N-8500MS IP Multifunctional Master Station [Top] 15 16 1. Handset 6. Liquid crystal display Lift the handset for handset conversation. Lifting Displays the dialed number or the number of a the handset disconnects both the hands-free call received in 2 lines of 16 digits. Pressing the microphone and the speaker.
  • Page 50 GENERAL DESCRIPTION Chapter 1 11. Push-to-talk key [PTT] 15. Paging key [CALL] Pressing this key while calling a party by means Makes a paging. (Refer to 2-25.) of a continuous call tone permits a voice call to 16. Paging response key [RESP.] be made.
  • Page 51 GENERAL DESCRIPTION Chapter 1 [Bottom] 2 8. MAC address 3 0. Microphone This is the MAC address* for the unit. Since Used for hands-free conversation. the relationship of each unit location to its MAC Note address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that might block sound and prevent conversations.
  • Page 52 GENERAL DESCRIPTION Chapter 1 6.2.2. N-8510MS IP Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-15.) microphone and the speaker. 8. Push-to-talk key [PTT] 2.
  • Page 53 GENERAL DESCRIPTION Chapter 1 [Rear] CONTACT IN 14 15 14. AC adapter terminal [DC INPuT] 17. ACT indicator (green) Connect the AC adapter* to this terminal. Lights while transmitting or receiving data. * Use the AD-1210P/1215P (optional) or its 1 8. FD indicator (yellow) equivalent. Lights when the network is in full duplex communications.
  • Page 54 GENERAL DESCRIPTION Chapter 1 [Bottom] 19. mAC address 2 0. Microphone This is the MAC address* for the unit. Since Used for hands-free conversation. Note the relationship of each unit location to its MAC address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that might block sound and prevent conversations.
  • Page 55 GENERAL DESCRIPTION Chapter 1 6.2.3. N-8600MS IP Multifunctional Master Station [Top] 15 16 1. Handset 6. Liquid crystal display Lift the handset for handset conversation. Lifting Displays the dialed number or the number of a the handset disconnects both the hands-free call received in 2 lines of 16 digits. Pressing the microphone and the speaker.
  • Page 56 GENERAL DESCRIPTION Chapter 1 11. Push-to-talk key [PTT] 15. Paging key [CALL] Pressing this key while calling a party by means Makes a paging. (Refer to 2-25.) of a continuous call tone permits a voice call to 16. Paging response key [RESP.] be made.
  • Page 57 GENERAL DESCRIPTION Chapter 1 [Bottom] 26. mAC address 2 8. Microphone This is the MAC address* for the unit. Since Used for hands-free conversation. the relationship of each unit location to its MAC Note address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that might block sound and prevent conversations.
  • Page 58 GENERAL DESCRIPTION Chapter 1 6.2.4. N-8610RM IP Remote Microphone Station [Top] N-8610RM IP REMOTE MICROPHONE STATION 11 12 13 1. microphone 6. Indication label insert slots Used for conversation and voice announcements. Labels can be printed using the SX-2000 Setting Software. 2. Power indicator (green) For details, refer to the instruction manual of the Lights when the power is turned on.
  • Page 59 GENERAL DESCRIPTION Chapter 1 1 0. Talk key 11. Function keys (L1 – L3) Press this key to broadcast a voice announcement Positioned in top-down order (L1, L2, L3). These and conversation. keys operate in the same manner as the Function If the Talk key is set to "PTT" ("press-to-talk") keys (R1 –...
  • Page 60 GENERAL DESCRIPTION Chapter 1 [Rear] 15. AC adapter terminal [DC INPuT] Connect the AC adapter* to this terminal. Use the AD-1210P/1215P (optional) or its equivalent. IP REMOTE MICROPHONE STATION 16. Network connection terminal [LAN] Can be connected to a network of 10BASE- DC INPUT T/100BASE-TX in auto-sensing.
  • Page 61 GENERAL DESCRIPTION Chapter 1 6.2.5. N-8540DS IP Door Station [Front] [Side] [Rear] [Top] 1. Speaker 6. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent. 2. Status indicator (red) Flashes when a call or paging announcement is 7. Contact output terminals [H, C] received, continuously lights during conversation, External equipment such as an electronic lock...
  • Page 62 GENERAL DESCRIPTION Chapter 1 6.2.6. N-8640DS IP Door Station [Front] [Rear] 1. Speaker 7. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent. 2. Status indicator (red) Flashes when a call or paging announcement is 8. External connection cables received, continuously lights during conversation, • External contact input (HOT: Gray, COM:...
  • Page 63 GENERAL DESCRIPTION Chapter 1 6.2.7. N-8650DS IP Door Station [Front] [Rear] 1. Speaker 5. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent. 2. Call button/Status indicator (red) Used to call the preprogrammed master station. 6. External connection cables Flashes when a call or paging announcement is • External contact input (HOT: Gray, COM:...

  • Page 64: Substation Interface Units And Their Connected Equipment

    GENERAL DESCRIPTION Chapter 1 6.3. Substation Interface Units and Their Connected Equipment 6.3.1. N-8000RS/8010RS 2-Core Shielded Substation Interface Unit [Front] 1 2 3 4 5 Note: The figure represents the N-8000RS. 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the unit. Lights when power is supplied to the unit. 2. LNK/ACT indicator [LNK/ACT] (green) 5. mAC address Lights when connected to a network, and flashes This is the MAC address* for the unit. Since the while transmitting or receiving data.
  • Page 65 GENERAL DESCRIPTION Chapter 1 6.3.2. RS-150 Indoor Substation [Front] [Rear] 1. Speaker 3. Connection cable (orange, brown, black) Outputs call tones and used for hands-free Connects to the 2-core shielded substation conversations. interface unit. 2. Call button Used to call the preprogrammed master station. 6.3.3. RS-160 Indoor Vandal-Resistant Substation and RS-170 Outdoor Vandal-Resistant Substation [Front] [Rear] The RS-170 substation has a weather-resistant coating on its printed circuit board.
  • Page 66 GENERAL DESCRIPTION Chapter 1 6.3.4. RS-180 Emergency Substation [Front] [Rear] The RS-180 substation has a weather-resistant coating on its printed circuit board. 1. Speaker 4. Connection cable (orange, brown, black) Outputs call tones and used for hands-free Connects to the 2-core shielded substation conversations. interface unit. 2. Status indicator (red) 5. Control cable (blue, white) Flashes when a call is received, continuously lights Connectable to an external equipment such as an during a conversation, and is off while in standby...
  • Page 67 GENERAL DESCRIPTION Chapter 1 6.3.5. RS-140 Switch Panel [Front] [Side] 1. Status indicator (red) 5. Connection cable (brown, red, orange) Flashes when a call is received, continuously lights Connects to the 2-core shielded substation during a conversation, and is off while in standby interface unit. mode. The indicator also continuously lights while receiving a paging announcement.
  • Page 68 GENERAL DESCRIPTION Chapter 1 6.3.6. RS-142 Switch Board [Front] 1. Connection cables (Brown, Red, Orange) Connects to the 2-core shielded substation interface unit. 2. Speaker cables (Yellow, Green, Blue) Connects to an external speaker. 3. Call button interlock cable (Purple) Connects to the RS-141 Optional handset. 4. Call button 1 cables (White, Brown) Used to call the preprogrammed master station. 5. Call button 2 cables (Orange, Gray) Used to call the preprogrammed master station. 6.3.7. RS-143 Switch Panel [Front] [Side]...
  • Page 69 GENERAL DESCRIPTION Chapter 1 6.3.8. RS-144 Switch Panel [Front] [Side] 1. Emergency call button [EMERGENCY] 4. Speaker cables (Yellow, Green, Blue) Used to call the preprogrammed master station. Connects to an external speaker. 2. Call button [NORMAL] 5. Call button interlock cable (Purple) Used to call the preprogrammed master station. Connects to the RS-141 Optional handset. 3. Connection cables (Brown, Red, Orange) Connects to the 2-core shielded substation interface unit.
  • Page 70 GENERAL DESCRIPTION Chapter 1 6.3.9. RS-141 Indoor Option Handset for RS-140/142/143/144 [Front] 1. Volume control Adjusts the call volume heard at the handset. 2. Connection cable (brown, red, orange) Connects to the 2-core shielded substation interface unit. 3. Speaker cable (yellow, green, blue) Connects to the external speaker. 4. Handset cable (purple) Connects to the RS-140/143/144 Switch Panel or the RS-142 Switch Board. 5.
  • Page 71 GENERAL DESCRIPTION Chapter 1 6.3.10. N-8400RS 4-Wire Substation Interface Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the unit. Lights when power is supplied to the unit. 2. LNK/ACT indicator [LNK/ACT] (green) 5. mAC address Lights when connected to a network, and flashes This is the MAC address* for the unit. Since the while transmitting or receiving data.
  • Page 72 GENERAL DESCRIPTION Chapter 1 6.3.11. N-8410MS Analog Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-15.) microphone and the speaker. 8. Push-to-talk key [PTT] 2.
  • Page 73 GENERAL DESCRIPTION Chapter 1 [Rear] 1 4. Hands-free speaker volume control switch [HANDS FREE SP VOL] Adjusts the hands-free speaker volume. 1 5. Handset speaker volume control dial [HAND HANDS FREE HAND SET LINE SET SP VOL] SP VOL SP VOL Adjusts the handset speaker volume. 16. Line connection terminal [LINE] Connects to the 4-wire substation interface unit.
  • Page 74 GENERAL DESCRIPTION Chapter 1 6.3.12. RS-450 Indoor Substation [Front] [Rear] 1. Speaker 3. microphone Outputs call tones and used for hands-free Used for hands-free conversation. conversations. 4. Connection cable (brown, red, orange, yellow) 2. Call button Connects to the 4-wire substation interface unit. Used to call the preprogrammed master station. 6.3.13. RS-460 Indoor Vandal-Resistant Substation and RS-470 Outdoor Vandal-Resistant Substation [Front] [Rear] The RS-470 substation has...
  • Page 75 GENERAL DESCRIPTION Chapter 1 6.3.14. RS-480 4-Wire Multi-Purpose Substation [Front] [Rear] The RS-480 substation has a weather-resistant coating on its printed circuit board. 1. Speaker 5. Handset cable (purple) Outputs call tones and used for hands-free Connects to the RS-481 Option Handset. conversations. 6. Connection cable (brown, red, orange, yellow) 2. Status indicator (red) Connects to the 4-wire substation interface unit. Flashes when a call is received, continuously lights 7. Control cable (blue, green) during a conversation, and is off while in standby...
  • Page 76 GENERAL DESCRIPTION Chapter 1 6.3.15. RS-442 4-Wire Switch Board [Front] 1. Connection cable (brown, red, orange, yellow) 5. Speaker cable (red, black) Connects to the 4-wire substation interface unit. Connects to the external speaker. 2. Control cable (green, blue) 6. microphone Connectable to an external indicator. Fix the microphone to an operation panel. closed contact provided only during 7. Call button connection cables (white, gray, conversation.

  • Page 77: Interface Unit

    GENERAL DESCRIPTION Chapter 1 6.4. Interface unit 6.4.1. N-8000MI Multi Interface Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates this unit. Lights when power is supplied to the unit. 2. LNK/ACT indicator [LNK/ACT] (green) 5. mAC address Lights when connected to a network, and flashes This is the MAC address for the unit.
  • Page 78 GENERAL DESCRIPTION Chapter 1 13. Audio output terminal [AuDIO OuT] 1 4. PBX interface terminal [PBX IF] Includes audio outputs (maximum 0 dB , under Connects to the Exchange of the EXES-2000 600 Ω, balanced) and control outputs (relay or EXES-6000 system by a tie-line, or the PBX contact withstand voltage: 24 V DC, control exchange via the analog E&M interface.
  • Page 79 GENERAL DESCRIPTION Chapter 1 6.4.3. N-8000AF Audio Interface Unit [Front] [Rear] 1 2 3 4 5 6 7 16 17 1. Reset key [RESET] 1 0. Audio output terminal [AUDIO OUTPUT] Pressing this key reactivates this unit. This terminal connects to a recording device, etc. (Refer to 3-83, "Terminal plug connection.") 2. LNK/ACT indicator [LNK/ACT] (green) Max.
  • Page 80 GENERAL DESCRIPTION Chapter 1 6.4.4. N-8000AL Telephone Interface Unit [Front] [Rear] 1 2 3 4 5 6 1. Reset key [RESET] 7. Cord clamp Pressing this key reactivates this unit. Pass the power cord through this clamp to ensure that the plug does not pull out when the unit is 2. LNK/ACT indicator [LNK/ACT] (green) mounted to a wall.
  • Page 81 GENERAL DESCRIPTION Chapter 1 6.4.5. N-8000DI Direct Select Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 5. mAC address Pressing this key reactivates this unit. This is the MAC address* for the unit. Since the relationship of each unit location to its MAC address 2. LNK/ACT indicator [LNK/ACT] (green) is established when setting the network attributes, Lights when connected to a network, and flashes...
  • Page 82 GENERAL DESCRIPTION Chapter 1 6.4.6. SX-200IP IP Interface Module [Front] 1 2 3 FOR SX-2000 SERIES ONLY LINK/ACT 10/100M RESET RUN IP INTERFACE MODULE model SX-200IP 1. mAC address 4. Network connection terminal [LAN] This is the MAC address* for the unit. Since the Connects to a 10BASE-T- or 100BASE-TX- relationship of each unit location to its MAC address compatible network.

  • Page 83: System Function Table

    GENERAL DESCRIPTION Chapter 1 7. SYSTEM FUNCTION TABLE 7.1. Basic Functions IP stations or the system consisting of Exchanges and stations makes the following functions available. 7.1.1. Master station's functions Reference page Function Description Operation Setting The desired party can be called by dialing its station Individual call p.
  • Page 84 GENERAL DESCRIPTION Chapter 1 Reference page Function Description Operation Setting When it is desirable to hold the line during a conversation, Mic off if any dialing key ([0] – [9]) is pressed, the microphone p. 2-14 is disabled as long as the key is pressed. Hold Pressing the Hold key during a conversation places the conversation on hold, transmitting a hold tone to both...
  • Page 85 GENERAL DESCRIPTION Chapter 1 Reference page Function Description Operation Setting Zone paging Calls can be made to one of the preprogrammed zones. p. 2-25 p. 5-67 p. 5-82 Selectable Calls can be made to up to 50 zones of the p.
  • Page 86 Station to make or receive calls to or from the outside p. 2-58 p. 5-90 connection line telephone. Using the Multi interface unit for tie-line connection between the N-8000 Series intercom system exchange Tie-line and other series intercom system exchanges via 4-wire p. 2-67 p. 5-45 connection...
  • Page 87 GENERAL DESCRIPTION Chapter 1 7.1.2. Remote microphone station’s functions Reference page Function Description Operation Setting The desired party can be called by pressing the station Conversation Individual call call key into which the station number to be called is p. 2-95 p. 5-76 programmed. Automatic Incoming calls are automatically connected after a brief connection...
  • Page 88 GENERAL DESCRIPTION Chapter 1 Reference page Function Description Operation Setting Current conversations can be placed on hold to call a third party by pressing the Transfer key. The Call Transfer original conversation can be subsequently restored p. 2-15 or transferred to the third party after conclusion of the second call.
  • Page 89 GENERAL DESCRIPTION Chapter 1 7.1.3. Door station's functions Reference page Function Description Operation Setting Pressing the call button allows the preprogrammed p. 5-68 Call Master Station or the analog telephone connected to p. 2-117 p. 5-83 the N-8000AL unit to be called. Emergency calls can be made by quickly pressing p.
  • Page 90 GENERAL DESCRIPTION Chapter 1 7.1.5. Telephone's functions Reference page Function Description Operation Setting Calls can be made to the desired station by dialing its Individual call p. 2-134 number. When a station is assigned to a call group, if the station is Conversation called, all stations within that group are simultaneously Group call...
  • Page 91 GENERAL DESCRIPTION Chapter 1 Reference page Function Description Operation Setting Zone paging Calls can be made to one of the preprogrammed zones. p. 2-143 Selectable Calls can be made to up to 50 zones of the p. 5-100 p. 2-144 paging preprogrammed multiple zones.
  • Page 92 GENERAL DESCRIPTION Chapter 1 7.1.6. Outside line's functions Reference page Function Description Operation Setting Calls four preprogrammed stations Direct in line call simultaneously. p. 2-159 p. 5-90 Calls the desired station directly via a designated Direct inward dialing call station. Zone paging Calls can be made to one of the preprogrammed zones.

  • Page 93: Other Functions

    GENERAL DESCRIPTION Chapter 1 7.2. Other Functions Reference page Function Description Operation Setting Response Priority: When the system's call response mode is set to "Selective Response" and a station simultaneously receives multiple calls, priorities can be assigned to p. 5-36 calls to be responded to. Priority p.
  • Page 94 GENERAL DESCRIPTION Chapter 1 Reference page Function Description Operation Setting Call/conversation sync The contact output of the door station is closed p. 5-37 p. 2-185 contact output depending on their respective operations. p. 5-64 When dialing operations (up to 20 digits) have been preprogrammed into the external control input of the N-8640DS/8650DS, such dialing operations can IP door station external...

  • Page 95: Two Call Response Methods

    GENERAL DESCRIPTION Chapter 1 8. TWO CALL RESPONSE METHODS Two different call response methods are available to the N-8000 system: "Sequential Response" and "Selective Response." The former is used in "Master-to-Master" systems that allow free communication between Master Stations by calling one another, while the latter is used in "Master-to-Sub" systems in which substations installed in different locations call one specified Master Station.

  • Page 96: Paging Function Outlines

    GENERAL DESCRIPTION Chapter 1 9. PAGING FuNCTION OuTLINES There are two types of paging: (1) PA paging by way of external PA equipment and (2) Station paging by way of the station's internal speaker. Both types have access to the (1) zone paging function which pages one zone, (2) the selectable paging function which pages multiple selected zones, and (3) the all-call paging function which pages all zones simultaneously.

  • Page 97: Paging Functions

    GENERAL DESCRIPTION Chapter 1 9.1.3. External input paging Microphone announcements or background music can be broadcast to any desired channel by connecting a Remote microphone or playback components to the N-8000MI/8000AF unit. Note External input pagings with priority ON take precedence over paging calls and conversations. Audio signal: 1 pair (0 dB*) N-8000MI...

  • Page 98: Station Paging Receiving Mode

    GENERAL DESCRIPTION Chapter 1 9.3. Station Paging Receiving Mode The station that receives Station Paging operates in either Conversation priority mode or Paging priority mode as described below. However, when the exchange to which the station connects is the N-8010EX, the mode is fixed to the Conversation priority mode. Use the supplied N-8000 Setting Software for the mode setting.

  • Page 99: Responding To Paging

    To respond to the paging, use the station assigned to the paged zone. Use this mode when each paging zone is independent. When using external PA speakers, their zones must match those of master stations. Building A Building B Building C Hello, Mr. TOA. Zone 1 Zone 2 Zone 3 Please respond.

  • Page 100: Outline Of The Message Paging Function

    GENERAL DESCRIPTION Chapter 1 10. OUTLINE OF THE MESSAGE PAGING FUNCTION Emergency communication systems can be created using the N-8500MS/8510MS/8600MS IP Master Stations or the N-8610RM IP Remote Microphone Station. Messages preprogrammed into the IP Master Station or the IP Remote Microphone Station can automatically be broadcast through operation of that station's keys or by means of external control input.

  • Page 101: Message Recording

    GENERAL DESCRIPTION Chapter 1 10.1. Message Recording • Use the N-8000 Setting Software to record the Message on a PC and program it into the IP Master Station or the IP Remote Microphone Station from the PC. • Messages of up to 20 seconds in length can be recorded and programmed.

  • Page 102: Message Paging Zones

    GENERAL DESCRIPTION Chapter 1 (2) Only the N-8510MS standard IP Master Station can initiate Message pagings using the make contact signal input if its rear panel-mounted Message Startup terminal is connected to a switch, sensor or other external device. When the N-8510MS Station receives the make contact signal while it is in use, it stops its current operation and initiates the Message paging.

  • Page 103: Message Paging Priority Level

    GENERAL DESCRIPTION Chapter 1 10.6. Message Paging Priority Level The Message paging takes precedence over normal conversations and paging calls (except Emergency paging). When the station to which the Message is being transmitted is in operation, all such operations are forcibly terminated, allowing the Message paging to go through. Such terminated operations are not restored even after the Message paging is completed.

  • Page 104: Other Function Outline

    GENERAL DESCRIPTION Chapter 1 11. OTHER FuNCTION OuTLINE 11.1. Tie-line Connection Conversations or paging can be performed by connecting the N-8000MI unit to the exchange of EXES-2000 or EXES-6000 Series intercom systems. Wiring requires two pairs of cables per line, and the connected exchange must be equipped with a Tie-line unit (TI-20A for the EXES-2000 and TI-600 for the EXES-6000).

  • Page 105: Bgm

    GENERAL DESCRIPTION Chapter 1 11.3. BGM Background music can be transmitted to the station speakers in standby mode by connecting the N-8000MI unit to musical playing equipment. Any BGM program can be selected from 8 channels at each station. BGM signal: 1 pair each (0 dB*) Channel 1 BGM 7 N-8000MI...

