Page 1 OPERATING INSTRUCTIONS PACKET INTERCOM SYSTEM N-8000 SERIES Thank you for purchasing TOA's Packet Intercom system. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
Page 2: Table Of Contents
TABLE OF CONTENTS 1. SAFETY PRECAUTIONS For N-8000EX/8010EX/8000RS/8010RS/8400RS/8000MI/8000DI/8000AF 8000CO/8000AL ......................13 2. OPERATING INSTRUCTIONS CONFIGURATION ..........15 Chapter 1 : GENERAL DESCRIPTION 1. GENERAL DESCRIPTION ..................1-2 2. FEATURES ........................1-3 3. HANDLING PRECAUTIONS ..................1-3 4. SPECIFICATIONS ......................1-4 5.
Page 3 11. OTHER FUNCTION OUTLINE 11.1. Tie-line Connection ....................1-80 11.2. PBX Interface (E and M Interface) ................. 1-80 11.3. BGM ........................1-81 11.4. Contact Input and Output Functions ..............1-81 11.5. Time Signal ......................1-85 11.6. Audio Trigger ......................1-85 11.7.
Page 4 4.10. Message Pagings (available only when IP Master Stations are used) ..... 2-63 4.11. Audio Trigger Function Settings (only when the N-8050DS is used) ....... 2-65 4.12. IP Door Station's Speaker Output Switching Control (only when the N-8640DS/8650DS is used) ..............
Page 5 N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE FUNCTIONS AND OPERATION 1. BASIC USAGE 1.1. Calling from a Telephone (Individual Calls) ..............2-88 1.2. Receiving a Call ......................2-89 2. CONVERSATION FUNCTIONS AND OPERATION 2.1. Calling ......................... 2-90 2.2. Call Transfer ....................... 2-91 2.3.
Page 6 OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 1. PRIORITIES 1.1. Call Priority (available only when in "Selective Response" mode) ......2-132 1.2. Speech path Priority ....................2-132 2. TIME-OUT ........................2-133 3. RECORDING (only when the N-8000AF is used) ........2-133 4. GROUP BLOCKING ....................
Page 7 20. AUTOMATIC DAYLIGHT SAVING TIME (SUMMER TIME) CORRECTION ............... 2-146 REMARKS [List of Signal Tones] ....................2-147 Chapter 3 : INSTALLATION & WIRING 1. INSTALLATION OF THE EXCHANGE 1.1. Equipment Rack Mounting ................... 3-2 1.2. Desk-Top Installation ....................3-3 1.3. Wall Mounting .......................
Page 8 9.2. Wall Surface Mounting ....................3-43 10. INSTALLATION OF OPTION HANDSET ............3-45 11. WIRING 11.1. Exchange Connection .................... 3-46 11.2. Connections of Stations Used in conjunction with the Exchange ......3-48 11.3. N-8000RS/8010RS Substation Interface Unit Connection ........3-53 11.4.
Page 9 1.2. PC Network Settings ....................5-2 1.3. Notes on Setting Update ....................5-2 2. INSTALLING SOFTWARE 2.1. System Requirements ....................5-3 2.2. Activating the Setup Guide ................... 5-3 2.3. Required Component Installation ................. 5-4 2.4. N-8000 Setting Software Installation ................5-5 3.
Page 10 3. DISPLAYING THE MENU SCREEN ................ 6-3 4. NETWORK SETTING ....................6-5 5. OPERATION STATUS DISPLAY 5.1. N-8000EX/8010EX ....................... 6-6 5.2. N-8000RS/8010RS ....................... 6-8 5.3. N-8400RS ........................6-9 5.4. N-8000MI ........................6-11 5.5. N-8000DI ........................6-13 5.6. N-8000AF ........................6-14 5.7.
Page 11 7. SYSTEM SETTINGS 7.1. Entering Maintenance Screen ..................7-7 7.2. Network Settings ......................7-8 7.3. Station Number Settings ....................7-9 7.4. System Clock Settings ....................7-10 7.5. Restarting the Equipment ................... 7-11 Chapter 8 : APPENDIX 1. FULL DUPLEX AND HALF DUPLEX CONVERSATIONS 1.1.
Page 12 5.25. RS-144 Switch Panel ....................8-32 5.26. N-8400RS Substation Interface Unit ................ 8-33 5.27. RS-450 Indoor Substation ..................8-34 5.28. RS-460 Indoor Vandal-Resistant Substation ............8-34 5.29. RS-470 Outdoor Vandal-Resistant Substation ............8-35 5.30. RS-480 Emergency Substation ................8-36 5.31. RS-481 Option Handset ...................
Page 13: Safety Precautions
AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit • Do not block the ventilation slots in the unit's cover...
Page 14 · To mount the unit on the TOA equipment rack, use the rack mounting hardware supplied with the • Do not stand or sit on, nor hang down from the unit unit.
Page 15: Operating Instructions Configuration
2. OPERATING INSTRUCTIONS CONFIGURATION This operating instruction consists of Chapter 1 – 8 as follows. Please read the necessary chapter as required. Chapter 1 • System Configuration General Description • Nomenclature and Functions To all users • System Function • Master station's Functions and Chapter 2 Operation Function and...
Page 16: Chapter 1 : General Description
Chapter 1 GENERAL DESCRIPTION This chapter describes the N-8000 Series Packet Intercom System's basic equipment configurations (exchanges, stations and various interface units), component functions and operations, and two types of conversation methods.
Page 17: General Description
Chapter 1: GENERAL DESCRIPTION 1. GENERAL DESCRIPTION The N-8000 Series is a packet intercom system (IP network compatible intercom) employing packet audio technology* . By connecting IP intercom exchanges (which can connect up to 16 stations per exchange), IP stations, and various kinds of interface units to a network (LAN or WAN*...
Page 18: Features
Chapter 1: GENERAL DESCRIPTION 2. FEATURES • Exchanges, IP stations, and various kinds of interface units can be connected over a data communications network. • Can be connected to an existing local area network (LAN) or wide-area network (WAN). The system can also be easily connected to fiber-optic networks without restrictions on operating distance.
Page 19: Specifications
Chapter 1: GENERAL DESCRIPTION 4. SPECIFICATIONS Number of Units Connectable to LAN: Maximum 192 (a total of Exchanges, IP stations, and various kinds of interface units) Line Capacity: Maximum 3072 (192 Exchanges x 16 stations per Exchange) Speech Link Capacity: Maximum 768 (192 N-8000EX Exchanges) Single exchange N-8000EX:...
Page 20 Chapter 1: GENERAL DESCRIPTION External Contact Output: N-8000MI: Maximum 3072 (When 192 Multi interface units are connected) N-8000DI: Maximum 6144 (When 192 Direct select units are connected) N-8000AF: Maximum 1536 (When 192 Audio interface units are connected) External Contact Input: N-8000MI: Maximum 3072 (When 192 Multi interface units are connected) N-8000DI:...
Page 21: System Configuration
Chapter 1: GENERAL DESCRIPTION 5. SYSTEM CONFIGURATION 5.1. System Configuration Example This system consists of the following equipment. 2-wire type exchange N-8000EX/8010EX 2-wire type station N-8000MS N-8010MS RS-191 N-8031MS N-8033MS N-8011MS N-8020MS N-8050DS 2-core shielded type exchange N-8000RS/8010RS 2-core shielded type station Network RS-150 RS-160/170...
Page 22 Chapter 1: GENERAL DESCRIPTION IP type station N-8500MS/8600MS N-8510MS Network N-8540DS N-8640DS N-8650DS Multi interface unit N-8000MI Direct select unit N-8000DI Audio interface unit N-8000AF Telephone interface unit N-8000AL C/O interface unit N-8000CO...
Page 23 Chapter 1: GENERAL DESCRIPTION 5.1.1. Exchange 5.1.3. Peripheral components [2-wire type exchange] N-8000MI: Multi Interface Unit N-8000EX: IP Intercom Exchange N-8000DI: Direct Select Unit N-8010EX: IP Intercom Exchange N-8000AF: Audio Interface Unit N-8000CO: C/O Interface Unit [2-core shielded type exchange] N-8000AL: Telephone Interface Unit N-8000RS: Substation Interface Unit...
Page 24: Component Description
Chapter 1: GENERAL DESCRIPTION 5.2. Component Description 5.2.1. Exchange [2-wire type exchange] • N-8000EX IP Intercom Exchange The Exchange permits connection of up to sixteen 2-wire type stations and features two outputs for public address paging. The speech links consist of 4 internal links and 8 external links. The exchange is equipped with a networking interface, allowing connection with IP stations, various kinds of interface units, and other IP intercom exchanges.
Page 25 Chapter 1: GENERAL DESCRIPTION 5.2.2. Stations [IP station] Specification Speech Method Installation Method Type of Stations Auto- External Control Control Wall cascade- Power Hands- Wall Flush- Display dialing speaker output input surface Handset Headset Desk top connection free hanging mounting mounting N-8500MS: IP Multifunctional...
Page 26 Chapter 1: GENERAL DESCRIPTION [2-wire type station] Specification Speech Method Installation Method Type of Stations Auto- External Control External Wall Display dialing speaker output dial input Handset Hands- Wall Flush- surface Headset Desk top free hanging mounting mounting N-8000MS: Multifunctional Master Station N-8010MS: Standard Master Station...
Page 27 Chapter 1: GENERAL DESCRIPTION [2-core shielded station] Specification Type of Stations Speech Method Installation Method External speaker Control output Handset Hands-free Flush-mounting Wall surface mounting RS-150: Sub Station RS-160: Sub Station RS-170: *2, *3 Sub Station RS-180: *2, *3 Sub Station RS-140: Switch Panel RS-143:...
Page 28 Chapter 1: GENERAL DESCRIPTION 5.2.3. Peripheral components [N-8000MI Multi Interface Unit] Having 2 channels each for audio input and output, and 16 contacts each for control input and output, the N- 8000MI performs the following interface functions*. • Tie-line interface for connection with the EXES-2000 and EXES-6000 systems. •...
Page 29 Chapter 1: GENERAL DESCRIPTION [N-8000DI Direct Select Unit] Having 32 contacts each for control input and output, the N-8000DI performs the following interface functions. • Interface to control an indicator or external equipment such as a CCTV's switcher using relay contacts. •...
Page 30: Rack Mounting Examples For Exchanges
Chapter 1: GENERAL DESCRIPTION 5.3. Rack Mounting Examples for Exchanges Note The Exchange N-8000EX in these examples can be replaced with the N-8010EX/8000RS/8010RS/8400RS. 5.3.1. A 128-line exchange system 5.3.2. A 192-line exchange system 5.3.3. A 256-line exchange system One CR-273 Equipment Rack is One CR-413 Equipment Rack is Two CR-273 Equipment Racks are used.
Page 31 Chapter 1: GENERAL DESCRIPTION 5.3.4. A 3072-line exchange system Sixteen CR-413 Equipment Racks are used. Blower unit (BU-412) Rack No. 1 No. 8 No. 9 No. 15 No. 16 Exchange (N-8000EX) Exchange (N-8000EX) Blank panel (2U) Blank panel (2U) Blank panel (2U) Exchange (N-8000EX) Exchange (N-8000EX) Perforated panel...
Page 32: Nomenclature And Functions
Chapter 1: GENERAL DESCRIPTION 6. NOMENCLATURE AND FUNCTIONS 6.1. IP Intercom Exchanges and Their Connected Equipment 6.1.1. N-8000EX IP Intercom Exchange [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the exchange. Lights when power is supplied to the exchange.
Page 33 Chapter 1: GENERAL DESCRIPTION 6.1.2. N-8010EX IP Intercom Exchange [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the exchange. Lights when power is supplied to the exchange. 2. LNK/ACT indicator [LNK/ACT] (green) 5.
Page 34 Chapter 1: GENERAL DESCRIPTION 6.1.3. N-8000MS Multifunctional Master Station [Top] 15 16 1. Handset 5. Speaker Lift the handset for handset conversation. Lifting Outputs call tones and used for hands-free the handset disconnects both the hands-free conversations. microphone and the speaker. 6.
Page 35 Chapter 1: GENERAL DESCRIPTION 9. Redial key [REDIAL] 14. Arrow keys [ Permits the last called number to be dialed. Use these keys to perform auto-dial registration (Refer to p.2-8.) (refer to 2-11) or system settings (refer to Chapter 10. Function key [FUNCTION] Use this key to perform function settings such as 15.
Page 36 Chapter 1: GENERAL DESCRIPTION [Bottom] 22. Speaker selector switch [INT.SP/EXT.SP] 24. Wall bracket mounting slots Used to select either an internal (INT.SP) or an Hang the mounting bracket hooks to these slots external (EXT.SP) speaker. when using the YC-280 Wall Mounting Bracket. (Refer to 3-19, 3-23.)
Page 37 Chapter 1: GENERAL DESCRIPTION 6.1.4. N-8010MS Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-14.) microphone and the speaker.
Page 38 Chapter 1: GENERAL DESCRIPTION [Rear] 14. Line connection terminal [LINE] Connects to the exchange. (RJ-11 modular jack) [Bottom] 15. Microphone 16. Wall bracket mounting slots Used for hands-free conversation. Hang the hooks of the mounting bracket to these slots when using the YC-280 Wall Mounting Note Bracket.
Page 39 Chapter 1: GENERAL DESCRIPTION 6.1.5. N-8011MS Standard Hands-free Master Station [Top] 1. Paging response key [RESP.] 7. Redial key [REDIAL] Responds to a paging. (Refer to 2-29.) Permits the last called number to be dialed. (Refer to 2-8.) 2. Paging key [CALL] Makes a paging.
Page 40 Chapter 1: GENERAL DESCRIPTION [Rear] 12. Line connection terminal [LINE] Connects to the exchange. (RJ-11 modular jack) [Bottom] 13. Microphone 14. Wall bracket mounting slots Used for hands-free conversation. Hang the mounting bracket hooks to these slots when using the YC-290 Wall mounting bracket. Note (Refer to 3-21,...
Page 41 Chapter 1: GENERAL DESCRIPTION 6.1.6. N-8020MS Industrial-Use Master Station [Top] 1. Handset 7. Redial key [REDIAL] Lift the handset for handset conversation. Lifting Permits the last called number to be dialed. the handset disconnects both the hands-free (Refer to 2-8.) microphone and the speaker.
Page 42 Chapter 1: GENERAL DESCRIPTION [Rear] Protection cover 14 15 13. Line connection cable [LINE] Shift the Speaker selector switch (16) located on Connects to the exchange. (3 m-length cable the bottom surface of the unit to the EXT.SP with RJ-11 modular plug) position when using the external speaker.
Page 43 Chapter 1: GENERAL DESCRIPTION 6.1.7. N-8031MS Flush-Mount Master Station [Front] [Rear] 1. Status indicator (red) 7. Function key [FUNCTION] Flashes when a call is received, continuously Use this key to perform function settings such as lights during a conversation, and is off while in assigning call transfer recipients or programming standby mode.
Page 44 Chapter 1: GENERAL DESCRIPTION 14. Handset connection terminals [CN302] 15. External dial input terminals [CN306] A dedicated RS-191 Option Handset can be An external switch such as a footswitch can be connected. (Refer to 3-51.) connected. (Refer to 3-52.) One-touch dial function needs be programmed when using the external switch.
Page 45 Chapter 1: GENERAL DESCRIPTION 6.1.9. N-8033MS Flush-Mount Master Station [Front] [Rear] 1. Status indicator (red) 8. Redial key [REDIAL] Flashes when a call is received, continuously Permits the last called number to be dialed. lights during a conversation, and is off while in (Refer to 2-8.) standby mode.
Page 46 Chapter 1: GENERAL DESCRIPTION 6.1.10. N-8050DS Door Station [Front] [Rear] 1. Speaker 4. Microphone Outputs call tones and used for hands-free Used for hands-free conversation. conversations. 5. Line connection terminal [LINE] 2. Status indicator (red) Connects to the exchange. (Terminal block) Flashes when a call is received, continuously (Refer to 3-49.)
Page 47: Ip Station
Chapter 1: GENERAL DESCRIPTION 6.2. IP Station 6.2.1. N-8500MS IP Multifunctional Master Station [Top] 15 16 1. Handset 6. Liquid crystal display Lift the handset for handset conversation. Lifting Displays the dialed number or the number of a the handset disconnects both the hands-free call received in 2 lines of 16 digits.
Page 48 Chapter 1: GENERAL DESCRIPTION 11. Push-to-talk key [PTT] 15. Paging key [CALL] Pressing this key while calling a party by means Makes a paging. (Refer to 2-24.) of a continuous call tone permits a voice call to be made. (Refer to 2-9.) Also, pressing this 16.
Page 49 Chapter 1: GENERAL DESCRIPTION [Bottom] 28. MAC address 30. Microphone This is the MAC address* for the unit. Since the Used for hands-free conversation. relationship of each unit location to its MAC Note address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that...
Page 50 Chapter 1: GENERAL DESCRIPTION 6.2.2. N-8510MS IP Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-14.) microphone and the speaker.
Page 51 Chapter 1: GENERAL DESCRIPTION [Rear] CONTACT IN 14 15 14. AC adapter terminal [DC INPUT] 17. ACT indicator (green) Connect the AC adapter* to this terminal. Lights while transmitting or receiving data. * Use the AD-1210P/1215P (optional) or its 18. FD indicator (yellow) equivalent.
Page 52 Chapter 1: GENERAL DESCRIPTION [Bottom] 22. MAC address 23. Microphone This is the MAC address* for the unit. Since the Used for hands-free conversation. relationship of each unit location to its MAC Note address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that...
Page 53 Chapter 1: GENERAL DESCRIPTION 6.2.3. N-8600MS IP Multifunctional Master Station [Top] 15 16 1. Handset 6. Liquid crystal display Lift the handset for handset conversation. Lifting Displays the dialed number or the number of a the handset disconnects both the hands-free call received in 2 lines of 16 digits.
Page 54 Chapter 1: GENERAL DESCRIPTION 11. Push-to-talk key [PTT] 15. Paging key [CALL] Pressing this key while calling a party by means Makes a paging. (Refer to 2-24.) of a continuous call tone permits a voice call to be made. (Refer to 2-9.) Also, pressing this 16.
Page 55 Chapter 1: GENERAL DESCRIPTION [Bottom] 26. MAC address 28. Microphone This is the MAC address* for the unit. Since the Used for hands-free conversation. relationship of each unit location to its MAC Note address is established when setting the network Avoid placing obstacles close to the microphone attributes, keep track of this relationship for later that...
Page 56 Chapter 1: GENERAL DESCRIPTION 6.2.4. N-8540DS IP Door Station [Front] [Side] [Rear] [Top] 1. Speaker 6. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent.
Page 57 Chapter 1: GENERAL DESCRIPTION 6.2.5. N-8640DS IP Door Station [Front] [Rear] 1. Speaker 7. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent. 2.
Page 58 Chapter 1: GENERAL DESCRIPTION 6.2.6. N-8650DS IP Door Station [Front] [Rear] 1. Speaker 5. AC adapter terminal Outputs call tones and used for hands-free Connect the AC adapter* to this terminal. conversations. * Use the AD-1210P/1215P (optional) or its equivalent. 2.
Page 59: Substation Interface Units And Their Connected Equipment
Chapter 1: GENERAL DESCRIPTION 6.3. Substation Interface Units and Their Connected Equipment 6.3.1. N-8000RS/8010RS 2-Core Shielded Substation Interface Unit [Front] 1 2 3 4 5 Note: The figure represents the N-8000RS. 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the unit.
Page 60 Chapter 1: GENERAL DESCRIPTION 6.3.2. RS-150 Indoor Substation [Front] [Rear] 1. Speaker 3. Connection cable (orange, brown, black) Outputs call tones and used for hands-free Connects to the 2-core shielded substation conversations. interface unit. 2. Call button Used to call the preprogrammed master station. 6.3.3.
