Page 1 2 0 1 3 2 0 1 3 2 0 1 3 R A M C V R A M C V R A M C V O W N E R ’ S M A N U A L O W N E R ’...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of features Chrysler Group LLC shall be deemed to be deleted and the and equipment that are either standard or optional on this name Chrysler Canada Inc.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VAN CONVERSIONS/CAMPERS ... .6 HOW TO USE THIS MANUAL .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained tech- Congratulations on selecting your new Chrysler Group nicians and genuine parts, and cares about your satisfac- LLC vehicle. Be assured that it represents precision tion.
Page 7 INTRODUCTION 5...
Page 8: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS VAN CONVERSIONS/CAMPERS This Owners Manual contains WARNINGS against op- The New Vehicle Limited Warranty does not apply to erating procedures that could result in a collision or body modifications or special equipment installed by van bodily injury.
Page 9: Vehicle Identification Number
INTRODUCTION 7 Operating instructions for the special equipment in- VEHICLE IDENTIFICATION NUMBER stalled by the conversion/camper manufacturer should The Vehicle Identification Number (VIN) is found on the also be supplied with your vehicle. If these instructions left front corner of the instrument panel, visible through are missing, please contact your authorized dealer for the windshield.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Vehicle Identification Number NOTE: It is illegal to remove or alter the VIN.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .12 VEHICLE SECURITY ALARM — IF EQUIPPED ......17 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY (RKE) — SLIDING SIDE DOOR ....44 IF EQUIPPED ......21 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Supplemental Active Head Restraints (AHR) . . .68 COMMERCIAL CARGO VEHICLES (NO FACTORY INSTALLED REAR SEATS) — IF ▫ Enhanced Seat Belt Use Reminder System EQUIPPED......115 (BeltAlert®) .
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch.
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.
Page 16: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Removing Key Fob From Ignition WARNING! (Continued) Place the shift lever in PARK. Turn the Key Fob to the • Allowing children to be in a vehicle unattended is OFF position and then remove the Key Fob. dangerous for a number of reasons.
Page 17: Key-In-Ignition Reminder
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 SENTRY KEY® CAUTION! The Sentry Key® Immobilizer system prevents unauthor- An unlocked car is an invitation to thieves. Always ized vehicle operation by disabling the engine. The remove the Key Fob from the ignition and lock all system does not need to be armed or activated.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the bulb check, it indicates that someone used an invalid Replacement Keys Key Fob to start the engine. Either of these conditions will NOTE: Only Key Fobs that are programmed to the result in the engine being shut off after two seconds.
Page 19: Vehicle Security Alarm - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 NOTE: When having the Sentry Key® Immobilizer sys- VEHICLE SECURITY ALARM — IF EQUIPPED tem serviced, bring all vehicle Key Fobs with you to the The Vehicle Security Alarm monitors the vehicle doors authorized dealer.
Page 20: Rearming Of The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rearming Of The System 2. Perform one of the following methods to lock the vehicle: The Vehicle Security Alarm will rearm itself after the 15 • Press LOCK on the interior power door lock switch additional minutes of headlights and Vehicle Security with the driver and/or passenger door open.
Page 21: Tamper Alert
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 NOTE: Vehicle Security Alarm will arm regardless of whether you are in the vehicle or not. If you remain in the vehicle • The driver’s door key cylinder and the liftgate button and open a door, the alarm will sound.
Page 22: Security System Manual Override
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Security System Manual Override NOTE: • The front courtesy overhead console and door cour- The Vehicle Security Alarm will not arm if you lock the doors using the manual door lock plunger. tesy lights will not turn off if the dimmer control is in the “Dome ON”...
Page 23: Remote Keyless Entry (Rke)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 REMOTE KEYLESS ENTRY (RKE) — IF Two RKE transmitters may be supplied with the vehicle. EQUIPPED Vehicles built without the powered options will be equipped from the factory with three-button RKE trans- This system allows you to lock or unlock the doors and mitters, and those built with power options will be liftgate, and activate the Panic Alarm, optional power...
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key Fob With Three-Button RKE Transmitter Key Fob With Seven-Button RKE Transmitter Seven-button RKE transmitters will provide functions that Remote Unlock Doors And Liftgate allow the same basic operation as the three-button, but may Press and release the UNLOCK button on the RKE also be used to operate the power liftgate (optional), power transmitter once to unlock the driver’s side or twice to...
Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Remote Key Unlock On First Press 2. Press and hold the LOCK button on a programmed RKE transmitter for at least 4 seconds, but no longer This feature lets you program the system to unlock either than 10 seconds.
Page 26 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the Remote Lock Doors And Liftgate following steps: Press and release the LOCK button on the RKE transmit- ter to lock all doors and liftgate. The turn signal lights 1.