  • Page 106: Contact Input And Output Functions

    GENERAL DESCRIPTION Chapter 1 11.4. Contact Input and Output Functions The following functions can be realized by using the N-8000MI's, the N-8000DI's, or N-8000AF's contact input and output. However, the functions that can be realized are different depending on the models as shown in the table below.
  • Page 107 GENERAL DESCRIPTION Chapter 1 11.4.3. Contact bridge function (external contact interlock) Contact signals can be transmitted by way of a network. N-8640DS Contact output N-8050DS Contact output N-8000EX/8010EX N-8000MI/8000DI N-8000MI/8000DI Contact output Contact input 11.4.4. Paging busy input Busy status data from an airport broadcast system or similar large sound systems can be received when the N-8000MI is interlocked with such systems, allowing important information to be accurately transmitted.
  • Page 108 GENERAL DESCRIPTION Chapter 1 11.4.6. Direct select This function can be used when the system's call response mode is set to "Selective Response." By separately making an operation panel for a specified Master Station which is equipped with the lamps and buttons corresponding to other stations, and by assigning the Master Station and other stations to the N-8000DI's contact input and output channels, the stations that are calling the Master Station are indicated by means of lamps.

  • Page 109: Time Signal

    GENERAL DESCRIPTION Chapter 1 11.5. Time Signal This function pagings set sound sources to set paging zones according to preprogrammed schedules using the N-8000AF Audio Interface. The operation mode of one of the Audio Interfaces in the system must be set to "Time Signal,"...

  • Page 110: Recording

    GENERAL DESCRIPTION Chapter 1 11.7. Recording Setting the Audio Interface Unit's operation mode to Conversation Recording allows the recording of conversations, conferences, paging calls and scan monitoring of the Master Stations and telephones (used instead of stations). It is also possible to record conversations of the outside line telephones. Such conversations and conferences are recorded on recorders connected to the Audio Interface Unit.

  • Page 111: Broadcast To Sx-2000 System

    GENERAL DESCRIPTION Chapter 1 11.10. Broadcast to SX-2000 System Using the SX-200IP IP Interface Module in the SX-2000 system allows broadcasts from the N-8600MS Multifunctional master station or N-8610RM IP Remote microphone station to be made to the SX-2000 system. SX-2000 system (1) SX-2000SM SX-2100AI SX-200IP Slot...
  • Page 112 Chapter 2 FUNCTION AND OPERATION This chapter describes the system functions and operation of the N-8000 Series Packet Intercom System.

  • Page 113: Chapter 2 : Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1. BASIC USAGE Operation is the same for both the stations connected to the exchange and the IP stations connected to a LAN, and also for the N-8031MS Hands-free Master Station used in combination with the RS-191 Handset. 1.1.

  • Page 114: Receiving A Call (When The System Is Set To "Sequential Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 1.2. Receiving a Call (when the system is set to "Sequential Response" mode) Step 1. Answer a received call. 1-1. When the called station's incoming call mode is set to "Automatic Connection Mode*,"...
  • Page 115 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Multi-Functional Master Station response] The Multi-Functional Master Station can respond to stations displayed on the LCD in the same way as the Standard Master Station. When multiple calls are simultaneously received, the call to be answered can be selected with the following operation.

  • Page 116: Station Speaker Volume

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 1.4. Station Speaker Volume The master station speaker volume can be preset using the supplied N-8000 Setting Software, however it can also be adjusted at the station. When using the master station other than the N-8410MS: •...

  • Page 117: Speech Method

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 1.5. Speech Method 1.5.1. Hands-free conversation Permits conversations to be made without using the handset when a call is made without lifting a handset or received in automatic connection mode. Duplex conversations [Operation when both stations are engaged in hands-free conversation] •...
  • Page 118 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 1.5.2. Handset conversation Calls can be made or received by lifting the handset. Duplex conversations 1.5.3. PTT conversation This function makes announcements and conversations possible to areas with a high ambient noise level. Pressing the Push-to-talk key during a hands-free conversation enables one-way conversation from the party who pressed the Push-to-talk key.

  • Page 119: Conversation Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2. CONVERSATION FUNCTIONS AND OPERATION 2.1. Calling 2.1.1. Individual calls • The desired party can be called by pressing its station number with or without lifting the handset. • Conversation can start when the called party answers and the call tone stops. •...
  • Page 120 Call The call tone stops as long as the Push-to-talk key is pressed, enabling the called party to hear your voice. Hello, Mr. TOA. • The original continuous call tone resumes as soon as the Push-to-talk key is released. Call •...

  • Page 121: Setting Call Receiving Modes (Only When The System Is Set To "Sequential Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.1.5. Group calls • When a station is assigned to group call member station, if the station is called, this station (representative station) and all member stations are simultaneously called by a continuous call tone regardless of their call receiving mode settings.

  • Page 122: Speed Dialing

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.3. Speed Dialing 2.3.1. Auto-dialing (N-8000MS/8500MS/8600MS only) When the dial operation (up to 20-digit numbers) is preprogrammed into each station's Auto Dial key, such programmed call can be made by simply pressing a single key.
  • Page 123 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.3.2. One-touch dialing Programming the dial operation (up to 32-digit numbers) into the station's [7], [8], [9], [0] or off-hook* key allows calls or other operation to be made by one-touch dialing. * The action to lift up the handset.
  • Page 124 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.3.3. Dial pattern activation (N-8600MS only) When the dial operation (up to 380-digit numbers) is preprogrammed into the N-8600MS as dial pattern, such programmed call can be made by the following operation. Press the function key, [2], and then the function [Example] key followed by the dial pattern number (01 −...

  • Page 125: Hold

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.4. Hold 2.4.1. Mic off Disabling the microphone during a conversation places the line on hold. [Mic off] [Example] Hold down any key of [0] through [9] continuously Mic off during a conversation.

  • Page 126: Call Transfer

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.5. Call Transfer Either party engaged in two-party conversation can call the third party to make conversation with (placing the original conversation partner on hold). After the conversation end, it is possible to restore the original two-party conversation or transfer the conversation with the third party to the original conversation partner.
  • Page 127 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Transferring calls to the third party] Step 3. To connect the third party to the original conversation partner being placed on hold, either press the Clear key or replace the handset. This permits conversation between the second and third parties. The first party The second party No.

  • Page 128: Automatic Transfer

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.6. Automatic Transfer Note Calls cannot be automatically transferred to the station connected via the multi interface unit. 2.6.1. Group hunting Calls to a busy station set for Group hunting are automatically transferred to another designated station. This Group hunting function also applies to the call transfer 2-15) performed during conversation.
  • Page 129 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [When the called station and the call forwarding receiving stations are all busy] The called station and the call forwarding receiving stations differ in operations during conversations depending on the system's call response mode. Sequential response mode: When the designated station set for Group hunting to which a call was transferred is busy, the call is automatically transferred to the next designated station, and this continues in series until a free line is found.
  • Page 130 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.6.2. Absence transfer When no response is made to a call to the station set for Absence transfer for a set period of time, the call is automatically transferred to another designated station. Calls received during conversations can be transferred.
  • Page 131 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.6.3. Call forwarding Calls to stations set for call forwarding are automatically transferred to another designated station without sounding a call tone. Two different modes are available: one is Call forwarding, in which calls are manually rerouted to the selected station, and the other is Time-based Call forwarding, which transfers calls only when the preset time is reached.
  • Page 132 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Calls to stations set for Time-based Call forwarding] Step 1. When the preset transfer time is reached, the station's display shows the station (e.g. No. 62) has entered the Time-based Call forwarding mode (N-8000MS/8500MS/8600MS only). Transfer destination Transfer destination station name station number...

  • Page 133: Remote Response

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.7. Remote Response (only when the system is set to "Sequential Response" mode) When a station is being called, such calls can be answered by another station instead if these stations are assigned to the same group.
  • Page 134 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Remote response group new programming] Function designation number (Confirmation tone) [Remote response group member addition] Member station number (Confirmation tone) [Remote response group erasure] (Confirmation tone) [Remote response group member erasure] Member station number (Confirmation tone) Notes...

  • Page 135: Executive Priority

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2.8. Executive Priority (only when the system is set to "Sequential Response" mode) If a called station is busy, as indicated by a busy tone, performing Priority operation from a call station transmits a short priority call tone, then forcibly terminates the current conversation, allowing the call to go through.

  • Page 136: Paging Function And Operation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3. PAGING FUNCTION AND OPERATION 3.1. Paging Paging stations are preprogrammed. Paging durations can be limited by preprogramming the time limit (between 10 and 990 seconds in 10-second units) for each exchange or IP station. Note Use the supplied N-8000 Setting Software to enable or disable the paging operation and to set the paging duration.
  • Page 137 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3.1.2. Selectable paging Paging calls can be made to up to 50 preprogrammed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Press the Paging key, then [ ] key followed by the desired paging zone number (1 −...
  • Page 138 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3.1.3. Selectable paging to individual zones or the zones set by a zone pattern (N-8600MS only) Broadcasts can be made to the preset multiple zones (individual zones or a zone group set as a zone pattern*). * A pattern into which multiple paging zones are grouped.
  • Page 139 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3.1.4. All-call paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Press the Paging key, followed by the paging zone number "0" (for all-call paging). A paging tone is transmitted to all zones.
  • Page 140 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3.1.5. Emergency paging This function terminates all conversations, paging calls and other functions currently in progress throughout the system, and simultaneously makes a paging call to all stations, the N-8000EX IP Intercom Exchange's audio outputs, the N-8000MI Multi-Interface Unit designated as paging output, and N-8000AF Audio Interface Unit's audio output.
  • Page 141 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 3.1.6. Paging priority [Emergency paging] Emergency paging takes precedence over conversations, paging calls and all other functions. Initiating Emergency paging terminates all other functions currently in operation, and these functions are not restored even when the page is completed.

  • Page 142: Responding To Paging

    Press the Paging Response key. The paging party who made the last page is called and put through to the paged party. Building A Building B Building C Hello, Mr. TOA. Zone 1 Zone 2 Zone 3 Please respond. Speaker Speaker •...
  • Page 143 The paging party who made the paging to the designated zone last is called and put through to the paged party. [Example] Zone 1 Zone 2 Speakers Hello, Mr. TOA. Please respond to Response 002. (Zone number with 3-digit length) The station that can make response is as follows.

  • Page 144: Broadcast To Sx-2000 System (N-8600Ms Only, Only When Sx-200Ip Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4. BROADCAST TO SX-2000 SYSTEM (N-8600MS only, only when SX-200IP is used) 4.1. Selected Zone Broadcast Broadcasts can be made to the zone(s), or zones assigned to a zone pattern* within the SX-2000 system area.

  • Page 145: General-Purpose Broadcast

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.2. General-Purpose Broadcast General broadcast patterns* having been set in the SX-2000 system can be activated. Contain the preset broadcast sound sources, output zones, and other settings. For details, refer to the SX- 2000 Setting Software Instructions.

  • Page 146: Bgm Broadcast

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.2.2. Termination Step 1. Press the Function key. Step 2. Select the control pattern to which the function to activate a general broadcast pattern is assigned. Press the following keys in order. SX-2000 system ID Control pattern number* number (01 –...
  • Page 147 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.3.2. Termination Step 1. Press the Function key. Step 2. Select the control pattern to which a BGM pattern end function is assigned. Press the following keys in order. SX-2000 system ID Control pattern number* number (01 –...

  • Page 148: Control Output Activation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.4. Control Output Activation The control output of the SX-2000 system can be activated. 4.4.1. Activating the control output Step 1. Press the Function key. Step 2. Select a control pattern set for the control output pattern. Press the following keys in order.
  • Page 149 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.4.2. Deactivating the control output Step 1. Press the Function key. Step 2. Select a control pattern set for the control output pattern. Press the following keys in order. Multiple control patterns* can be sequentially selected by repeating key operation shown below.

  • Page 150: Multi-Operation Activation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.5. Multi-Operation Activation 4.5.1. Simultaneously activating selected zone broadcast and control output pattern Broadcasts to the SX-2000 zone (individual zone or zone pattern* ) and SX-2000 system's control output activation can be performed at the same time. Broadcast durations can be limited by preprogramming the time limit (between 1 and 20 minutes in 1-minute units) for each station.
  • Page 151 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Step 4. Press the [ ] key. Confirmation tone sounds, then a chime tone is transmitted to the selected zone(s). The control output(s) assigned to the selected control output pattern are activated. Step 5.
  • Page 152 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 4.5.2. Simultaneously activating paging, selected zone broadcast, and control output pattern Broadcasts to the N-8000 system zone (paging zone or paging zone pattern* ) and the SX-2000 system zone (individual zone or zone pattern* ), and SX-2000 system's control output activation can be performed at the same time.
  • Page 153 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 2-2. When selecting an N-8000 zone pattern Press the following keys in order. N-8000 zone pattern number (001 – 216) 2-3. When selecting a SX-2000 zone Press the following keys in order. one numbers are assigned as shown in the table below.
  • Page 154 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Step 4. Press the [ ] key. Confirmation tone sounds, then a paging pre-announcement tone or chime tone is transmitted to the selected zone(s). The control output(s) assigned to the selected control output pattern are activated. Step 5.

  • Page 155: Other Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5. OTHER FUNCTIONS AND OPERATION 5.1. Scan Monitor The station can scan arbitrary stations for auditory monitoring. The station to be scan-monitored must be preprogrammed into a monitor group or can be selected each time by designating the station number.
  • Page 156 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Operation] Step 1. Automatic Scan 1-1. When scan-monitoring the preprogrammed stations Press the [ ], [2] keys, then the monitor group number (1 − 4), followed by the [ ] key. When monitoring two or more groups, press the group numbers consecutively.

  • Page 157: Three-Party Conference

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.2. Three-Party Conference A simultaneous (full duplex) three-party handset conversation can be held by calling up other master stations in sequence. It is possible to call a conference by calling other stations from the standby mode or by calling a third party from the two-party conversation mode.
  • Page 158 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Step 3. Dial the station number of the third party. When the third party answers, the second party is released from hold mode, permitting a 3-party conversation to proceed. Conversation (on hold) Station number of the third party Calling Call tone...
  • Page 159 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.2.2. Initiating a 3-party conference during a 2-party conversation Step 1. While connected with the second party, press the Transfer key. The second party will be placed on hold. Conversation (on hold) Step 2.
  • Page 160 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Step 3. The conference is terminated when the originator of the conference either presses the Clear key or replaces the handset. This completes the conference call. If a called party other than the originator of the conference presses the Clear key or replaces the station handset, that party can exit the conference.

  • Page 161: Time Signal (Only When The N-8000Af Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.3. Time Signal (only when the N-8000AF is used) The Time Signal function broadcasts preset sound sources over preset paging zones according to preprogrammed schedules. The N-8000AF Audio Interface of which operation mode has been set to "Time Signal"...
  • Page 162 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [External timer-initiated event settings] • "Time Signal" broadcasts can be triggered by make contact from an external timer connected to the N-8000AF Audio Interface's contact input. • The external timer-initiated event is comprised of the following contents for each contact input (1 − 8): Paging zones (up to 10 zones selected from 192), sound source numbers (0 −...
  • Page 163 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Operation when the Time Signal broadcast overlaps other calls or broadcasts] • Operation during overlap is the same as for external input broadcasts (refer to 2-181). • When a station is in use, the time signal is broadcast to all other stations except the busy station. 5.3.3.
  • Page 164 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.3.6. Manually trigger time signal Time Signal can be activated simultaneously with the master station's dial operation, through which the sound source number, external equipment control ON/OFF, and paging zone number should be designated. •...
  • Page 165 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.3.7. Time signal temporary exception Any station can be temporarily excepted from the time signal-initiated paging destinations through key operations at the master station. Up to 10 stations can be simultaneously excepted through a single operation. Once registered for temporary exception, the stations will not accept any time signal-initiated paging calls until exception cancellation is performed to those stations.
  • Page 166 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.3.9. Cancelling the reserved time signal schedule The reserved Time Signal Schedule can be cancelled through key operations at any station. Function designation No. (confirmation tone) 4.3.10. Confirming the reserved time signal schedule (N-8000MS/8500MS/8600MS only) The reserved Time Signal Schedule can be confirmed through key operations at any station.

  • Page 167: Pbx Connection (Only When The N-8000Mi Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.4. PBX Connection (only when the N-8000MI is used) If the Multi interface unit is connected to the PBX's analog E&M interface, calls or conversations can be mutually made between the N-8000 system's stations and the PBX's extension telephones or paging calls can be initiated from the PBX extension telephone.
  • Page 168 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.4.3. Being paged from a PBX extension telephone Dialing the intercom access number, " ," "8," and the N-8000 system's paging zone number in this order at the PBX extension telephone permits the paging calls to be made to the N-8000 system's stations. The method for responding a paging call at the station is the same as when it is paged from the N-8000 system's station.

  • Page 169: Outside Line Connection (Only When The N-8000Co Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.5. Outside Line Connection (only when the N-8000CO is used) Outside lines can be connected to the N-8000 system, permitting the system's master stations to make or receive outside line telephone calls. 5.5.1.
  • Page 170 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.5.3. Receiving calls from an outside line telephone There are two modes for receiving calls from an outside line telephone: Direct-In Line and Direct-In Dialing. The audible call tone for a received outside line call is different from those of other incoming calls. (Refer to "List of Signal Tones"...
  • Page 171 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.5.4. Receiving paging from an outside line telephone Stations can receive paging calls from outside line telephones. Note Outside line telephones can page system stations only when Direct-In Dialing has been enabled by the supplied N-8000 Setting Software.
  • Page 172 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] Function designation C/O interface unit access number number (1-digit or 2-digit) (Confirmation tone) [Erasure] Function designation The originally called (your) station number number (Confirmation tone)
  • Page 173 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.5.6. Outside line Absence transfer Outside line telephones can be designated as the transfer destinations for Absence transfer (refer to 2-19). This Outside line Absence transfer function also applies to the call transfer 2-15) performed during conversation.
  • Page 174 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] Function designation C/O interface unit access number number (1-digit or 2-digit) (Confirmation tone) [Erasure] The originally called (your) Function designation station number number (Confirmation tone)
  • Page 175 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.5.7. Outside line Call forwarding Outside line telephones can be designated as the transfer destinations for Call forwarding (refer to 2-20). Destinations for both manual and automatic time-interlocked Call forwarding can be set to outside line telephones.
  • Page 176 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] C/O interface unit access number Function designation number (1-digit or 2-digit) (Confirmation tone) [Erasure] The originally called Function designation (your) station number number (Confirmation tone) Note...
  • Page 177 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Calls to stations set for outside line Time-based Call forwarding] Step 1. When the preset transfer time is reached, the Transfer destination station's display shows the station (e.g. No. 62) N-8000CO’s equipment number has entered the Time-based Call forwarding mode Transfer destination...

  • Page 178: Tie-Line Connection (Only When The N-8000Mi Is Used)

    5.6. Tie-Line Connection (only when the N-8000MI is used) Using the Multi interface unit for tie-line connection between the N-8000 Series intercom system exchange and other series intercom system exchanges via 4-wire private lines permits calls, conversations, or paging calls to be mutually made between stations connected to the tie-line connected exchanges.
  • Page 179 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.6.3. Making paging calls to another intercom system Step 1. Press the tie-line access number. The called intercom system can be connected. Step 2. After confirming that a dial tone from the connected intercom system is heard, dial the paging operation number of the connected intercom system, and make a paging call to the connected intercom system.

  • Page 180: Bgm (Only When The N-8000Mi Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.7. BGM (only when the N-8000MI is used) Connecting playback components to the Multi interface unit permits Background music selectable from up to 8 programs to be heard from each station speaker while in standby mode. It is possible to make or receive calls at the station even in BGM mode.
  • Page 181 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [BGM volume adjustment] BGM volume can be adjusted in 5 increments. • Press [Function key][1][9][ ] to increase the volume. Function designation number • Press [Function key][1][9][ ] to decrease the volume. Function designation number 2-70...

  • Page 182: External Equipment Control (Only When The N-8000Mi/8000Di/8000Af/8050Ds/8540Ds/8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.8. External Equipment Control (only when the N-8000MI/8000DI/8000AF/8050DS/8540DS/8640DS/8650DS is used) External equipment can be controlled by transmitting a one-shot make output signal (or make/break contact signal) to the contact of the designated Multi-Interface unit, Direct Select unit, or Audio Interface unit, or by manually causing the station to transmit a one-shot make output signal to the contact of the designated door station.
  • Page 183 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Make output operation] Press [Function key][3][1], then the access number for the contact corresponding to the external equipment to be controlled. Function designation number Contact access No. (2 – 4 digits) ..
  • Page 184 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Door station one-shot make output operation (when the N-8640DS/8650DS is used)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. Press the function designation number corresponding to the contact output, followed by the door station number to be controlled.

  • Page 185: Door Remote Control (Only When The N-8050Ds/8540Ds/8640Ds/8650Ds /8000Mi/8000Di/8000Af Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.9. Door Remote Control (only when the N-8050DS/8540DS/8640DS/8650DS/8000MI/8000DI/8000AF is used) N-8050DS/8540DS/8640DS/8650DS's contact outputs can be shorted for a set period of time by the dial operation at the master station engaged in conversation with the N-8050DS Door Station or N-8540DS/8640DS/8650DS IP Door Station of which "Door station contact output"...
  • Page 186 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION [Operation (when using the contact outputs of the N-8640DS/8650DS)] The N-8640DS/8650DS has 5 contact outputs. The contact output to be controlled can be selected through key operation. Step 1. Press the Transfer key during a conversation. Current conversation is placed on hold, transmitting a hold tone to other party.