Page 61 Chapter 1: GENERAL DESCRIPTION 6.3.4. RS-180 Emergency Substation [Front] [Rear] The RS-180 substation has a weather-resistant coating on its printed circuit board. 1. Speaker 4. Connection cable (orange, brown, black) Outputs call tones and used for hands-free Connects to the 2-core shielded substation conversations.
Page 62 Chapter 1: GENERAL DESCRIPTION 6.3.5. RS-140 Switch Panel [Front] [Side] 1. Status indicator (red) 5. Connection cable (brown, red, orange) Flashes when a call is received, continuously Connects to the 2-core shielded substation lights during a conversation, and is off while in interface unit.
Page 63 Chapter 1: GENERAL DESCRIPTION 6.3.6. RS-142 Switch Board [Front] 1. Connection cables (Brown, Red, Orange) Connects to the 2-core shielded substation interface unit. 2. Speaker cables (Yellow, Green, Blue) Connects to an external speaker. 3. Call button interlock cable (Purple) Connects to the RS-141 Optional handset.
Page 64 Chapter 1: GENERAL DESCRIPTION 6.3.8. RS-144 Switch Panel [Front] [Side] 1. Emergency call button [EMERGENCY] 4. Speaker cables (Yellow, Green, Blue) Used to call the preprogrammed master station. Connects to an external speaker. 2. Call button [NORMAL] 5. Call button interlock cable (Purple) Used to call the preprogrammed master station.
Page 65 Chapter 1: GENERAL DESCRIPTION 6.3.9. RS-141 Indoor Option Handset for RS-140/142/143/144 [Front] 1. Volume control Adjusts the call volume heard at the handset. 2. Connection cable (brown, red, orange) Connects to the 2-core shielded substation interface unit. 3. Speaker cable (yellow, green, blue) Connects to the external speaker.
Page 66 Chapter 1: GENERAL DESCRIPTION 6.3.10. N-8400RS 4-Wire Substation Interface Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates the unit. Lights when power is supplied to the unit. 2. LNK/ACT indicator [LNK/ACT] (green) 5.
Page 67 Chapter 1: GENERAL DESCRIPTION 6.3.11. N-8410MS Analog Standard Master Station [Top] 12 13 1. Handset 7. Transfer key [TRANSFER] Lift the handset for handset conversation. Lifting Used to transfer the current conversation to the handset disconnects both the hands-free another station. (Refer to 2-14.) microphone and the speaker.
Page 68 Chapter 1: GENERAL DESCRIPTION [Rear] 14. Hands-free speaker volume control switch [HANDS FREE SP VOL] Adjusts the hands-free speaker volume. 15. Handset speaker volume control dial [HAND HANDS FREE HAND SET LINE SET SP VOL] SP VOL SP VOL Adjusts the handset speaker volume. 16.
Page 69 Chapter 1: GENERAL DESCRIPTION 6.3.12. RS-450 Indoor Substation [Front] [Rear] 1. Speaker 3. Microphone Outputs call tones and used for hands-free Used for hands-free conversation. conversations. 4. Connection cable (brown, red, orange, yellow) 2. Call button Connects to the 4-wire substation interface unit. Used to call the preprogrammed master station.
Page 70 Chapter 1: GENERAL DESCRIPTION 6.3.14. RS-480 4-Wire Multi-Purpose Substation [Front] [Rear] The RS-480 substation has a weather-resistant coating on its printed circuit board. 1. Speaker 5. Handset cable (purple) Outputs call tones and used for hands-free Connects to the RS-481 Option Handset. conversations.
Page 71 Chapter 1: GENERAL DESCRIPTION 6.3.15. RS-481 Indoor Option Handset for RS-480 [Front] 1. Volume control Adjusts the call volume heard at the handset. 2. Handset cable (purple) Connects to the RS-480 Substation. 3. Handset Used to make handset calls from the RS-480 station.
Page 72: Interface Unit
Chapter 1: GENERAL DESCRIPTION 6.4. Interface Unit 6.4.1. N-8000MI Multi Interface Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 4. Power indicator [POWER] (green) Pressing this key reactivates this unit. Lights when power is supplied to the unit. 2.
Page 73 Chapter 1: GENERAL DESCRIPTION 13. Audio output terminal [AUDIO OUT] 14. PBX interface terminal [PBX IF] Includes audio outputs (maximum 0 dB* , under Connects to the Exchange of the EXES-2000 or 600 Ω, balanced) and control outputs (relay EXES-6000 system by a tie-line, or the PBX contact withstand voltage: 24 V DC, control exchange via the analog E&M interface.
Page 74 Chapter 1: GENERAL DESCRIPTION 6.4.3. N-8000AF Audio Interface Unit [Front] [Rear] 1 2 3 4 5 6 7 16 17 1. Reset key [RESET] 10. Audio output terminal [AUDIO OUTPUT] Pressing this key reactivates this unit. This terminal connects to a recording device, etc. (Refer to 3-75, "Terminal plug connection.") 2.
Page 75 Chapter 1: GENERAL DESCRIPTION 6.4.4. N-8000AL Telephone Interface Unit [Front] [Rear] 1 2 3 4 5 6 1. Reset key [RESET] 7. Cord clamp Pressing this key reactivates this unit. Pass the power cord through this clamp to ensure that the plug does not pull out when the 2.
Page 76 Chapter 1: GENERAL DESCRIPTION 6.4.5. N-8000DI Direct Select Unit [Front] 1 2 3 4 5 1. Reset key [RESET] 5. MAC address Pressing this key reactivates this unit. This is the MAC address* for the unit. Since the relationship of each unit location to its MAC 2.
Page 77: System Function Table
Chapter 1: GENERAL DESCRIPTION Chapter 1: GENERAL DESCRIPTION 7. SYSTEM FUNCTION TABLE 7.1. Basic Functions IP stations or the system consisting of Exchanges and stations makes the following functions available. 7.1.1. Master station's functions Reference page Function Description Operation Setting The desired party can be called by dialing its station Individual call P.
Page 78 Chapter 1: GENERAL DESCRIPTION Chapter 1: GENERAL DESCRIPTION Reference page Function Description Operation Setting Current conversations can be placed on hold to call a third party by pressing the Transfer key. The original Call transfer* conversation can be subsequently restored or P.
Page 79 Master Station to make or receive calls to or from the P. 2-45 P. 5-75 connection outside line telephone. Using the Multi interface unit for tie-line connection between the N-8000 Series intercom system exchange and other series intercom system Tie-line Other exchanges via 4-wire private lines permits calls, P.
Page 80 Chapter 1: GENERAL DESCRIPTION Reference page Function Description Operation Setting audio output destination 8640DS/8650DS IP door station engaged in IP door station's conversations with the master station can be switched speaker output to either the internal speaker or the speaker Other switching control connected to the external speaker terminal by the...
Page 81 Chapter 1: GENERAL DESCRIPTION 7.1.4. Telephone's functions Reference page Function Description Operation Setting Calls can be made to the desired station by dialing its Individual call P. 2-90 – number. When a station is assigned to a call group, if the Conversation station is called, all stations within that group are simultaneously called by a continuous call tone...
Page 82 Chapter 1: GENERAL DESCRIPTION Reference page Function Description Operation Setting Calls can be made to one of the preprogrammed Zone paging P. 2-99 zones. P. 5-82 Selectable Calls can be made to up to 10 zones of the P. 2-100 paging preprogrammed multiple zones.
Page 83 Chapter 1: GENERAL DESCRIPTION 7.1.5. Outside line's functions Reference page Function Description Operation Setting Calls four preprogrammed stations Direct in line call simultaneously. P. 2-114 P. 5-75 Calls the desired station directly via a designated Direct inward dialing call station. Calls can be made to one of the preprogrammed Zone paging P.
Page 84: Other Functions
Chapter 1: GENERAL DESCRIPTION 7.2. Other Functions Reference page Function Description Operation Setting Response Priority: When the system's call response mode is set to "Selective Response" and a station simultaneously receives multiple calls, priorities can be assigned to P. 5-28 calls to be responded to.
Page 85 Chapter 1: GENERAL DESCRIPTION Reference page Function Description Operation Setting Call/conversation sync contact The contact output of the door station is closed P. 2-140 output depending on their respective operations. When dialing operations (up to 20 digits) have been P. 5-28 preprogrammed into the external control input of the N- P.
Page 86: Two Call Response Methods
Chapter 1: GENERAL DESCRIPTION 8. TWO CALL RESPONSE METHODS Two different call response methods are available to the N-8000 system: “Sequential Response” and “Selective Response.” The former is used in “Master-to-Master” systems that allow free communication between Master Stations by calling one another, while the latter is used in “Master-to-Sub” systems in which substations installed in different locations call one specified Master Station.
Page 87: Paging Function Outlines
Chapter 1: GENERAL DESCRIPTION 9. PAGING FUNCTION OUTLINES There are two types of paging: (1) PA paging by way of external PA equipment and (2) Station paging by way of the station's internal speaker. Both types have access to the (1) zone paging function which pages one zone, (2) the selectable paging function which pages multiple selected zones, and (3) the all-call paging function which pages all zones simultaneously.
Page 88: Paging Functions
Chapter 1: GENERAL DESCRIPTION 9.1.3. External input paging Microphone announcements or background music can be broadcast to any desired channel by connecting a Remote microphone or playback components to the N-8000MI/8000AF unit. Note External input pagings with priority ON take precedence over paging calls and conversations. Audio signal: 1 pair (0 dB*) N-8000MI...
Page 89: Station Paging Receiving Mode
Chapter 1: GENERAL DESCRIPTION 9.3. Station Paging Receiving Mode The station that receives Station Paging operates in either Conversation priority mode or Paging priority mode as described below. However, when the exchange to which the station connects is the N-8010EX, the mode is fixed to the Conversation priority mode.
Page 90: Responding To Paging
To respond to the paging, use the station assigned to the paged zone. Use this mode when each paging zone is independent. When using external PA speakers, their zones must match those of master stations. Building A Building B Building C Hello, Mr. TOA. Zone 1 Zone 2 Zone 3 Please respond.
Page 91: Outline Of The Message Paging Function
Chapter 1: GENERAL DESCRIPTION 10. OUTLINE OF THE MESSAGE PAGING FUNCTION Emergency communication systems can be created using the N-8500MS/8510MS/8600MS IP Master Stations. Messages preprogrammed into the IP Master Station can automatically be broadcast through operation of that station's keys or by means of external control input. As with the Paging function, public address devices and/or speaker stations can be selected to receive message outputs.
Page 92: Message Recording
Chapter 1: GENERAL DESCRIPTION 10.1. Message Recording • Use the N-8000 Setting Software to record the Message on a PC and program it into the IP Master Station from the PC. • Messages of up to 20 seconds in length can be recorded and programmed.
Page 93: Message Paging Zones
Chapter 1: GENERAL DESCRIPTION (2) Only the N-8510MS standard IP Master Station can initiate Message pagings using the make contact signal input if its rear panel-mounted Message Startup terminal is connected to a switch, sensor or other external device. When the N-8510MS Station receives the make contact signal while it is in use, it stops its current operation and initiates the Message paging.
Page 94: Message Paging Priority Level
Chapter 1: GENERAL DESCRIPTION 10.6. Message Paging Priority Level The Message paging takes precedence over normal conversations and paging calls (except Emergency paging). When the station to which the Message is being transmitted is in operation, all such operations are forcibly terminated, allowing the Message paging to go through.
Page 95: Other Function Outline
Chapter 1: GENERAL DESCRIPTION 11. OTHER FUNCTION OUTLINE 11.1. Tie-line Connection Conversations or paging can be performed by connecting the N-8000MI unit to the exchange of EXES-2000 or EXES-6000 Series intercom systems. Wiring requires two pairs of cables per line, and the connected exchange must be equipped with a Tie-line unit (TI-20A for the EXES-2000 and TI-600 for the EXES-6000).
Page 96: Bgm
Chapter 1: GENERAL DESCRIPTION 11.3. BGM Background music can be transmitted to the station speakers in standby mode by connecting the N-8000MI unit to musical playing equipment. Any BGM program can be selected from 8 channels at each station. BGM signal: 1 pair each (0dB*) Channel 1 BGM 7 N-8000MI...
Page 97 Chapter 1: GENERAL DESCRIPTION 11.4.2. Remote dial control When the N-8000MI's or the N-8000DI's contact input terminal is closed, a station is made to automatically perform dial operation. A set of up to 20 dial codes (including dial numbers and key operations) can be assigned to each contact input terminal.
Page 98 Chapter 1: GENERAL DESCRIPTION 11.4.4. Paging busy input Busy status data from an airport broadcast system or similar large sound systems can be received when the N-8000MI is interlocked with such systems, allowing important information to be accurately transmitted. N-8000MI Busy signal Large airport broadcast system, etc.
Page 99 Chapter 1: GENERAL DESCRIPTION 11.4.6. Direct select This function can be used when the system's call response mode is set to “Selective Response.” By separately making an operation panel for a specified Master Station which is equipped with the lamps and buttons corresponding to other stations, and by assigning the Master Station and other stations to the N- 8000DI's contact input and output channels, the stations that are calling the Master Station are indicated by means of lamps.
Page 100: Time Signal
Chapter 1: GENERAL DESCRIPTION 11.5. Time Signal This function pagings set sound sources to set paging zones according to preprogrammed schedules using the N-8000AF Audio Interface. The operation mode of one of the Audio Interfaces in the system must be set to “Time Signal,”...
Page 101: Recording
Chapter 1: GENERAL DESCRIPTION 11.7. Recording Setting the Audio Interface Unit's operation mode to Conversation Recording allows the recording of conversations, conferences, paging calls and scan monitoring of the Master Stations and telephones (used instead of stations). It is also possible to record conversations of the outside line telephones. Such conversations and conferences are recorded on recorders connected to the Audio Interface Unit.
Page 102: Chapter 2 : Functions And Operation
Chapter 2 FUNCTIONS AND OPERATION This chapter describes the system functions and operation of the N-8000 Series Packet Intercom System.
Page 103: Master Station'sfunctions And Operation
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1. BASIC USAGE Operation is the same for both the stations connected to the exchange and the IP stations connected to a LAN, and also for the N-8031MS Hands-free Master Station used in combination with the RS-191 Handset. 1.1.
Page 104: Receiving A Call (When The System Is Set To "Sequential Response" Mode)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1.2. Receiving a Call (when the system is set to "Sequential Response" mode) Step 1. Answer a received call. 1-1. When the called station's incoming call mode is set to "Automatic Connection Mode*,"...
Page 105 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Multi-Functional Master Station response] The Multi-Functional Master Station can respond to stations displayed on the LCD in the same way as the Standard Master Station. When multiple calls are simultaneously received, the call to be answered can be selected with the following operation.
Page 106: Station Speaker Volume
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1.4. Station Speaker Volume The master station speaker volume can be preset using the supplied N-8000 Setting Software program, however it can also be adjusted at the station. When using the master station other than the N-8410MS: •...
Page 107: Speech Method
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1.5. Speech Method 1.5.1. Hands-free conversation Permits conversations to be made without using the handset when a call is made without lifting a handset or received in automatic connection mode. Duplex conversations [Ambient noise level measuring function] The master station has a function to measure ambient noise level at its installation site, automatically making...
Page 108 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 1.5.2. Handset conversation Calls can be made or received by lifting the handset. Duplex conversations 1.5.3. PTT conversation This function makes announcements and conversations possible to areas with a high ambient noise level. Pressing the Push-to-talk key during a hands-free conversation enables one-way conversation from the party who pressed the Push-to-talk key.
Page 109: Conversation Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2. CONVERSATION FUNCTIONS AND OPERATION 2.1. Calling 2.1.1. Individual calls • The desired party can be called by pressing its station number with or without lifting the handset. • Conversation can start when the called party answers and the call tone stops. •...
Page 110 Call The call tone stops as long as the Push-to-talk key is pressed, enabling the called party to hear your voice. Hello, Mr. TOA. • The original continuous call tone resumes as soon as the Push-to-talk key is released. Call •...
Page 111: Setting Call Receiving Modes (Only When The System Is Set To "Sequential Response" Mode)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.1.5. Group calls • When a station is assigned to group call member station, if the station is called, this station (representative station) and all member stations are simultaneously called by a continuous call tone regardless of their call receiving mode settings.
Page 112: Speed Dialing
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.3. Speed Dialing 2.3.1. Auto-dialing (N-8000MS/8500MS/8600MS only) When the dial operation (up to 20-digit numbers) is preprogrammed into each station's Auto Dial key, such programmed call can be made by simply pressing a single key.
Page 113 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.3.2. One-touch dialing The dial operation (up to 32-digit numbers) programmed into the station's [7], [8], [9], and [0] keys, and [Off-Hook*] can be called by one-touch dialing. * The action to lift up the handset. No.
Page 114: Hold
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.4. Hold 2.4.1. Mic off Disabling the microphone during a conversation places the line on hold. [Mic off] [Example] Hold down any key of [0] through [9] continuously Mic off during a conversation.
Page 115: Call Transfer
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.5. Call Transfer Either party engaged in two-party conversation can call the third party to make conversation with (placing the original conversation partner on hold). After the conversation end, it is possible to restore the original two- party conversation or transfer the conversation with the third party to the original conversation partner.
Page 116 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Transferring calls to the third party] Step 3. To connect the third party to the original conversation partner being placed on hold, either press the Clear key or replace the handset. This permits conversation between the second and third parties. The first party The second party No.
Page 117: Automatic Transfer
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.6. Automatic Transfer Note Calls cannot be automatically transferred to the station connected via the multi interface unit. 2.6.1. Group hunting Calls to a busy station set for Group hunting are automatically transferred to another designated station. This Group hunting function also applies to the call transfer 2-14) performed during conversation.
Page 118 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [When the called station and the call forwarding receiving stations are all busy] The called station and the call forwarding receiving stations differ in operations during conversations depending on the system’s call response mode. Sequential response mode: When the designated station set for Group hunting to which a call was transferred is busy, the call is automatically transferred to the next designated station, and this continues in series until a free line is found.
Page 119 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.6.2. Absence transfer When no response is made to a call to the station set for Absence transfer for a set period of time, the call is automatically transferred to another designated station. Calls received during conversations can be transferred.
Page 120 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.6.3. Call forwarding Calls to stations set for call forwarding are automatically transferred to another designated station without sounding a call tone. Two different modes are available: one is Call forwarding, in which calls are manually rerouted to the selected station, and the other is Time-based Call forwarding, which transfers calls only when the preset time is reached.
Page 121 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Calls to stations set for Time-based Call forwarding] Step 1. When the preset transfer time is reached, the station's display shows the station (e.g. No. 62) has entered the Time-based Call forwarding mode (N-8000MS/8500MS/8600MS only). Transfer destination station number Transfer destination station name...
Page 122: Remote Response
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.7. Remote Response (only when the system is set to "Sequential Response" mode) When a station is being called, such calls can be answered by another station instead if these stations are assigned to the same group.
Page 123 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Remote response group new programming] Function designation number (Confirmation tone) [Remote response group member addition] Member station number (Confirmation tone) [Remote response group erasure] (Confirmation tone) [Remote response group member erasure] Member station number (Confirmation tone) Notes...
Page 124: Executive Priority
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 2.8. Executive Priority (only when the system is set to "Sequential Response" mode) If a called station is busy, as indicated by a busy tone, performing Priority operation from a call station transmits a short priority call tone, then forcibly terminates the current conversation, allowing the call to go through.
Page 125: Paging Function And Operation
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 3. PAGING FUNCTION AND OPERATION 3.1. Paging Paging stations are preprogrammed. Paging durations can be limited by preprogramming the time limit (between 10 and 990 seconds in 10-second units) for each exchange or IP station. Note Use the supplied N-8000 Setting Software program to enable or disable the paging operation and to set the paging duration.
