OPERATING INSTRUCTIONS
Rev. 1.00
N-8000 SIP GATEWAY
Thank you for purchasing TOA's N-8000 SIP Gateway.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N-8000 and is the answer not in the manual?

Questions and answers

Related Manuals for Toa N-8000

Summary of Contents for Toa N-8000

  • Page 1 OPERATING INSTRUCTIONS Rev. 1.00 N-8000 SIP GATEWAY Thank you for purchasing TOA’s N-8000 SIP Gateway. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

  • Page 2: Table Of Contents

    3.1.5. Control functions ................2-6 Chapter 3 Settings 1. SETTINGS ......................3-2 1.1. Setting image for N-8000 side and SIP telephone side, and a main of SIP Gateway ................. 3-2 1.2. Setting of N-8000 system ................3-2 1.3. Preparation for .................

  • Page 3: General Description

    Chapter 1 General Description...

  • Page 4: System Image

    General Description Chapter 1 1. GENERAL DESCRIPTION This manual is described for N-8000 SIP Gateway that has interconnecting functions between N-8000 and SIP system. 2. SYSTEM IMAGE 3. BASIC FUNCTIONS N-8000 SIP Gateway has new functions by software working on Windows7 Professional 32/64bits, as below.

  • Page 5: Setting Structure

    General Description Chapter 1 4. SETTING STRUCTURE There are 2 software settings to create a system, and another setting is needed for the other system which is SIP system. Note indicates settings which are explained in Section3 and 4. Operating Instructions...

  • Page 6: Chapter 2 Functions

    Chapter 2 Functions...

  • Page 7: Conditions Of Sip Gateway

    Functions Chapter 2 1. CONDITIONS OF SIP GATEWAY N-8000 SIP Gateway is tested with a SIP server of Cisco Systems, Asterisk, FreeSwitch, and Sipelia of Genetec Security Center. 2. SIP GATEWAY STRUCTURE A SIP Gateway consists of 5 virtual master stations with one virtual N-8000EX, 5 virtual SIP clients, and audio processing functions.

  • Page 8: Sip Gateway Functions

    N-8000 station is connected to SIP telephone via N-8000 virtual station in a SIP Gateway. SIP telephone is connected to N-8000 station via virtual SIP Client station in a SIP Gateway. SIP telephone makes a station paging to N-8000 system with additional dials.

  • Page 9: Call From N-8000 To Sip

    By an example, its function is explained below. [System example] [Setting concept] When N-8000 calls 801, virtual SIP client 1 has a setting to call to 2001. Automatically transfer to 2001. When N-8000MS(102) calls 805, virtual SIP client 5 has a setting to call to 2005, within a selected time (0 to 5 seconds), N-8600MS dials 2004, then talk.

  • Page 10: Call From Sip To N-8000

    [Setting concept] When SIP telephone calls 3995, virtual N-8000MS 1 has a setting of calling 101. SIP telephone and N-8000 101 starts to talk. When SIP telephone calls 3999, virtual N-8000MS 5 has a setting of calling 202, Within a selected time (0 to 5 seconds), SIP telephone dials 103, then talk.

  • Page 11: Paging Function

    Functions Chapter 2 3.1.4. Paging function Paging from SIP telephone to N-8000 system. 3.1.5. Control functions Door remote control from SIP telephone for Door stations. Operating Instructions...

  • Page 12: Settings

    Chapter 3 Settings...

  • Page 13: Setting Image For N-8000 Side And Sip Telephone Side, And A Main Of Sip Gateway

    1. SETTINGS 1.1. Setting image for N-8000 side and SIP telephone side, and a main of SIP Gateway There are 3 steps of setting which are setting of N-8000 system, setting of SIP system, and setting of SIP gateway. 1.2.

  • Page 14: Preparation For And

    Settings Chapter 3 1.3. Preparation for The following is a window of SIP Gateway. Settings are by a clicking File, there are menu of B: “SipClientSetting” and C: “SipGatewaySetting.” 1.4. Preparation for SIP Client setting Connecting to SIP system, the following info. is needed. Item Comment IP address of SIP Server...