  • Page 187: Message Pagings (Available Only When Ip Master Stations Are Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.10. Message Pagings (available only when IP Master Stations are used) Message pagings can be made using messages preprogrammed into the N-8500MS/8600MS Multi-Functional IP Master Station or N-8510MS Standard IP Master Station. The Message paging is output to the preset paging zones.
  • Page 188 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Step 2. Message Paging Termination There are two termination methods. 2-1. Termination by IP Master Station key. Press the Clear key. Note This operation forcibly terminates the Message Paging even if the number of broadcast repetitions is set.

  • Page 189: Audio Trigger Function Settings (Only When The N-8050Ds/8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.11. Audio Trigger Function Settings (only when the N-8050DS/8640DS/8650DS is used) Audio Trigger function settings for the N-8050DS Door Station and the N-8640DS/8650DS IP Door station can be performed at the Master Station (refer to 2-120).
  • Page 190 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.11.3. Confirming audio trigger setting status (N-8000MS/8500MS/8600MS only) The setting status of the Audio Trigger function can be confirmed at any Multi-Functional Master Station by designating a Door Station. Displayed for 5 sec. 2 0 0 : A c t i v e Function designation number...
  • Page 191 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.11.5. Changing the audio trigger detection time The time interval for detecting sound to activate the alarm function can be changed at any station by designating a Door Station. Set the detection time using the dial keys 1 − 9. The larger the number becomes, the longer the detection time becomes.

  • Page 192: Ip Door Station's Speaker Output Switching Control (Only When The N-8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.12. IP Door Station's Speaker Output Switching Control (only when the N-8640DS/8650DS is used) The audio output destination of the N-8640DS/8650DS IP door station engaged in conversations with its master station can be switched to either the internal speaker or the speaker connected to the external speaker terminal by the master station's dial operation.

  • Page 193: Access Code Authentication (Except N-8500Ms/8510Ms)

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 5.13. Access Code Authentication (except N-8500MS/8510MS) Usage of the master station can be restricted when the access code authentication is enabled. Entering a preprogrammed 4-digit access code number before each function key number permits the master station to be used as usual.

  • Page 194: Master Station Operation Table

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 6. MASTER STATION OPERATION TABLE Function Item Operation Remarks Call Call Dial station No. [X][X] ··· [X] Station No: 2 – 6 digits Redialing Press the [Redial] key Recall Press the [ ] key Voice Calling Voice a call to a called party by pressing the [PTT] key as the...
  • Page 195 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks Call Programming Dial [Function] [4] [1] [ ] [the C/O line interface access Station No: 2 – 6 digits forwarding at your station number] [ ] keys. Erasure at your station Dial [Function] [4] [1] [your station No.] [ ] keys.
  • Page 196 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks 3-party 2-party conversation Dial [Function] [5] [1] [second party station No.]. Conference-Originating conference Station Operation 3-party conversation Dial [Transfer] [third party station No.]. Switching from 2-party Dial [Transfer] [Function] [5] [1] [third party station No.] during conversation to a conversation.
  • Page 197 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks Broadcast to Multi-operation Dial [Paging] [N-8000 zone or zone pattern selection, N-8000 paging SX-2000 system activation SX-2000 zone or zone pattern selection]··· zone No.: 1 – 3 digits or other activation (N-8000 paging call, [N-8000 zone or zone pattern selection, SX-2000 zone or...
  • Page 198 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks Channel selection Dial [Function] [1] [channel number] keys. Channel number: 0 – 8 Dial [Function] [1] [ ] keys. Increasing a number by 1 Dial [Function] [1] [ ] keys.

  • Page 199: Multifunctional Master Station's Lcd Display Table

    FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION 7. MULTIFUNCTIONAL MASTER STATION'S LCD DISPLAY TABLE Standby mode Holding Current time Your station number Called station's number Called station's name 1 2 : 0 0 A M 2 0 0 : N - 8 0 0 0 M S H o l d i n g 1 0 0...
  • Page 200 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Paging Redial Paging zone number Paging zone name R e d i a l 0 : 4 0 0 Z o n e 0 : A L L C A L L P a g i n g Dialing data Note:...
  • Page 201 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Making a 3-party conference call Selected zone broadcast (originator) SX-2000 system ID number Called party's station number Called party's station name Z o n e 1 : S X 3 0 0 : N - 8 5 0 0 M S P a g i n g C a l l i n g...
  • Page 202 FUNCTIONS AND OPERATION Chapter 2 MASTER STATION'S FUNCTIONS AND OPERATION Selective Response • Third call displayed (Third received call is normal, but an Emergency call precedes it. ) • Call in (no waiting call) 3rd call station's number 3rd call station's name Called station's number Called station's name 3 0 0...

  • Page 203: Remote Microphone Station'sfunctions And Operation

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 1. FUNCTIONS ASSIGNABLE TO THE FUNCTION KEY Any one of the functions shown in the table below can be assigned to the Function keys on the N-8610RM Remote microphone station and Function key Function key...

  • Page 204: Functions Enabled With The Remote Microphone Station

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 2. FUNCTIONS ENABLED WITH THE REMOTE MICROPHONE STATION Operation Function Remarks (reference page) Functions available Calling (Station number) p. 2-95 Assign each individual exclusively for function other than a Sequential response p.

  • Page 205: Function Comparison Table Between N-8610Rm And Rm-200Sa

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 3. FUNCTION COMPARISON TABLE BETWEEN N-8610RM AND RM-200SA The table below shows the difference between the functions assignable to the N-8610RM Remote microphone station and RM-200SA Remote microphone regarding broadcasts to the SX-2000 system. N-8610RM Remote Type of broadcast made to SX-2000 RM-200SA Remote microphone...

  • Page 206: Conversation Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4. CONVERSATION FUNCTIONS AND OPERATION 4.1. Calling 4.1.1. Using a station call key Step 1. Press the station call key into which the station call number to be called is programmed. Status indicator Selection indicator Station call key...

  • Page 207: Receiving A Call (When The System Is Set To "Sequential Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4.2. Receiving a Call (when the system is set to "Sequential Response" mode) Step 1. Answer a received call. 1-1. When the called station's incoming call mode is set to "Automatic Connection Mode*,"...

  • Page 208: Receiving A Call (When The System Is Set To "Selective Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4.3. Receiving a Call (when the system is set to "Selective Response" mode) Note: Only continuous call tones is available in "Selective Response" mode. Step 1. Answer a received call. 1-1.

  • Page 209: Station Speaker Volume

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4.4. Station Speaker Volume The station speaker volume can be preset using the supplied N-8000 Setting Software, however it can also be adjusted at the station. The speaker volume level can be changed in 5 steps (in 3 dB per step). •...
  • Page 210 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4.5.2. PTT conversation This function makes announcements and conversations possible to areas with a high ambient noise level. Pressing the PTT key during a hands-free conversation enables one-way conversation from the party who pressed the PTT key.

  • Page 211: One-Touch Dialing

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 4.6. One-touch dialing Programming the dial operation* (up to 32-digit numbers) into the station's [7], [8], [9], or [0] key allows paging or other operation to be performed by one-touch dialing. * [0] −...

  • Page 212: Using The Privacy Function

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 5. USING THE PRIVACY FUNCTION The Privacy function refuses all paging, scan monitor, and station calls except Emergency paging calls. Note The Privacy mode can be set or reset only when the Remote Microphone Station is placed in the state below. •...

  • Page 213: Paging Function And Operation

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 6. PAGING FUNCTION AND OPERATION 6.1. Paging Call Paging stations are preprogrammed. Paging duration can be limited by preprogramming the time limit (between 10 and 990 seconds in 10-second units) for each station.
  • Page 214 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION Step 3. Speak into the microphone when the microphone indicator of the Talk key begins to light green. When a part of the zones being broadcast to is assigned to the N-8000 zone selection key other than the key pressed in Step 1, the status indicator of so assigned zone selection key flashes green.
  • Page 215 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION [When the Talk key is set to "PTT"] Step 1. Press the N-8000 zone selection key. (N-8000 zone (Example) selection). Status indicator Paging zones and Paging zone patterns can be selected in combination by pressing 2 or more keys Selection indicator in sequence.

  • Page 216: Responding To Paging

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION Step 3. Speak into the microphone while holding down the Talk key when the microphone indicator of the Talk key begins to light green. When a part of the zones being broadcast to is assigned to the N-8000 zone selection key other than the key pressed in Step 1, the status indicator of so assigned zone selection key flashes green.

  • Page 217: Broadcast To Sx-2000 System

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 7. BROADCAST TO SX-2000 SYSTEM (only when using SX-200IP) 7.1. Selected Zone Broadcast Broadcasts can be made to the zone(s), or zones assigned to a zone pattern* within the SX-2000 system. Broadcast durations can be limited by preprogramming the time limit (between 1 and 20 minutes in 1-minute units) for each station.
  • Page 218 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION Step 3. Speak into the microphone when the microphone indicator of the Talk key begins to light green. When a part of the zones being broadcast to is assigned to the SX-2000 zone selection key other than the key pressed in Step 1, the status indicator of so assigned zone selection key flashes green.
  • Page 219 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION [When the Talk key is set to "PTT"] Step 1. Press the SX-2000 zone selection key. (Zone selection) (Example) Multiple zones and zone patterns can also be selected in Status indicator combination by pressing 2 or more keys in sequence.
  • Page 220 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION Step 3. Speak into the microphone while holding down the Talk key when the microphone indicator of the Talk key begins to light green. When a part of the zones being broadcast to is assigned to the SX-2000 zone selection key other than the key pressed in Step 1, the status indicator of so assigned Zone pattern key flashes green.

  • Page 221: General-Purpose Broadcast

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 7.2. General-Purpose Broadcast General broadcast patterns* having been set in the SX-2000 system can be activated. * Contain the preset broadcast sound sources, output zones, and other settings. For details, refer to the SX- 2000 Setting Software Instructions.

  • Page 222: Bgm Broadcast

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 7.3. BGM Broadcast The BGM pattern* having been set in the SX-2000 system can be activated. * A broadcast pattern containing BGM source, output zone, and other preset items. For details, refer to the SX- 2000 Setting Software Instructions.

  • Page 223: Multi-Operation Activation

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 7.5. Multi-Operation Activation 7.5.1. Simultaneously activating selected zone broadcast and control output pattern When the control output pattern is programmed into the zone selection key, broadcasts to the SX-2000 zone (zone and zone pattern* ) and SX-2000 control output activation can be made simultaneously.
  • Page 224 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 7.5.2. Simultaneously activating paging, selected zone broadcast, and control output pattern Broadcasts to the N-8000 paging zone (paging zone and paging zone pattern) and the SX-2000 zone (zone and zone pattern) can be made at the same time.
  • Page 225 FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION [Operation] Basic operations are the same as those when making paging calls 2-102) and zone selectable broadcast 2-106). Multiple keys including the N-8000 zone selection key, SX-2000 zone selection key, and Control output key can be selected in random order at the time of zone (N-8000) and zone (SX-2000) selection.

  • Page 226: Other Functions

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 8. OTHER FUNCTIONS 8.1. Using the Shift Key Following 2 different functions can be assigned to the Remote microphone station's key in advance: one activated with a single key operation and another activated with key operation in conjunction with the Shift key.

  • Page 227: Remote Microphone Station Operation Table

    FUNCTIONS AND OPERATION Chapter 2 REMOTE MICROPHONE STATION'S FUNCTIONS AND OPERATION 9. REMOTE MICROPHONE STATION OPERATION TABLE The table below shows the remote microphone station's exclusive operations. For the same operations as those of the master station, refer to "MASTER STATION OPERATION TABLE"...

  • Page 228: Door Station'sfunctions And Operation

    FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION DOOR STATION'S FUNCTIONS AND OPERATION 1. CALLING FROM A DOOR STATION 1.1. Calling from a Door Station (when the system is set to "Sequential Response" mode) Step 1. Press the call button to call the pre-programmed master station or telephone. The call tone is heard through the calling station's internal speaker.

  • Page 229: Calling From A Door Station (When The System Is Set To "Selective Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION 1.2. Calling from a Door Station (when the system is set to "Selective Response" mode) Flashes Step 1. Press the call button to call the pre-programmed master station or telephone. The status indicator flashes.

  • Page 230: Making An Emergency Call (Only Possible When System Is Set For "Selective Response")

    FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION 2. MAKING AN EMERGENCY CALL (only possible when system is set for "Selective Response") Emergency Calls take precedence over other calls. If the Master Station or telephone responds to the Emergency Call, the conversation becomes an Emergency Conversation and is handled with a higher priority than other conversations and paging calls.

  • Page 231: Audio Trigger Function (N-8050Ds/8640Ds/8650Ds Only)

    FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION 4. AUDIO TRIGGER FUNCTION (N-8050DS/8640DS/8650DS only) Alarm operation is activated if audio that enters the preprogrammed N-8050DS Door Station's and N-8640DS/8650DS IP Door station’s microphone meets set conditions. Notes • This function may accidentally be activated in response to ambient sounds (e.g. rain, wind, music, traffic noise).
  • Page 232 FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION [Alarm detection method] One of the following 2 methods can be selected for the Alarm detection method. • Level detection Activates alarm if a sound pressure level exceeding the set level is detected for a specified period of time. • Audio detection Activates alarm if a human voice is detected.

  • Page 233: Call Button Restriction (N-8050Ds/8640Ds/8650Ds Only)

    FUNCTIONS AND OPERATION Chapter 2 DOOR STATION'S FUNCTIONS AND OPERATION 5. CALL BUTTON RESTRICTION (N-8050DS/8640DS/8650DS only) (Only when the system is used to "Sequential Response" mode) Enabling the Call button restriction function changes the usage of the Call button. Pressing the Call button 3 times within 3 seconds performs calling operation.

  • Page 234: Substation/Switch Panel'sfunctions And Operation

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION This section describes the functions and operations of the substation, switch panel, and switch board to be connected to the Substation Interface Unit. Hereinafter, these connected devices are collectively called "Substation."...

  • Page 235: Operation Using The Call Button (When The System Is Set To "Selective Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 1.2. Operation Using the Call Button (when the system is set to "Selective Response" mode) Flashes Step 1. Press the call button to call the pre-programmed master station or telephone. The status indicator flashes (RS-140/180/480 only).

  • Page 236: Calling By Lifting The Handset

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 1.3. Calling by Lifting the Handset (only when the RS-141 is combined with the RS-140/142/143/144, and when the RS-481 is combined with the RS-442/480.) Step 1. Lift the handset. Flashes Calls the preprogrammed master station or Note telephone.

  • Page 237: Making An Emergency Call

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 2. MAKING AN EMERGENCY CALL (only when system response mode is set for "Selective Response") Emergency Calls take precedence over other calls. If the Master Station or telephone responds to the Emergency Call, the conversation becomes an Emergency Conversation and is handled with a higher priority than other conversations and paging calls.

  • Page 238: Using The Call Button With A Lower Priority

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 2.2. Using the Call Button with a Lower Priority The call button assigned a lower priority can also initiate the emergency calls through the operation described below. Notes • The RS-140/180/480 is not capable of initiating Emergency Calls through the operation described below, but can initiate Emergency Calls by changing the call priority order settings.

  • Page 239: Receiving A Call

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 3. RECEIVING A CALL Flashes Steady-on Step 1. When receiving a call from the master station, the call tone sounds only once, after which the calling party's voice is heard immediately through the internal speaker. Brief call tone Voice Step 2.

  • Page 240: Using The Privacy Function (Rs-140 Only)

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 5. USING THE PRIVACY FUNCTION (RS-140 only) The Privacy function refuses all paging and station calls except Emergency paging calls. 5.1. Privacy Mode Settings Press the Privacy button on the RS-140 Switch Panel when the Privacy indicator is unlit.

  • Page 241: Call Button Restriction

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 6. CALL BUTTON RESTRICTION (Only when the system is used to "Sequential Response" mode) 6.1. Stations to Which the Call Button Restriction Function can be Programmed • RS-150/160/170 only of the substations to be connected to the N-8000RS/8010RS N-8000RS/8010RS RS-150 RS-160...

  • Page 242: Making A Call

    FUNCTIONS AND OPERATION Chapter 2 SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION 6.3. Making a Call Step 1. Press the Call button 3 times within 3 seconds. Flashes Immediately after the Call button is so pressed 3 times, the preprogrammed master station or telephone is called. Steady-on Step 2.

  • Page 243: N-8000Al Telephone Interface Connected Telephone Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE FUNCTIONS AND OPERATION 1. BASIC USAGE 1.1. Calling from a Telephone (Individual Calls) Step 1. Lift the handset and press the station number to be called. Call tone The calling station's handset speaker sounds an audible call tone.

  • Page 244: Receiving A Call

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 1.2. Receiving a Call Step 1. When a call is received, lift the handset to answer the call. Step 2. To finish conversations, replace the handset. 2-133...

  • Page 245: Conversation Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2. CONVERSATION FUNCTIONS AND OPERATION 2.1. Calling 2.1.1. Individual calls • To call a station, lift the handset, then press its station number. • Conversation can begin when the called party answers and the call tone stops. •...

  • Page 246: Call Transfer

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.2. Call Transfer Either party engaged in two-party conversation can call the third party to make conversation with (placing the original conversation partner on hold). After the conversation ends, it is possible to restore the original two- party conversation or transfer the conversation with the third party to the original conversation partner.
  • Page 247 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Transferring calls to the third party] Step 3. To connect the third party to the original conversation partner being placed on hold, replace the handset. This permits conversation between the second and third parties. The first party The second party No.

  • Page 248: Automatic Transfer

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3. Automatic Transfer Note Calls cannot be automatically transferred to the station connected via the multi interface unit or the C/O line interface unit. 2.3.1. Group hunting Calls to a busy telephone set for Group hunting are automatically transferred to another designated station or telephone.
  • Page 249 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE Programming or erasure can be performed at your telephone. Function designation Transfer destination number station number [Programming] (Confirmation tone) Function designation The originally called number (your) telephone number [Erasure] (Confirmation tone) [Setting example] Calls can be transferred to designated stations in a cyclical manner.
  • Page 250 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3.2. Absence transfer When no response is made to a call to the telephone set for Absence transfer for a set period of time, the call is automatically transferred to another designated station or telephone. Calls received during conversations can be transferred.
  • Page 251 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3.3. Call forwarding Calls to telephones set for Call forwarding are automatically transferred to another designated station or telephone without sounding a call tone. Two different modes are available: one is Call forwarding, in which calls are manually rerouted to the selected station, and the other is Time-based Call forwarding, which transfers calls only when the preset time is reached.
  • Page 252 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Calls to stations set for Time-based Call forwarding] Step 1. When the preset transfer time is reached, the telephone enters the Time-based Call forwarding mode. Step 2. Calls to stations (original telephone) are automatically transferred to the transfer destination station without sounding a call tone.

  • Page 253: Executive Priority (Only When The System Is Set To "Sequential Response" Mode)

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.4. Executive Priority (Only when the system is set to "Sequential Response" mode) If a called station is busy, as indicated by a busy tone, performing Priority operation from a call telephone transmits a short priority call tone, then forcibly terminates the current conversation, allowing the call to go through.

  • Page 254: Paging Function And Operation

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3. PAGING FUNCTION AND OPERATION 3.1. Paging Paging stations are preprogrammed. Paging durations can be limited by preprogramming the time limit (between 10 and 990 seconds in 10-second units) for each C/O line interface unit. Note Use the supplied N-8000 Setting Software to enable or disable the paging operation and to set the paging duration.
  • Page 255 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.2. Selectable paging Paging calls can be made to up to 50 preprogrammed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Lift the handset, then press the [ ][8][ ] keys, followed by the desired paging zone number (1 −...
  • Page 256 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.3. All-call paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Lift the handset, then press the [ ][8] keys, followed by the paging zone number 0 (for all-call paging). A paging tone is transmitted to all zones.
  • Page 257 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.4. Emergency paging This function terminates all conversations, paging calls and other functions currently in progress throughout the system, and simultaneously makes a paging call to all of the pre-programmed zones. Use the supplied N-8000 Setting Software to set the paging zones.

  • Page 258: Receiving Paging Calls (Only Emergency Pagings Can Be Received)

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.5. Paging priority [Emergency paging] Emergency paging takes precedence over conversations, paging calls and all other functions. Initiating Emergency paging terminates all other functions currently in operation, and these functions are not restored even when the page is completed.

  • Page 259: Other Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4. OTHER FUNCTIONS AND OPERATION 4.1. Scan Monitor The telephone can scan arbitrary stations for auditory monitoring. The station to be scan-monitored must be preprogrammed into a monitor group or can be selected each time by designating the station number.
  • Page 260 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Operation] Step 1. Automatic Scan 1-1. When scan-monitoring the preprogrammed stations: Press the [ ] and [2] keys, then monitor group number (1 − 4), followed by the [#] key. When monitoring two or more groups, dial the group numbers consecutively.

  • Page 261: External Equipment Control (Only When The N-8000Mi/8000Di/8000Af/8050Ds/8540Ds/8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.2. External Equipment Control (only when the N-8000MI/8000DI/8000AF/8050DS/8540DS/8640DS/8650DS is used) External equipment can be controlled by making the Multi-Interface Unit's, Direct Select Unit's, or Audio Interface Unit’s contact output designated by telephone operation provide a one-shot make contact or make/ break contact, or by making the designated door station's contact output provide a one-shot make contact.
  • Page 262 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Make output operation] Press [ ][3][1] keys, then the access number for the contact corresponding to the external equipment to be controlled. Function designation number Contact access No. (2 – 4 digits) [Break output operation] Press [ ][3][2] keys, then the access number for the contact corresponding to the external equipment to be controlled.
  • Page 263 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Door station one-shot make output operation (when the N-8640DS/8650DS is used)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. Press the function designation number corresponding to the contact output, followed by the door station number to be controlled.