Page 126 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 3.1.2. Selectable paging Paging calls can be made to up to 10 preprogrammed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to p.5-102.) Step 1. Press the Paging key, then [ ] key followed by the desired paging zone number (1 –...
Page 127 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 3.1.3. All-call paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to p.5-102.) Step 1.
Page 128 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 3.1.4. Emergency paging This function terminates all conversations, paging calls and other functions currently in progress throughout the system, and simultaneously makes a paging call to all stations, the N-8000EX IP Intercom Exchange's audio outputs, the N-8000MI Multi-Interface Unit designated as paging output, and N-8000AF Audio Interface Unit's audio output.
Page 129 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 3.1.5. Paging priority [Emergency paging] Emergency paging takes precedence over conversations, paging calls and all other functions. Initiating Emergency paging terminates all other functions currently in operation, and these functions are not restored even when the page is completed.
Page 130: Responding To Paging
Press the Paging Response key. The paging party who made the last page is called and put through to the paged party. Building A Building B Building C Hello, Mr. TOA. Zone 1 Zone 2 Zone 3 Please respond. Speaker Speaker •...
Page 131 The paging party who made the paging to the designated zone last is called and put through to the paged party. [Example] Zone 1 Zone 2 Speakers Hello, Mr. TOA. Please respond to Response 002. (Zone number with 3-digit length) The station that can make response is as follows. • Station assigned to the paged zone •...
Page 132: Other Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4. OTHER FUNCTIONS AND OPERATION 4.1. Scan Monitor The station can scan arbitrary stations for auditory monitoring. The station to be scan-monitored must be preprogrammed into a monitor group or can be selected each time by designating the station number.
Page 133 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Operation] Step 1. Automatic Scan 1-1. When scan-monitoring the preprogrammed stations Press the [ ], [2] keys, then the monitor group number (1 – 4), followed by the [ ] key. When monitoring two or more groups, press the group numbers consecutively.
Page 134: Three-Party Conference
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.2. Three-Party Conference A simultaneous (full duplex) three-party handset conversation can be held by calling up other master stations in sequence. It is possible to call a conference by calling other stations from the standby mode or by calling a third party from the two-party conversation mode.
Page 135 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Step 3. Dial the station number of the third party. When the third party answers, the second party is released from hold mode, permitting a 3-party conversation to proceed. Conversation (on hold) Station number of the third party Calling Call tone...
Page 136 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.2.2. Initiating a 3-party conference during a 2-party conversation Step 1. While connected with the second party, press the Transfer key. The second party will be placed on hold. Conversation (on hold) Step 2.
Page 137 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Step 3. The conference is terminated when the originator of the conference either presses the Clear key or replaces the handset. This completes the conference call. If a called party other than the originator of the conference presses the Clear key or replaces the station handset, that party can exit the conference.
Page 138: Time Signal (Only When The N-8000Af Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.3. Time Signal (only when the N-8000AF is used) The Time Signal function broadcasts preset sound sources over preset paging zones according to preprogrammed schedules. The N-8000AF Audio Interface of which operation mode has been set to "Time Signal"...
Page 139 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [External timer-initiated event settings] • "Time Signal" broadcasts can be triggered by make contact from an external timer connected to the N- 8000AF Audio Interface's contact input. • The external timer-initiated event is comprised of the following contents for each contact input (1 – 8): Paging zones (up to 10 zones selected from 192), sound source numbers (0 –...
Page 140 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Operation when the Time Signal broadcast overlaps other calls or broadcasts] • Operation during overlap is the same as for external input broadcasts (refer to 2-136). • When a station is in use, the time signal is broadcast to all other stations except the busy station. 4.3.3.
Page 141 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.3.6. Manually trigger time signal Time Signal can be activated simultaneously with the master station's dial operation, through which the sound source number, external equipment control ON/OFF, and paging zone number should be designated. •...
Page 142 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.3.7. Time signal temporary exception Any station can be temporarily excepted from the time signal-initiated paging destinations through key operations at the master station. Up to 10 stations can be simultaneously excepted through a single operation. Once registered for temporary exception, the stations will not accept any time signal-initiated paging calls until exception cancellation is performed to those stations.
Page 143 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.3.9. Cancelling the reserved time signal schedule The reserved Time Signal Schedule can be cancelled through key operations at any station. Function designation No. (confirmation tone) 4.3.10. Confirming the reserved time signal schedule (N-8000MS/8500MS/8600MS only) The reserved Time Signal Schedule can be confirmed through key operations at any station.
Page 144: Pbx Connection (Only When The N-8000Mi Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.4. PBX Connection (only when the N-8000MI is used) If the Multi interface unit is connected to the PBX's analog E&M interface, calls or conversations can be mutually made between the N-8000 system's stations and the PBX's extension telephones or paging calls can be initiated from the PBX extension telephone.
Page 145 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.4.3. Being paged from a PBX extension telephone Dialing the intercom access number, " ," "8," and the N-8000 system's paging zone number in this order at the PBX extension telephone permits the paging calls to be made to the N-8000 system's stations. The method for responding a paging call at the station is the same as when it is paged from the N-8000 system's station.
Page 146: Outside Line Connection (Only When The N-8000Co Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.5. Outside Line Connection (only when the N-8000CO is used) Outside lines can be connected to the N-8000 system, permitting the system's master stations to make or receive outside line telephone calls. 4.5.1.
Page 147 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.5.3. Receiving calls from an outside line telephone There are two modes for receiving calls from an outside line telephone: Direct-In Line and Direct-In Dialing. The audible call tone for a received outside line call is different from those of other incoming calls. (Refer to "List of Signal Tones"...
Page 148 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.5.4. Receiving paging from an outside line telephone Stations can receive paging calls from outside line telephones. Note Outside line telephones can page system stations only when Direct-In Dialing has been enabled by the supplied N-8000 Setting Software.
Page 149 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] Function designation C/O interface unit access number number (1-digit or 2-digit) (Confirmation tone) [Erasure] Function designation The originally called (your) number station number (Confirmation tone)
Page 150 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.5.6. Outside line Absence transfer Outside line telephones can be designated as the transfer destinations for Absence transfer (refer to 2-18). This Outside line Absence transfer function also applies to the call transfer 2-14) performed during conversation.
Page 151 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] Function designation C/O interface unit access number number (1-digit or 2-digit) (Confirmation tone) [Erasure] The originally called (your) Function designation station number number (Confirmation tone)
Page 152 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.5.7. Outside line Call forwarding Outside line telephones can be designated as the transfer destinations for Call forwarding (refer to 2-19). Destinations for both manual and automatic time-interlocked Call forwarding can be set to outside line telephones.
Page 153 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Programming or erasure can be performed at your station. [Programming] C/O interface unit access number Function designation number (1-digit or 2-digit) (Confirmation tone) [Erasure] The originally called Function designation number (your) station number (Confirmation tone) Note...
Page 154 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Calls to stations set for outside line Time-based Call forwarding] Step 1. When the preset transfer time is reached, the Transfer destination outside line number Transfer destination station's display shows the station (e.g. No. 62) has (unit number) outside line name entered the Time-based Call forwarding mode (N-...
Page 155: Tie-Line Connection (Only When The N-8000Mi Is Used)
4.6. Tie-Line Connection (only when the N-8000MI is used) Using the Multi interface unit for tie-line connection between the N-8000 Series intercom system exchange and other series intercom system exchanges via 4-wire private lines permits calls, conversations, or paging calls to be mutually made between stations connected to the tie-line connected exchanges.
Page 156 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.6.3. Making paging calls to another intercom system Step 1. Press the tie-line access number. The called intercom system can be connected. Step 2. After confirming that a dial tone from the connected intercom system is heard, dial the paging operation number of the connected intercom system, and make a paging call to the connected intercom system.
Page 157: Bgm (Only When The N-8000Mi Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.7. BGM (only when the N-8000MI is used) Connecting playback components to the Multi interface unit permits Background music selectable from up to 8 programs to be heard from each station speaker while in standby mode. It is possible to make or receive calls at the station even in BGM mode.
Page 158 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [BGM volume adjustment] BGM volume can be adjusted in 5 increments. • Press [Function key][1][9][ ] to increase the volume. Function designation number • Press [Function key][1][9][ ] to decrease the volume. Function designation number 2-57...
Page 159: External Equipment Control (Only When The N-8000Mi/8000Di/8050Ds/8540Ds/8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.8. External Equipment Control (only when the N-8000MI/8000DI/8050DS/8540DS/8640DS/8650DS is used) External equipment can be controlled by transmitting a one-shot make output signal (or make or break contact signal) to the contact of the designated Multi-Interface or Direct Select unit, or by manually causing the station to transmit a one-shot make output signal to the contact of the designated door station.
Page 160 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Make output operation] Press [Function key][3][1], then the access number for the contact corresponding to the external equipment to be controlled. Function designation number Contact access No. (2 – 4 digits) ..
Page 161 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Door station one-shot make output operation (when the N-8640DS/8650DS is used)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. Press the function designation number corresponding to the contact output, followed by the door station number to be controlled.
Page 162: Door Remote Control
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.9. Door Remote Control (only when the N-8050DS/8540DS/8640DS/8650DS/8000MI/8000DI is used) N-8050DS/8540DS/8640DS/8650DS's contact outputs can be shorted for a set period of time by the dial operation at the master station engaged in conversation with the N-8050DS Door Station or N- 8540DS/8640DS/8650DS IP Door Station of which "Door station contact output"...
Page 163 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION [Operation (when using the contact outputs of the N-8640DS/8650DS)] The N-8640DS/8650DS has 5 contact outputs. The contact output to be controlled can be selected through key operation. Step 1. Press the Transfer key during a conversation. Current conversation is placed on hold, transmitting a hold tone to other party.
Page 164: Message Pagings (Available Only When Ip Master Stations Are Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.10. Message Pagings (available only when IP Master Stations are used) Message pagings can be made using messages preprogrammed into the N-8500MS/8600MS Multi-Functional IP Master Station or N-8510MS Standard IP Master Station. The Message paging is output to the preset paging zones.
Page 165 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Step 2. Message Paging Termination There are two termination methods. 2-1. Termination by IP Master Station key. Press the Clear key. Note This operation forcibly terminates the Message Paging even if the number of broadcast repetitions is set.
Page 166: Audio Trigger Function Settings (Only When The N-8050Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.11. Audio Trigger Function Settings (only when the N-8050DS is used) Audio Trigger function settings for the N-8050DS Door Station can be performed at the Master Station (refer to 2-79). 4.11.1.
Page 167 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.11.3. Confirming audio trigger setting status (N-8000MS/8500MS/8600MS only) The setting status of the Audio Trigger function can be confirmed at any Multi-Functional Master Station by designating a Door Station. Displayed for 5 sec. 2 0 0 : A c t i v e Function designation number...
Page 168 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.11.5. Changing the audio trigger detection time The time interval for detecting sound to activate the alarm function can be changed at any station by designating a Door Station. Set the detection time (in second) using the dial keys 1 – 9. detection time (in second) Function designation number Door station number...
Page 169: Ip Door Station's Speaker Output Switching Control (Only When The N-8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 4.12. IP Door Station's Speaker Output Switching Control (only when the N-8640DS/8650DS is used) The audio output destination of the N-8640DS/8650DS IP door station engaged in conversations with its master station can be switched to either the internal speaker or the speaker connected to the external speaker terminal by the master station’s dial operation.
Page 170: Master Station Operation Table
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 5. MASTER STATION OPERATION TABLE Function Item Operation Remarks Call Call Dial station No. [X][X] ··· [X] Station No: 2 – 6 digits Redialing Press the [Redial] key Recall Press the [ ] key Voice Calling Voice a call to a called party by pressing the [PTT] key as the...
Page 171 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks Call Programming Dial [Function] [4] [1] [ ] [the C/O line interface access Station No: 2 – 6 digits forwarding at your station number] [ ] keys. Erasure at your station Dial [Function] [4] [1] [your station No.] [ ] keys.
Page 172 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Function Item Operation Remarks Time signal Changing time signal Dial [Function] [9] [0] [schedule No.] keys. Schedule No.: 01 – 16 schedules Suspending time Dial [Function] [9] [0] [0] [0] keys. signal schedules Manually trigger Dial [Function] [9] [1] [sound source No.] [external control]...
Page 173: Multifunctional Master Station's Lcd Display Table
Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION 6. MULTIFUNCTIONAL MASTER STATION'S LCD DISPLAY TABLE Standby mode Holding Current time Your station number Called station's number Called station's name 1 2 : 0 0 A M 2 0 0 : N - 8 0 0 0 M S H o l d i n g 1 0 0...
Page 174 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Paging Redial Paging zone number Paging zone name R e d i a l 0 : 4 0 0 Z o n e 0 : A L L C A L L P a g i n g Dialing data Note:...
Page 175 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Audio Trigger alarm received Making a 3-party conference call (originator) Called station's number Called station's name Called party's station number Called party's station name 2 0 0 : N - 8 0 0 0 M S 3 0 0 : N - 8 5 0 0 M S C a l l...
Page 176 Chapter 2: FUNCTIONS AND OPERATION MASTER STATION'S FUNCTIONS AND OPERATION Selective Response • 100th call displayed (100th received call is normal, but an Emergency call precedes it. ) • Call in (no waiting call) C a l l - i n 9 9 / C a l l - i n •...
Page 177: Door Station'sfunctions And Operation
Chapter 2: FUNCTIONS AND OPERATION DOOR STATION DOOR STATION'S FUNCTIONS AND OPERATION 1. CALLING FROM A DOOR STATION 1.1. Calling from a Door Station (when the system is set to "Sequential Response" mode) Step 1. Press the call button to call the pre-programmed master station or telephone. The call tone is heard through the calling station’s internal speaker.
Page 178: Calling From A Door Station (When The System Is Set To "Selective Response" Mode)
Chapter 2: FUNCTIONS AND OPERATION DOOR STATION 1.2. Calling from a Door Station (when the system is set to "Selective Response" mode) Step 1. Press the call button to call the pre-programmed master station or telephone. Flashes The status indicator flashes. Note When the call time limit has been set, if no response is made within a set period of time, the call is automatically terminated.
Page 179: Making An Emergency Call (Only Possible When System Is Set For "Selective Response")
Chapter 2: FUNCTIONS AND OPERATION DOOR STATION 2. MAKING AN EMERGENCY CALL (only possible when system is set for "Selective Response") Emergency Calls take precedence over other calls. If the Master Station or telephone responds to the Emergency Call, the conversation becomes an Emergency Conversation and is handled with a higher priority than other conversations and paging calls.
Page 180: Audio Trigger Function (N-8050Ds Only)
Chapter 2: FUNCTIONS AND OPERATION DOOR STATION 4. AUDIO TRIGGER FUNCTION (N-8050DS only) Alarm operation is activated if audio that enters the preprogrammed N-8050DS Door Station's microphone meets set conditions. Notes • Use the supplied N-8000 Setting Software program to perform audio trigger function setting. (Refer to 5-64.) •...
Page 181: Door Station Operation Table
Chapter 2: FUNCTIONS AND OPERATION DOOR STATION [Alarm trigger conditions] Either of the following conditions is used to trigger the alarm. • Level detection Activates alarm if a sound pressure level exceeding the set level is detected for a specified period of time. •...
Page 182: Substation/Switch Panel'sfunctions And Operation
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL SUBSTATION/SWITCH PANEL'S FUNCTIONS AND OPERATION This section describes the functions and operations of the substation, switch panel, and switch board to be connected to the Substation Interface Unit. Hereinafter, these connected devices are collectively called "Substation."...
Page 183: Operation Using The Call Button (When The System Is Set To "Selective Response" Mode)
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 1.2. Operation Using the Call Button (when the system is set to "Selective Response" mode) Step 1. Press the call button to call the pre-programmed master station or telephone. Flashes The status indicator flashes (RS-140/180/480 only). Note When the call time limit has been set, if no response is made within a set period of time, the call is automatically terminated.
Page 184: Calling By Lifting The Handset (Only When The Rs-141 Is Combined With The Rs-140/142/143/144, And When The Rs-481 Is Combined With The Rs-480.)
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 1.3. Calling by Lifting the Handset (only when the RS-141 is combined with the RS-140/142/143/144, and when the RS-481 is combined with the RS-480.) Flashes Step 1. Lift the handset. Calls the preprogrammed master station or telephone.
Page 185: Making An Emergency Call
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 2. MAKING AN EMERGENCY CALL (only when system response mode is set for "Selective Response") Emergency Calls take precedence over other calls. If the Master Station or telephone responds to the Emergency Call, the conversation becomes an Emergency Conversation and is handled with a higher priority than other conversations and paging calls.
Page 186: Using The Call Button With A Lower Priority
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 2.2. Using the Call Button with a Lower Priority The call button assigned a lower priority can also initiate the emergency calls through the operation described below. Notes • The RS-140/180/480 is not capable of initiating Emergency Calls through the operation described below, but can initiate Emergency Calls by changing the call priority order settings.
Page 187: Receiving A Call
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 3. RECEIVING A CALL Flashes Steady-on Step 1. When receiving a call from the master station, the call tone sounds only once, after which the calling party's voice is heard immediately through the internal speaker. Brief call tone Voice Step 2.
Page 188: Using The Privacy Function (Rs-140 Only)
Chapter 2: FUNCTIONS AND OPERATION SUBSTATION/SWITCH PANEL 5. USING THE PRIVACY FUNCTION (RS-140 only) The Privacy function refuses all paging and station calls except Emergency paging calls. 5.1. Privacy Mode Settings Press the Privacy button on the RS-140 Switch Panel when the Privacy indicator is unlit.
Page 189: N-8000Al Telephone Interface Connected Telephone Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE FUNCTIONS AND OPERATION 1. BASIC USAGE 1.1. Calling from a Telephone (Individual Calls) Step 1. Lift the handset and press the station number to be called. Call tone The calling station's handset speaker sounds an audible call tone.
Page 190: Receiving A Call
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 1.2. Receiving a Call Step 1. When a call is received, lift the handset to answer the call. Step 2. To finish conversations, replace the handset. 2-89...
Page 191: Conversation Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2. CONVERSATION FUNCTIONS AND OPERATION 2.1. Calling 2.1.1. Individual calls • To call a station, lift the handset, then press its station number. • Conversation can begin when the called party answers and the call tone stops. •...
Page 192: Call Transfer
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.2. Call Transfer Either party engaged in two-party conversation can call the third party to make conversation with (placing the original conversation partner on hold). After the conversation ends, it is possible to restore the original two- party conversation or transfer the conversation with the third party to the original conversation partner.
Page 193 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Transferring calls to the third party] Step 3. To connect the third party to the original conversation partner being placed on hold, replace the handset. This permits conversation between the second and third parties. The first party The second party No.
Page 194: Automatic Transfer
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3. Automatic Transfer Note Calls cannot be automatically transferred to the station connected via the multi interface unit or the C/O line interface unit. 2.3.1. Group hunting Calls to a busy telephone set for Group hunting are automatically transferred to another designated station or telephone.
Page 195 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE Programming or erasure can be performed at your telephone. Function designation Transfer destination number station number [Programming] (Confirmation tone) Function designation The originally called number (your) telephone number [Erasure] (Confirmation tone) [Setting example] Calls can be transferred to designated stations in a cyclical manner.
Page 196 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3.2. Absence transfer When no response is made to a call to the telephone set for Absence transfer for a set period of time, the call is automatically transferred to another designated station or telephone. Calls received during conversations can be transferred.
Page 197 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.3.3. Call forwarding Calls to telephones set for Call forwarding are automatically transferred to another designated station or telephone without sounding a call tone. Two different modes are available: one is Call forwarding, in which calls are manually rerouted to the selected station, and the other is Time-based Call forwarding, which transfers calls only when the preset time is reached.
Page 198 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Calls to stations set for Time-based Call forwarding] Step 1. When the preset transfer time is reached, the telephone enters the Time-based Call forwarding mode. Step 2. Calls to stations (original telephone) are automatically transferred to the transfer destination station without sounding a call tone.