  • Page 15: Sip Client Setting

    Settings Chapter 3 1.5. SIP Client Setting Here is for all about SIP system. Step 1. Setting for SIP Server. The port number with 5060 is a default of SIP protocol. Step 2. SIP virtual Client telephone number which is registered to SIP server. Step 3. A password for a SIP virtual Client for an authentication. Step 4.

  • Page 16: Sip Gateway Setting

    Step 6. Waiting time for specific dialing from N-8000 or SIP telephone. After this time, SIP Gateway connects automatically to a certain station which is set in 4 for calling from N-8000, or in 5 for calling from SIP telephone.

  • Page 17: Setting Example Of N-8000 Sip Gateway

    [System example] [Setting example] When N-8000 side calls 801, N-8000 SIP Gateway connects to 2001 and 3 speech paths are prepared for this function, and when N-8000 side calls 804, N-8000 SIP Gateway connects to 2005 and 2 speech paths are prepared for this function.
  • Page 18 N-8000 SIP gateway software is installed. Note: In the later step, equipment No. will be used. The next is setting for virtual N-8000MS. Line 1 to 5 are used for N-8000 SIP Gateway, 801 to 805 are set according to this example.
  • Page 19 Settings Chapter 3 This is for the function that calling to 801 in the N-8000 system has 3 speech paths that goes to 2001 in SIP system. The following example is a setting for 801 to add 802 in the box of “Group hunting to.”...
  • Page 20 A setting of SIP server is also needed. All SIP server has a different way for the setting, therefore the following is just basic setting contents. · 5 SIP clients for N-8000 SIP Gateway shall be prepared. Extension numbers shall be 3995 to 3999 for this example.

  • Page 21: Setting Of Sip Server

    Chapter 4 Setting of SIP server...

  • Page 22: Setting For Asterisk

    Setting of SIP server Chapter 4 1. SETTING OF SIP SERVER What N-8000 SIP Gateway requires are as below; · Extension number (telephone number) for SIP clients. · Corresponding password for each extension number. Additional setting like transferring function can be set by other settings.

  • Page 23: Setting For Freeswitch

    Setting of SIP server Chapter 4 1.2. Setting for FreeSwitch Files for a basic setting are with directory/default/****(Extension number).xml and dialplan/default.xml. Configuration idea with (Extension number).xml (Extension number and password can be set in this file.) Step 1. New user setting file is added. That file like 3995.xml can be created by copying 1000.xml.
  • Page 24 Setting of SIP server Chapter 4 Configuration idea for dialplan/default.xml (5 clients for N-8000 SIP Gateway is added, and busy transferring function is added.) e.x.) <extension name="N8000SIP1_Extension"> * For User1 (3995) <condition field="destination_number" expression="^(3995)$"> <action application="export" data="dialed_extension=$1"/> <action application="set" data="hangup_after_bridge=true"/>...

  • Page 25: Setting Of Cisco Call Manager

    Setting of SIP server Chapter 4 1.3. Setting of Cisco Call Manager 1.3.1. Registration procedure of SIP Client into Cisco SIP Server Step 1. Create a new profile with Digest Authentication for Telephone Security *only the beginning. Operating Instructions...
  • Page 26 Setting of SIP server Chapter 4 Operating Instructions...
  • Page 27 Setting of SIP server Chapter 4 Step 2. Adding extension number Operating Instructions...
  • Page 28 Setting of SIP server Chapter 4 Step 3. Adding SIP Client Operating Instructions...
  • Page 29 Setting of SIP server Chapter 4 Operating Instructions...
  • Page 30 Setting of SIP server Chapter 4 3-10 3-13 3-11 3-12 4-10 Operating Instructions...
  • Page 31 Setting of SIP server Chapter 4 3-14 *e.g., "ring transferring setting" like 3995 transferred to 3996, 3996 transferred to 3997, .., is one of the idea to use easily a function of SIP Gateway. 3-15 4-11 Operating Instructions...
  • Page 32 Setting of SIP server Chapter 4 Step 4. Adding users password "p@ssw0rd" password "p@ssw0rd" *Until this setting, pressing save is better to continue. 4-12 Operating Instructions...
  • Page 33 Setting of SIP server Chapter 4 4-13 Operating Instructions...
  • Page 34 201511...