  • Page 264: Door Remote Control (Only When The N-8050Ds/8540Ds/8640Ds/8650Ds /8000Mi/8000Di/8000Af Is Used)

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.3. Door Remote Control (only when the N-8050DS/8540DS/8640DS/8650DS/8000MI/8000DI/8000AF is used) N-8050DS/8540DS/8640DS/8650DS's contact outputs can be shorted for a set period of time by the dial operation at the telephone engaged in conversation with the N-8050DS Door Station or N-8540DS/8640DS/8650DS IP Door Station of which "Door station contact output"...
  • Page 265 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Operation (when using the contact outputs of the N-8640DS/8650DS)] The N-8640DS/8650DS has 5 contact outputs. The contact output to be controlled can be selected through key operation. Step 1. Hook-flash* during a two-party conversation. The current conversation is placed on hold, transmitting a hold tone to the other party.

  • Page 266: Ip Door Station's Speaker Output Switching Control (Only When The N-8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.4. IP Door Station's Speaker Output Switching Control (only when the N-8640DS/8650DS is used) The audio output destination of the N-8640DS/8650DS IP door station engaged in conversations with its telephone can be switched to either the internal speaker or the speaker connected to the external speaker terminal by the telephone's dial operation.

  • Page 267: Access Code Authentication

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.5. Access Code Authentication Usage of the telephone can be restricted when the access code authentication is enabled. Entering a preprogrammed 4-digit access code number before each function key number permits the telephone to be used as usual.

  • Page 268: Telephone Operation Table

    FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 5. TELEPHONE OPERATION TABLE Function Item Operation Remarks Call/Response Call Dial station No. [X][X] ··· [X] Station No.: 2 – 6 digits Response Lift the handset. Conversation Handset conversation Conversation can be made by lifting the handset. Call transfer Call transfer Hook-flash during a conversation.
  • Page 269 FUNCTIONS AND OPERATION Chapter 2 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE Function Item Operation Remarks External Speaker output (When switching to the internal speaker) Hook-flash during a conversation with the N-8640DS/8650DS, equipment switching control control then dial [ ] [ ] [0] keys. (When switching to the external speaker) Hook-flash during a conversation with the N-8640DS/8650DS, then dial [ ] [ ] [1] keys.

  • Page 270: Operation From An Outside Line

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE OPERATION FROM AN OUTSIDE LINE (only when the N-8000CO is used) 1. CALLING A STATION Direct-In Line and Direct-In Dialing functions allow the N-8000 system to receive calls from an outside line telephone.

  • Page 271: Paging

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 2. PAGING If the N-8000CO C/O Line Interface Unit is set to receive Direct-In Dialing calls as well operate paging calls, N-8000 system paging can be initiated from the outside line telephone. Also, a paging time limit can be set by programming a time limit (in 10 seconds units from 10 −...
  • Page 272 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE [Example paging to the zone 23] Zone 1 Speakers 1, 2 Amplifier Zone 23 (Zone number with 3-digit length) N-8000CO's outside line number No. 1001 No. 1003 No. 1002 No. 1004 (Dial confirmation tone) Zone 192 Speaker...

  • Page 273: Selectable Paging

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 2.2. Selectable Paging Paging calls can be made to up to 50 preprogrammed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.
  • Page 274 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE [Example paging to the zone 1, 23, and 105.] Zone 1 Speakers 1~ 4 Amplifier Zone 23 (Zone number with 3-digit length) N-8000CO's outside line number No. 1000 No. 1003 No.

  • Page 275: All-Call Paging

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 2.3. All-Call Paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software to set the paging zones. (Refer to 5-121.) Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.

  • Page 276: Other Functions And Operation

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3. OTHER FUNCTIONS AND OPERATION 3.1. Scan Monitor If the N-8000CO C/O Line Interface Unit is set to allow scan monitor operation, the outside line telephone can scan arbitrary stations for auditory monitoring. It is also possible to set an outside line control password to be used when dialing from the outside line telephone.
  • Page 277 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE during monitoring. Note In the case of the RS-140/180/480, the status indicator does not light even if set to "Display ON" mode. [Operation] Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.

  • Page 278: Time Signal (Only When The N-8000Af Is Used)

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2. Time Signal (only when the N-8000AF is used) Change, suspension, confirmation, reservation, and reservation confirmation of the time signal schedule can be made from the outside line telephone when the Direct-In Dialing function is set to the N-8000CO unit. It is also possible to set an outside line control password to be used when dialing from the outside line telephone.
  • Page 279 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2.2. Suspending time signal schedules The System Time Signal schedule can be suspended through operation from the outside line telephone. To restart the suspended schedules, change the time signal schedule. (Refer to 2-167.) [Operation] Step 1.
  • Page 280 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2.3. Time signal schedule confirmation The System Time Signal schedule can be confirmed through operation from the outside line telephone. With an audible tone through the telephone, its schedule can be confirmed by operations from the outside line telephone.
  • Page 281 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2.4. Reserving the time signal schedule change The System Time Signal schedule can be reserved through operation from the outside line telephone. To set the reserved day, designate the day from one (next day) to 9 days later by number (1 − 9) after performing the reservation operation.
  • Page 282 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2.5. Cancelling the reserved time signal schedule The System Time Signal schedule reservation can be cancelled through operation from the outside line telephone. [Operation] Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.
  • Page 283 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.2.6. Confirming the reserved time signal schedule The System Time Signal schedule reservation can be confirmed through operation from the outside line telephone. With an audible tone through the outside line telephone, its schedule reservation can be confirmed by operations from the outside line telephone.

  • Page 284: External Equipment Control (Only When The N-8000Mi/8000Di/8000Af/8050Ds/8540Ds/8640Ds/8650Ds Is Used)

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 3.3. External Equipment Control (only when the N-8000MI/8000DI/8000AF/8050DS/8540DS/8640DS/8650DS is used) If the N-8000CO C/O Line Interface Unit is set to allow external equipment control operation, the outside line telephone can control external equipment by making the designated Multi-Interface unit, Direct Select unit, or Audio Interface unit provide one-shot make contact or make/break contact at its contact output, or by making the designated door station provide one-shot make contact at its contact output.
  • Page 285 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE [Make output operation] First dial the N-8000CO interface's outside line number and confirm that a dial confirmation tone is heard, and then dial [ ][3][1]+[4-digit outside line control password]+[access number for the contact corresponding to external equipment to be controlled].
  • Page 286 FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE [Door station one-shot make output operation (N-8640DS/8650DS is used.)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. First dial the N-8000CO interface's outside line number and confirm that a dial confirmation tone is heard, and then dial [Function designation number]+[4-digit outside line control password]+[door station number to be controlled].

  • Page 287: Outside Line Telephone Operation Table

    FUNCTIONS AND OPERATION Chapter 2 OPERATION FROM AN OUTSIDE LINE 4. OUTSIDE LINE TELEPHONE OPERATION TABLE Function Item Operation Remarks Call Direct In Line Dial [N-8000CO's outside line number] keys. Direct-In Dialing Dial [N-8000CO's outside line number] [station No.] keys. Station No: 2 –...

  • Page 288: Other Functions (Convenient Functions)

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 1. PRIORITIES There are two priorities: Call Priority and Speech path Priority. 1.1. Call Priority (available only when in "Selective Response" mode) • This priority can only be used when the system is set for "Selective Response." •...

  • Page 289: Time-Out

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 2. TIME-OUT This function restricts the duration of calling, conversation, and paging to prevent the speech path from being left unused when a user neglects to terminate conversation or paging. When the set time has elapsed, stations automatically return to standby state. Notes •...

  • Page 290: Group Blocking

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 4. GROUP BLOCKING Stations can be blocked into groups (up to 31 groups) which can or cannot make calls to each other. Paging zone numbers available among such groups can also be set. Note Use the supplied N-8000 Setting Software to set the station groups, calls that can be made among groups, and paging zones that can be mutually called.

  • Page 291: Paging Delay Output

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 5. PAGING DELAY OUTPUT This function controls the audio output according to the connected external equipment's activation time. Delay time can be inserted into the time duration from paging operation completion to paging pre-announcement tone output (or paging commencement).

  • Page 292: External Input Paging

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 7. EXTERNAL INPUT PAGING (only when the N-8000MI/8000AF is used) By connecting the Remote microphone or playback components to the Multi-interface unit or Audio interface unit, activating its control input enables broadcasting to the preprogrammed zone(s). There are two methods of activation: one is to use the Audio input terminal (A in the following figure), and the other is to use the Contact input terminal (B).

  • Page 293: Paging Sync Contact Output Control

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 8. PAGING SYNC CONTACT OUTPUT CONTROL (only when the N-8000MI/8000AF is used) The contact output of both the N-8000MI and N-8000AF interface units can be set as the paging output destination. This makes it possible to control connected external equipment in synchronization with paging activation.

  • Page 294: Calling Station Indication/Cctv Interlock

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 9. CALLING STATION INDICATION/CCTV INTERLOCK (only when the N-8000MI/8000DI/8000AF is used) By installing a lamp type indication board* at the specified station, conversation partners and calling stations that made calls to the specified station during conversation can be displayed on the board. The indication board can be shared among multiple stations (up to 8 stations) to indicate which station within the group has been called.

  • Page 295: Outside Line Calling Station Indication/Cctv Interlock

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 10. OUTSIDE LINE CALLING STATION INDICATION/CCTV INTERLOCK (only when the N-8000CO/8000MI/8000DI/8000AF is used) The calling station indication/CCTV interlock can be enabled at the time of making calls to or receiving calls from the outside line or during conversations.

  • Page 296: Call/Conversation Sync Contact Output

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 11. CALL/CONVERSATION SYNC CONTACT OUTPUT (only when the N-8050DS/8540DS/8640DS/8650DS is used) The contact output of the N-8050DS Door Station or N-8540DS/8640DS/8650DS IP Door Station is closed in synchronization with its own station's operating status. The timing that the contact output is closed can be selected from 4 patterns;...

  • Page 297: Ip Door Station External Control Input

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 12. IP DOOR STATION EXTERNAL CONTROL INPUT (only when the N-8640DS/8650DS is used) When dialing operations (up to 20 digits) have been preprogrammed into the external control input of the N-8640DS/8650DS IP Door Station, such dialing operations can be performed by closing the N-8640DS/8650DS's contact input.

  • Page 298: Remote Dial Control

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 13. REMOTE DIAL CONTROL (only when the N-8000MI/8000DI is used) When the N-8000MI/8000DI's contact input terminal is closed, an arbitrary station is made to automatically perform dial operation. A set of up to 32 dial codes (including dial numbers and key operations) can be assigned to each contact input terminal.

  • Page 299: Direct Select (Only When The N-8000Di Is Used)

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 14. DIRECT SELECT (only when the N-8000DI is used) This function can be used when the system's call response mode is set to "Selective Response." By separately making an operation panel for a specified Master Station which is equipped with the lamps and buttons corresponding to other stations, and by assigning the Master Station and other stations to the N-8000DI's contact input and output channels, the stations that are calling the specified Master Station are indicated by means of lamps.

  • Page 300: Contact Bridge Function

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 15. CONTACT BRIDGE FUNCTION (only when the N-8000MI/8000DI/8050DS/8540DS/8640DS/8650DS is used) Contact signals can be transmitted by way of a network. N-8640DS Contact output N-8050DS Contact output N-8000EX/8010EX N-8000MI/8000DI N-8000MI/8000DI Contact output Contact input Either of the following 2 control input's operation modes can be selected.

  • Page 301: System Diagnosis

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 17. SYSTEM DIAGNOSIS (only when the N-8000MI/8000DI/8000AF is used) The N-8000MI/8000DI/8000AF diagnoses the system condition, and provides its results at the contact output terminal as open or closed contact. The system diagnosis is performed in a way that the N-8000MI/8000DI/8000AF connects the target equipment via the network.

  • Page 302: Time Signal

    FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 18. TIME SIGNAL (Refer to 2-50, "Time Signal".) 19. TIME CORRECTION Synchronizes the clocks of all components in the system with the one as a clock master. The Master Clock transmits a sync command to all other system equipment once a day. Use the supplied N-8000 Setting Software for the Master Clock setting.
  • Page 303 FUNCTIONS AND OPERATION Chapter 2 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 21. NTP CLIENT FUNCTION (only when the N-8000AF is used) Synchronizes the clock of the N-8000AF with NTP Server once a day when the NTP Client function of the N-8000AF set as a clock master is enabled. Set the IP address and port number of NTP Server using the supplied N-8000 Setting Software.

  • Page 304: Remarks

    FUNCTIONS AND OPERATION Chapter 2 REMARKS REMARKS [List of Signal Tones] Timing Signal Tone 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 Dial tone Busy tone...

  • Page 305: Chapter 3 : Installation & Wiring

    Chapter 3 INSTALLATION & WIRING This chapter describes installation and wiring procedures, including the installation and connection of the Exchange, stations, and various kinds of interface units.

  • Page 306: Installation Of The Exchange

    INSTALLATION & WIRING Chapter 3 1. INSTALLATION Of The exChANGe The N-8000EX/8010EX can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 1.1. equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 307: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 1.1.3. N-8000ex/8010ex mounting N-8000EX/8010EX Rack mounting bracket Tapping screw 3 x 8 (supplied with the N-8000EX/8010EX) (supplied with the N-8000EX/8010EX) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000EX/8010EX) Step 1. Install rack-mounting bracket N-8000EX/8010EX.

  • Page 308: Wall Mounting

    INSTALLATION & WIRING Chapter 3 1.3. Wall Mounting Step 1. Install the supplied wall-mounting bracket to the N-8000EX/8010EX using each 2 supplied screws and removed screws from the case. Wall mounting bracket (supplied with the N-8000EX/8010EX) Tapping screw 3 x 8 (removed from the case) N-8000EX/8010EX Tapping screw 3 x 8...

  • Page 309: Installation Of The Substation Interface Unit

    INSTALLATION & WIRING Chapter 3 2. INSTALLATION Of The SUBSTATION INTeRfACe UNIT The N-8000RS/8010RS/8400RS can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 2.1. equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 310: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 2.1.3. N-8000RS/8010RS/8400RS mounting N-8000RS/8010RS/8400RS Tapping screw 3 x 8 (supplied with the N-8000RS Rack mounting bracket /8010RS/8400RS) (supplied with the N-8000RS /8010RS/8400RS) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000RS/8010RS/8400RS) Step 1.

  • Page 311: Wall Mounting

    INSTALLATION & WIRING Chapter 3 2.3. Wall Mounting Step 1. Install the optional YC-850 Wall mounting bracket to the N-8000RS/8010RS/8400RS. YC-850 Wall mounting bracket Machine screw M3 x 6 (supplied with the YC-850) N-8000RS/8010RS/8400RS Step 2. Mount the N-8000RS/8010RS/8400RS on the wall. Notes •...

  • Page 312: Installation Of The Multi Interface Unit

    INSTALLATION & WIRING Chapter 3 3. INSTALLATION Of The MULTI INTeRfACe UNIT The N-8000MI can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 3.1. equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 313: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 3.1.3. N-8000MI mounting N-8000MI Tapping screw 3 x 8 Rack mounting bracket (supplied with the N-8000MI) (supplied with the N-8000MI) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000MI) Step 1. Install the rack-mounting bracket to the N-8000MI. Step 2.

  • Page 314: Wall Mounting

    INSTALLATION & WIRING Chapter 3 3.3. Wall Mounting Step 1. Install the supplied wall-mounting bracket to the N-8000MI using 4 removed screws from the case. Wall mounting bracket (supplied with the N-8000MI) Tapping screw 3 x 8 (removed from the case) N-8000MI Tapping screw 3 x 8 (removed from the case)

  • Page 315: Installation Of The Direct Select Unit

    INSTALLATION & WIRING Chapter 3 4. INSTALLATION Of The DIReCT SeLeCT UNIT The N-8000DI can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 4.1. equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 316: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 4.1.3. N-8000DI mounting N-8000DI Tapping screw 3 x 8 (supplied with the N-8000DI) Rack mounting bracket (supplied with the N-8000DI) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000DI) Step 1. Install the rack-mounting bracket to the N-8000DI.

  • Page 317: Wall Mounting

    INSTALLATION & WIRING Chapter 3 4.3. Wall Mounting Step 1. Install the optional YC-850 Wall mounting bracket to the N-8000DI. YC-850 Wall mounting bracket Machine screw M3 x 6 (supplied with the YC-850) N-8000DI Step 2. Mount the N-8000DI on the wall. Notes •...

  • Page 318: Installation Of The Audio Interface Unit, C/O Interface Unit And Telephone Interface Unit

    INSTALLATION & WIRING Chapter 3 5. INSTALLATION Of The AUDIO INTeRfACe UNIT, C/O INTeRfACe UNIT AND TeLePhONe INTeRfACe UNIT The N-8000AF/8000CO/8000AL can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 5.1.
  • Page 319 INSTALLATION & WIRING Chapter 3 5.1.2. N-8000Af/8000CO/8000AL mounting Use the optional mounting hardware set when installing the unit in an equipment rack. [When mounting a single unit] Use the optional MB-15B-BK hardware set. Tapping screw 3 x 14 Component parts of MB-15B-BK Tapping screw 3 x 8 N-8000AF/8000CO/8000AL Blank bracket...

  • Page 320: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 5.2. Desk-Top Installation When installing the N-8000AF/8000CO/8000AL on a desk, secure the supplied plastic feet to the unit's bottom using the supplied machine screws. Machine screw M3 x 8 (supplied with the N-8000AF/8000CO/8000AL) Plastic foot (supplied with the N-8000AF/8000CO/8000AL) N-8000AF/8000CO/8000AL 5.3.

  • Page 321: Installation Of The Ip Module

    INSTALLATION & WIRING Chapter 3 Step 2. Mount the N-8000AF/8000CO/8000AL on the wall. Notes • Use appropriate screws for the construction of wall. • Wood screws 3.5 x 20 are supplied with the YC-850. • The socket-outlet shall be installed near the equipment and the plug (disconnecting device) shall be easily accessible.

  • Page 322: Installation Of Master Stations

    INSTALLATION & WIRING Chapter 3 7. INSTALLATION Of MASTeR STATIONS Master stations can be installed in either of two ways: (1) wall mounting or (2) desk-top installation. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.

  • Page 323: Wall Hanging

    INSTALLATION & WIRING Chapter 3 7.2. Wall hanging 7.2.1. N-8000MS/8010MS/8020MS/8410MS/8500MS/8510MS/8600MS The station can be mounted on a wall using an optional YC-280 Wall-mounting bracket. The YC-280 can be installed to a one-gang electrical box. [Mounting example] Station YC-280 Wall mounting bracket Wall surface Hook...
  • Page 324 INSTALLATION & WIRING Chapter 3 [YC-280 dimensional drawing] 4.6 x 6 Unit: mm Rubber foot mounting position (desk-top application) 2-ø4.5 4.5 x 10 [Installation completion drawing] • N-8000MS/8010MS/8410MS/8500MS/8510MS/8600MS Unit: mm YC-280 YC-280 72.1 83.5 • N-8020MS Unit: mm YC-280 YC-280 76.2 106.5 3-20...
  • Page 325 INSTALLATION & WIRING Chapter 3 7.2.2. N-8011MS The station can be mounted on a wall using an optional YC-290 Wall mounting bracket. The YC-290 can be installed to a one-gang electrical box. [Mounting example] Station YC-290 Wall mounting bracket Wall surface Hook Wood screw 3.5 x 20...
  • Page 326 INSTALLATION & WIRING Chapter 3 [YC-290 dimensional drawing] 4.6 x 6 Unit: mm Rubber foot mounting position (desk-top application) 2-ø4.5 4.5 x 10 [Installation completion drawing] • N-8011MS Unit: mm YC-290 YC-290 72.1 3-22...

  • Page 327: Desk-Top Installation

    INSTALLATION & WIRING Chapter 3 7.3. Desk-Top Installation 7.3.1. N-8000MS/8010MS/8020MS/8410MS/8500MS/8510MS/8600MS In desktop installations, the front operation panel can be inclined 16˚ from the desk surface for easier operation by attaching the YC-280 Wall mounting bracket to its bottom surface. [Mounting example] Hang the wall mounting bracket hook on the station's wall bracket mounting slot to install.
  • Page 328 INSTALLATION & WIRING Chapter 3 7.3.2. N-8011MS In desktop installations, the front operation panel can be inclined 16˚ from the desk surface for easier operation by attaching the YC-290 Wall mounting bracket to its bottom surface. [Mounting example] Station YC-290 Wall mounting bracket Rubber foot (supplied with the YC-290) Hook...