Page 199: Executive Priority (Only When The System Is Set To "Sequentialresponse" Mode)
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 2.4. Executive Priority (Only when the system is set to "Sequential Response" mode) If a called station is busy, as indicated by a busy tone, performing Priority operation from a call telephone transmits a short priority call tone, then forcibly terminates the current conversation, allowing the call to go through.
Page 200: Paging Function And Operation
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3. PAGING FUNCTION AND OPERATION 3.1. Paging Paging stations are preprogrammed. Paging durations can be limited by preprogramming the time limit (between 10 and 990 seconds in 10-second units) for each C/O line interface unit. Note Use the supplied N-8000 Setting Software program to enable or disable the paging operation and to set the paging duration.
Page 201 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.2. Selectable paging Paging calls can be made to up to 10 preprogrammed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to 5-102.) Step 1. Lift the handset, then press the [ ][8][ ] keys, followed by the desired paging zone number (1 –...
Page 202 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.3. All-call paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to 5-102.) Step 1.
Page 203 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.4. Emergency paging This function terminates all conversations, paging calls and other functions currently in progress throughout the system, and simultaneously makes a paging call to all of the pre-programmed zones. Use the supplied N-8000 Setting Software program to set the paging zones.
Page 204: Receiving Paging Calls (Only Emergency Pagings Can Be Received)
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 3.1.5. Paging priority [Emergency paging] Emergency paging takes precedence over conversations, paging calls and all other functions. Initiating Emergency paging terminates all other functions currently in operation, and these functions are not restored even when the page is completed.
Page 205: Other Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4. OTHER FUNCTIONS AND OPERATION 4.1. Scan Monitor The telephone can scan arbitrary stations for auditory monitoring. The station to be scan-monitored must be preprogrammed into a monitor group or can be selected each time by designating the station number.
Page 206 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Operation] Step 1. Automatic Scan 1-1. When scan-monitoring the preprogrammed stations: Press the [ and [2] keys, then monitor group number (1 – 4), followed by the [#] key. When monitoring two or more groups, dial the group numbers consecutively. 1-2.
Page 207: External Equipment Control (Only When The N-8000Mi/8000Di/8050Ds/8540Ds/8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.2. External Equipment Control (only when the N-8000MI/8000DI/8050DS/8540DS/8640DS/8650DS is used) External equipment can be controlled by making the Multi-Interface Unit's or Direct Select Unit's contact output designated by telephone operation provide a one-shot make contact or make/break contact, or by making the designated door station's contact output provide a one-shot make contact.
Page 208 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Make output operation] Press [ ][3][1] keys, then the access number for the contact corresponding to the external equipment to be controlled. Function designation number Contact access No. (2 – 4 digits) [Break output operation] Press [ ][3][2] keys, then the access number for the contact corresponding to the external equipment to be controlled.
Page 209 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Door station one-shot make output operation (when the N-8640DS/8650DS is used)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. Press the function designation number corresponding to the contact output, followed by the door station number to be controlled.
Page 210: Door Remote Control
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.3. Door Remote Control (only when the N-8050DS/8540DS/8640DS/8650DS/8000MI/8000DI is used) N-8050DS/8540DS/8640DS/8650DS's contact outputs can be shorted for a set period of time by the dial operation at the telephone engaged in conversation with the N-8050DS Door Station or N- 8540DS/8640DS/8650DS IP Door Station of which "Door station contact output"...
Page 211 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE [Operation (when using the contact outputs of the N-8640DS/8650DS)] The N-8640DS/8650DS has 5 contact outputs. The contact output to be controlled can be selected through key operation. Step 1. Hook-flash* during a two-party conversation. The current conversation is placed on hold, transmitting a hold tone to the other party.
Page 212: Ip Door Station's Speaker Output Switching Control (Only When The N-8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 4.4. IP Door Station's Speaker Output Switching Control (only when the N-8640DS/8650DS is used) The audio output destination of the N-8640DS/8650DS IP door station engaged in conversations with its telephone can be switched to either the internal speaker or the speaker connected to the external speaker terminal by the telephone’s dial operation.
Page 213: Telephone Operation Table
Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE 5. TELEPHONE OPERATION TABLE Function Item Operation Remarks Call/Response Call Dial station No. [X][X] ··· [X] Station No.: 2 – 6 digits Response Lift the handset. Conversation Handset conversation Conversation can be made by lifting the handset. Call transfer Call transfer Hook-flash during a conversation.
Page 214 Chapter 2: FUNCTIONS AND OPERATION N-8000AL TELEPHONE INTERFACE CONNECTED TELEPHONE Function Item Operation Remarks External Speaker output (When switching to the internal speaker) equipment switching control Hook-flash during a conversation with the control N-8640DS/8650DS, then dial [ ] [0] keys. (When switching to the external speaker) Hook-flash during a conversation with the N-8640DS/8650DS, then dial [...
Page 215: Operation From An Outside Line
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE OPERATION FROM AN OUTSIDE LINE (only when the N-8000CO is used) 1. CALLING A STATION Direct-In Line and Direct-In Dialing functions allow the N-8000 system to receive calls from an outside line telephone.
Page 216: Paging
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 2. PAGING If the N-8000CO C/O Line Interface Unit is set to receive Direct-In Dialing calls as well operate paging calls, N-8000 system paging can be initiated from the outside line telephone. Also, a paging time limit can be set by programming a time limit (in 10 seconds units from 10 –...
Page 217 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE [Example paging to the zone 23] Zone 1 Speakers Amplifier 1, 2 Zone 23 (Zone number with 3-digit length) N-8000CO's outside line number No. 1001 No. 1003 No. 1002 No. 1004 (Dial confirmation tone) Zone 192 Speaker...
Page 218: Selectable Paging
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 2.2. Selectable Paging Paging calls can be made to up to 10 preprogrammed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to 5-102.) Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.
Page 219 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE [Example paging to the zone 1, 23, and 105.] Zone 1 Speakers Amplifier 1~ 4 Zone 23 (Zone number with 3-digit length) N-8000CO's outside line number No. 1000 No. 1003 No.
Page 220: All-Call Paging
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 2.3. All-Call Paging Paging calls can be made simultaneously to all of the pre-programmed zones. Use the supplied N-8000 Setting Software program to set the paging zones. (Refer to 5-102.) Step 1.
Page 221: Other Functions And Operation
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3. OTHER FUNCTIONS AND OPERATION 3.1. Scan Monitor If the N-8000CO C/O Line Interface Unit is set to allow scan monitor operation, the outside line telephone can scan arbitrary stations for auditory monitoring. It is also possible to set an outside line control password to be used when dialing from the outside line telephone.
Page 222 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE during monitoring. Note In the case of the RS-140/180/480, the status indicator does not light even if set to "Display ON" mode. [Operation] Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.
Page 223: Time Signal (Only When The N-8000Af Is Used)
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2. Time Signal (only when the N-8000AF is used) Change, suspension, confirmation, reservation, and reservation confirmation of the time signal schedule can be made from the outside line telephone when the Direct-In Dialing function is set to the N-8000CO unit. It is also possible to set an outside line control password to be used when dialing from the outside line telephone.
Page 224 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2.2. Suspending time signal schedules The System Time Signal schedule can be suspended through operation from the outside line telephone. To restart the suspended schedules, change the time signal schedule. (Refer to 2-122.) [Operation] Step 1.
Page 225 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2.3. Time signal schedule confirmation The System Time Signal schedule can be confirmed through operation from the outside line telephone. With an audible tone through the telephone, its schedule can be confirmed by operations from the outside line telephone.
Page 226 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2.4. Reserving the time signal schedule change The System Time Signal schedule can be reserved through operation from the outside line telephone. To set the reserved day, designate the day from one (next day) to 9 days later by number (1 – 9) after performing the reservation operation.
Page 227 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2.5. Cancelling the reserved time signal schedule The System Time Signal schedule reservation can be cancelled through operation from the outside line telephone. [Operation] Step 1. Lift the handset and dial the N-8000CO's outside line number. The N-8000CO unit automatically responds to the call and a dial confirmation tone is transmitted to the caller.
Page 228 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.2.6. Confirming the reserved time signal schedule The System Time Signal schedule reservation can be confirmed through operation from the outside line telephone. With an audible tone through the outside line telephone, its schedule reservation can be confirmed by operations from the outside line telephone.
Page 229: External Equipment Control (Only When The N-8000Mi/8000Di/8050Ds/8540Ds/8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 3.3. External Equipment Control (only when the N-8000MI/8000DI/8050DS/8540DS/8640DS/8650DS is used) If the N-8000CO C/O Line Interface Unit is set to allow external equipment control operation, the outside line telephone can control external equipment by making the designated Multi-Interface or Direct Select unit provide one-shot make contact or make/break contact at its contact output, or by making the designated door station provide one-shot make contact at its contact output.
Page 230 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE [Make output operation] First dial the N-8000CO interface’s outside line number and confirm that a dial confirmation tone is heard, and then dial [ ][3][1]+[4-digit outside line control password]+[access number for the contact corresponding to external equipment to be controlled].
Page 231 Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE [Door station one-shot make output operation (N-8640DS/8650DS is used.)] The N-8640DS/8650DS has 5 contact outputs. Function designation number differs depending on the contact output to be controlled. First dial the N-8000CO interface’s outside line number and confirm that a dial confirmation tone is heard, and then dial [Function designation number]+[4-digit outside line control password]+[door station number to be controlled].
Page 232: Outside Line Telephone Operation Table
Chapter 2: FUNCTIONS AND OPERATION OPERATION FROM AN OUTSIDE LINE 4. OUTSIDE LINE TELEPHONE OPERATION TABLE Function Item Operation Remarks Call Direct In Line Dial [N-8000CO's outside line number] keys. Direct-In Dialing Dial [N-8000CO's outside line number] [station No.] keys. Station No: 2 –...
Page 233: Priorities
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 1. PRIORITIES There are two priorities: Call Priority and Speech path Priority. 1.1. Call Priority (available only when in "Selective Response" mode) • This priority can only be used when the system is set for "Selective Response." •...
Page 234: Time-Out
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 2. TIME-OUT This function restricts the duration of calling, conversation, and paging to prevent the speech path from being left unused when a user neglects to terminate conversation or paging. When the set time has elapsed, stations automatically return to standby state. Notes •...
Page 235: Group Blocking
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 4. GROUP BLOCKING Stations can be blocked into groups (up to 31 groups) which can or cannot make calls to each other. Paging zone numbers available among such groups can also be set. Note Use the supplied N-8000 Setting Software to set the station groups, calls that can be made among groups, and paging zones that can be mutually called.
Page 236: Paging Delay Output
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 5. PAGING DELAY OUTPUT This function controls the audio output according to the connected external equipment's activation time. Delay time can be inserted into the time duration from paging operation completion to paging pre- announcement tone output (or paging commencement).
Page 237: External Input Paging
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 7. EXTERNAL INPUT PAGING (only when the N-8000MI/8000AF is used) By connecting the Remote microphone or playback components to the Multi-interface unit or Audio interface unit, activating its control input enables broadcasting to the preprogrammed zone(s). There are two methods of activation: one is to use the Audio input terminal (A in the following figure), and the other is to use the Contact input terminal (B).
Page 238: Paging Sync Contact Output Control (Only When The N-8000Mi/8000Af Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 8. PAGING SYNC CONTACT OUTPUT CONTROL (ONLY WHEN THE N-8000MI/8000AF is used) The contact output of both the N-8000MI and N-8000AF interface units can be set as the paging output destination. This makes it possible to control connected external equipment in synchronization with paging activation.
Page 239: Calling Station Indication/Cctv Interlock (Only When The N-8000Mi/8000Di Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 9. CALLING STATION INDICATION/CCTV INTERLOCK (only when the N-8000MI/8000DI is used) By installing a lamp type indication board* at the specified station, conversation partners and calling stations that made calls to the specified station during conversation can be displayed on the board. The indication board can be shared among multiple stations (up to 8 stations) to indicate which station within the group has been called.
Page 240: Outside Line Calling Station Indication/Cctv Interlock (Only When The N-8000Co/8000Mi/8000Di Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 10. OUTSIDE LINE CALLING STATION INDICATION/CCTV INTERLOCK (only when the N-8000CO/8000MI/8000DI is used) The calling station indication/CCTV interlock can be enabled at the time of making calls to or receiving calls from the outside line or during conversations.
Page 241: Call/Conversation Sync Contact Output (Only When The N-8050Ds/8540Ds/8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 11. CALL/CONVERSATION SYNC CONTACT OUTPUT (only when the N-8050DS/8540DS/8640DS/8650DS is used) The contact output of the N-8050DS Door Station or N-8540DS/8640DS/8650DS IP Door Station is closed in synchronization with its own station's operating status. The timing that the contact output is closed can be selected from 3 patterns;...
Page 242: Ip Door Station External Control Input (Only When The N-8640Ds/8650Ds Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 12. IP DOOR STATION EXTERNAL CONTROL INPUT (only when the N-8640DS/8650DS is used) When dialing operations (up to 20 digits) have been preprogrammed into the external control input of the N- 8640DS/8650DS IP Door Station, such dialing operations can be performed by closing the N- 8640DS/8650DS’s contact input.
Page 243: Remote Dial Control (Only When The N-8000Mi/8000Di Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 13. REMOTE DIAL CONTROL (only when the N-8000MI/8000DI is used) When the N-8000MI/8000DI's contact input terminal is closed, an arbitrary station is made to automatically perform dial operation. A set of up to 32 dial codes (including dial numbers and key operations) can be assigned to each contact input terminal.
Page 244: Direct Select (Only When The N-8000Di Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 14. DIRECT SELECT (only when the N-8000DI is used) This function can be used when the system's call response mode is set to “Selective Response.” By separately making an operation panel for a specified Master Station which is equipped with the lamps and buttons corresponding to other stations, and by assigning the Master Station and other stations to the N- 8000DI's contact input and output channels, the stations that are calling the specified Master Station are indicated by means of lamps.
Page 245: Contact Bridge Function
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 15. CONTACT BRIDGE FUNCTION (only when the N-8000MI/8000DI/8050DS/8540DS/8640DS/8650DS is used) Contact signals can be transmitted by way of a network. N-8640DS Contact output N-8050DS Contact output N-8000EX/8010EX N-8000MI/8000DI N-8000MI/8000DI Contact output Contact input Either of the following 2 control input's operation modes can be selected.
Page 246: System Diagnosis (Only When The N-8000Mi/8000Di Is Used)
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 17. SYSTEM DIAGNOSIS (only when the N-8000MI/8000DI is used) The N-8000MI/8000DI diagnoses the system condition, and provides its results at the contact output terminal as open or closed contact. The system diagnosis is performed in a way that the N-8000MI/8000DI connects the target equipment via the network.
Page 247: Time Signal
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) 18. TIME SIGNAL (Refer to 2-37, "Time Signal".) 19. TIME CORRECTION This function adjusts the clocks of all the system equipment. When the N-8000AF's Time Sync function is enabled, that N-8000AF functions as Master Clock, which can be set using the N-8000 Setting Software. This function adjusts the system clock once a day.
Page 248: [List Of Signal Tones]
Chapter 2: FUNCTIONS AND OPERATION OTHER FUNCTIONS (CONVENIENT FUNCTIONS) REMARKS [List of Signal Tones] Timing Signal Tone 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 Dial tone Busy tone...
Page 249 Chapter 3 INSTALLATION & WIRING This chapter describes installation and wiring procedures, including the installation and connection of the Exchange, stations, and various kinds of interface units.
Page 250: Chapter 3: Installation & Wiring
Chapter 3: INSTALLATION & WIRING 1. INSTALLATION OF THE EXCHANGE The N-8000EX/8010EX can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 1.1. Equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 251: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 1.1.3. N-8000EX/8010EX mounting N-8000EX/8010EX Rack mounting bracket Tapping screw 3 x 8 (supplied with the N-8000EX/8010EX) (supplied with the N-8000EX/8010EX) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000EX/8010EX) Step 1. Install the rack-mounting bracket to the N-8000EX/8010EX.
Page 252: Wall Mounting
Chapter 3: INSTALLATION & WIRING 1.3. Wall Mounting Step 1. Install the supplied wall-mounting bracket to the N-8000EX/8010EX using each 2 supplied screws and removed screws from the case. Wall mounting bracket (supplied with the N-8000EX/8010EX) Tapping screw 3 x 8 (removed from the case) N-8000EX/8010EX Tapping screw 3 x 8...
Page 253: Installation Of The Substation Interface Unit
Chapter 3: INSTALLATION & WIRING 2. INSTALLATION OF THE SUBSTATION INTERFACE UNIT The N-8000RS/8010RS/8400RS can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 2.1. Equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 254: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 2.1.3. N-8000RS/8010RS/8400RS mounting N-8000RS/8010RS/8400RS Tapping screw 3 x 8 (supplied with the N-8000RS Rack mounting bracket /8010RS/8400RS) (supplied with the N-8000RS /8010RS/8400RS) Rack mounting screw 5 x 12 with plain washer (supplied with the N-8000RS/8010RS/8400RS) Step 1.
Page 255: Wall Mounting
Chapter 3: INSTALLATION & WIRING 2.3. Wall Mounting Step 1. Install the optional YC-850 Wall mounting bracket to the N-8000RS/8010RS/8400RS. YC-850 Wall mounting bracket Machine screw M3 x 6 (supplied with the YC-850) N-8000RS/8010RS/8400RS Step 2. Mount the N-8000RS/8010RS/8400RS on the wall. Notes •...
Page 256: Installation Of The Multi Interface Unit
Chapter 3: INSTALLATION & WIRING 3. INSTALLATION OF THE MULTI INTERFACE UNIT The N-8000MI can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 3.1. Equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 257: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 3.1.3. N-8000MI mounting N-8000MI Tapping screw 3 x 8 Rack mounting bracket (supplied with the N-8000MI) (supplied with the N-8000MI) Step 1. Install the rack-mounting bracket to the Rack mounting screw 5 x 12 with plain washer N-8000MI.
Page 258: Wall Mounting
Chapter 3: INSTALLATION & WIRING 3.3. Wall Mounting Step 1. Install the supplied wall-mounting bracket to the N-8000MI using 4 removed screws from the case. Wall mounting bracket (supplied with the N-8000MI) Tapping screw 3 x 8 (removed from the case) N-8000MI Tapping screw 3 x 8 (removed from the case)
Page 259: Installation Of The Direct Select Unit
Chapter 3: INSTALLATION & WIRING 4. INSTALLATION OF THE DIRECT SELECT UNIT The N-8000DI can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 4.1. Equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 260: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 4.1.3. N-8000DI mounting N-8000DI Tapping screw 3 x 8 Rack mounting bracket (supplied with the N-8000DI) (supplied with the N-8000DI) Step 1. Install the rack-mounting bracket to the Rack mounting screw 5 x 12 with plain washer N-8000DI.
Page 261: Wall Mounting
Chapter 3: INSTALLATION & WIRING 4.3. Wall Mounting Step 1. Install the optional YC-850 Wall mounting bracket to the N-8000DI. YC-850 Wall mounting bracket Machine screw M3 x 6 (supplied with the YC-850) N-8000DI Step 2. Mount the N-8000DI on the wall. Notes •...
Page 262: Installation Of The Audio Interface Unit,C/O Interface Unit And Telephone Interface Unit
Chapter 3: INSTALLATION & WIRING 5. INSTALLATION OF THE AUDIO INTERFACE UNIT,C/O INTERFACE UNIT AND TELEPHONE INTERFACE UNIT The N-8000AF/8000CO/8000AL can be installed in any of three ways: (1) equipment rack mounting, (2) wall mounting, and (3) desk-top installation. 5.1. Equipment Rack Mounting A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
Page 263 Chapter 3: INSTALLATION & WIRING 5.1.2. N-8000AF/8000CO/8000AL mounting Use the optional mounting hardware set when installing the unit in an equipment rack. [When mounting a single unit] Use the optional MB-15B-BK hardware set. Component parts of MB-15B-BK Tapping screw 3 x 14 Tapping screw 3 x 8 N-8000AF/8000CO/8000AL Blank bracket...