  • Page 329: Flush Mounting

    INSTALLATION & WIRING Chapter 3 7.4. flush Mounting [N-8031MS] Attach the N-8031MS to the YC-241 Back box or an electrical box installed in a wall. Wall Wall surface surface Acoustic material (supplied with the N-8031MS) Note Lay it down along the inside of the box. N-8031MS YC-241 Back box or 5-gang electrical box...
  • Page 330 INSTALLATION & WIRING Chapter 3 [YC-241 dimensional drawing] Unit: mm 4-φ6 83.5 10-M4 Dimension of knockout hole A: φ27.1 B: φ21.5 C: φ34 3-26...
  • Page 331 Knockout holes Note When installing the N-8033MS outdoors or at locations where it gets wet with water, tightly seal the panel edges. For sealing method, consult your TOA dealer. [Installation completion drawing] Unit: mm Seal the panel edges. 3-27...
  • Page 332 INSTALLATION & WIRING Chapter 3 [YC-841 dimensional drawing] Unit: mm 6-φ5 Knockout hole φ12.7 Knockout hole φ20.9 Knockout hole 4-M4 φ12.7 Knockout hole φ20.9 Knockout hole 3-28...

  • Page 333: Wall Surface Mounting

    INSTALLATION & WIRING Chapter 3 7.5. Wall Surface Mounting [N-8031MS] Attach the N-8031MS to the YC-251 Wall-mount box installed on a wall. Wall surface Acoustic material (supplied with the N-8031MS) Note Lay it down along the inside of the box. YC-251 Wall-mount box N-8031MS Machine screw M4 x 25...
  • Page 334 (waterproof type). For the cord bush, contact the After installing the N-8033MS, TOA dealer where the unit was check first if the conversations purchased. can be made, then attach the both ends of the adhesive sheet YC-841 bottom to the N-8033MS’s front surface...

  • Page 335: Installation Of Remote Microphone Station

    INSTALLATION & WIRING Chapter 3 8. INSTALLATION Of ReMOTe MICROPhONe STATION 8.1. Desk-Top Installation 8.1.1 N-8610RM expansion with the addition of the RM-210 When adding an RM-210 Remote Microphone Extension to expand the N-8610M, use the RM-210's Extension cable and included Linkage Bracket to link the 2 units. Follow the procedures below.

  • Page 336: Wall Hanging

    INSTALLATION & WIRING Chapter 3 8.2. Wall hanging The N-8610RM can be mounted on a wall using an optional WB-RM200 Wall-Mounting Bracket. 8.2.1 N-8610RM [WB-RM200 mounting dimensions] Step 1. Install the WB-RM200 Wall-Mounting Bracket to the wall. WB-RM200 (optional) In this case, leave the LAN cable out of the notch in the bracket.
  • Page 337 INSTALLATION & WIRING Chapter 3 8.2.2 RM-210 The RM-210 can be mounted on a wall using an optional WB-RM200 Wall-Mounting Bracket. Step 1. Install the N-8610RM to the wall. (Refer to the previous page.) Step 2. Install the WB-RM200 used for mounting the RM-210 to the wall.

  • Page 338: Creating Remote Microphone Name Labels

    INSTALLATION & WIRING Chapter 3 8.3. Creating Remote Microphone Name Labels 8.3.1. Creating name labels using the Sx-2000 Setting Software Using the SX-2000 Setting Software function, assigned names of preset N-8610RM and RM-210 Function keys can be printed out. Once printed, cut out the printed names with scissors to use them as corresponding name labels.
  • Page 339 INSTALLATION & WIRING Chapter 3 8.3.3. If the name label is not printed correctly The name label created using the SX-2000 Setting Software may not be printed in correct size depending on the configuration environment of your PC. In such cases, try one of the methods described below. (1) Preparation by hand Copy the handwriting label on pages 3-36 and 3-37...
  • Page 340 INSTALLATION & WIRING Chapter 3 [Preparing handwriting label] Precautions on Printing Be sure to print out the corresponding pages of this PDF file 100% in size. To do so, set the print items of the Adobe Acrobat or Adobe Reader as follows. Note that the Adobe Acrobat's or Adobe Reader's default setting will reduce the size of pages to be printed.
  • Page 341 INSTALLATION & WIRING Chapter 3 Name label B Name label B Name label B Name label B Guideline Actual size 3-37...

  • Page 342: Installation Of Door Stations

    INSTALLATION & WIRING Chapter 3 9. INSTALLATION Of DOOR STATIONS Door station N-8050DS/8540DS/8640DS/8650DS can be installed in either of two ways: (1) flush mounting or (2) wall surface mounting. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.
  • Page 343 N-8500DS/8540DS's front panel. of the N-8050DS/8540DS with coating. For the coating method, consult your TOA dealer. • Treat unused cables so as not to short-circuit. (N-8640DS only) [YC-150 dimensional drawing] Unit: mm 4-φ6...
  • Page 344 INSTALLATION & WIRING Chapter 3 [N-8650DS] Mount the panel mount frame to the YC-150 Back box or 3-gang electrical box installed in a wall, then attach the N-8650DS to the panel mount frame. Step 1. Loosen the screw on the N-8650DS's bottom, then detach the panel mount frame. Screw Panel mount frame N-8650DS's bottom...

  • Page 345: Wall Surface Mounting

    INSTALLATION & WIRING Chapter 3 9.2. Wall Surface Mounting [N-8050DS/8540DS/8640DS] Attach the N-8050DS/8540DS/8640DS to the YS-13A Wall-mount box installed on a wall. N-8640DS only N-8050DS only Wall Install the YC-13A with its rear surface Acoustic material (supplied with the N-8050DS) plate removed.
  • Page 346 N-8050DS/8540DS Wall surface with coating. For the coating method, consult your TOA dealer. • Treat unused cables so as not to short-circuit. (N-8640DS The figure represents the N-8050DS/8540DS.
  • Page 347 INSTALLATION & WIRING Chapter 3 [N-8650DS] Attach the N-8650DS to the YS-13A Wall-mount box installed on a wall. Step 1. Loosen the screw on the N-8650DS's bottom, then detach the panel mount frame. Screw Panel mount frame N-8650DS's bottom Step 2. Mount the panel mount frame to the back Step 3.

  • Page 348: Installation Of Substations

    INSTALLATION & WIRING Chapter 3 10. INSTALLATION Of SUBSTATIONS The Substations can be installed in either of 2 ways: flush mounting using the YC-302 2-gang electrical box or commercial electrical box, or wall surface mounting using the YC-822/823 Wall-mount box. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.
  • Page 349 INSTALLATION & WIRING Chapter 3 [YC-302 dimensional drawing] [Outlet box] [Cover] Unit: mm 3-φ21.5 (Knockout hole) 4-M4 2-φ27.1 (Knockout hole) 2-M4 4-φ21.5 (Knockout hole) 4-φ27.1 (Knockout hole) 3-45...

  • Page 350: Wall Surface Mounting

    INSTALLATION & WIRING Chapter 3 10.2. Wall Surface Mounting Attach the Substation to the YC-822 or YC-823 Wall-mount box installed on a wall. Wall surface Substation YC-822/823 Machine screw M4 x 25 (supplied with the substation) Note In the case of the YC-823, install it facing the ø6 weep hole side down.
  • Page 351 INSTALLATION & WIRING Chapter 3 [YC-822 dimensional drawing] Unit: mm 4-M4 (for substation mounting) 8-5×7 oval hole (for wall mounting) φ28 (Knockout hole) φ28 hole [YC-823 dimensional drawing] Unit: mm 4-M4 (for substation mounting) 8-5×7 oval hole (for wall mounting) φ28 hole φ6 weep hole 3-47...

  • Page 352: Installation Of Switch Panel

    INSTALLATION & WIRING Chapter 3 11. INSTALLATION Of SWITCh PANeL Switch panel RS-140/143/144 can be installed in either of two ways: (1) flush mounting or (2) wall surface mounting. 11.1. flush Mounting Mount the Switch panel to the YC-801 Flush-mount box or electrical box mounted in the wall. Wall surface Machine screw M4 x 30 (supplied with the RS-140/143/144)
  • Page 353 INSTALLATION & WIRING Chapter 3 [YC-801 dimensional drawing] Unit: mm 2-φ6 2-M4 Dimension of knockout hole A: φ21.5 B: φ27.1 3-49...

  • Page 354: Wall Surface Mounting

    INSTALLATION & WIRING Chapter 3 11.2. Wall Surface Mounting Attach the Switch panel to the YC-802 Wall-mount box installed on a wall. Wall surface Machine screw M4 x 30 (supplied with the RS-140/143/144) RS-140 83.5 mm YC-802 Wall-mount box Mounting bracket (supplied with the RS-140/143/144) UNC No.
  • Page 355 INSTALLATION & WIRING Chapter 3 [YC-802 dimensional drawing] Unit: mm φ34 knockout hole 50.5 22.5 4-double knockout hole 4-7x5 3-51...

  • Page 356: Installation Of Option Handset

    INSTALLATION & WIRING Chapter 3 12. INSTALLATION Of OPTION hANDSeT Option handset RS-141/191/481 can be installed in a wall. Mount the option handset to the YC-302 or electrical box mounted in the wall. YC-302 or electrical box Wall surface Machine screw M4 x 25 (supplied with the RS-141/191/481) Option handset Note: This figure represents the RS-191.

  • Page 357: Wiring

    INSTALLATION & WIRING Chapter 3 13. WIRING 13.1. exchange Connection N-8000EX/8010EX Exchange 16 lines Be sure to ground. Mini-clamp connector 232D-02S1B-DA5 (DDK) (Supplied with the N-8000EX/8010EX) To AC mains or a UPS (Uninterruptible power supply system)* Note If there is a danger of lightning strikes, insert an appropriate power gap arrester into the power line.
  • Page 358 INSTALLATION & WIRING Chapter 3 N-8000EX only N-8000EX/8010EX Exchange RJ-45 connector To network Removable terminal plug (supplied with the N-8000EX) Control input PA Paging amplifier, etc Line input [General description of connection] For cables, refer to 3-81. 1. Power supply connection 4.

  • Page 359: Connections Of Stations Used In Conjunction With The Exchange

    INSTALLATION & WIRING Chapter 3 13.2. Connections of Stations Used in conjunction with the exchange 13.2.1. Station and exchange connection The cables from the N-8000EX Exchange to the Station have no polarity. [N-8000MS/8010MS/8011MS] To connect the cables from the N-8000EX Exchange to the Master Station, use the connection cable supplied with each station and a commercially available RJ-11 modular jack.
  • Page 360 INSTALLATION & WIRING Chapter 3 [N-8031MS/8033MS] To connect the cables from the N-8000EX Exchange to the Master station, use the removable terminal plug (2P) supplied with the N-8031MS/8033MS. Refer to p. 3-83 "Terminal plug connection." To the exchange via the Terminal Board Twisted pair cable Removable terminal plug (2p) (supplied with the N-8031MS/8033MS)
  • Page 361 INSTALLATION & WIRING Chapter 3 13.2.3. external speaker terminals and control output terminals connections [N-8000MS] These terminals are designed for exclusive connection with external speakers. Press down the desired push-in terminal button on the rear panel with a tip of standard driver, and insert the cable securely.
  • Page 362 INSTALLATION & WIRING Chapter 3 Step 4. After inserting the cables in the supplied rubber bushing, insert the bushing into the station, then put the protection cover back in place. Protection cover Protection cover fixing screw (the screw removed in Step 1) Since wire leads can be pinched, make them as short as possible.
  • Page 363 INSTALLATION & WIRING Chapter 3 13.2.5. N-8031MS/8033MS and external switch connections External switches such as footswitches can be connected to the N-8031MS's/8033MS's external dial input terminal. Note The cable length from the external switch should not exceed 3 m. [Connections] 8 mm Press down.

  • Page 364: N-8000Rs/8010Rs Substation Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.3. N-8000RS/8010RS Substation Interface Unit Connection N-8000RS/8010RS Substation interface unit 16 lines Brown RJ-45 connector Be sure to ground. Orange 3P removable terminal plug To AC mains or a UPS (supplied with the N-8000RS (Uninterruptible power supply To network /8010RS) system)*...

  • Page 365: Connections Of Stations Used In Conjunction With The N-8000Rs/8010Rs

    INSTALLATION & WIRING Chapter 3 13.4. Connections of Stations Used in conjunction with the N-8000RS/8010RS 13.4.1. RS-180 and external relay connections External Diode RS-180 power supply Relay Blue (HOT) – 24 V DC White (COM) Open collector output: 24 V DC, Max. 30 mA Note: Cut out the control cables if they are not used to avoid short-circuiting.
  • Page 366 INSTALLATION & WIRING Chapter 3 13.4.4. RS-140/142/143/144, RS-141, and speaker connections N-8000RS/8010RS Substation interface unit 3P removable terminal plug (supplied with the N-8000RS/8010RS) Brown Orange 2-core shielded cable RS-140/142/143/144 Brown (A) Red (B) Orange (C) Yellow (C+) Green (B+) N.C. Blue (A+) Purple (H) Note: This figure represents...

  • Page 367: N-8400Rs Substation Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.5. N-8400RS Substation Interface Unit Connection N-8400RS Substation interface unit 16 lines RJ-45 connector Be sure to ground. 4P removable terminal plug (supplied with the N-8400RS) To AC mains or a UPS To network (Uninterruptible power supply system)* Two pairs of twisted pair cable Note If there is a danger of lightning strikes,...

  • Page 368: Connections Of Stations Used In Conjunction With The N-8400Rs

    INSTALLATION & WIRING Chapter 3 13.6. Connections of Stations Used in conjunction with the N-8400RS 13.6.1. Station and substation interface unit connections [N-8410MS] [RS-450/460/470/480] N-8400RS Substation interface unit N-8400RS Substation interface unit 4P removable terminal plug 4P removable terminal plug (supplied with the N-8400RS) (supplied with the N-8400RS) Two pairs of twisted pair cable...
  • Page 369 INSTALLATION & WIRING Chapter 3 13.6.2. RS-480 and external relay connections External Diode RS-480 power supply Relay Blue (HOT) – 24 V DC White (COM) Open collector output: 24 V DC, Max. 30 mA Note: Cut out the control cables if they are not used to avoid short-circuiting. 13.6.3.

  • Page 370: Multi Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.7. Multi Interface Unit Connection N-8000MI 9P removable terminal plug (supplied with the N-8000MI) Be sure to ground this Be sure to ground this terminal unless the unit terminal unless the unit connects to a PBX. connects to PBX.
  • Page 371 INSTALLATION & WIRING Chapter 3 N-8000MI Input volume controls RJ-45 connector 8P removable terminal plug To network (supplied with the N-8000MI) Mini-clamp connector 232D-02S1B-DA5 (DDK) (supplied with the N-8000MI) To the tie-line unit of intercom system or the PBX's analog E&M interfaces Control input Line output * Control output...
  • Page 372 INSTALLATION & WIRING Chapter 3 [Connecting to the PBx's analog e&M interface] Connect the PBX's transmitting line to the unit's RX terminal, and the PBX's receiving line to the TX terminal. Also connect the PBX's M (Mouth) line to the unit's E (Ear) terminal, and the PBX's E line to the M terminal. N-8000MI's PBX interface terminal To PBX's ground point To PBX analog E&M interface's M and E lines...

  • Page 373: Direct Select Unit Connection

    INSTALLATION & WIRING Chapter 3 13.8. Direct Select Unit Connection N-8000DI Direct select unit Be sure to ground. To AC mains or a UPS (Uninterruptible power supply system)* Contact input signals Contact input signals Note If there is a danger of lightning strikes, insert an appropriate surge arrester into the power line.
  • Page 374 INSTALLATION & WIRING Chapter 3 N-8000DI Direct select unit RJ-45 connector To network Contact output signals Contact output signals 16P removable terminal plug (supplied with the N-8000DI) Contact output signals Contact output signals 3. Contact output terminal connection 4. Network connection Contact output terminals have no polarity.

  • Page 375: Audio Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.9. Audio Interface Unit Connection N-8000AF Audio interface unit Be sure to ground. RJ-45 connector To AC mains or a UPS To network (Uninterruptible power supply system)* Contact input Contact output signals signals Note If there is a danger of lightning strikes, insert an appropriate surge arrester into the power line.
  • Page 376 INSTALLATION & WIRING Chapter 3 3. Audio input terminal connection 5. Contact input terminal connection Connect the microphone, audio device, etc. to this (Refer to 3-83, Terminal plug connection.) [Specification of no-voltage make contact input] terminal using the two-core shielded cable. (Refer to 3-83, Terminal plug connection.) Short-circuit current: 5 mA...

  • Page 377: C/O Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.10. C/O Interface Unit Connection N-8000CO C/O interface unit Be sure to ground. RJ-45 connector To network To AC mains or a UPS (Uninterruptible power supply system)* Mini-clamp connector Note 232D-02S1B-DA5 (DDK) (supplied with the N-8000CO) If there is a danger of lightning strikes, insert an appropriate surge arrester A pair of twisted pair cables...

  • Page 378: Telephone Interface Unit Connection

    INSTALLATION & WIRING Chapter 3 13.11. Telephone Interface Unit Connection N-8000AL Telephone interface unit Be sure to ground. RJ-45 connector To network To AC mains or a UPS (Uninterruptible power supply system)* Mini-clamp connector 232D-02S1B-DA5 (DDK) Note (supplied with the N-8000AL) If there is a danger of lightning strikes, insert an appropriate surge arrester into the power line.

  • Page 379: Ip Station Connection

    Use the AC adapter AD-1210P/1215P (optional) 4. Network connection terminal connection or the equivalent. Can be connected to a network of 10BASE- As for the usable adapter, consult your TOA T/100BASE-TX in auto-sensing. dealer. Connecting the station to a PoE (Power over Ethernet) switching hub compliant with IEEE802.3af...
  • Page 380 Ferrite clamp (supplied with the N-8510MS) * Use the AC adapter AD-1210P/1215P (optional) or the equivalent. As for the usable adapter, consult your TOA dealer. 2. Message start terminal connection Press down the desired push- in terminal button with a tip of standard driver, and insert the cable securely.
  • Page 381 Connect the AC adapter*. ø3.5 mm mini jack. * Use the AC adapter AD-1210P/1215P (optional) or Connect the headset speaker. the equivalent. As for the usable adapter, consult your TOA 4. headset microphone connection dealer. ø3.5 mm mini jack. Connect the headset microphone.
  • Page 382 * Use the AC adapter AD-1215P (optional) or the T/100BASE-TX in auto-sensing. equivalent. Connecting the station to a PoE (Power over As for the usable adapter, consult your TOA Ethernet) switching hub compliant with IEEE802.3af dealer. eliminates the need for an AC adapter. (For...
  • Page 383 Connecting the station to a PoE (Power over the equivalent. Ethernet) switching hub compliant with IEEE802.3af As for the usable adapter, consult your TOA eliminates the need for an AC adapter. (For dealer. connection, refer to the instruction manual supplied with the switching hub.)
  • Page 384 Connecting the station to a PoE (Power over the equivalent. Ethernet) switching hub compliant with IEEE802.3af As for the usable adapter, consult your TOA eliminates the need for an AC adapter. (For dealer. connection, refer to the instruction manual supplied with the switching hub.)

  • Page 385: Type Of Cable

    INSTALLATION & WIRING Chapter 3 13.13. Type of Cable The types of cables are to be determined according to the following conditions. • To use twisted pair wires (such as those used for electronic push-button telephone) for wiring between the Exchange and the stations, for wiring between the N-8400RS Substation interface unit and the N-8410MS Master station or the RS-450/460/470/480 Substations, and for connections to the Multi interface unit's audio input/output terminals and PBX interface terminals.

  • Page 386: Relations Between Core Diameter Of Cable And Maximum Cable Length

    INSTALLATION & WIRING Chapter 3 13.14. Relations Between Core Diameter of Cable and Maximum Cable Length Refer to the following chart as guidelines when designing the distance between the Exchange and stations so that loop resistance value becomes 170 Ω or less. Conductor diameter Loop resistance Maximum cable length between the Exchange and station.

  • Page 387: Connector Connection

    INSTALLATION & WIRING Chapter 3 13.15. Connector Connection 13.15.1. Mini-clamp connector connection Connect the mini-clamp connector supplied with the N-8000EX, N-8010EX, N-8000MI, N-8000CO, N-8000AL to a cable using a commercially available tool (pliers). Step 1. Cut off two-cable ends in equal length, and insert them Cover (transparent side) securely to a cover section (transparent side) of the mini-clamp connector.
  • Page 388 INSTALLATION & WIRING Chapter 3 Step 2. Loosen the terminal screws and insert the cables. Step 3. Tighten the terminal screws securely. Notes • Tug lightly on the cable to be sure that it does not pull free. If the cable pulls free, loosen the terminal screw again and reconnect from Step 2.
  • Page 389 Chapter 4 SYSTEM DESIGN FLOW This chapter describes system setting items and switching on power to the system.

  • Page 390: Chapter 4 System Design Flow

    Chapter 4 1. SYSTEM DESIGN PRECAUTIONS System and equipment settings must be performed before operating the N-8000 Series systems. Three different methods are available for individual settings, and the details of these methods are explained in each of the following chapters.

  • Page 391: Network Settings Using A Personal Computer

    SYSTEM DESIGN FLOW Chapter 4 4. NETWORk SETTINGS USING A PERSONAL COMPUTER Network settings involving the use of a PC can vary depending on the network configuration. No particular care need be taken within the LAN (i.e. the range within which broadcast transmission is permitted), however some planning regarding the enabling of settings is required for configurations extending beyond the perimeter of the LAN.
  • Page 392 SYSTEM DESIGN FLOW Chapter 4 [Setting procedures] Step 1. Using a system setting PC* , set a network* for Exchanges, Various kinds of interface units, and IP stations that permit broadcast communications with this PC. PC (A) in the illustration on the previous page LAN (A) in the illustration on the previous page Use the supplied N-8000 Setting Software program's unit scan function to perform settings.
  • Page 393 SYSTEM DESIGN FLOW Chapter 4 5. SYSTEM SETTING ITEMS AND DEFAULT All system setting items except the auto-dialing programming can be set using the N-8000 Setting Software. Some setting items, however, can also be set on the browser or at stations. The browser can only make the connected Exchange-, Various kinds of interface units-, or IP station-related items, while stations can only make the connected Exchange- or their own stations-related items.
  • Page 394 SYSTEM DESIGN FLOW Chapter 4 5.2. Exchange Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2, 3 p. 5-30 Subnet Mask * 255.255.255.0 p. 6-5 1, 2, 3 p. 7-8 Default Gateway * 0.0.0.0 1, 2, 3 Web server port number * p.
  • Page 395 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Function settings Audio trigger time-out Time limit 10 seconds Paging with call tone Delay time p. 5-36 Paging response mode Zone number designation response mode Paging priority mode Paging priority Calling station indication During call and talk p.
  • Page 396 SYSTEM DESIGN FLOW Chapter 4 5.3. Multi Interface Unit Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-38 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * p.
  • Page 397 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Audio I/O Input mode Unused p. 5-45 Output mode Unused Input sensitivity Level 1 Access number Paging zone p. 5-46 Output level Level 4 Line attributer Line start Wink start Contact inputs Contact Input No.

  • Page 398: Sub Stations

    SYSTEM DESIGN FLOW Chapter 4 5.4. Sub Stations Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-50 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 p.

  • Page 399: Ip Stations

    SYSTEM DESIGN FLOW Chapter 4 5.5. IP Stations Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2, 3 p. 5-58 Subnet Mask * 255.255.255.0 p. 6-5 1, 2, 3 p. 7-8 Default Gateway * 0.0.0.0 1, 2, 3 Web server port number * 1, 2...
  • Page 400 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Incoming call mode Automatic Function settings 2 connection mode p. 5-65 with call tone Microphone sensitivity Level 2 Speaker output * Level 3 p. 5-65 p. 2-5 Station speaker sound volume Level 3 p.
  • Page 401 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Access to emergency all paging call Function settings 2 operation Access to audio trigger setting p. 5-67 operation External equipment control Speed dialing Onetouch dial * p. 5-68 p. 2-12 p.
  • Page 402 SYSTEM DESIGN FLOW Chapter 4 5.6. Stations Reference Side TAB Item Default page Function settings Incoming call mode Automatic connection mode p. 5-80 with call tone Microphone sensitivity Level 2 Speaker output * Level 3 p. 5-80 p. 2-5 Station speaker sound volume Level 3 p.
  • Page 403 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Function settings Door station mode Call Activation - push 3 times Access to priority call Refusal of priority call setting Access to emergency call operation p. 5-82 Access to paging call operation Access to emergency all paging call operation Access to audio trigger setting...

  • Page 404: C/O Interface

    SYSTEM DESIGN FLOW Chapter 4 5.7. C/O Interface Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-58 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 p.

  • Page 405: Telephone Interface

    SYSTEM DESIGN FLOW Chapter 4 5.8. Telephone Interface Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-93 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 p.
  • Page 406 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Function settings 2 Microphone sensitivity Level 2 Speaker output Level 3 p. 5-99 Station speaker sound volume Level 3 Group call member Call forwarding destination station * p. 5-99 p.

  • Page 407: Audio Interface

    SYSTEM DESIGN FLOW Chapter 4 5.9. Audio Interface Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-102 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 p.
  • Page 408 SYSTEM DESIGN FLOW Chapter 4 Reference Side TAB Item Default page Schedule Settings Paging No. p. 5-109 Source Access to external control Contact Output Contact Output No. Access No. p. 5-110 Access No. digits Line status Unused Network status Unused •...

  • Page 409: Direct Select

    SYSTEM DESIGN FLOW Chapter 4 5.10. Direct Select Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-111 Subnet Mask * 255.255.255.0 1, 2 p. 6-5 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 p.

  • Page 410: Gateway

    SYSTEM DESIGN FLOW Chapter 4 5.11. Gateway Reference Side TAB Item Default page Network settings IP address * 192.168.1.1 1, 2 p. 5-118 Subnet Mask * 255.255.255.0 1, 2 Default Gateway * 0.0.0.0 1, 2 Web server port number * 1, 2 TCP start port number 5000...
  • Page 411 Chapter 5 SYSTEM SETTINGS BY SOFTWARE This chapter describes how to install and use the N-8000 system settings software.

  • Page 412: Chapter 5 System Settings By Software

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 1. N-8000 SETTING SOFTWARE GENERAl DESCRIpTION 1.1. General Description The supplied N-8000 Setting Software program is for performing system settings and features following two functions. 1.1.1. Equipment scan and network setting functions Detect the Exchange, various kinds of interface units, and IP station connected to the local network, and then perform equipment network settings.

  • Page 413: Installing Software

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 2. INSTAllING SOFTWARE 2.1. System Requirements This program has been designed based on the following system requirements. • OS: Windows XP Professional SP2 or later, Windows Vista Business, Windows 7 Professional, Windows 8.1 Pro* •...

  • Page 414: Required Component Installation (Except When The Os Is Windows 8.1)

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 If your Web browser is not JavaScript-enabled, the screen at right will be displayed. Press the English button to display English screens. 2.3. Required Component Installation (Except when the OS is Windows 8.1) To activate the N-8000 Setting Software program, the following components are required. •...

  • Page 415: N-8000 Setting Software Installation

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 2.4. N-8000 Setting Software Installation Step 1. Click "Installation Start" in the "N- 8000 Setting software Installation" section N-8000 Setting Software Setup Guide screen to start software program installation. The installer will start up. Step 2.
  • Page 416 SYSTEM SETTINGS BY SOFTWARE Chapter 5 The screen "Select Installation Folder" will be displayed. Step 5. If you need to change the folder to install the program, select a desired folder. To install the software into a different folder other than indicated on the screen, press [Browse...] button or [Disk Cost...] button to select a desired folder.

  • Page 417: Operating The N-8000 Setting Software Program On Windows 8.1

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 2.5. Operating the N-8000 Setting Software program on Windows 8.1 To activate the N-8000 Setting Software program on Windows 8.1 Pro, the following procedures are required. Activation of Microsoft .NET Framework 3.5 (Refer to the next item.) Installation of Microsoft SQl Server 2012 Express (See the next...
  • Page 418 SYSTEM SETTINGS BY SOFTWARE Chapter 5 2.5.2. Installation of Microsoft SQl Server 2012 Express Step 1. Download "Microsoft SQL Server 2012 Express." Access the Microsoft Download Center for download. Step 2. Run the downloaded installer, then click "New SQL Server stand-alone installation or add features to an existing installation."...
  • Page 419 SYSTEM SETTINGS BY SOFTWARE Chapter 5 The screen "Feature Selection" will be displayed. Step 5. Press [Next] button. The screen "Instance Configuration" will be displayed. Step 6. Check that "SQLExpress" is preset in Named instance field and "SQLEXPRESS” in Instance ID field, then press [Next] button.
  • Page 420 SYSTEM SETTINGS BY SOFTWARE Chapter 5 screen "Database Engine Configuration" will be displayed. Step 8. Press [Next] button. The screen "Error Reporting" will be displayed. Step 9. Press [Next] button. Installation begins. Installation Complete screen is displayed when the installation is successfully completed.

  • Page 421: N-8000 Setting Software Uninstallation

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 2.5.4. Giving the user the permission to change the "N8000Config.mdf" and "N8000Config_log.ldf" files Step 1. Open the folder to which you installed the N-8000 Setting Software program, then right-click the "N8000Config.mdf" file to select its properties. The screen "N8000Config Properties"...

  • Page 422: Folder Configuration

    Chapter 5 2.7. Folder Configuration The N-8000 Setting Software program is installed in the default location C:\Program Files\TOA\N-8000. The system setting file is created in the location (1) for Windows XP or (2) for Windows Vista, Windows 7, and Windows 8.1 as follows:...

  • Page 423: Activating N-8000 Setting Software Program

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 3. ACTIVATING N-8000 SETTING SOFTWARE pROGRAM Step 1. Double-click the shortcut icon created on the desk-top screen when installing, or double-click the ConfigurationSoft.exe created in the installed folder directly. [System Selection] screen is displayed. (1) New System (3) Import button Creates a new system.
  • Page 424 SYSTEM SETTINGS BY SOFTWARE Chapter 5 After system name and password have been entered correctly, N-8000 Setting Software program initial screen is displayed. Step 3. Click [Unit Scan (Network Settings)] when detecting equipment. Step 4. Click [System Settings] when setting system. Step 5.

  • Page 425: Unit Scan (Network Settings)

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 4. UNIT SCAN (NETWORk SETTINGS) These functions enable the detection and network setting of Exchanges, various kinds of interface units, and IP stations connected to the local area network. The equipment detection function can only be used within the effective broadcast range (refer to 8-9).

  • Page 426: Changing Equipment Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 4.2. Changing Equipment Settings 4.2.1. Single Unit Selection and Activation Select the device to be changed on the Equipment IP Setting screen, then click "Change IP Settings" button. The following screen shows an example in which a single device is activated after it has been selected on the Equipment IP Setting screen.

  • Page 427: System Setting Function

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 5. SYSTEM SETTING FUNCTION Performs individual system settings. Use the Unit Scan/Network Setting function, a browser, an N-8000MS Multifunctional station, or an N-8500MS/8600MS IP Multifunctional station to set the IP address correctly, then use this System Setting function to update the exchange's, various kinds of interface units, or IP station's setting data.

  • Page 428: Menu

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 (7) C/O Interface tab (10) Direct Select tab Perform settings related to the C/O interface Perform settings related to the Direct select unit. Available tabs include: [Network Settings], unit. Available tabs include: [Network Settings], [Function Settings 1], [Function Settings 2] and [Function Settings], [Contact Input] and [Contact [Scan Monitor].

  • Page 429: Overall System Configuration Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Equipment Registration 5.2.3. Help About : Displays the version number of this software program. 5.3. Overall System Configuration Settings Click "General" tab. 5.3.1. Equipment registration Determines the configuration of the equipment connected to the network within the system and register it. Program data can be entered manually, or it can be imported using data scan for the Equipment using the Unit Scan/Network Setting function.
  • Page 430 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Equipment Registration [Screen description] (1) Starting Equipment Number Enter the first unit number to be set. Unit numbers of 1 – 192 are automatically assigned in sequential order starting with the number entered here. However, duplicated numbers cannot be assigned. (2) Equipment No.
  • Page 431 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Equipment Registration Step 3. Set the Equipment name, Model, IP Address, and Web Port. These items can be set directly by clicking and editing the data in each cell, or by importing equipment data detected using the Unit Scan/Network Setting function.
  • Page 432 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Station Table 5.3.2. Station number and type settings Step 1. Click "Station Table" tab to display the setting screen. Step 2. Select the number of digits in the station number. Step 3. Set each item as follows: (1) Equipment No.
  • Page 433 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Station Table (6) Station name Set the name of each station using up to eight alphanumeric characters. Station names can be displayed on multifunctional stations. [Collective setup] Pressing the Collective setup button permits station types, station numbers, and station names for all or selected stations to be set all at once.
  • Page 434 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Network Communication Registration 5.3.3. Network communications registration Enables or disables unicast network communications among equipment connected to the network. Step 1. Click "Network Communication Registration" tab to display the following setting screen. Step 2. Select device combinations capable of network communications. Selection can be made by clicking the combinations that allow communications.
  • Page 435 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Multicast Registration 5.3.4. Multicast communications registration Enables or disables Multicast communications among equipment connected to the network. When multicast communications are an available option, performing this registration conserves network bandwidth by allowing multicast paging. Step 1.
  • Page 436 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: System Settings 5.3.5. System settings registration Perform settings common to the entire system. Step 1. Click "System Settings" tab to display the following setting screen. (1) Response Mode Set the Response Mode. Sequential: Responds to individual calls in order of receipt. Selective: The master station selects a station and responds to that station.
  • Page 437 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: System Settings (5) DST (Summer time) Settings Set daylight saving time. with DST: Set whether or not to enable daylight saving time. Start/End: Set the date and time to start and end daylight saving time. Designate it in the format [hour] of [day] of [nth week] of [month].
  • Page 438 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Gateway Settings 5.3.6. Gateway Settings Perform settings necessary for making broadcasts to the SX-2000 system. Prepare the SX-2000 Setting file in advance. Step 1. Click the “Gateway Settings” tab. The setting screen below is displayed. Step 2.
  • Page 439 SYSTEM SETTINGS BY SOFTWARE Chapter 5 General: Gateway Settings SX-2000 System name, IP address, and other related items are displayed. Step 4. Select the SX-200IP to be connected. 4-1. Mark the checkbox of the SX- 200IP connection. Up to 8 SX-200IP units can be connected per SX-2000 System.

  • Page 440: Exchange Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Network Settings 5.4. Exchange Settings Click "Exchange" tab to select the exchange to be set. Choose the name or number of the exchange from the list. 5.4.1. Network settings Step 1. Click "Network Settings" tab to display the following setting screen. Step 2.
  • Page 441 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 442 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Network Settings (6) Network ID When connecting a PC to the exchange using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 443 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Exchange is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 444 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Sampling Frequency Correction 5.4.2. Sampling frequency correction settings Step 1. Click "Sampling Frequency Correction" tab to display the following setting screen. Step 2. Set individual items. (1) Sampling Frequency Correction Select this tab when setting the transfer of sampling frequency correction data between different networks. (Correction data is automatically transmitted and received within the range that can receive broadcast packets.) Note: See...
  • Page 445 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Function Settings 5.4.3. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Transfer settings Set the transfer function ON or OFF for the station connected to the exchange. Call forwarding: Calls to stations are automatically transferred to another designated station without sounding a call tone only when Call forwarding function is enabled.
  • Page 446 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Function Settings (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station. If setting a time-out, enter the time limit after which calls to the station are automatically terminated.
  • Page 447 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Exchange: Function Settings (10) Calling station indication Select either "During call and talk" or "During talk" mode when performing the calling station indication function. The table below shows the timing that the Multi interface unit's, Direct select unit’s, or Audio interface unit’s contact output is closed.

  • Page 448: Multi Interface Unit Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Network Settings 5.5. Multi Interface Unit Settings Click "Multi Interface" tab to select the multi interface unit to be set. Choose the name or number of the multi interface unit from the list. 5.5.1.
  • Page 449 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 450 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Network Settings (6) Network ID When connecting a PC to the multi interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 451 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Multi interface unit is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 452 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Sampling Frequency Correction 5.5.2. Sampling frequency correction settings Step 1. Click "Sampling Frequency Correction" tab to display the following setting screen. Step 2. Set individual items. (1) Sampling Frequency Correction Select this tab when setting the transfer of sampling frequency correction data between different networks. (Correction data is automatically transmitted and received within the range that can receive broadcast packets.) Note: See...
  • Page 453 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Function Settings 5.5.3. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily. The setting range is from 1 to 9 (in 1-second units).
  • Page 454 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Function Settings (3) Aux input paging Allows external input broadcasts to take precedence over all-zone paging and individual zone paging. (4) Delay Time Set the delay time before paging is initiated. (5) paging response mode Select either "Zone Selection"...
  • Page 455 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Audio I/O 5.5.4. Audio I/O settings Step 1. Click "Audio I/O" tab. The corresponding setting screen is displayed. Step 2. Perform settings for each item of Audio I/O Ch 1 and Ch 2. Set how to use the Multi-interface unit's Audio input and output terminals.
  • Page 456 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Audio I/O (2) Output mode Setting "Input mode" to "Aux input paging," "BGM" or "Unused" permits "PA paging" to be selected. Tie-line: Select this item when connecting the Multi interface unit to the exchange of different series intercom system (EXES-2000 or EXES-6000 series system).
  • Page 457 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Contact Input 5.5.5. Contact input setting Step 1. Click "Contact Input" tab. The setting screen is displayed. Step 2. Set each item of "Contact input." (1) Contact input No. (Can't be edited.) The Multi interface unit's contact input terminal number.
  • Page 458 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Contact Input Aux input paging: Select this item when activating playback components or other devices connected to the Multi interface unit's audio input terminal from the control input. Paging busy 1: Select this item when sending externally-connected paging equipment's busy status data to the Audio output 1.
  • Page 459 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Multi Interface: Contact Output 5.5.6. Contact output setting Step 1. Click "Contact Output" tab. The setting screen is displayed. Step 2. Set each item of "Contact output." Set the access number for the contact output terminal to be activated when the station performs external equipment control (one-shot make output or make/break output).

  • Page 460: Setting Sub-Station Interface

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Network Settings 5.6. Setting Sub-station Interface Click "Sub-station Interface" tab to select the Sub-station Interface to be set. Choose the name or number of the Sub-station Interface unit from the list. 5.6.1. Network settings Step 1.
  • Page 461 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 462 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Network Settings (6) Network ID When connecting a PC to the Sub-station interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 463 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Sub-station interface unit is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 464 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Function Settings 5.6.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Transfer settings (N-8400RS only) Set the transfer function ON or OFF for the station connected to the exchange. Call forwarding: Calls to stations are automatically transferred to another designated station without sounding a call tone only when Call forwarding function is enabled.
  • Page 465 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Function Settings Paging time-out: Set whether to limit the duration of paging call with the station. If setting a time- out, enter the time limit after which paging calls to the station are automatically (N-8400RS only) terminated.
  • Page 466 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Sub-station Settings 5.6.3. Sub-station Settings Step 1. Click "Sub-station Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Common settings Set common functions of all substations to be connected to the substation interface unit. Call master: Enter the master station number to be called when each station's "Call 1,"...
  • Page 467 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Sub-station Interface: Sub-station Settings Priority call (Selective response mode only): Set the priority level from 1 to 5 to be assigned to each station’s "Call 1," "Call 2," or "Call 3" button. Priority level 1 is the lowest, and Priority level 5 is the same as the priority for the Emergency call button.

  • Page 468: Setting Ip Stations

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Network Settings 5.7. Setting Ip Stations Click "IP Station" tab to select the IP station to be set. Choose the name or number of the IP station from the list. 5.7.1. Network settings Step 1.
  • Page 469 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 470 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Network Settings (6) Network ID When connecting a PC to the IP station using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 471 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the IP station is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 472 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 1 5.7.2. Function settings Step 1. Click "Function Settings 1" tab to display the following setting screen. Available item differs depending on the type of IP stations. Step 2. Set individual items. (1) Transfer settings (Ip Master station and Ip Remote microphone station only) Set the transfer function ON or OFF.
  • Page 473 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 1 (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station. If setting a time-out, enter the time limit after which calls to the station are automatically terminated.
  • Page 474 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 1 (9) Calling station indication Select either "During call and talk" or "During talk" mode when performing the calling station indication function. The table below shows the timing that the Multi interface unit’s, Direct select unit’s, or Audio interface unit’s contact output is closed.
  • Page 475 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 2 Step 3. Click "Function Settings 2" tab to display the following setting screen. Available item differs depending on the type of IP stations. Step 4. Set individual items. (1) Incoming call mode Call receiving mode 2-10) can be selected either "Automatic connection"...
  • Page 476 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 2 (5) priority call (Selective response mode, Ip door station only) Call priorities can be adjusted in five increments from 1 (minimum) to 5 (maximum). Level 5 is the same priority as an emergency call. The default sensitivity is Level 1.
  • Page 477 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Function Settings 2 (12) Audio Trigger (N-8640DS/8650DS only) Performs the audio trigger settings for the station. Access to audio trigger: Set whether or not to use the audio trigger function. (13) Mode (N-8640DS/8650DS only) Selects operation when audio is detected.
  • Page 478 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Speed Dialing 5.7.3. Speed dialing settings Step 1. Click "Speed Dialing" tab to display the following setting screen. Available item differs depending on the type of stations. Step 2. Enter the station numbers to be called for each of the one-touch dial keys ([7], [8], [9] and [0] keys) and the Off-Hook function*.
  • Page 479 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Scan Monitor 5.7.4. Scan Monitor settings (Ip Master station and Ip Remote microphone station only) Step 1. Click "Scan monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.
  • Page 480 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Message Paging 5.7.5. Message paging settings (Ip Master station and Ip Remote microphone station only) Step 1. Click "Message Paging" tab to display the following setting screen. Step 2. Mark the [Operate message paging] checkbox. This allows the following items to be set. Step 3.
  • Page 481 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Message Paging Step 8. Perform settings for [Contact sync control]. Set the Multi Interface unit's, Direct Select unit's, or Audio Interface unit's unit number and the contact output number that is closed in synchronization with the start of the message paging. Make during activation: The contact is closed when the message paging is started, and opens when the broadcast ends.
  • Page 482 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Remote Mic Settings 5.7.6. Remote microphone setting (N-8600MS and Ip Remote microphone station only) Step 1. Click "Remote Mic Settings" tab. The setting screen below is displayed. Step 2. Perform Talk key setting. 2-1.
  • Page 483 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Remote Mic Settings Step 4. Perform priority setting.(N-8600MS and N-8610RM) Select one of 2 settings in the table below when making simultaneous paging/zone broadcasts. Options Settings N-8000 Paging with call tone, delay time, and time-out set in the Function setting (see 5-63) SX-2000 Chime tone,delay time, and time-out set in the Remote microphone setting (see...
  • Page 484 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Remote Mic Settings [Setting the details of the function] (1) Paging (N-8000)/Zone (SX) Broadcast destinations can be selected either from zones of the SX-2000 system or those of the N-8000 system. Multiple zones can be set. If the SX-2000 system zone is set, a control output pattern can also be programmed.
  • Page 485 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Remote Mic Settings (2) Tenkey The following keys can be selected. Paging call, Paging response, Hold, Transfer, Function, Redial, 1, 2, 3, 4, 5, 6, 7, 8, 9, , 0, #, and C (3) Function The following functions can be selected.
  • Page 486 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Remote Mic Settings (6) Control output (SX) Control output destination can be selected from the control output patterns. Clicking the [Add] button displays the pattern selection dialog. Select the ID of SX-2000 from the pull-down menu, then enter pattern number assigned to the control input. The ID of SX-2000 is the one of the SX-2000 system having been set to the SX-200IP Smart matrix IP module in the Gateway setting 5-28).
  • Page 487 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Pattern 5.7.7. pattern setting (N-8600MS and Ip Remote microphone only) Each pattern of the "Zone," "Control" and "Dial" can be registered. Step 1. Click "Pattern" tab. The setting screen is displayed. Step 2. Select the Pattern type. It can be selected from "Zone,"...
  • Page 488 SYSTEM SETTINGS BY SOFTWARE Chapter 5 IP Station: Pattern • When setting the new zone pattern (N-8000) When "User setting" is selected, the N-8000 System's zone patterns can be set. In this event, regard the [AO1] - [AO32] as the N-8000 System's zones, and read them as follows. 1 of [AO1] Zone 1 2 of [AO1]...