Page 264: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 5.2. Desk-Top Installation When installing the N-8000AF/8000CO/8000AL on a desk, secure the supplied plastic feet to the unit's bottom using the supplied machine screws. Machine screw M3 x 8 (supplied with the N-8000AF/8000CO/8000AL) Plastic foot (supplied with the N-8000AF/8000CO/8000AL) N-8000AF/8000CO/8000AL...
Page 265 Chapter 3: INSTALLATION & WIRING Step 2. Mount the N-8000AF/8000CO/8000AL on the wall. Notes • Use appropriate screws for the construction of wall. • Wood screws 3.5 x 20 are supplied with the YC-850. • The socket-outlet shall be installed near the equipment and the plug (disconnecting device) shall be easily accessible.
Page 266: Installation Of Master Stations
Chapter 3: INSTALLATION & WIRING 6. INSTALLATION OF MASTER STATIONS Master stations can be installed in either of two ways: (1) wall mounting or (2) desk-top installation. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.
Page 267: Wall Hanging
Chapter 3: INSTALLATION & WIRING 6.2. Wall Hanging 6.2.1. N-8000MS/8010MS/8020MS/8410MS/8500MS/8510MS/8600MS The station can be mounted on a wall using an optional YC-280 Wall-mounting bracket. The YC-280 can be installed to a one-gang electrical box. [Mounting example] Station YC-280 Wall mounting bracket Wall surface Hook...
Page 268 Chapter 3: INSTALLATION & WIRING [YC-280 dimensional drawing] 4.6 x 6 Unit: mm Rubber foot mounting position (desk-top application) 2-ø4.5 4.5 x 10 [Installation completion drawing] • N-8000MS/8010MS/8410MS/8500MS/8510MS/8600MS Unit: mm YC-280 YC-280 72.1 83.5 • N-8020MS Unit: mm YC-280 YC-280 76.2 106.5 3-20...
Page 269 Chapter 3: INSTALLATION & WIRING 6.2.2. N-8011MS The station can be mounted on a wall using an optional YC-290 Wall mounting bracket. The YC-290 can be installed to a one-gang electrical box. [Mounting example] Station YC-290 Wall mounting bracket Wall surface Hook Wood screw 3.5 x 20...
Page 270 Chapter 3: INSTALLATION & WIRING 4.6 x 6 [YC-290 dimensional drawing] Unit: mm Rubber foot mounting position (desk-top application) 2-ø4.5 4.5 x 10 [Installation completion drawing] • N-8011MS Unit: mm YC-290 YC-290 72.1 3-22...
Page 271: Desk-Top Installation
Chapter 3: INSTALLATION & WIRING 6.3. Desk-Top Installation 6.3.1. N-8000MS/8010MS/8020MS/8410MS/8500MS/8510MS/8600MS In desktop installations, the front operation panel can be inclined 16˚ from the desk surface for easier operation by attaching the YC-280 Wall mounting bracket to its bottom surface. [Mounting example] Hang the wall mounting bracket hook on the station's wall bracket mounting slot to install.
Page 272 Chapter 3: INSTALLATION & WIRING 6.3.2. N-8011MS In desktop installations, the front operation panel can be inclined 16˚ from the desk surface for easier operation by attaching the YC-290 Wall mounting bracket to its bottom surface. [Mounting example] Station YC-290 Wall mounting bracket Rubber foot (supplied with the YC-290) Hook...
Page 273: Flush Mounting
Chapter 3: INSTALLATION & WIRING 6.4. Flush Mounting [N-8031MS] Attach the N-8031MS to the YC-241 Back box or an electrical box installed in a wall. Wall Wall surface surface Acoustic material (supplied with the N-8031MS) Note Lay it down along the inside of the box. N-8031MS YC-241 Back box or 5-gang electrical box...
Page 274 Chapter 3: INSTALLATION & WIRING [YC-241 dimensional drawing] Unit: mm 83.5 4-φ6 10-M4 Dimension of knockout hole A: φ27.1 B: φ21.5 C: φ34 3-26...
Page 275: Wall Surface Mounting
Knockout holes Note When installing the MS-8033 outdoors or at locations where it gets wet with water, tightly seal the panel edges. For sealing method, consult your TOA dealer. [Installation completion drawing] Unit: mm Seal the panel edges. 3-27...
Page 276 Chapter 3: INSTALLATION & WIRING [YC-841 dimensional drawing] Unit: mm 6-φ5 Knockout hole φ12.7 Knockout hole φ20.9 Knockout hole 4-M4 φ12.7 Knockout hole φ20.9 Knockout hole 3-28...
Page 277: Wall Surface Mounting
Chapter 3: INSTALLATION & WIRING 6.5. Wall Surface Mounting [N-8031MS] Attach the N-8031MS to the YC-251 Wall-mount box installed on a wall. Wall surface Acoustic material (supplied with the N-8031MS) Note Lay it down along the inside of the box. YC-251 Wall-mount box N-8031MS Machine screw M4 x 25...
Page 278 (waterproof type). For the cord bush, contact the After installing the N-8033MS, TOA dealer where the unit was check first if the conversations purchased. can be made, then attach the both ends of the adhesive sheet YC-841 bottom to the N-8033MS’s front surface...
Page 279: Flush Mounting
Chapter 3: INSTALLATION & WIRING 7. INSTALLATION OF DOOR STATIONS Door station N-8050DS/8540DS/8640DS/8650DS can be installed in either of two ways: (1) flush mounting or (2) wall surface mounting. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.
Page 280 N-8500DS/8540DS's front panel. the N-8050DS/8540DS with coating. For the coating method, consult your TOA dealer. • Treat unused cables so as not to short-circuit. (N-8640DS only) [YC-150 dimensional drawing] Unit: mm 4-φ6...
Page 281 Chapter 3: INSTALLATION & WIRING [N-8650DS] Mount the panel mount frame to the YC-150 Back box or 3-gang electrical box installed in a wall, then attach the N-8650DS to the panel mount frame. Step 1. Mount the panel mount frame to the YC-150 Step 2.
Page 282 Chapter 3: INSTALLATION & WIRING 7.2. Wall Surface Mounting [N-8050DS/8540DS/8640DS] Attach the N-8050DS/8540DS/8640DS to the YS-13A Wall-mount box installed on a wall. N-8640DS only N-8050DS only Wall Install the YC-13A with its rear surface Acoustic material (supplied with the N-8050DS) plate removed.
Page 283 N- 8050DS/8540DS with coating. For the coating method, Wall surface consult your TOA dealer. • Treat unused cables so as not to short-circuit. (N-8640DS The figure represents the N-8050DS/8540DS. only)
Page 284 Chapter 3: INSTALLATION & WIRING [N-8650DS] Attach the N-8650DS to the YS-13A Wall-mount box installed on a wall. Step 1. Mount the panel mount frame to the back Step 2. Attach the N-8650DS to the panel mount box. frame. Hook the tabs on the N-8650DS's upper side into the panel mount frame's slots, fit them into place, then secure the both bottom sides with a screw.
Page 285: Flush Mounting
Chapter 3: INSTALLATION & WIRING 8. INSTALLATION OF SUBSTATIONS The Substations can be installed in either of 2 ways: flush mounting using the YC-302 2-gang electrical box or commercial electrical box, or wall surface mounting using the YC-822/823 Wall-mount box. Note When using the PA paging function, keep the station as far away from the PA paging speaker as possible to avoid acoustic feedback.
Page 286 Chapter 3: INSTALLATION & WIRING [YC-302 dimensional drawing] [Outlet box] [Cover] Unit: mm 3-φ21.5 (Knockout hole) 4-M4 2-φ27.1 (Knockout hole) 2-M4 4-φ21.5 (Knockout hole) 4-φ27.1 (Knockout hole) 3-38...
Page 287 Chapter 3: INSTALLATION & WIRING 8.2. Wall Surface Mounting Attach the Substation to the YC-822 or YC-823 Wall-mount box installed on a wall. Wall surface Substation YC-822/823 Machine screw M4 x 25 (supplied with the substation) Note In the case of the YC-823, install it facing the ø6 weep hole side down.
Page 288 Chapter 3: INSTALLATION & WIRING [YC-822 dimensional drawing] Unit: mm 4-M4 (for substation mounting) 8-5×7 oval hole (for wall mounting) φ28 (Knockout hole) φ28 hole [YC-823 dimensional drawing] Unit: mm 4-M4 (for substation mounting) 8-5×7 oval hole (for wall mounting) φ28 hole φ6 weep hole 3-40...
Page 289: Flush Mounting
Chapter 3: INSTALLATION & WIRING 9. INSTALLATION OF SWITCH PANEL Switch panel RS-140/143/144 can be installed in either of two ways: (1) flush mounting or (2) wall surface mounting. 9.1. Flush Mounting Mount the Switch panel to the YC-801 Flush-mount box or electrical box mounted in the wall. Wall surface Machine screw M4 x 30 (supplied with the RS-140/143/144)
Page 290 Chapter 3: INSTALLATION & WIRING [YC-801 dimensional drawing] Unit: mm 2-φ6 2-M4 Dimension of knockout hole A: φ21.5 B: φ27.1 3-42...
Page 291 Chapter 3: INSTALLATION & WIRING 9.2. Wall Surface Mounting Attach the Switch panel to the YC-802 Wall-mount box installed on a wall. Wall surface Machine screw M4 x 30 (supplied with the RS-140/143/144) RS-140 83.5 mm YC-802 Wall-mount box Mounting bracket (supplied with the RS-140/143/144) UNC No.
Page 292 Chapter 3: INSTALLATION & WIRING [YC-802 dimensional drawing] Unit: mm φ34 knockout hole 50.5 22.5 4-double knockout hole 4-7x5 3-44...
Page 293: Installation Of Option Handset
Chapter 3: INSTALLATION & WIRING 10. INSTALLATION OF OPTION HANDSET Option handset RS-141/191/481 can be installed in a wall. Mount the option handset to the YC-302 or electrical box mounted in the wall. YC-302 or electrical box Wall surface Machine screw M4 x 25 (supplied with the RS-141/191/481) Option handset Note: This figure represents the RS-191.
Page 294: Wiring
Chapter 3: INSTALLATION & WIRING 11. WIRING 11.1. Exchange Connection N-8000EX/8010EX Exchange 16 lines Be sure to ground. Mini-clamp connector 232D-02S1B-DA5 (DDK) (Supplied with the N-8000EX/8010EX) To AC mains or a UPS (Uninterruptible power supply system)* Note If there is a danger of lightning strikes, insert an appropriate power gap arrester into the power line.
Page 295 Chapter 3: INSTALLATION & WIRING N-8000EX only N-8000EX/8010EX Exchange RJ-45 connector To network Removable terminal plug (supplied with the N-8000EX) Control input PA Paging amplifier, etc Line input [General description of connection] For cables, refer to 3-73. 1. Power supply connection 4.
Page 296: Connections Of Stations Used In Conjunction With The Exchange
Chapter 3: INSTALLATION & WIRING 11.2. Connections of Stations Used in conjunction with the Exchange 11.2.1. Station and Exchange connection The cables from the N-8000EX Exchange to the Station have no polarity. [N-8000MS/8010MS/8011MS] To connect the cables from the N-8000EX Exchange to the Master Station, use the connection cable supplied with each station and a commercially available RJ-11 modular jack.
Page 297 Chapter 3: INSTALLATION & WIRING [N-8031MS/8033MS] To connect the cables from the N-8000EX Exchange to the Master station, use the removable terminal plug (2P) supplied with the N-8031MS/8033MS. Refer to p. 3-75 "Terminal plug connection." To the exchange via the Terminal Board Twisted pair cable Removable terminal plug (2p) (supplied with the N-8031MS/8033MS)
Page 298 Chapter 3: INSTALLATION & WIRING 11.2.3. External speaker terminals and control output terminals connections [N-8000MS] These terminals are designed for exclusive connection with external speakers. Press down the desired push-in terminal button on the rear panel with a tip of standard driver, and insert the cable securely.
Page 299 Chapter 3: INSTALLATION & WIRING Step 4. After inserting the cables in the supplied rubber bushing, insert the bushing into the station, then put the protection cover back in place. Protection cover Protection cover fixing screw (the screw removed in Step 1) Since wire leads can be pinched, make them as short as possible.
Page 300 Chapter 3: INSTALLATION & WIRING 11.2.5. N-8031MS/8033MS and external switch connections External switches such as footswitches can be connected to the N-8031MS's/8033MS's external dial input terminal. Note The cable length from the external switch should not exceed 3 m. [Connections] 8 mm Press down.
Page 301: N-8000Rs/8010Rs Substation Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.3. N-8000RS/8010RS Substation Interface Unit Connection N-8000RS/8010RS Substation interface unit 16 lines Brown RJ-45 connector Be sure to ground. Orange 3P removable terminal plug To AC mains or a UPS (supplied with the N-8000RS (Uninterruptible power supply To network /8010RS) system)*...
Page 302: Connections Of Stations Used In Conjunction With The N-8000Rs/8010Rs
Chapter 3: INSTALLATION & WIRING 11.4. Connections of Stations Used in conjunction with the N-8000RS/8010RS 11.4.1. RS-180 and external relay connections External Diode RS-180 power supply Relay Blue (HOT) – 24 V DC White (COM) Open collector output: 24 V DC, Max. 30 mA Note: Cut out the control cables if they are not used to avoid short-circuiting.
Page 303 Chapter 3: INSTALLATION & WIRING 11.4.4. RS-140/142/143/144, RS-141, and speaker connections N-8000RS/8010RS Substation interface unit 3P removable terminal plug (supplied with the N-8000RS/8010RS) Brown Orange 2-core shielded cable RS-140/142/143/144 Brown Red (B) Orange (C) Yellow (C+) Green (B+) N.C. Blue (A+) Purple (H) Note: This figure represents...
Page 304: N-8400Rs Substation Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.5. N-8400RS Substation Interface Unit Connection N-8400RS Substation interface unit 16 lines RJ-45 connector Be sure to ground. 4P removable terminal plug (supplied with the N-8400RS) To AC mains or a UPS To network (Uninterruptible power supply system)* Two pairs of twisted pair cable Note If there is a danger of lightning strikes,...
Page 305: Connections Of Stations Used In Conjunction With The N-8400Rs
Chapter 3: INSTALLATION & WIRING 11.6. Connections of Stations Used in conjunction with the N-8400RS 11.6.1. Station and substation interface unit connections [N-8410MS] [RS-450/460/470/480] N-8400RS Substation interface unit N-8400RS Substation interface unit 4P removable terminal plug 4P removable terminal plug (supplied with the N-8400RS) (supplied with the N-8400RS) Two pairs of twisted pair cable...
Page 306 Chapter 3: INSTALLATION & WIRING 11.6.2. RS-480 and external relay connections External Diode RS-480 power supply Relay Blue (HOT) – 24 V DC White (COM) Open collector output: 24 V DC, Max. 30 mA Note: Cut out the control cables if they are not used to avoid short-circuiting. 11.6.3.
Page 307: Multi Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.7. Multi Interface Unit Connection N-8000MI 9P removable terminal plug (supplied with the N-8000MI) Be sure to ground this terminal unless the unit connects to a PBX. (For grounding in PBX connection, refer to 3-61.) Contact input signals Contact output signals Contact input signals...
Page 308 Chapter 3: INSTALLATION & WIRING N-8000MI Input volume controls RJ-45 connector 8P removable terminal plug To network (supplied with the N-8000MI) Mini-clamp connector 232D-02S1B-DA5 (DDK) (supplied with the N-8000MI) To the tie-line unit of intercom system or the PBX's analog E&M interfaces Control input Line output * Control output...
Page 309 Chapter 3: INSTALLATION & WIRING [Connecting to the PBX's analog E&M interface] Connect the PBX's transmitting line to the unit's RX terminal, and the PBX's receiving line to the TX terminal. Also connect the PBX's M (Mouth) line to the unit's E (Ear) terminal, and the PBX's E line to the M terminal. N-8000MI's PBX interface terminal To PBX's ground point To PBX analog E&M interface's M and E lines...
Page 310: Direct Select Unit Connection
Chapter 3: INSTALLATION & WIRING 11.8. Direct select Unit Connection N-8000DI Direct select unit Be sure to ground. To AC mains or a UPS (Uninterruptible power supply system)* Contact input signals Contact input signals Note If there is a danger of lightning strikes, insert an appropriate surge arrester into the power line.
Page 311 Chapter 3: INSTALLATION & WIRING N-8000DI Direct select unit RJ-45 connector To network Contact output signals Contact output signals 16P removable terminal plug (supplied with the N-8000DI) Contact output signals Contact output signals 3. Contact output terminal connection 4. Network connection Contact output terminals have no polarity.
Page 312: Audio Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.9. Audio Interface Unit Connection N-8000AF Audio interface unit Be sure to ground. RJ-45 connector To AC mains or a UPS To network (Uninterruptible power supply system)* Contact input Contact output signals signals Note If there is a danger of lightning strikes, insert an appropriate surge arrester into the power line.
Page 313 Chapter 3: INSTALLATION & WIRING 3. Audio input terminal connection 5. Contact input terminal connection Connect the microphone, audio device, etc. to this (Refer to 3-75, Terminal plug connection.) terminal using the two-core shielded cable. [Specification of no-voltage make contact input] (Refer to 3-75, Terminal plug connection.) Short-circuit current: 5 mA...
Page 314: C/O Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.10. C/O Interface Unit Connection N-8000CO C/O interface unit Be sure to ground. RJ-45 connector To network To AC mains or a UPS (Uninterruptible power supply system)* Mini-clamp connector Note 232D-02S1B-DA5 (DDK) (supplied with the N-8000CO) If there is a danger of lightning strikes, insert an appropriate surge arrester...
Page 315: Telephone Interface Unit Connection
Chapter 3: INSTALLATION & WIRING 11.11. Telephone Interface Unit Connection N-8000AL Telephone interface unit Be sure to ground. RJ-45 connector To network To AC mains or a UPS (Uninterruptible power supply system)* Mini-clamp connector 232D-02S1B-DA5 (DDK) Note (supplied with the N-8000AL) If there is a danger of lightning strikes, insert an appropriate surge arrester...
Page 316: Ip Station Connection
* Use the AC adapter AD-1210P/1215P (optional) 4. Network connection terminal connection or the equivalent. Can be connected to a network of 10BASE- As for the usable adapter, consult your TOA T/100BASE-TX in auto-sensing. dealer. Connecting the station to a PoE (Power over Ethernet) switching hub compliant with 2.
Page 317 Ferrite clamp (supplied with the N-8510MS) * Use the AC adapter AD-1210P/1215P (optional) or the equivalent. As for the usable adapter, consult your TOA dealer. 2. Message start terminal connection Press down the desired push- in terminal button with a tip of standard driver, and insert the cable securely.
Page 318 Connect the AC adapter*. ø3.5 mm mini jack. * Use the AC adapter AD-1210P/1215P (optional) Connect the headset speaker. or the equivalent. As for the usable adapter, consult your TOA 4. Headset microphone connection dealer. ø3.5 mm mini jack. Connect the headset microphone.
Page 319 * Use the AC adapter AD-1210P/1215P (optional) Connecting the station to a PoE (Power over or the equivalent. Ethernet) switching hub compliant with As for the usable adapter, consult your TOA IEEE802.3af eliminates the need for an AC dealer. adapter. (For connection, refer to the instruction manual supplied with the switching hub.)
Page 320 Can be connected to a network of 10BASE- * Use the AC adapter AD-1210P/1215P (optional) T/100BASE-TX in auto-sensing. or the equivalent. Connecting the station to a PoE (Power over As for the usable adapter, consult your TOA Ethernet) switching compliant with dealer.