  • Page 489: Setting Stations Connected To The Exchange, And Analog Master Stations Connected To The Substation Interface Unit

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Function Settings 5.8. Setting Stations Connected to the Exchange, and Analog Master Stations Connected to the Substation Interface Unit Click "Station" to select the station to be set. Choose the number of the exchange, exchange name, line number, station number or station name from the list.
  • Page 490 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Function Settings Step 2. Set individual items. (1) Incoming call mode Call receiving mode 2-10) can be selected either "Automatic Connection" or "Continuous Call". Call with a call tone or without a call tone can be set on both modes. The door station is fixed to "Automatic connection"...
  • Page 491 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Function Settings (8) Calling station indication/CCTV control Control output : Set the Multi interface unit's, Direct select unit's, or Audio interface unit’s unit number and contact output terminal number, which provide a make signal when the station is called.
  • Page 492 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Function Settings (13) Trigger (Door station only) Selects the trigger. Level: Detects sounds of a sound pressure level higher than the set level that last for a specified period of time. Audio: Detects human voices. Duration (Level): Set the time interval till sounds are detected.
  • Page 493 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Speed Dialing 5.8.2. Speed dialing settings Step 1. Click "Speed Dialing" tab to display the following setting screen. Available item differs depending on the type of stations. Step 2. Enter the station numbers to be called for each of the one-touch dial keys ([7], [8], [9] and [0] keys) and the Off-Hook function.
  • Page 494 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Station: Scan Monitor 5.8.3. Scan monitor settings Step 1. Click "Scan monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.

  • Page 495: Setting C/O Interface

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Network Settings 5.9. Setting C/O Interface Click "C/O Interface" tab to select the C/O Interface to be set. Choose the number of the C/O interface unit or name from the list. 5.9.1. Network settings Step 1.
  • Page 496 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 497 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Network Settings (6) Network ID When connecting a PC to the C/O interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 498 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Function Settings 1 (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the C/O interface unit is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 499 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Function Settings 1 Step 2. Set individual items. (1) Calling station indication/CCTV control Control output : Set the Multi interface unit's, Direct select unit's, or Audio interface unit’s unit number and contact output terminal number, which provide a make signal when the station is called.
  • Page 500 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Function Settings 2 Step 1. Click "Function Settings 2" tab to display the following setting screen. Step 2. Set individual items. (1) C/O Setting Name: Set the name of the C/O line. (2) Timeout Timeout: Set the time interval for automatic termination of conversations ( 1 –...
  • Page 501 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Function Settings 2 Member: Up to 3 member stations can be simultaneously called up when the representative station receives a call. Note If the representative station has not been set, calls are not made to the member stations. (5) paging with call tone Sounds a pre-announcement tone when paging is initiated.
  • Page 502 SYSTEM SETTINGS BY SOFTWARE Chapter 5 C/O Interface: Scan Monitor 5.9.3. Scan monitor settings Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.

  • Page 503: Setting Telephone Interface

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Network Settings 5.10. Setting Telephone Interface Click "Telephone Interface" tab to select the Telephone Interface to be set. Choose the number of the Telephone Interface unit or name from the list. 5.10.1. Network settings Step 1.
  • Page 504 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 505 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Network Settings (6) Network ID When connecting a PC to the Telephone interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 506 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Telephone interface unit is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 507 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Function Settings 1 5.10.2. Function settings Step 1. Click "Function Settings 1" tab to display the following setting screen. Step 2. Set individual items. (1) Transfer settings Set the transfer function ON or OFF for the station connected to the exchange. Call forwarding: Calls to stations are automatically transferred to another designated station without sounding a call tone only when Call forwarding function is enabled.
  • Page 508 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Function Settings 1 (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station. If setting a time-out, enter the time limit after which calls to the station are automatically terminated.
  • Page 509 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Function Settings 2 Step 1. Click "Function Settings 2" tab to display the following setting screen. Step 2. Set individual items. (1) level Microphone sensitivity: Station hands-free microphone sensitivity can be adjusted in three increments from 1 (minimum) to 3 (maximum).
  • Page 510 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Function Settings 2 (4) Door remote Set the Multi interface unit's, Direct select unit's, or Audio interface unit’s unit number and contact output terminal number to be used for door remote control. (5) Calling station indication/CCTV control Control output : Set the Multi interface unit's, Direct select unit's, or Audio interface unit’s unit number...
  • Page 511 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Telephone Interface: Scan Monitor 5.10.3. Scan Monitor settings Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.

  • Page 512: Setting Audio Interface

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Network Settings 5.11. Setting Audio Interface Click "Audio Interface" tab to select the Audio Interface to be set. Choose the number of the Audio interface unit or name from the list. 5.11.1. Network settings Step 1.
  • Page 513 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 514 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Network Settings (6) Network ID When connecting a PC to the Audio interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
  • Page 515 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Audio interface unit is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
  • Page 516 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Function Settings 5.11.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily. The setting range is from 1 to 9 (in 1-second units).
  • Page 517 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Function Settings (3) paging Set the operation mode of the audio interface unit. Delay Time: Set the delay time before paging is initiated. Aux input paging priority: Allows external input broadcasts to take precedence over all-zone paging and individual zone paging.
  • Page 518 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Function Settings (2) External timer Perform settings for broadcasting time signals enabled by a make signal from external equipment connected to the contact input of the audio interface unit. Contact Input: The Audio interface unit’s contact input terminal number. (Can’t be edited.) Enable: Enables the external timer function of the selected contact input.
  • Page 519 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Function Settings (3) Day Set the day that the event takes place. Note: Multiple events cannot be simultaneously registered for the same time of the same day. Step 3-2. Set the Weekly schedule. (1) Weekly schedule Shows a list of events registered on a day/time basis.
  • Page 520 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Audio Interface: Contact Output 5.11.3. Contact output setting Step 1. Click "Contact Output" tab to display the following setting screen. Step 2. Set each item of "Contact output." Set the access number for the contact output terminal to be activated when the station performs external equipment control (one-shot make output or make/break output).

  • Page 521: Setting Direct Select

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Network Settings 5.12. Setting Direct Select Click "Direct Select" tab to select the Direct Select to be set. Choose the number of the Direct select unit or name from the list. 5.12.1. Network settings Step 1.
  • Page 522 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 523 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Network Settings (8) WAN port No. Set the start port number to be used for each protocol as viewed from the WAN side. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 524 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Function Settings 5.12.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set the following item. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily. The setting range is from 1 to 9 (in 1-second units).
  • Page 525 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Contact Input 5.12.3. Contact input setting Step 1. Click "Contact Input" tab to display the following setting screen. Step 2. Set each item of "Contact input." (1) Contact input No. (Can't be edited.) The Direct select unit's contact input terminal number.
  • Page 526 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Contact Input Remote dial control: When the Multi interface unit's or Direct select unit's contact input terminal is closed, a station is made to automatically perform dial operation. A set of up to 20 dial codes (including dial numbers and key operations) can be assigned to each contact input terminal.
  • Page 527 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Direct Select: Contact Output 5.12.4. Contact output setting Step 1. Click "Contact Output" tab to display the following setting screen. Step 2. Set each item of "Contact output." Set the access number for the contact output terminal to be activated when the station performs external equipment control (one-shot make output or make/break output).

  • Page 528: Setting Gateway

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Gateway: Network Settings 5.13. Setting Gateway Click "Gateway" tab to select the IP module to be set. Choose the name or number of the IP module from the list. 5.13.1. Network settings Step 1. Click "Network Settings" tab to display the following setting screen. Step 2.
  • Page 529 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Gateway: Network Settings (4) port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
  • Page 530 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Gateway: Network Settings (6) Network ID When connecting a PC to the exchange using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...

  • Page 531: Paging Zone Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Paging Zone Settings 5.14. paging Zone Settings Step 1. Click "Paging" to display the following setting screen. Step 2. Select the paging number digit. Select the number for [Paging No. digit]. Zones are automatically indicated depending on which number is set. The maximum number of zones is 192.
  • Page 532 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Paging Zone Settings Step 5. Select stations, external PA paging outputs, and N-8000MI/8000AF's contact outputs included in each zone. Pressing the down arrow button of the paging zone to be set displays individual buttons containing output destination information (station, PA paging output, or N-8000MI/8000AF's contact output).

  • Page 533: Group Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 Group: Group Blocking Group 5.15. Group Settings Step 1. Click "Group" to set either Group Blocking or Remote Response group. 5.15.1. Group blocking settings Stations can be divided into groups, to each of which call-to-other groups setting and paging zone setting can be assigned.
  • Page 534 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Group: Group Blocking To [Group blocking group settings] Step 1. Click "Group blocking to" tab to display the following screen. Step 2. Tick the cell for the group to be selected to "Group blocking group" and "Paging." Press the right arrow button of "Restricted Station Calling Group"...
  • Page 535 SYSTEM SETTINGS BY SOFTWARE Chapter 5 Group: Remote Response Group 5.15.2. Remote response group settings Setting the remote response station group permits any station programmed for this function to respond to calls to other stations within the group. Up to 16 stations can be preset. Also, this function is only possible when the system is set to sequential response mode.

  • Page 536: When Settings Are Completed

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 6. WHEN SETTINGS ARE COMplETED 6.1. Saving Setting Contents to Files Save the setting contents to a specified location (refer to 5-12). Select [File Save] from the menu bar. 6.2. Uploading Settings Uploads setting contents currently being edited. Before uploading, be sure to save the settings contents to file as described above.

  • Page 537: Printing Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 6.4. printing Settings The settings in edit can be printed. Select [File Print] from the menu bar. The set data of the equipment registered in the system can be printed. [print example] 5-127...

  • Page 538: System Clock Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 7. SYSTEM ClOCk SETTINGS The N-8000 Setting Software program allows the clocks for all exchanges, various kinds of interface units, and IP stations connected to the system to be set. To set exchange clocks individually (for example, if there is a time difference between exchanges), use either the browser (refer to 6-42), the N-8000MS Multifunctional Master station, or the N-8500MS/8600MS IP Multifunctional Master station (refer to...

  • Page 539: Message Paging Settings

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 8. MESSAGE pAGING SETTINGS Create and set the messages to be used in the IP Master station’s and IP Remote microphone station’s message paging. 8.1. Display the Setting Screen Clicking [Message Paging Settings] on the initial screen displays the Message Paging Setting screen. [Initial screen] [Message paging Setting screen] (1) list of Original Messages...

  • Page 540: Menu

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.2. Menu 8.2.1. File New: Creates a new message. Save: Saves the message. Save As: Assigns a name to the message and saves it. Delete: Deletes the message. Rename File: Changes the name of the message. Read WAVE File: Creates original messages by converting WAV-format files to the original format.

  • Page 541: Create And Test-Listen To The Original Messages

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.3. Create and Test-listen to the Original Messages Click the [List of Original Messages] tab on the message paging setting screen. The list of original messages that have been created is displayed. (10) [Screen description] (1) Recording/playback progress indicator Pressing the Save button after moving the knob Progress bar indicates the progress of the...
  • Page 542 SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.3.1. Creating new messages Connect the input source (microphone, external playback device, etc.) to be recorded to the PC. The recording sound volume corresponds to the input sound volume set in the PC. Set the PC sound volume to an appropriate level.
  • Page 543 SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.3.4. Creating messages from WAV-format files WAV-format file can be converted to original format files and saved as original messages. Note The compatible WAV-format file specifications are: • 16 bits and 16 kHz sampling frequency •...
  • Page 544 SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.3.6. Test-listening to messages Step 1. Select the message to listen to from the list of created messages. Step 2. Press the Playback button or select [Edit Playback] from the menu bar. The message automatically stops after being played to its end.

  • Page 545: Registering Messages In The Ip Master Station And Ip Remote Microphone Station

    SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.4. Registering Messages in the Ip Master Station and Ip Remote Microphone Station Click the [Message Registration] tab on the message paging settings screen. [Screen description] (1) Siren tone selection (6) Clear all button The currently selected siren tone is displayed Clears all selection of stations.
  • Page 546 SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.4.1. Test-listening to a siren tone Step 1. Select the desired siren tone from the pull-down menu. Step 2. Press the Test-listen button. The selected siren tone plays and automatically stops upon reaching its end. The test siren tone is played back on the PC together with the announcement "This is a sample."...
  • Page 547 SYSTEM SETTINGS BY SOFTWARE Chapter 5 8.4.4. Registering messages from the pC to the Ip Master stations and Ip Remote microphone stations Step 1. Designate the message to be transferred to the IP Master stations or IP Remote microphone stations. The message to be transferred can be selected by dragging and dropping them from the messages list to the stations list.

  • Page 548: Chapter 6 : System Settings Using The Browser

    Chapter 6 SYSTEM SETTINGS USING THE BROWSER This chapter describes browser network settings, and system maintenance functions.

  • Page 549: Outline Of Settings Using Browser

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 1. OUTlINE Of SETTINGS USING BROWSER Network settings can be updated and maintenance functions controlled by connecting to all exchanges, various kinds of interface units and IP stations in the system via the PC's browser*. If an exchange, interface unit or IP station is not within range for the PC to administrate broadcast communications, use another PC to enable communications with all exchanges, various kinds of interface units and IP stations in the system.

  • Page 550: Displaying The Menu Screen

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 3. DISplaYING THE MENU SCREEN Note Perform the PC's network setting in advance to allow the PC to communicate with all exchanges, various kinds of interface units and IP stations in the system. The user authentication screen will not be displayed unless the PC's network setting completed.
  • Page 551 SYSTEM SETTINGS USING THE BROWSER Chapter 6 The setting menu screen is displayed once you have entered the correct user name and the password. The screen below is an example for the N-8000EX. Note Use the menu located on the left of the screen to display each setting screen. These screens will not be displayed properly using the browser's "Back"...

  • Page 552: Network Setting

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 4. NETWORk SETTING Click "Network Setting" on the menu on the left of the screen. The screen below is an example for the N-8000EX. (1) Ip address Enter the IP address of the exchange, interface unit or IP station. (factory-preset: 192.168.1.1) (2) Subnet Mask Set the subnet mask.

  • Page 553: Operation Status Display

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 (6) Save button Write set data into the settings file in the equipment. Notes • The status indicator located on the equipment remains lit during the write process. Do not switch off or restart the power or remove the LAN cable while the light is on. • Changed network settings are not immediately updated, and the new settings take effect only after the exchange, interface unit or IP station has been restarted. Restart the exchange, interface unit or IP station by pressing the restart button that appears at the upper right of the screen whenever settings have been changed.
  • Page 554 SYSTEM SETTINGS USING THE BROWSER Chapter 6 [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response." (2) line No.

  • Page 555: N-8000Rs/8010Rs

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.2. N-8000RS/8010RS The screen below is an example for the N-8000RS. Note Only 1 link is displayed in the N-8010RS. [Operation buttons] (1) Refresh Updates status data for speech path and line. (2) line No. and Terminal No. buttons Used to display line numbers or station numbers for each station.

  • Page 556: N-8400Rs

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 (2) Calling Station Displays the number of the calling station. (3) Called Station Displays the number of the called station. (4) Station on hold Displays the number of the station on hold. (5) Status Displays the operating status of the speech path.
  • Page 557 SYSTEM SETTINGS USING THE BROWSER Chapter 6 [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response." (2) Terminal No.

  • Page 558: N-8000Mi

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.4. N-8000MI [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and line No. buttons Used to display line numbers or station numbers for each station. [link status] Displays the Multi interface unit's current link status.
  • Page 559 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (4) Station on hold Displays the number of the station on hold. (5) Status Displays the operating status of the speech path. [Contact] Displays the Multi interface unit's current contact status. Pressing the Refresh button updates data. (1) Contact No.

  • Page 560: N-8000Di

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.5. N-8000DI [Operation buttons] (1) Refresh Updates status data for contact. [Contact] Displays the Direct select unit’s current contact status. Pressing the Refresh button updates data. (1) Contact No. Direct select unit’s contact input and output terminal numbers. (2) Input Current status of the contact input terminal is displayed.

  • Page 561: N-8000Af

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.6. N-8000af [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and line No. buttons Used to display line numbers or station numbers for each station. [link status] Displays the Audio interface unit’s current link status. Pressing the Update button updates this data.

  • Page 562: N-8000Co

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 (4) Status Displays the operating status of the speech path. [Contact] Displays the Audio interface unit’s current contact status. Pressing the Refresh button updates data. (1) Contact No. Audio interface unit’s contact input and output terminal numbers. (2) Input Current status of the contact input terminal is displayed. Indicator abbreviations are as follows: ON: Make, OFF: Break (3) Output Current status of the contact output terminal is displayed.
  • Page 563 SYSTEM SETTINGS USING THE BROWSER Chapter 6 [Operation buttons] (1) Refresh Updates status data for speech path and line. (2) Terminal No. and line No. buttons Used to display line numbers or station numbers for each station. [link status] Displays the C/O interface unit’s current link status. Pressing the Refresh button updates this data. (1) Calling Station Displays the number of the calling station.

  • Page 564: N-8000Al

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.8. N-8000al Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
  • Page 565 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) automatic transfer Displays the station number to which calls to the Telephone interface unit are to be automatically transferred. (6) level Displays sound volume set for the Telephone interface unit’s.

  • Page 566: N-8500Ms/8510Ms

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.9. N-8500MS/8510MS The screen below is an example for the N-8500MS. Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
  • Page 567 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Call receiving Displays the call tone mode of the IP master station. (6) automatic transfer Displays the station number to which calls to the IP master station are to be automatically transferred.

  • Page 568: N-8600Ms

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.10. N-8600MS Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
  • Page 569 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Call receiving Displays the call tone mode of the IP master station. (6) automatic transfer Displays the station number to which calls to the IP master station are to be automatically transferred.

  • Page 570: N-8540Ds

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.11. N-8540DS [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and line No. buttons Used to display line number or station number. [Operation status] Displays the IP door station's current status of speech path and line. Pressing the Refresh button updates data. (1) Calling Station Displays the number of the calling station.

  • Page 571: N-8640Ds/8650Ds

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 5.12. N-8640DS/8650DS The screen below is an example for the N-8640DS. [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and line No. buttons Used to display line number or station number. [Operation status] Displays the IP door station's current status of speech path and line.
  • Page 572 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) level Displays sound volume set for the IP door station. Indicator abbreviations are as follows: MIC: Microphone sensitivity Speaker output volume...

  • Page 573: Line Status Indication (Only For Exchange And Sub-Station Interface Unit)

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 6. lINE STaTUS INDICaTION (ONlY fOR EXCHaNGE aND SUB-STaTION INTERfaCE UNIT) 6.1. N-8000EX/8010EX Click "Line Status" on the menu on the left side of the screen. Displays information on line status and connected stations. The screen below is an example for the N-8000EX.
  • Page 574 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (3) Status Displays line status. (4) Call receiving Displays the call tone mode of the connected station. (5) automatic transfer Displays the station number to which calls to the connected station are to be automatically transferred. (6) level Displays sound volume set for the connected station.

  • Page 575: N-8000Rs/8010Rs

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 6.2. N-8000RS/8010RS Click "Line Status" on the menu on the left side of the screen. Displays information on line status and set stations. The screen below is an example for the N-8000RS. [Operation buttons] (1) Refresh Updates status data for line and set station to the latest data.

  • Page 576: N-8400Rs

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 (4) level Displays sound volume set for the Sub station interface unit. Indicator abbreviations are as follows: MIC: Microphone sensitivity Speaker output volume Signal: Call tone volume 6.3. N-8400RS Click "Line Status" on the menu on the left side of the screen. Displays information on line status and connected stations.
  • Page 577 SYSTEM SETTINGS USING THE BROWSER Chapter 6 [line Status] Displays the setting contents of all the stations connected to the N-8400RS. The symbols "–" displayed in a row indicate that no connection is made to the line. (1) No. Line numbers (2) Model No.

  • Page 578: Network Status Indication

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 7. NETWORk STaTUS INDICaTION Click "Network Status" on the menu on the left side of the screen. Connections between all exchanges, various kinds of interface units and IP stations and networks within the system can be confirmed.