Page 321: Type Of Cable
Chapter 3: INSTALLATION & WIRING 11.13. Type of Cable The types of cables are to be determined according to the following conditions. • To use twisted pair wires (such as those used for electronic push-button telephone) for wiring between the Exchange and the stations, for wiring between the N-8400RS Substation interface unit and the N-8410MS Master station or the RS-450/460/470/480 Substations, and for connections to the Multi interface unit's audio input/output terminals and PBX interface terminals.
Page 322: Relations Between Core Diameter Of Cable And Maximum Cable Length
Chapter 3: INSTALLATION & WIRING 11.14. Relations Between Core Diameter of Cable and Maximum Cable Length Refer to the following chart as guidelines when designing the distance between the Exchange and stations so that loop resistance value becomes 170 or less. Conductor diameter Maximum cable length between the Exchange and station.
Page 323: Connector Connection
Chapter 3: INSTALLATION & WIRING 11.15. Connector Connection 11.15.1. Mini-clamp connector connection Connect the mini-clamp connector supplied with the N-8000EX,N-8010EX,N-8000MI,N-8000CO,N-8000AL to a cable using a commercially available tool (pliers). Step 1. Cut off two-cable ends in equal length, and insert them Cover (transparent side) securely to a cover section (transparent side) of the mini-clamp connector.
Page 324 Chapter 3: INSTALLATION & WIRING Step 2. Loosen the terminal screws and insert the cables. Step 3. Tighten the terminal screws securely. Notes • Tug lightly on the cable to be sure that it does not pull free. If the cable pulls free, loosen the terminal screw again and reconnect from Step 2.
Page 325: Chapter 4 : System Design Flow
Chapter 4 SYSTEM DESIGN FLOW This chapter describes system setting items and switching on power to the system.
Page 326: System Design Precautions
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 1. SYSTEM DESIGN PRECAUTIONS System and equipment settings must be performed before operating the N-8000 Series systems. Three different methods are available for individual settings, and the details of these methods are explained in each of the following chapters.
Page 327: Network Settings Using A Personal Computer
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 4. NETWORK SETTINGS USING A PERSONAL COMPUTER Network settings involving the use of a PC can vary depending on the network configuration. No particular care need be taken within the LAN (i.e. the range within which broadcast transmission is permitted), however some planning regarding the enabling of settings is required for configurations extending beyond the perimeter of the LAN.
Page 328 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… [Setting procedures] Step 1. Using a system setting PC* , set a network* for Exchanges, Various kinds of interface units, and IP stations that permit broadcast communications with this PC. PC (A) in the illustration on the previous page LAN (A) in the illustration on the previous page Use the supplied N-8000 Setting Software program's unit scan function to perform settings.
Page 329 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5. SYSTEM SETTING ITEMS AND DEFAULT All system setting items except the auto-dialing programming can be set using the N-8000 Setting Software. Some setting items, however, can also be set on the browser or at stations. The browser can only make the connected Exchange-, Various kinds of interface units-, or IP station-related items, while stations can only make the connected Exchange- or their own stations-related items.
Page 330 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.2. Exchange Reference Side TAB Item Default page Network settings IP address 1, 2, 3 192.168.1.1 p. 5-23 1, 2, 3 255.255.255.0 p. 6-5 Subnet Mask p. 7-8 1, 2, 3 Default Gateway 0.0.0.0 p.
Page 331 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Audio trigger time-out Function settings Time limit 10 seconds Paging with call tone p. 5-29 Delay time Paging response mode Zone number designation response mode Paging priority mode Paging priority Calling station indication During call and talk...
Page 332 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.3. Multi Interface Unit Reference Side TAB Item Default page Network settings IP address 1, 2 192.168.1.1 p. 5-31 1, 2 255.255.255.0 Subnet Mask p. 6-5 1, 2 Default Gateway 0.0.0.0 Web server port number * 1, 2 p.
Page 333 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Audio I/O Input mode Unused p. 5-38 Output mode Unused Level 1 Input sensitivity access number p. 5-39 Paging zone Output level Level 4 Line attributer Wink start Line start Contact inputs Contact Input No.
Page 334: Sub Stations
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.4. Sub Stations Reference Side TAB Item Default page Network settings 1, 2 IP address * 192.168.1.1 p. 5-43 1, 2 Subnet Mask * 255.255.255.0 p. 6-5 1, 2 Default Gateway * 0.0.0.0 Web server port number * 1, 2 p.
Page 335: Ip Stations
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.5. IP Stations Reference Side TAB Item Default page Network settings 1, 2, 3 IP address 192.168.1.1 p. 5-51 1, 2, 3 p. 6-5 Subnet Mask 255.255.255.0 p. 7-8 1, 2, 3 Default Gateway 0.0.0.0 Web server port number * 1, 2...
Page 336 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Function settings 2 Incoming call mode Automatic connection mode p. 5-58 with call tone Microphone sensitivity Level 2 p. 5-58 Speaker output Level 3 p. 2-5 Station speaker sound volume Level 3 p.
Page 337 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Onetouch dial Speed dialing p. 5-61 p. 2-12 Master calling p. 5-61 Auto Dial p. 2-11 Scan monitor Scan monitor sequencing time 3 seconds p. 5-62 Monitor Alert None Scan monitor group Message Paging...
Page 338: Stations
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.6. Stations Reference Side TAB Item Default page Function settings Incoming call mode Automatic connection mode p. 5-65 with call tone Microphone sensitivity Level 2 Speaker output Level 3 p. 5-65 p. 2-5 Station speaker sound volume Level 3 p.
Page 339 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Onetouch dial p. 5-68 Speed dialing p. 2-12 Master calling p. 5-68 p. 2-11 Auto Dial Scan monitor Scan monitor sequencing time 3 seconds p. 5-69 Monitor Alert None Scan monitor group •...
Page 340: C/O Interface
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.7. C/O Interface Reference Side TAB Item Default page Network settings 1, 2 IP address 192.168.1.1 p. 5-70 1, 2 Subnet Mask 255.255.255.0 p. 6-5 1, 2 Default Gateway 0.0.0.0 Web server port number * 1, 2 p.
Page 341: Telephone Interface
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.8. Telephone Interface Reference Side TAB Item Default page Network settings 1, 2 IP address 192.168.1.1 p. 5-78 1, 2 255.255.255.0 Subnet Mask p. 6-5 1, 2 Default Gateway 0.0.0.0 Web server port number * 1, 2 p.
Page 342 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Function settings 2 Level 2 Microphone sensitivity Speaker output Level 3 p. 5-84 Station speaker sound volume Level 3 Group call member Call forwarding destination station p. 5-84 p.
Page 343: Audio Interface
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.9. Audio Interface Reference Side TAB Item Default page Network settings 1, 2 IP address 192.168.1.1 p. 5-87 1, 2 255.255.255.0 Subnet Mask p. 6-5 1, 2 Default Gateway 0.0.0.0 Web server port number * 1, 2 p.
Page 344 Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… Reference Side TAB Item Default page Schedule Settings Paging No. p. 5-94 Source Access to external control • All of the above items can be set on the N-8000 Setting Software. 4-20...
Page 345: Direct Select
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.10. Direct Select Reference Side TAB Item Default page Network settings 1, 2 IP address 192.168.1.1 p. 5-95 1, 2 255.255.255.0 Subnet Mask p. 6-5 1, 2 Default Gateway 0.0.0.0 Web server port number * 1, 2 p.
Page 346: Paging
Chapter 4: BEFORE PERFORMING SYSTEM SETTINGS… 5.11. Paging Reference Side TAB Item Default page Paging Paging No. digit Paging port 6000 (to 6039) p. 5-102 Paging Zone Name Select stations and external PA paging p. 5-103 outputs • All of the above items can be set on the N-8000 Setting Software. 5.12.
Page 347: Chapter 5 : System Settings By Software
Chapter 5 SYSTEM SETTINGS BY SOFTWARE This chapter describes how to install and use the N-8000 system settings software.
Page 348: N-8000 Setting Software General Description
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 1. N-8000 SETTING SOFTWARE GENERAL DESCRIPTION 1.1. General Description The supplied N-8000 Setting Software program is for performing system settings and features following two functions. 1.1.1. Equipment scan and network setting functions Detect the Exchange, various kinds of interface units, and IP station connected to the local network, and then perform equipment network settings.
Page 349: Installing Software
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 2. INSTALLING SOFTWARE 2.1. System Requirements This program has been designed based on the following system requirements. • OS: Windows XP Professional SP2 or later/Vista Business/7 Professional • CPU: Pentium 2 GHz or greater •...
Page 350: Required Component Installation
Chapter 5: SYSTEM SETTINGS BY SOFTWARE If your Web browser is not JavaScript-enabled, the screen at right will be displayed. Press the English button to display English screens. 2.3. Required Component Installation To activate the N-8000 Setting Software program, the following components are required. •...
Page 351: N-8000 Setting Software Installation
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 2.4. N-8000 Setting Software Installation 2.4.1. Installation Step 1. Press [Installation start] button in the "N-8000 Setting Software Installation" section on the N- 8000 Setting Software Setup Guide screen to start software program installation. Step 2.
Page 352 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Step 5. Press [Next] button. The screen ready for program installation is displayed. Step 6. Press [Next] button to install the software program into the selected folder. The setup completion screen is displayed when the installation is correctly completed.
Page 353 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 2.4.3. Folder configuration The N-8000 Setting Software program is installed in the default location C:\Program Files\TOA\N-8000. The system setting file is created in the location (1) for Windows 2000/XP or (2) for Windows Vista/7 as...
Page 354: Activating N-8000 Setting Software Program
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 3. ACTIVATING N-8000 SETTING SOFTWARE PROGRAM Step 1. Double-click the shortcut icon created on the desk-top screen when installing, or double-click the ConfigurationSoft.exe created in the installed folder directly. [System Selection] screen is displayed. (1) New System (3) Import button Creates a new system.
Page 355 Chapter 5: SYSTEM SETTINGS BY SOFTWARE After system name and password have been entered correctly, N-8000 Setting Software program initial screen is displayed. Step 3. Click [Unit Scan (Network Settings)] when detecting equipment. Step 4. Click [System Settings] when setting system. Step 5.
Page 356: Unit Scan (Network Settings)
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 4. UNIT SCAN (NETWORK SETTINGS) These functions enable the detection and network setting of Exchanges, various kinds of interface units, and IP stations connected to the local area network. The equipment detection function can only be used within the effective broadcast range (refer to 8-9).
Page 357: Changing Equipment Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 4.2. Changing Equipment Settings 4.2.1. Single Unit Selection and Activation Select the device to be changed on the Equipment IP Setting screen, then click "Change IP Settings" button. The following screen shows an example in which a single device is activated after it has been selected on the Equipment IP Setting screen.
Page 358: System Setting Function
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 5. SYSTEM SETTING FUNCTION Performs individual system settings. Use the Unit Scan/Network Setting function, a browser, an N-8000MS Multifunctional station, or an N-8500MS/8600MS IP Multifunctional station to set the IP address correctly, then use this System Setting function to update the exchange's, various kinds of interface units, or IP station's setting data.
Page 359: Menu
Chapter 5: SYSTEM SETTINGS BY SOFTWARE (7) C/O Interface tab (10) Direct Select tab Perform settings related to the C/O interface unit. Perform settings related to the Direct select unit. Available tabs include: [Network Settings], Available tabs include: [Network Settings], [Function Settings 1], [Function Settings 2] and [Function Settings], [Contact Input] and [Contact [Scan Monitor].
Page 360: Overall System Configuration Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Equipment Registration 5.2.3. Help About : Displays the version number of this software program. 5.3. Overall System Configuration Settings Click "General" tab. 5.3.1. Equipment registration Determines the configuration of the equipment connected to the network within the system and register it. Program data can be entered manually, or it can be imported using data scan for the Equipment using the Unit Scan/Network Setting function.
Page 361 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Equipment Registration [Screen description] (1) Starting Equipment Number Enter the first unit number to be set. Unit numbers of 1 – 192 are automatically assigned in sequential order starting with the number entered here. However, duplicated numbers cannot be assigned.
Page 362 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Equipment Registration Step 3. Set the Equipment name, Model, IP Address, and Web Port. These items can be set directly by clicking and editing the data in each cell, or by importing equipment data detected using the Unit Scan/Network Setting function.
Page 363 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Station Table 5.3.2. Station number and type settings Step 1. Click "Station Table" tab to display the setting screen. Step 2. Select the number of digits in the station number. Step 3.
Page 364 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Station Table (6) Station name Set the name of each station using up to eight alphanumeric characters. Station names can be displayed on multifunctional stations. [Collective setup] Pressing the Collective setup button permits station types, station numbers, and station names for all or selected stations to be set all at once.
Page 365 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Network Communication Registration 5.3.3. Network communications registration Enables or disables unicast network communications among equipment connected to the network. Step 1. Click "Network Communication Registration" tab to display the following setting screen. Step 2.
Page 366 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: Multicast Registration 5.3.4. Multicast communications registration Enables or disables Multicast communications among equipment connected to the network. When multicast communications are an available option, performing this registration conserves network bandwidth by allowing multicast paging.
Page 367 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: System Settings 5.3.5. System settings registration Perform settings common to the entire system. Step 1. Click "System Settings" tab to display the following setting screen. (1) Response Mode Set the Response Mode.
Page 368 Chapter 5: SYSTEM SETTINGS BY SOFTWARE General: System Settings (4) DST (Summer time) Settings Set daylight saving time. with DST: Set whether or not to enable daylight saving time. Start/End: Set the date and time to start and end daylight saving time. Designate it in the format [hour] of [day] of [nth week] of [month].
Page 369: Exchange Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Network Settings 5.4. Exchange Settings Click "Exchange" tab to select the exchange to be set. Choose the name or number of the exchange from the list. 5.4.1. Network settings Step 1.
Page 370 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 371 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Network Settings (6) Network ID When connecting a PC to the exchange using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 372 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Exchange is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
Page 373 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Sampling Frequency Correction 5.4.2. Sampling frequency correction settings Step 1. Click "Sampling Frequency Correction" tab to display the following setting screen. Step 2. Set individual items. (1) Sampling Frequency Correction Select this tab when setting the transfer of sampling frequency correction data between different networks.
Page 374 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Function Settings 5.4.3. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Transfer settings Set the transfer function ON or OFF for the station connected to the exchange. Call forwarding: Calls to stations are automatically transferred to another designated station without sounding a call tone only when Call forwarding function is...
Page 375 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Function Settings (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station. If setting a time-out, enter the time limit after which calls to the station are automatically terminated.
Page 376 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Exchange: Function Settings (10) Calling station indication Select either "During call and talk" or "During talk" mode when performing the calling station indication function. The table below shows the timing that the Multi interface unit's or Direct select unit's contact output is closed.
Page 377: Multi Interface Unit Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Network Settings 5.5. Multi Interface Unit Settings Click "Multi Interface" tab to select the multi interface unit to be set. Choose the name or number of the multi interface unit from the list. 5.5.1.
Page 378 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 379 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Network Settings (6) Network ID When connecting a PC to the multi interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 380 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Multi interface unit is connected.
Page 381 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Sampling Frequency Correction 5.5.2. Sampling frequency correction settings Step 1. Click "Sampling Frequency Correction" tab to display the following setting screen. Step 2. Set individual items. (1) Sampling Frequency Correction Select this tab when setting the transfer of sampling frequency correction data between different networks.
Page 382 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Function Settings 5.5.3. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily.
Page 383 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Function Settings (3) Aux input paging Allows external input broadcasts to take precedence over all-zone paging and individual zone paging. (4) Delay Time Set the delay time before paging is initiated. (5) Paging response mode Select either "Zone Selection"...
Page 384 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Audio I/O 5.5.4. Audio I/O settings Step 1. Click on the Audio I/O tab. The corresponding setting screen is displayed. Step 2. Perform settings for each item of Audio I/O Ch 1 and Ch 2. Set how to use the Multi-interface unit's Audio input and output terminals.
Page 385 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Audio I/O (2) Output mode Setting "Input mode" to "Aux input paging," "BGM" or "Unused" permits "PA paging" to be selected. Tie-line: Select this item when connecting the Multi interface unit to the exchange of different series intercom system (EXES-2000 or EXES-6000 series system).
Page 386 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Contact Input 5.5.5. Contact input setting Step 1. Click on the Contact Input tab. The setting screen is displayed. Step 2. Set each item of "Contact input." (1) Contact input No.
Page 387 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Contact Input Aux input paging: Select this item when activating playback components or other devices connected to the Multi interface unit's audio input terminal from the control input. Paging busy 1: Select this item when sending externally-connected paging equipment's busy status data to the Audio output 1.
Page 388 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Multi Interface: Contact Output 5.5.6. Contact output setting Step 1. Click on the Contact Output tab. The setting screen is displayed. Step 2. Set each item of "Contact output." Set the access number for the contact output terminal to be activated when the station performs external equipment control (one-shot make output or make/break output).
Page 389: Setting Sub-Station Interface
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Network Settings 5.6. Setting Sub-station Interface Click "Sub-station-interface" tab to select the Sub-station Interface to be set. Choose the name or number of the Sub-station Interface unit from the list. 5.6.1.
Page 390 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 391 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Network Settings (6) Network ID When connecting a PC to the Sub-station interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 392 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Sub-station interface unit is connected.
Page 393 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Function Settings 5.6.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds.
Page 394 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Function Settings (3) Paging response mode Select either "Zone Selection" or "Automatic response" modes when responding to the paging. Zone Selection: Responds to a paging call by designating the number of the paging zone. Respond to the paging party who made the paging to the designated zone last is called.
Page 395 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Sub-station Settings 5.6.3. Sub-station Settings Step 1. Click "Sub-station Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Common settings Set common functions of all substations to be connected to the substation interface unit. Call master: Enter the master station number to be called when each station's "Call 1"...
Page 396 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Sub-station Interface: Sub-station Settings Calling station indication/CCTV control Control output: Set the Multi interface unit's or Direct select unit's number and contact output terminal number, which provide a make signal when the station is called.
Page 397: Setting Ip Stations
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Network Settings 5.7. Setting IP Stations Click "IP Station" tab to select the IP station to be set. Choose the name or number of the IP station from the list. 5.7.1.
Page 398 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 399 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Network Settings (6) Network ID When connecting a PC to the IP station using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 400 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the IP station is connected. Setting this communication capacity prevents sound quality deterioration and longer time delays caused by excess conversation and/or paging communications traffic.
Page 401 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 1 5.7.2. Function settings Step 1. Click "Function Settings 1" tab to display the following setting screen. Available item differs depending on the type of IP stations. Step 2.
Page 402 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 1 (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station.
Page 403 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 1 (9) Calling station indication Select either "During call and talk" or "During talk" mode when performing the calling station indication function. The table below shows the timing that the Multi interface unit's or Direct select unit's contact output is closed.
Page 404 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 2 Step 3. Click "Function Settings 2" tab to display the following setting screen. Available item differs depending on the type of IP stations. Step 4.
Page 405 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 2 (5) Priority call (Selective response mode, IP door station only) Call priorities can be adjusted in five increments from 1 (minimum) to 5 (maximum). Level 5 is the same priority as an emergency call.
Page 406 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Function Settings 2 (12) Door station mode (IP door station only) Set whether to operate the IP door station in door station mode*. * The call tone sounds only once at the IP door station when the IP door station calls the pre-programmed master station.
Page 407 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Speed Dialing 5.7.3. Speed dialing settings Step 1. Click "Speed Dialing" tab to display the following setting screen. Available item differs depending on the type of stations. Step 2.
Page 408 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Scan Monitor 5.7.4. Scan Monitor settings (IP master station only) Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.
Page 409 Chapter 5: SYSTEM SETTINGS BY SOFTWARE IP Station: Message Paging 5.7.5. Message Paging settings (IP master station only) Step 1. Click "Message Paging" tab to display the following setting screen. Step 2. Mark the [Operate message paging] checkbox. This allows the following items to be set. Step 3.
Page 410: Setting Stations Connected To The Exchange, And Analog Master Stations Connected To The Substation Interface Unit
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Function Settings 5.8. Setting Stations Connected to the Exchange, and Analog Master Stations Connected to the Substation Interface Unit Click "Station" to select the station to be set. Choose the number of the exchange, exchange name, line number, station number or station name from the list.
Page 411 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Function Settings Step 2. Set individual items. (1) Incoming call mode Call receiving mode 2-10) can be selected either "Automatic Connection" or "Continuous Call". Call with a call tone or without a call tone can be set on both modes. The door station is fixed to "Automatic connection"...
Page 412 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Function Settings (8) Calling station indication/CCTV control Control output : Set the Multi interface unit's or Direct select unit's number and contact output terminal number, which provide a make signal when the station is called. Called station's No.: Provides a make contact when the station to be set here is called.
Page 413 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Function Settings (12) Trigger (Door station only) Selects the trigger. Level: Detects sounds of a sound pressure level higher than the set level that last for a specified period of time.
Page 414 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Speed Dialing 5.8.2. Speed dialing settings Step 1. Click "Speed Dialing" tab to display the following setting screen. Available item differs depending on the type of stations. Step 2.
Page 415 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Station: Scan Monitor 5.8.3. Scan monitor settings Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.
Page 416: Setting C/O Interface
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Network Settings 5.9. Setting C/O Interface Click "C/O Interface" tab to select the C/O Interface to be set. Choose the number of the C/O interface unit or name from the list. 5.9.1.
Page 417 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 418 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Network Settings (6) Network ID When connecting a PC to the C/O interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 419 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Function Settings1 (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the C/O interface unit is connected.
Page 420 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Function Settings1 Step 2. Set individual items. (1) Calling station indication/CCTV control Control output : Set the Multi interface unit's or Direct select unit's number and contact output terminal number, which provide a make signal when the station is called.
Page 421 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Function Settings2 Step 1. Click "Function Settings 2" tab to display the following setting screen. Step 2. Set individual items. (1) C/O Setting Name: Set the name of the C/O line. (2) Timeout Timeout: Set the time interval for automatic termination of conversations ( 1 –...
Page 422 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Function Settings2 Member: Up to 3 member stations can be simultaneously called up when the representative station receives a call. Note If the representative station has not been set, calls are not made to the member stations. (5) Paging with call tone Sounds a pre-announcement tone when paging is initiated.
Page 423 Chapter 5: SYSTEM SETTINGS BY SOFTWARE C/O Interface: Scan Monitor 5.9.3. Scan monitor settings Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.
Page 424: Setting Telephone Interface
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Network Settings 5.10. Setting Telephone Interface Click "Telephone Interface" tab to select the Telephone Interface to be set. Choose the number of the Telephone Interface unit or name from the list. 5.10.1.
Page 425 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 426 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Network Settings (6) Network ID When connecting a PC to the Telephone interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 427 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Telephone interface unit is connected.
Page 428 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Function Settings1 5.10.2. Function settings Step 1. Click "Function Settings 1" tab to display the following setting screen. Step 2. Set individual items. (1) Transfer settings Set the transfer function ON or OFF for the station connected to the exchange.
Page 429 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Function Settings1 (3) Time limit Set the time-out value for calling, conversation or paging functions in ten-second units between 10 and 990 seconds. Call time-out: Set whether to limit the duration of a call to the station. If setting a time-out, enter the time limit after which calls to the station are automatically terminated.
Page 430 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Function Settings2 Step 1. Click "Function Settings 2" tab to display the following setting screen. Step 2. Set individual items. (1) Level Microphone sensitivity: Station hands-free microphone sensitivity can be adjusted in three increments from 1 (minimum) to 3 (maximum).
Page 431 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Function Settings2 (4) Door remote Set the Multi interface unit's or Direct select unit's unit number and contact output terminal number to be used for door remote control. (5) Calling station indication/CCTV control Control output : Set the Multi interface unit's or Direct select unit's unit number and contact output...
Page 432 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Telephone Interface: Scan Monitor 5.10.3. Scan Monitor settings Step 1. Click "Scan Monitor" tab to display the following setting screen. Step 2. Set the scan monitor sequencing time in 1-second units from 1 to 10 seconds. Step 3.
Page 433: Setting Audio Interface
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Network Settings 5.11. Setting Audio Interface Click "Audio Interface" tab to select the Audio Interface to be set. Choose the number of the Audio interface unit or name from the list. 5.11.1.
Page 434 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 435 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Network Settings (6) Network ID When connecting a PC to the Audio interface unit using the global IP address, enter the number that identifies networks for each range accessible by the PC using the local address. When networks are connected as shown below, for example, assign different ID numbers for each, such as "1"...
Page 436 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Network Settings (9) Available bit rate Set the capacity (or a usable upper limit value) of the network line to which the Audio interface unit is connected.
Page 437 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Function Settings 5.11.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set individual items. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily.
Page 438 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Function Settings (4) Input level Set the audio input sensitivity. (5) Time sync function Set the Time sync function. Adjust enable: Set whether or not to enable the time sync function. Start time/End time: Set time ranges that make the time sync function operable.
Page 439 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Function Settings (3) External control External equipment can be set to be activated when the timer-controlled or time signal programs are initiated. Equipment No.: Select the equipment number of the Multi interface unit, Direct select unit, or Audio interface unit of which operation mode is set to "Time signal."...
Page 440 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Audio Interface: Function Settings (2) Detail Detailed contents of events can be set and confirmed. Name: Set an event name. Set the name of each event using up to eight alphanumeric characters. Time: Set the time that the event takes place.
Page 441: Setting Direct Select
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Network Settings 5.12. Setting Direct Select Click "Direct Select" tab to select the Direct Select to be set. Choose the number of the Direct select unit or name from the list. 5.12.1.
Page 442 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Network Settings (4) Port No. Set the start port number to be used for each protocol. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 443 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Network Settings (8) WAN Port No. Set the start port number to be used for each protocol as viewed from the WAN side. [Web server] Allows entry of the Web server's port number. The valid range is from 1 to 65535. The default factory setting is 80.
Page 444 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Function Settings 5.12.2. Function settings Step 1. Click "Function Settings" tab to display the following setting screen. Step 2. Set the following item. (1) Oneshot make time (second) Sets the duration that the external control output terminals are shorted momentarily.
Page 445 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Contact Input 5.12.3. Contact input setting Step 1. Click "Contact Input" tab to display the following setting screen. Step 2. Set each item of "Contact input." (1) Contact input No.
Page 446 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Contact Input Remote dial control: When the Multi interface unit's or Direct select unit's contact input terminal is closed, a station is made to automatically perform dial operation. A set of up to 20 dial codes (including dial numbers and key operations) can be assigned to each contact input terminal.
Page 447 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Direct Select: Contact Output 5.12.4. Contact output setting Step 1. Click "Contact Output" tab to display the following setting screen. Step 2. Set each item of "Contact output." Set the access number for the contact output terminal to be activated when the station performs external equipment control (one-shot make output or make/break output).
Page 448: Paging Zone Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Paging Zone Settings 5.13. Paging Zone Settings Step 1. Click "Paging" to display the following setting screen. Step 2. Select the paging number digit. Select the number for [Paging No. digit]. Zones are automatically indicated depending on which number is set.
Page 449 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Paging Zone Settings Step 5. Select stations, external PA paging outputs, and N-8000MI/8000AF's contact outputs included in each zone. Pressing the down arrow button of the paging zone to be set displays individual buttons containing output destination information (station, PA paging output, or N-8000MI/8000AF's contact output).
Page 450: Group Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Group: Group Blocking Group 5.14. Group Settings Step 1. Click "Group" to set either Group Blocking or Remote Response group. 5.14.1. Group blocking settings Stations can be divided into groups, to each of which call-to-other groups setting and paging zone setting can be assigned.
Page 451 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Group: Group Blocking To [Group blocking group settings] Step 1. Click "Group Blocking To" tab to display the following screen. Note The screen above is an example that Group 1 selects calling groups and paging zones. Step 2.
Page 452 Chapter 5: SYSTEM SETTINGS BY SOFTWARE Chapter 5: SYSTEM SETTINGS BY SOFTWARE Group: Remote Response Group 5.14.2. Remote response group settings Setting the remote response station group permits any station programmed for this function to respond to calls to other stations within the group. Up to 16 stations can be preset.
Page 453: When Settings Are Completed
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 6. WHEN SETTINGS ARE COMPLETED 6.1. Saving Setting Contents to Files Save the setting contents to a specified location (refer to p. 5-7). Select [File Save] from the menu bar. 6.2. Uploading Settings Uploads setting contents currently being edited. Before uploading, be sure to save the settings contents to file as described above.
Page 454: Printing Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 6.4. Printing Settings The settings in edit can be printed. Select [File Print] from the menu bar. The set data of the equipment registered in the system can be printed. [Print example] 5-108...
Page 455: System Clock Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 7. SYSTEM CLOCK SETTINGS The N-8000 Setting Software program allows the clocks for all exchanges, various kinds of interface units, and IP stations connected to the system to be set. To set exchange clocks individually (for example, if there is a time difference between exchanges), use either the browser (refer to 6-42), the N-8000MS Multifunctional Master station, or the N-8500MS/8600MS IP Multifunctional Master station (refer to...
Page 456: Message Paging Settings
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8. MESSAGE PAGING SETTINGS Create and set the messages to be used in the IP Master Station’s message paging. 8.1. Display the Setting Screen Clicking [Message Paging Settings] on the initial screen displays the Message Paging Setting screen. [Initial screen] [Message Paging Setting screen] (1) List of Original Messages...
Page 457: Menu
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.2. Menu 8.2.1. File New: Creates a new message. Save: Saves the message. Save As: Assigns a name to the message and saves it. Delete: Deletes the message. Rename File: Changes the name of the message. Read WAVE File: Creates original messages by converting WAV-format files to the original format.
Page 458: Create And Test-Listen To The Original Messages
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.3. Create and Test-Listen to the Original Messages Click the [List of Original Messages] tab on the message paging setting screen. The list of original messages that have been created is displayed. (10) [Screen description] (1) Recording/playback progress indicator Pressing the Save button after moving the knob Progress bar indicates the progress of the...
Page 459 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.3.1. Creating new messages Connect the input source (microphone, external playback device, etc.) to be recorded to the PC. The recording sound volume corresponds to the input sound volume set in the PC. Set the PC sound volume to an appropriate level.
Page 460 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.3.4. Creating messages from WAV-format files WAV-format file can be converted to original format files and saved as original messages. Note The compatible WAV-format file specifications are: • 16 bits and 16 kHz sampling frequency •...
Page 461 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.3.6. Test-listening to messages Step 1. Select the message to listen to from the list of created messages. Step 2. Press the Playback button or select [Edit Playback] from the menu bar. The message automatically stops after being played to its end.
Page 462: Registering Messages In The Ip Master Station
Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.4. Registering Messages in the IP Master Station Click the [Message Registration] tab on the message paging settings screen. [Screen description] (1) Siren tone selection (6) Clear all button The currently selected siren tone is displayed Clears all selection of stations.
Page 463 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.4.1. Test-listening to a siren tone Step 1. Select the desired siren tone from the pull-down menu. Step 2. Press the Test-listen button. The selected siren tone plays and automatically stops upon reaching its end. The test siren tone is played back on the PC together with the announcement "This is a sample."...
Page 464 Chapter 5: SYSTEM SETTINGS BY SOFTWARE 8.4.4. Registering messages from the PC to the IP Master Stations Step 1. Designate the message to be transferred to the IP Master Stations. The message to be transferred can be selected by dragging and dropping them from the messages list to the stations list.
Page 465 Chapter 6 SYSTEM SETTINGS USING THE BROWSER This chapter describes browser network settings, and system maintenance functions.
Page 466: Chapter 6: System Settings Using The Browser
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 1. OUTLINE OF SETTINGS USING BROWSER Network settings can be updated and maintenance functions controlled by connecting to all exchanges, various kinds of interface units and IP stations in the system via the PC's browser*. If an exchange, interface unit or IP station is not within range for the PC to administrate broadcast communications, use another PC to enable communications with all exchanges, various kinds of interface units and IP stations in the system.
Page 467: Displaying The Menu Screen
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 3. DISPLAYING THE MENU SCREEN Note Perform the PC's network setting in advance to allow the PC to communicate with all exchanges, various kinds of interface units and IP stations in the system. The user authentication screen will not be displayed unless the PC's network setting completed.
Page 468 Chapter 6: SYSTEM SETTINGS USING THE BROWSER The setting menu screen is displayed once you have entered the correct user name and the password. The screen below is an example for the N-8000EX. Note Use the menu located on the left of the screen to display each setting screen. These screens will not be displayed properly using the browser's "Back"...
Page 469: Network Setting
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 4. NETWORK SETTING Click "Network Setting" on the menu on the left of the screen. The screen below is an example for the N-8000EX. (1) IP Address Enter the IP address of the exchange, interface unit or IP station. (factory-preset: 192.168.1.1) (2) Subnet Mask Set the subnet mask.
Page 470: Operation Status Display
Chapter 6: SYSTEM SETTINGS USING THE BROWSER (6) Save button Write set data into the settings file in the equipment. Notes • The status indicator located on the equipment remains lit during the write process. Do not switch off or restart the power or remove the LAN cable while the light is on.
Page 471 Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response." (2) Line No.
Page 472: N-8000Rs/8010Rs
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.2. N-8000RS/8010RS The screen below is an example for the N-8000RS. Note Only 1 link is displayed in the N-8010RS. [Operation buttons] (1) Refresh Updates status data for speech path and line. (2) Line No. and Terminal No. buttons Used to display line numbers or station numbers for each station.
Page 473: N-8400Rs
Chapter 6: SYSTEM SETTINGS USING THE BROWSER (2) Calling Station Displays the number of the calling station. (3) Called Station Displays the number of the called station. (4) Station on hold Displays the number of the station on hold. (5) Status Displays the operating status of the speech path.
Page 474 Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response." (2) Terminal No.
Page 475: N-8000Mi
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.4. N-8000MI [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and Line No. buttons Used to display line numbers or station numbers for each station. [Link status] Displays the Multi interface unit's current link status.
Page 476 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (4) Station on hold Displays the number of the station on hold. (5) Status Displays the operating status of the speech path. [Contact] Displays the Multi interface unit's current contact status. Pressing the Refresh button updates data. (1) Contact No.
Page 477: N-8000Di
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.5. N-8000DI [Operation buttons] (1) Refresh Updates status data for contact. [Contact] Displays the Direct select unit’s current contact status. Pressing the Refresh button updates data. (1) Contact No. Direct select unit’s contact input and output terminal numbers. (2) Input Current status of the contact input terminal is displayed.
Page 478: N-8000Af
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.6. N-8000AF [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and Line No. buttons Used to display line numbers or station numbers for each station. [Link status] Displays the Audio interface unit’s current link status.
Page 479: N-8000Co
Chapter 6: SYSTEM SETTINGS USING THE BROWSER (4) Status Displays the operating status of the speech path. [Contact] Displays the Audio interface unit’s current contact status. Pressing the Refresh button updates data. (1) Contact No. Audio interface unit’s contact input and output terminal numbers. (2) Input Current status of the contact input terminal is displayed.
Page 480 Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Operation buttons] (1) Refresh Updates status data for speech path and line. (2) Terminal No. and Line No. buttons Used to display line numbers or station numbers for each station. [Link status] Displays the C/O interface unit’s current link status. Pressing the Refresh button updates this data. (1) Calling Station Displays the number of the calling station.
Page 481: N-8000Al
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.8. N-8000AL Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
Page 482 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Automatic transfer Displays the station number to which calls to the Telephone interface unit are to be automatically transferred.
Page 483: N-8500Ms/8510Ms
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.9. N-8500MS/8510MS The screen below is an example for the N-8500MS. Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
Page 484 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Call receiving Displays the call tone mode of the IP master station. (6) Automatic transfer Displays the station number to which calls to the IP master station are to be automatically transferred.
Page 485: N-8600Ms
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.10. N-8600MS Only when the system is set to "Selective Response" mode [Operation buttons] (1) Refresh Updates status data for speech path, line, and call-in*. * Call-in status refers to one station being called by others when the N-8000 system's call response mode is set to "Selective Response."...
Page 486 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Call receiving Displays the call tone mode of the IP master station. (6) Automatic transfer Displays the station number to which calls to the IP master station are to be automatically transferred.
Page 487: N-8540Ds
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.11. N-8540DS [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and Line No. buttons Used to display line number or station number. [Operation status] Displays the IP door station's current status of speech path and line. Pressing the Refresh button updates data. (1) Calling Station Displays the number of the calling station.
Page 488: N-8640Ds/8650Ds
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 5.12. N-8640DS/8650DS The screen below is an example for the N-8640DS. [Operation buttons] (1) Refresh Updates status data for speech path, line, and contact. (2) Terminal No. and Line No. buttons Used to display line number or station number. [Operation status] Displays the IP door station's current status of speech path and line.
Page 489 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (3) Station on hold Displays the number of the station on hold. (4) Status Displays the operating status of the speech path. (5) Level Displays sound volume set for the IP door station. Indicator abbreviations are as follows: MIC: Microphone sensitivity Speaker output volume...
Page 490: Line Status Indication (Only For Exchange And Sub-Station Interface Unit)
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 6. LINE STATUS INDICATION (only for Exchange and Sub-station interface unit) 6.1. N-8000EX/8010EX Click "Line Status" on the menu on the left side of the screen. Displays information on line status and connected stations. The screen below is an example for the N-8000EX.
Page 491 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (3) Status Displays line status. (4) Call receiving Displays the call tone mode of the connected station. (5) Automatic transfer Displays the station number to which calls to the connected station are to be automatically transferred. (6) Level Displays sound volume set for the connected station.
Page 492: N-8000Rs/8010Rs
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 6.2. N-8000RS/8010RS Click "Line Status" on the menu on the left side of the screen. Displays information on line status and set stations. The screen below is an example for the N-8000RS. [Operation buttons] (1) Refresh Updates status data for line and set station to the latest data.
Page 493: N-8400Rs
Chapter 6: SYSTEM SETTINGS USING THE BROWSER (4) Level Displays sound volume set for the Sub station interface unit. Indicator abbreviations are as follows: MIC: Microphone sensitivity Speaker output volume Signal: Call tone volume 6.3. N-8400RS Click "Line Status" on the menu on the left side of the screen. Displays information on line status and connected stations.
Page 494 Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Line Status] Displays the setting contents of all the stations connected to the N-8400RS. The symbols "–" displayed in a row indicate that no connection is made to the line. (1) No. Line numbers (2) Model No.
Page 495: Network Status Indication
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 7. NETWORK STATUS INDICATION Click "Network Status" on the menu on the left side of the screen. Connections between all exchanges, various kinds of interface units and IP stations and networks within the system can be confirmed.
Page 496: Operation Log
Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Network status setting] (1) No. Equipment number of the exchange, various kinds of interface units or IP station. (2) IP Address IP address of the exchange, various kinds of interface units or IP station. (3) Status "OK"...
Page 497 Indicates the line on which an event occurred. Station and IP address numbers are displayed. Note If the indication "Firmware failed. Please contact our sales office." is displayed, the system is suffering a problem and could fail. In such cases, please contact TOA immediately. 6-33...
Page 498: Stream Log
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 9. STREAM LOG Click "Stream Log" on the menu on the left side of the screen. The stream log is a history of voice communications (both conversations and paging) carried over the IP network.