  • Page 579: Operation Log

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 [Network status setting] (1) No. Equipment number of the exchange, various kinds of interface units or IP station. (2) Ip address IP address of the exchange, various kinds of interface units or IP station. (3) Status "OK"...
  • Page 580 (4) line 1, line 2 and line 3 Indicates the line on which an event occurred. Station and IP address numbers are displayed. Note If the indication "Firmware failed. Please contact our sales office." is displayed, the system is suffering a problem and could fail. In such cases, please contact TOA immediately. 6-33...

  • Page 581: Stream Log

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 9. STREaM lOG Click "Stream Log" on the menu on the left side of the screen. The stream log is a history of voice communications (both conversations and paging) carried over the IP network.
  • Page 582 SYSTEM SETTINGS USING THE BROWSER Chapter 6 [past stream screen] The screen below is an example for the N-8000EX. [past stream operation buttons] (1) Refresh Displays the last sixteen finished streams. (2) prev. page button Returns the display to the previous page. (3) Next page button Advances the display to the next page. [log items] (common to current and past stream logs) (1) Time Time the stream began.
  • Page 583 SYSTEM SETTINGS USING THE BROWSER Chapter 6 (4) link Speech path number. (5) Direction Sending or receiving. (6) fs Sampling frequency, either 8 kHz or 16 kHz. (7) Delay Time between voice input and output. (8) packets Number of packets transmitted or successfully received. (9) loss Number of packets lost due to network failures, which is counted at the receiving end only.

  • Page 584: System Management

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 10. SYSTEM MaNaGEMENT Click "System Management" on the menu on the left side of the screen. The screen below is an example for the N-8000EX. [User Data] The system name and password can be changed (refer to 6-39). (1) System Name Displays the user name entered on the user authentication screen when the browser was started (refer to 6-3).
  • Page 585 Updates firmware (refer to 6-41). Use the latest version of firmware, which is released on the following our web site. Tips • Download the latest version of firmware from our site http://www.toa-products.com/international/. • The current version is displayed above the Firmware Update button. (6) Clock retrieve button Pressing this button displays the date and time of the connected PC's clock (refer to 6-42).

  • Page 586: Changing System Names And Passwords

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 10.1. Changing System Names and passwords When adding the exchange, interface unit or IP station, or initializing the exchange, interface unit or IP station settings, the system name and password can be changed remotely using the browser even from locations where the system settings PC is not available.

  • Page 587: Downloading Setting File

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 10.3. Downloading Setting file Step 1. Press "Download" button to display "File Download" dialog. Step 2. Press "Save" button to display the dialog. Step 3. Select saving location, then enter file name. The default name is [IP address] .cfg. Step 4.

  • Page 588: Updating Firmware

    Step 2. Select the firmware (extension bin), then press "Open" button. Use the latest version of firmware, which is released on the following our web site. Tips • D ownload the latest version of firmware from our products data site http://www.toa-products.com/international/. • The current firmware version can be confirmed on the browser's system management screen. Step 3. Press "Firmware update" button to start firmware updating. Note The status indicator located on the exchange, interface unit or IP station remains lit during update.

  • Page 589: Clock Settings

    SYSTEM SETTINGS USING THE BROWSER Chapter 6 10.5. Clock Settings If there is a time difference between the exchange, interface unit or IP station system connected to the system, each exchange's time can be adjusted individually. When the red indication "Clock not set." is displayed in the "Clock setting"...

  • Page 590: Chapter 7 : Multifunctional Station Menu Screen

    Chapter 7 MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) This chapter describes the settings and displays available using the menu screen of the Multi-Functional Station and IP Multi-Functional Station.

  • Page 591: Keys Used For Menu Screen Operation

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 1. KEyS USEd FOR MENU SCREEN OPERATION The following keys are used to operate the menu screen of the N-8000MS Multifunctional Master Station and the N-8500MS/8600MS IP Multifunctional Master Station. Liquid crystal display: Displays the menu screen. Selection key: Used for item selection and input value set.

  • Page 592: Menu Items

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 2. MENU ITEMS Programs the contents into the Auto Dial key. 1. Auto-dialing programming (refer to 2-11) Monitors the Line connection status of the Exchange. 2. Line monitor (refer to 7-4) Updates the operation log files of the Exchange or 3.

  • Page 593: Monitoring Line Status

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 3. MONITORINg LINE STATUS Causes the station's LCD to display the connection status for all sixteen lines associated with the exchange to which the N-8000MS is connected. The N-8500MS/8600MS does not have the monitoring function. Step 1.

  • Page 594: Updating Log Files

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 4. UPdATINg LOg FILES Update the file that stores the operation logs for the exchange or N-8500MS/8600MS*. Use this function when some malfunction has made it impossible to view the operation log via a PC (refer to 6-32, Browser Operation Log Display).

  • Page 595: Setting The Lcd Backlight (N-8600Ms Only)

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 6. SETTINg THE LCd BACKLIgHT (N-8600MS only) ON/OFF of the N-8600MS’s LCD backlight can be set. Step 1. Press the Menu key to place the display in setting 1 : A u t o - d i a l i n g mode.

  • Page 596: System Settings

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 7. SySTEM SETTINgS Only a portion of system setting items can be set at the Multifunctional Station. 7.1. Entering Maintenance Screen Step 1. Press the Menu key to place the display in setting 1 : A u t o - d i a l i n g mode.

  • Page 597: Network Settings

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 7.2. Network Settings It is possible to change the IP address, subnet mask, and default gateway of the exchange or N-8500MS/8600MS*. * Exchange when the station performing setting is N-8000MS, and the N-8500MS/8600MS itself when it is the N-8500MS/8600MS.

  • Page 598: Station Number Settings

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 7.3. Station Number Settings It is possible to set the station number for all stations and IP stations. Step 1. Using the up or down arrow keys or the [2] key on 1 : N e t w o r k s e t the maintenance screen, move the cursor to "2: Line 2 : L i n e A t t r i b u t e...

  • Page 599: System Clock Settings

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 Step 6. Enter the station number (00-999999) of the E X 0 2 4 : L I N E 0 1 designated line using the dial keys, then press the 8 0 0 0 M S 2 0 0 0 Select key.

  • Page 600: Restarting The Equipment

    MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) Chapter 7 7.5. Restarting the Equipment Restart the exchange or N-8500MS/8600MS* when network settings have been changed. The exchange can be restarted at the Multifunctional Station even without pressing "Reset" key located on the exchange's front panel.

  • Page 601: Chapter 8 : Appendix

    Chapter 8 APPENDIX...

  • Page 602: Full Duplex And Half Duplex Conversations

    APPENDIX Chapter 8 1. FULL DUPLEX AND HALF DUPLEX CONVERSATIONS 1.1. Speech Method The Packet Intercom system uses 5 types of methods for conversations between stations. For conditions in which these speech methods are used, refer to the table on 8-5.
  • Page 603 APPENDIX Chapter 8 1.1.4. Full duplex conversation using echo canceller and voice switch This is a speech method using the echo Total set value of the canceller (see the previous page) in microphone sensitivity combination with the voice switch. In and speaker output [When only the echo canceller works] this method, the echo canceller works...
  • Page 604 APPENDIX Chapter 8 1.1.5. Half duplex conversation by way of PTT operation When the PTT key is pressed, this permits one-way conversation from the key-operated station. Releasing the PTT key enables one- way conversation from the other party. When the PTT keys at both stations are pressed simultaneously, the last key-operated One-way conversation station takes precedence.

  • Page 605: A Difference Of Speech Method Depending On Usage Conditions Of The Station

    APPENDIX Chapter 8 1.2. A Difference of Speech Method Depending on Usage Conditions of the Station Packet Intercom system permits hands-free full duplex conversation. However, operations of an echo canceller or a voice switch could change depending on the stations to be used, conversation partner, or each station's usage condition (handset or hands-free conversation), resulting in half duplex conversation.

  • Page 606: What If You Failed To Make Conversation Properly

    APPENDIX Chapter 8 1.3. what If You Failed to Make Conversation Properly • If the voice switches of the master and door stations do not flip properly, adjust the microphone sensitivity and speaker output volume of the stations. (For the master station, refer to 2-5, 5-65 and 5-80, and for the...

  • Page 607: Network Address Port Translation (Napt, Ip Masquerade) And N-8000 Setting Software Program

    APPENDIX Chapter 8 2.2. Network Address Port Translation (NAPT, IP Masquerade) and N-8000 Setting Software Program Because the Internet cannot be accessed using the local IP address, the local IP address must be converted into global IP address by means of Network Address Port Translation (NAPT, IP Masquerade). Router 1 Router 2 Internet...

  • Page 608: Unicast Vs. Multicast Communications

    APPENDIX Chapter 8 2.3. Unicast vs. Multicast Communications When making paging calls via multiple exchanges, various kinds of interface units, or IP stations connected to a network, either "unicast" or "multicast" may be selected as the communication method. For unicast communications, separate data packets are created and sent individually to each destination IP address.

  • Page 609: Unit Scan And Broadcast Communications Domains

    APPENDIX Chapter 8 2.5. Unit Scan and Broadcast Communications Domains The broadcast communications method is utilized to detect equipment (exchange, any kind of interface unit, or IP station) connected to a network. Therefore, only equipment within the network's multicasting range will be detected.

  • Page 610: Ntp (Network Time Protocol)

    APPENDIX Chapter 8 2.7. NTP (Network Time Protocol) NTP is a networking protocol for distributing accurate current time information over a TCP/IP network. Normally it uses UDP port 123 to communicate between server and client. The N-8000AF set to the NTP Client receives the time information in communication with NTP Server and synchronizes the current time.

  • Page 611: If Trouble Occurs

    APPENDIX Chapter 8 3. IF TROUBLE OCCURS: Symptom Potential Cause/Place to Inspect Remedy The exchange or any Power and cables may not be Connect the power source and cables kind of interface unit connected correctly. properly. does not operate. All indicators located on the Make sure the power is turned on.
  • Page 612 The exchange generates Check to see if the exchange's front The exchange may be malfunctioning. excessive heat. panel-mounted Status indicator flashes Contact your nearest TOA sales office continuously. immediately. The system temporarily Check to see if the indication A problem has occurred and the stops operating but is "Firmware failed.
  • Page 613 The switching hub may not be turned Turn on the switching hub. not illuminate for IP station. Station does not operate. The cable may not be connected Connect the cable correctly. correctly. A password has been Contact your nearest TOA dealer. – forgotten. 8-13...

  • Page 614: Indicator Status & Troubleshooting

    Action to Take Normal operation or power – Rapid flashing* Failure of fan Contact your nearest TOA dealer. (in a cycle of 200 ms) Flashes three times in a row (in a Failure Contact your nearest TOA dealer. cycle of 200 ms) at one-second intervals.

  • Page 615: Specifications

    APPENDIX Chapter 8 5. SPECIFICATIONS 5.1. N-8000EX IP Intercom Exchange Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 50 W (at rated), 75 W (max.) Interface Section for Station Number of Lines 16 lines Number of Speech Links Internal: 1/External: 2...

  • Page 616: N-8010Ex Ip Intercom Exchange

    APPENDIX Chapter 8 5.2. N-8010EX IP Intercom Exchange Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 50 W (at rated), 75 W (max.) Interface Section for Station Number of Lines 16 lines Number of Speech Links Internal: 4/External: 8...

  • Page 617: N-8000Ms Multifunctional Master Station

    APPENDIX Chapter 8 5.3. N-8000MS Multifunctional Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 618: N-8010Ms Standard Master Station

    APPENDIX Chapter 8 5.4. N-8010MS Standard Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 619: N-8011Ms Standard Hands-Free Master Station

    APPENDIX Chapter 8 5.5. N-8011MS Standard Hands-Free Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 620: N-8020Ms Industrial-Use Master Station

    APPENDIX Chapter 8 5.6. N-8020MS Industrial-Use Master Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 621: N-8031Ms Flush-Mount Master Station

    APPENDIX Chapter 8 5.7. N-8031MS Flush-Mount Master Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 622: N-8033Ms Flush-Mount Master Station

    APPENDIX Chapter 8 5.9. N-8033MS Flush-Mount Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 623: N-8050Ds Door Station

    APPENDIX Chapter 8 5.10. N-8050DS Door Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...

  • Page 624: N-8500Ms Ip Multifunctional Master Station

    APPENDIX Chapter 8 5.11. N-8500MS IP Multifunctional Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free or handset conversation Audio Frequency Range 300 Hz –...

  • Page 625: N-8510Ms Ip Standard Master Station

    APPENDIX Chapter 8 5.12. N-8510MS IP Standard Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free or handset conversation Audio Frequency Range 300 Hz –...

  • Page 626: N-8600Ms Ip Multifunctional Master Station

    APPENDIX Chapter 8 5.13. N-8600MS IP Multifunctional Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption Use of the AC adapter (12 V DC): 2.5 W (station only) Use of the PoE (48 V DC): 3 W Speech Method Hands-free or handset conversation...

  • Page 627: N-8610Rm Ip Microphone Station

    APPENDIX Chapter 8 5.14. N-8610RM IP Microphone Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (use of the optional AC adapter) Power Consumption Use of the AC adapter (12 V DC): 4 W (microphone only) 8.5 W (when connecting 4 RM-210, Extension units) Use of the PoE (48 V DC): 5.2 W (microphone only),...

  • Page 628: N-8540Ds Ip Door Station

    APPENDIX Chapter 8 5.15. N-8540DS IP Door Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free conversation Audio Frequency Range 300 Hz –...

  • Page 629: N-8640Ds Ip Door Station

    APPENDIX Chapter 8 5.16. N-8640DS IP Door Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption Use of the AC adapter (12 V DC): 3.5 W (station only) Use of the PoE (48 V DC): Speech Method Hands-free conversation...

  • Page 630: N-8650Ds Ip Door Station

    APPENDIX Chapter 8 5.17. N-8650DS IP Door Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption Use of the AC adapter (12 V DC): 3.5 W (station only) Use of the PoE (48 V DC): Speech Method Hands-free conversation...

  • Page 631: N-8000Rs Substation Interface Unit

    APPENDIX Chapter 8 5.18. N-8000RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 40 W (at rated), 50 W (max.) CU version: 35 W (at rated), 45 W (max.) Interface Section for Sub-station Number of Lines 16 lines...

  • Page 632: N-8010Rs Substation Interface Unit

    APPENDIX Chapter 8 5.19. N-8010RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 32 W (at rated), 38 W (max.) CU version: 26 W (at rated), 32 W (max.) Interface Section for Sub-station Number of Lines 16 lines...

  • Page 633: Rs-150 Indoor Substation

    APPENDIX Chapter 8 5.20. RS-150 Indoor Substation Rated Input Rated Impedance 625 Ω (1 W/25 V) Internal Speaker 4 cm cone-type Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24) 800 m/ø0.65 mm (AWG22) 1300 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch) Finish Panel:...

  • Page 634: Rs-170 Outdoor Vandal-Resistant Substation

    APPENDIX Chapter 8 5.22. RS-170 Outdoor Vandal-Resistant Substation Rated Input Rated Impedance 625 Ω (1 W/25 V) Internal Speaker 4 cm cone-type Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24) 800 m/ø0.65 mm (AWG22) 1300 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch) Finish...

  • Page 635: Rs-140 Switch Panel

    APPENDIX Chapter 8 5.24. RS-140 Switch Panel Call Button Momentary Privacy Button Latching Indicator When called: Status indicator (red) flashing In conversation: Status indicator (red) lit In privacy: Privacy indicator (red) lit Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24), 800 m/ø0.65 mm (AWG22), 1300 m/ø0.9 mm (AWG19) Operating Temperature 0 to 40°C...

  • Page 636: Rs-142 Switch Board

    APPENDIX Chapter 8 5.26. RS-142 Switch Board Call Button Wiring 4 cables (for 2 momentary switches) Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24), 800 m/ø0.65 mm (AWG22), 1300 m/ø0.9 mm (AWG19) Operating Temperature 0 to 40°C Weight 30 g Note: The design and specifications are subject to change without notice for improvement.

  • Page 637: N-8400Rs Substation Interface Unit

    APPENDIX Chapter 8 5.29. N-8400RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 30 W (at rated), 45 W (max.) CU version: 35 W (at rated), 50 W (max.) Interface Section for Sub-station Number of Lines 16 lines...

  • Page 638: N-8410Ms Analog Standard Master Station

    APPENDIX Chapter 8 5.30. N-8410MS Analog Standard Master Station Power Source 24 V DC (supplied from the sub station interface unit N-8400RS) Current Consumption Max. 30 mA Wiring Method 2 set of twisted pair cable Transmission System 4 wire baseband transmission system Signal Level 25 dB* (up), 0 dB* or less (down) Speech Method...

  • Page 639: Rs-450 Indoor Substation

    APPENDIX Chapter 8 5.31. RS-450 Indoor Substation Call Button Momentary (Emergency call: Press twice within 400 ms.) Rated Input Internal Speaker Cone-type Internal Microphone Electret condenser type Wiring Twisted pair cables (2-pair) Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22), 2000 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)

  • Page 640: Rs-470 Outdoor Vandal-Resistant Substation

    APPENDIX Chapter 8 5.33. RS-470 Outdoor Vandal-Resistant Substation Call Button Momentary (Emergency call: Press twice within 400 ms.) Rated Input Internal Speaker Cone-type Internal Microphone Electret condenser type Wiring Twisted pair cables (2-pair) Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22), 2000 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)

  • Page 641: Rs-442 Switch Board

    APPENDIX Chapter 8 5.35. RS-442 Switch Board Call Button Wiring 6 cables (for 3 momentary switches) Rated Input Control Output Open collector, Maximum controlled voltage: 30 V DC Control current: 30 mA Microphone Electret condenser microphone Wiring Twisted pair cables (2 pairs) Transmission Range 1 km/ø0.5 mm (AWG24) 1.5 km/ø0.65 mm (AWG22)

  • Page 642: N-8000Mi Multi Interface Unit

    APPENDIX Chapter 8 5.37. N-8000MI Multi Interface Unit Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 19 W (180 mA) (at rated), 24 W (230 mA) (max.) CU version: 16 W (250 mA) (at rated), 21 W (330 mA) (max.) Audio Input Input: 2 inputs (2P/input), Max.

  • Page 643: N-8000Co C/O Interface Unit

    APPENDIX Chapter 8 • Accessories AC power cord (2 m) ..........1 Machine screw M4 x 20 ......... 4 CD (for PC setting, maintenance use) ....1 Rack mounting bracket .......... 2 Removable terminal plug (9 pins) ......4 Tapping screw 3 x 8 ..........8 Removable terminal plug (8 pins) ......

  • Page 644: N-8000Af Audio Interface Unit

    APPENDIX Chapter 8 5.39. N-8000AF Audio Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 7 W (max.) Audio Input 1 input (transformer isolated), –58 to 0 dB*, 2 kΩ, balanced (MIC/LINE input, controllable on the software) with input volume control knob, removable terminal block (3 pins) Audio Output...

  • Page 645: N-8000Al Telephone Interface Unit

    APPENDIX Chapter 8 5.40. N-8000AL Telephone Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 8W (max.) Telephone Interface Number of Telephone Lines 1 line Selective Signal Type DTMF signal Monitoring Function Line Loop detection...

  • Page 646: N-8000Di Direct Select Unit

    APPENDIX Chapter 8 5.41. N-8000DI Direct Select Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 16 W (max.) Contact Input 32 inputs, no-voltage make contact input, open voltage: 24 V DC, short-circuit current: 5 mA or less, removable terminal block (20 pins) (1 common terminal for 4 inputs) Contact Output...

  • Page 647: Yc-280 Wall Mounting Bracket

    APPENDIX Chapter 8 5.43. YC-280 wall Mounting Bracket Finish Surface-treated steel plate, gray, paint Dimensions 100 (w) x 140 (h) x 31.8 (d) mm Weight 120 g Note: The design and specifications are subject to change without notice for improvement. •...

  • Page 648: Yc-241 Back Box

    APPENDIX Chapter 8 5.46. YC-241 Back Box Finish Colored chrome plating Dimensions 119 (w) x 276 (h) x 67 (d) mm Weight 100 g Note: The design and specifications are subject to change without notice for improvement. • Applicable model N-8031MS 5.47.

  • Page 649: Yc-302 2-Gang Electrical Box

    APPENDIX Chapter 8 5.50. YC-302 2-gang Electrical Box Quantity Packed per 10 pieces Display Carton Finish SPHT, MFZn4 (glazed chromate) Dimensions Outlet box: 102 (w) x 102 (h) x 44 (d) mm Cover: 106 (w) x 106 (h) x 13 (d) mm Weight 370 g Note: The design and specifications are subject to change without notice for improvement.

  • Page 650: Yc-823 Outdoor Wall-Mount Box

    APPENDIX Chapter 8 5.54. YC-823 Outdoor wall-Mount Box Finish Stainless steel plate, off-white Dimensions 124 (w) x 124 (h) x 62 (d) mm Weight 440 g Note: The design and specifications are subject to change without notice for improvement. • Accessories Wood screw 3.5 x 20 ..........

  • Page 651: Ad-1210P Ac Adapter

    APPENDIX Chapter 8 5.57. AD-1210P AC Adapter Model number AD-1210P CU AD-1210P CE Power Source 100 – 240 V AC, 50/60 Hz 230 V AC, 50 Hz Output 12 V DC, 1 A Current Consumption 270 mA (rated output) 120 mA (rated output) Cord Length 1.5 m 1.8 m...
  • Page 652 201408...