Page 499 Chapter 6: SYSTEM SETTINGS USING THE BROWSER [Past stream screen] The screen below is an example for the N-8000EX. [Past stream operation buttons] (1) Refresh Displays the last sixteen finished streams. (2) Prev. Page button Returns the display to the previous page. (3) Next Page button Advances the display to the next page.
Page 500 Chapter 6: SYSTEM SETTINGS USING THE BROWSER (4) Link Speech path number. (5) Direction Sending or receiving. (6) Fs Sampling frequency, either 8 kHz or 16 kHz. (7) Delay Time between voice input and output. (8) Packets Number of packets transmitted or successfully received. (9) Loss Number of packets lost due to network failures, which is counted at the receiving end only.
Page 501: System Management
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 10. SYSTEM MANAGEMENT Click "System Management" on the menu on the left side of the screen. The screen below is an example for the N-8000EX. [User Data] The system name and password can be changed (refer to 6-39).
Page 502 Use the latest version of firmware, which is released on the following our web site. Tips • Download the latest version of firmware from our site http://www.toa-products.com/international/. • The current version is displayed above the Firmware Update button. (6) Clock retrieve button Pressing this button displays the date and time of the connected PC's clock (refer to 6-42).
Page 503: Changing System Names And Passwords
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 10.1. Changing System Names and Passwords When adding the exchange, interface unit or IP station, or initializing the exchange, interface unit or IP station settings, the system name and password can be changed remotely using the browser even from locations where the system settings PC is not available.
Page 504: Downloading Setting File
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 10.3. Downloading Setting File Step 1. Press "Download" button to display "File Download" dialog. Step 2. Press "Save" button to display the dialog. Step 3. Select saving location, then enter file name. The default name is [IP address] .cfg. Step 4.
Page 505: Updating Firmware
Use the latest version of firmware, which is released on the following our web site. Tips • Download the latest version of firmware from our products data site http://www.toa-products.com/international/. • The current firmware version can be confirmed on the browser's system management screen. Step 3. Press "Firmware Update" button to start firmware updating.
Page 506: Clock Settings
Chapter 6: SYSTEM SETTINGS USING THE BROWSER 10.5. Clock Settings If there is a time difference between the exchange, interface unit or IP station system connected to the system, each exchange's time can be adjusted individually. When the red indication "Clock not set." is displayed in the "Clock setting"...
Page 507: Chapter 7 : Multifunctional Station Menu Screen Operation (N-8000Ms/8500Ms/8600Ms Only)
Chapter 7 MULTIFUNCTIONAL STATION MENU SCREEN OPERATION (N-8000MS/8500MS/8600MS only) This chapter describes the settings and displays available using the menu screen of the Multi-Functional Station and IP Multi-Functional Station.
Page 508: Keys Used For Menu Screen Operation
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 1. KEYS USED FOR MENU SCREEN OPERATION The following keys are used to operate the menu screen of the N-8000MS Multifunctional Master Station and the N-8500MS/8600MS IP Multifunctional Master Station. Liquid crystal display: Displays the menu screen. Selection key: Used for item selection and input value set.
Page 509: Menu Items
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 2. MENU ITEMS 1. Auto-dialing programming (refer to 2-11) Programs the contents into the Auto Dial key. Monitors the Line connection status of the Exchange. 2. Line monitor (refer to 7-4) Updates the operation log files of the Exchange or 3.
Page 510: Monitoring Line Status
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 3. MONITORING LINE STATUS Causes the station's LCD to display the connection status for all sixteen lines associated with the exchange to which the N-8000MS is connected. The N-8500MS/8600MS does not have the monitoring function. Step 1.
Page 511: Updating Log Files
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 4. UPDATING LOG FILES Update the file that stores the operation logs for the exchange or N-8500MS/8600MS*. Use this function when some malfunction has made it impossible to view the operation log via a PC (refer to 6-32, Browser Operation Log Display).
Page 512: Setting The Lcd Backlight (N-8600Ms Only)
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 6. SETTING THE LCD BACKLIGHT (N-8600MS only) ON/OFF of the N-8600MS’s LCD backlight can be set. Step 1. Press the Menu key to place the display in setting 1 : A u t o - d i a l i n g mode.
Page 513: System Settings
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 7. SYSTEM SETTINGS Only a portion of system setting items can be set at the Multifunctional Station. 7.1. Entering Maintenance Screen Step 1. Press the Menu key to place the display in setting 1 : A u t o - d i a l i n g mode.
Page 514: Network Settings
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 7.2. Network Settings It is possible to change the IP address, subnet mask, and default gateway of the exchange or N- 8500MS/8600MS*. * Exchange when the station performing setting is N-8000MS, and the N-8500MS/8600MS itself when it is the N- 8500MS/8600MS.
Page 515: Station Number Settings
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 7.3. Station Number Settings It is possible to set the station number for all stations and IP stations. Step 1. Using the up or down arrow keys or the [2] key on 1 : N e t w o r k s e t the maintenance screen, move the cursor to "2: Line 2 : L i n e A t t r i b u t e Attribute."...
Page 516: System Clock Settings
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION Step 6. Enter the station number (00-999999) of the E X 0 2 4 : L I N E 0 1 designated line using the dial keys, then press the 8 0 0 0 M S 2 0 0 0 Select key.
Page 517: Restarting The Equipment
Chapter 7: MULTIFUNCTIONAL STATION MENU SCREEN OPERATION 7.5. Restarting the Equipment Restart the exchange or N-8500MS/8600MS* when network settings have been changed. The exchange can be restarted at the Multifunctional Station even without pressing "Reset" key located on the exchange's front panel. * Exchange when the station performing restart is N-8000MS, and the N-8500MS/8600MS itself when it is the N-8500MS/8600MS.
Page 518 Chapter 8 APPENDIX...
Page 519: Chapter 8: Appendix
Chapter 8: APPENDIX 1. FULL DUPLEX AND HALF DUPLEX CONVERSATIONS 1.1. Speech Method The Packet Intercom system uses 5 types of methods for conversations between stations. For conditions in which these speech methods are used, refer to the table on 8-5.
Page 520 Chapter 8: APPENDIX 1.1.4. Full duplex conversation using echo canceller and voice switch This is a speech method using the Total set value of the echo canceller (see the previous page) microphone sensitivity in combination with the voice switch. In and speaker output [When only the echo canceller works] this method, the echo canceller works...
Page 521 Chapter 8: APPENDIX 1.1.5. Half duplex conversation by way of PTT operation When the PTT key is pressed, this permits one-way conversation from the key-operated station. Releasing the PTT key enables one- way conversation from the other party. When the PTT keys at both stations are pressed simultaneously, the last key-operated One-way conversation station takes precedence.
Page 522: A Difference Of Speech Method Depending On Usage Conditions Of The Station
Chapter 8: APPENDIX 1.2. A Difference of Speech Method Depending on Usage Conditions of the Station Packet Intercom system permits hands-free full duplex conversation. However, operations of an echo canceller or a voice switch could change depending on the stations to be used, conversation partner, or each station's usage condition (handset or hands-free conversation), resulting in half duplex conversation.
Page 523: What If You Failed To Make Conversation Properly
Chapter 8: APPENDIX 1.3. What If You Failed to Make Conversation Properly • For master stations, recalibrate by re-measuring ambient noise, if one-way conversation from the station in higher ambient noise area occurs. (Refer to 2-6.) • If the voice switches of the master and door stations do not flip properly, adjust the microphone sensitivity and speaker output volume of the stations.
Page 524: Network Address Port Translation (Napt, Ip Masquerade) And N-8000 Setting Software Program
Chapter 8: APPENDIX 2.2. Network Address Port Translation (NAPT, IP Masquerade) and N-8000 Setting Software Program Because the Internet cannot be accessed using the local IP address, the local IP address must be converted into global IP address by means of Network Address Port Translation (NAPT, IP Masquerade). Router 1 Router 2 Internet...
Page 525: Unicast Vs. Multicast Communications
Chapter 8: APPENDIX 2.3. Unicast vs. Multicast Communications When making paging calls via multiple exchanges, various kinds of interface units, or IP stations connected to a network, either "unicast" or "multicast" may be selected as the communication method. For unicast communications, separate data packets are created and sent individually to each destination IP address.
Page 526: Unit Scan And Broadcast Communications Domains
Chapter 8: APPENDIX 2.5. Unit Scan and Broadcast Communications Domains The broadcast communications method is utilized to detect equipment (exchange, any kind of interface unit, or IP station) connected to a network. Therefore, only equipment within the network's multicasting range will be detected.
Page 527: If Trouble Occurs
Chapter 8: APPENDIX 3. IF TROUBLE OCCURS: Symptom Potential Cause/Place to Inspect Remedy The exchange or any Power and cables may not be connected Connect the power source and cables kind of interface unit correctly. properly. does not operate. All indicators located on the equipment's Make sure the power is turned on.
Page 528 8500MS/8600MS only). The exchange Check to see if the exchange's front The exchange may be malfunctioning. generates excessive panel-mounted Status indicator flashes Contact your nearest TOA sales office heat. continuously. immediately. The system temporarily Check to see if the indication "Firmware...
Page 529 The switching hub may not be turned Turn on the switching hub. station. Station does not The cable may not be connected Connect the cable correctly. operate. correctly. A password has been Contact your nearest TOA dealer. – forgotten. 8-12...
Page 530: Indicator Status & Troubleshooting
Action to Take Normal operation or power – Rapid flashing* Failure of fan Contact your nearest TOA dealer. (in a cycle of 200 ms) Flashes three times in a Failure Contact your nearest TOA dealer. row (in a cycle of 200 ms) at one-second intervals.
Page 531: Specifications 5.1. N-8000Ex Ip Intercom Exchange
Chapter 8: APPENDIX 5. SPECIFICATIONS 5.1. N-8000EX IP Intercom Exchange Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 50 W (at rated), 75 W (max.) Interface Section for Station Number of Lines 16 lines Number of Speech Links Internal: 4/External: 8...
Page 532: N-8010Ex Ip Intercom Exchange
Chapter 8: APPENDIX 5.2. N-8010EX IP Intercom Exchange Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 50 W (at rated), 75 W (max.) Interface Section for Station Number of Lines 16 lines Number of Speech Links Internal: 4/External: 8...
Page 533: N-8000Ms Multifunctional Master Station
Chapter 8: APPENDIX 5.3. N-8000MS Multifunctional Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 534: N-8010Ms Standard Master Station
Chapter 8: APPENDIX 5.4. N-8010MS Standard Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 535: N-8011Ms Standard Hands-Free Master Station
Chapter 8: APPENDIX 5.5. N-8011MS Standard Hands-Free Master Station Power Source 48 V DC (supplied from the IP intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 536: N-8020Ms Industrial-Use Master Station
Chapter 8: APPENDIX 5.6. N-8020MS Industrial-Use Master Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 537: N-8031Ms Flush-Mount Master Station
Chapter 8: APPENDIX 5.7. N-8031MS Flush-Mount Master Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 538: N-8050Ds Door Station
Chapter 8: APPENDIX 5.9. N-8050DS Door Station Power Source 48 V DC (supplied from the IP Intercom exchange) Power Consumption 1.8 W (at rated), 2.4 W (max.) Wiring Method 1 set of twisted pair cable Transmission System 2 wire 160 kbps echo canceller transmission system Signal Level Under 0 dB* Speech Method...
Page 539: N-8500Ms Ip Multifunctional Master Station
Chapter 8: APPENDIX 5.10. N-8500MS IP Multifunctional Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free or handset conversation Audio Frequency Range 300 Hz –...
Page 540: N-8510Ms Ip Standard Master Station
Chapter 8: APPENDIX 5.11. N-8510MS IP Standard Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free or handset conversation Audio Frequency Range 300 Hz –...
Page 541: N-8600Ms Ip Multifunctional Master Station
Chapter 8: APPENDIX 5.12. N-8600MS IP Multifunctional Master Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption Use of the AC adapter (12 V DC): 2.5 W (station only) Use of the PoE (48 V DC): Speech Method Hands-free or handset conversation...
Page 542: N-8540Ds Ip Door Station
Chapter 8: APPENDIX 5.13. N-8540DS IP Door Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption 4.2 W (at rated), 6 W (max.) Speech Method Hands-free conversation Audio Frequency Range 300 Hz –...
Page 543: N-8640Ds Ip Door Station
Chapter 8: APPENDIX 5.14. N-8640DS IP Door Station Power Source Power supply device that complies with IEEE802.3af standard or 12 V DC (supplied from the AC adapter) Power Consumption Use of the AC adapter (12 V DC): 3.5 W (station only) Use of the PoE (48 V DC): Speech Method Hands-free conversation...
Page 544: N-8000Rs Substation Interface Unit
Chapter 8: APPENDIX 5.15. N-8000RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 40 W (at rated), 50 W (max.) CU version: 35 W (at rated), 45 W (max.) Interface Section for Sub-station Number of Lines 16 lines...
Page 545: N-8010Rs Substation Interface Unit
Chapter 8: APPENDIX 5.16. N-8010RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 32 W (at rated), 38 W (max.) CU version: 26 W (at rated), 32 W (max.) Interface Section for Substation Number of Lines 16 lines...
Page 546: Indoor Substation
Chapter 8: APPENDIX 5.17. RS-150 Indoor Substation Rated Input Rated Impedance 625 Ω (1 W/25 V) Internal Speaker 4 cm cone-type Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24) 800 m/ø0.65 mm (AWG22) 1300 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch) Finish Panel:...
Page 547: Outdoor Vandal-Resistant Substation
Chapter 8: APPENDIX 5.19. RS-170 Outdoor Vandal-Resistant Substation Rated Input Rated Impedance 625 Ω (1 W/25 V) Internal Speaker 4 cm cone-type Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24) 800 m/ø0.65 mm (AWG22) 1300 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch) Finish...
Page 548: Switch Panel
Chapter 8: APPENDIX 5.21. RS-140 Switch Panel Call Button Momentary Privacy Button Latching Indicator When called: Status indicator (red) flashing In conversation: Status indicator (red) lit In privacy: Privacy indicator (red) lit Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24), 800 m/ø0.65 mm (AWG22), 1300 m/ø0.9 mm (AWG19) Operating Temperature 0 to +40°C...
Page 549: Switch Board
Chapter 8: APPENDIX 5.23. RS-142 Switch Board Call Button Wiring 4 cables (for 2 momentary switches) Wiring 2-core shielded cable Transmission Range 500 m/ø0.5 mm (AWG24), 800 m/ø0.65 mm (AWG22), 1300 m/ø0.9 mm (AWG19) Operating Temperature 0 to +40°C Weight 30 g Note: The design and specifications are subject to change without notice for improvement.
Page 550: N-8400Rs Substation Interface Unit
Chapter 8: APPENDIX 5.26. N-8400RS Substation Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 30 W (at rated), 45 W (max.) CU version: 35 W (at rated), 50 W (max.) Interface Section for Substation Number of Lines 16 lines...
Page 551: Indoor Substation
Chapter 8: APPENDIX 5.27. RS-450 Indoor Substation Call Button Momentary (Emergency call: Press twice within 400 ms.) Rated Input Internal Speaker Cone-type Internal Mic Electret condenser type Wiring Twisted pair cables (2-pair) Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22), 2000 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)
Page 552: Outdoor Vandal-Resistant Substation
Chapter 8: APPENDIX 5.29. RS-470 Outdoor Vandal-Resistant Substation Call Button Momentary (Emergency call: Press twice within 400 ms.) Rated Input Internal Speaker Cone-type Internal Mic Electret condenser type Wiring Twisted pair cables (2-pair) Transmission Range 1000 m/ø0.5 mm (AWG24), 1500 m/ø0.65 mm (AWG22), 2000 m/ø0.9 mm (AWG19) Operating Temperature –10 to +50°C (Temperature range not to freeze the speaker and switch)
Page 553: Emergency Substation
Chapter 8: APPENDIX 5.30. RS-480 Emergency Substation Call Button Momentary (Emergency call: Press twice within 400 ms.) Rated Input Control Output Open collector, Maximum controlled voltage: 30 V DC, Control current: 30 mA Internal Speaker Cone-type Internal Mic Electret condenser type Indicator When called: Status indicator (red) flashing...
Page 554: N-8000Mi Multi Interface Unit
Chapter 8: APPENDIX 5.32. N-8000MI Multi Interface Unit Power Source CE version: 230 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption CE version: 19 W (180 mA) (at rated), 24 W (230 mA) (max.) CU version: 16 W (250 mA) (at rated), 21 W (330 mA) (max.) Audio Input Input : 2 inputs (2P/input), Max.
Page 555: N-8000Co C/O Interface Unit
Chapter 8: APPENDIX • Accessories AC power cord (2 m) ..........1 Machine screw M4 x 20 ......... 4 CD (for PC setting, maintenance use) ....1 Rack mounting bracket .......... 2 Removable terminal plug (9 pins) ......4 Tapping screw 3 x 8 ..........8 Removable terminal plug (8 pins) ......
Page 556: N-8000Af Audio Interface Unit
Chapter 8: APPENDIX 5.34. N-8000AF Audio Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 7 W (max.) Audio Input 1 input (transformer isolated), –58 to 0 dB*, 2 kΩ, balanced (MIC/LINE input, controllable on the software) with input volume control knob, removable terminal block (3 pins) Audio Output...
Page 557: N-8000Al Telephone Interface Unit
Chapter 8: APPENDIX 5.35. N-8000AL Telephone Interface Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 8W (max.) Telephone Interface Number of Telephone Lines 1 lines Selective Signal Type DTMF signal Monitoring Function Line Loop detection...
Page 558: N-8000Di Direct Select Unit
Chapter 8: APPENDIX 5.36. N-8000DI Direct Select Unit Power Source CE version: 220 – 240 V AC, 50/60 Hz CU version: 120 V AC, 50/60 Hz Power Consumption 16 W (max.) Contact Input 32 inputs, no-voltage make contact input, open voltage: 24 V DC, short-circuit current: 5 mA or less, removable terminal block (20 pins) (1 common terminal for 4 inputs) Contact Output...
Page 559: Yc-290 Wall Mounting Bracket
Chapter 8: APPENDIX 5.38. YC-290 Wall Mounting Bracket Finish Surface treated steel sheet, gray, paint Dimensions 64 (w) x 131.5 (h) x 31.8 (d) mm Weight 100 g Note: The design and specifications are subject to change without notice for improvement. •...
Page 560: Back Box
Chapter 8: APPENDIX 5.42. YC-150 Back Box Finish Zinc-plating, t1.6 Dimensions 184 (w) x 119 (h) x 57 (d) mm Weight 700 g Note: The design and specifications are subject to change without notice for improvement. • Applicable model N-8050DS/8540DS/8640DS/8650DS 5.43.
Page 561: Wall-Mount Box
Chapter 8: APPENDIX 5.46. YC-802 Wall-Mount Box Surface-treated steel plate, white Finish 75 (w) x 124 (h) x 50.5 (d) mm Dimensions Weight 360 g Note: The design and specifications are subject to change without notice for improvement. • Applicable model RS-140/143/144 5.47.
Page 562: Ad-1210P Ac Adapter
Chapter 8: APPENDIX 5.50. AD-1210P AC Adapter Model number AD-1210P CU AD-1210P CE Power Source 100 – 240 V, 50/60 Hz 230 V, 50 Hz Output 12 V DC, 1 A Current Consumption 270 mA (rated output) 120 mA (rated output) Cord Length 1.5 m 1.8 m...
Page 563 201110...

Toa N-8000 SERIES Operating Instructions Manual

Chapter 1 : GENERAL DESCRIPTION

Chapter 2 : FUNCTIONS and OPERATION

Chapter 3: INSTALLATION & WIRING

Chapter 4 : SYSTEM DESIGN FLOW

Chapter 5 : SYSTEM SETTINGS by SOFTWARE

Chapter 6: SYSTEM SETTINGS USING the BROWSER

Quick Links

Related Manuals for Toa N-8000 SERIES

Summary of Contents for Toa N-8000 SERIES