Page 27 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: Pressing the LOCK button on the RKE transmit- NOTE: ter while you are in the vehicle will activate the Vehicle • When you turn off the Panic Alarm by pressing the Security Alarm.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If equipped with a rear interior switch on the left rear If the vehicle is locked and the Vehicle Security Alarm is pillar, pushing this switch once will close the liftgate only. armed, pressing the LEFT Power Sliding Door button The liftgate cannot be opened from this switch.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Turn Off Flash Lights With RKE Lock — If 2. Press and hold the UNLOCK button on a programmed Equipped RKE transmitter for at least 4 seconds, but no longer than 10 seconds. Then, press and hold the LOCK This feature will cause the turn signal lights to flash when button while still holding the UNLOCK button.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Programming Additional Transmitters If you do not have a programmed RKE transmitter, contact your authorized dealer for details. Transmitter Battery Replacement The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate •...
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 Inserting Emergency Key Into Slot Separating RKE Transmitter 3. Remove and replace the battery. When replacing the battery, match the + sign on the battery to the + sign on the inside of the battery clip, located on the back cover. Avoid touching the new battery with your fingers.
Page 32: Remote Starting System - If Equipped
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. To assemble the RKE transmitter case, snap the two 2. Closeness to a radio transmitter such as a radio station halves together. tower, airport transmitter, and some mobile or CB radios. General Information REMOTE STARTING SYSTEM —...
Page 33: How To Use Remote Start
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 • System not disabled from previous remote start event How To Use Remote Start • Vehicle theft alarm not active All of the following conditions must be met before the engine will Remote Start: •...
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Start Abort Message On Electronic Vehicle To Enter Remote Start Mode Information Center (EVIC) — If Equipped The following messages will display in the EVIC if the Press and release the REMOTE START button vehicle fails to remote start or exits remote start prema- on the RKE transmitter twice within five sec- turely:...
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 • For security, power window and power sunroof op- To Exit Remote Start Mode And Drive The Vehicle eration (if equipped) are disabled when the vehicle is Before the end of the 15-minute cycle, press and release in the Remote Start mode.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Cancel Remote Start To Turn Off The Engine While In Remote Start Mode Remote Starting will also cancel if any of the following occur: Press and release the REMOTE START button 1 time or allow the engine to run for the entire 15 minute cycle.
Page 37: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 DOOR LOCKS Manual Door Locks Lock the front doors by pushing down on the lock knobs on each door trim panel. If the lock knob is down when you shut either front door, the door will lock.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be seriously or fatally injured.
Page 39: Power Door Locks - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 WARNING! (Continued) • Do not leave the key fob in or near the vehicle, or in a location accessible to children, and do not leave a vehicle equipped with Keyless Enter-N- Go™ in the ACC or ON/RUN position. A child could operate power windows, other controls, or move the vehicle.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE operate. A chime will sound if the Key Fob is in the If you press the power door lock switch while the sliding ignition switch and a door is open, as a reminder to door is open, the sliding door will lock.
Page 41: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 The Unlock Doors Automatically On Exit feature will not operate if there is any manual operation of the power door locks (lock or unlock). On vehicles equipped with the optional Electronic Ve- hicle Information Center (EVIC), refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)”...
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Window Lockout Switch — If Equipped The driver may lock out the rear power windows by depressing the bar switch just below the power window switches. Driver’s Power Window Switches NOTE: Power Window switches will also remain active for up to 10 minutes after the ignition switch has been turned to OFF, depending upon the accessory delay setting.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Front Passenger Power Window Switch There is a single switch on the front passenger’s door trim panel which operates the passenger door window and a set of switches that lock and unlock all doors. The switches will operate only when the ignition switch is in the ON/RUN or ACC position and during power acces- sory delay.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto-Down Feature — If Equipped Auto Up Feature With Anti-Pinch Protection — If Equipped The front window switches may be equipped with an Auto-Down feature. Press the window switch past the The front driver and front passenger switches may be detent, release, and the window will go down automati- equipped with an Auto Up feature.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 NOTE: Auto Up Reset — If Equipped • If the window runs into any obstacle during auto- To reactivate the Auto Up feature, perform the following steps after vehicle power is restored: closure, it will reverse direction and then go back down.
Page 46: Sliding Side Door
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The switches will operate only when the ignition switch NOTE: The sliding door windows do not fully open, is in the ON/RUN or ACC position and during power stopping several inches above the window sill. accessory delay.
Page 47: Power Sliding Side Door - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 rocking forward and back. Rocking the handle back- Always make sure that the sliding door is fully latched wards opens the door and rocking forward releases the anytime the vehicle is in motion. hold open latch in order to close the door.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Pulling the outside power sliding door handle a second time while the sliding door is power opening or power closing will allow the sliding door to be opened or closed manually. Press the button on the RKE transmitter twice within 5 seconds to open a power sliding door.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 • If the power sliding door encounters multiple obstruc- master lock button, located in the overhead console, to disable the switches and handles for the rear seat tions within the same cycle, the system will automati- passengers.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Sliding Side Door Open Flash Power Sliding Side Door Master Lock Switch The left and right exterior hazard lights will flash for 12 To provide a safer environment for small children riding seconds when either sliding door is opened.
Page 51: Sliding Side Door Child Protection Lock
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Sliding Side Door Child Protection Lock To provide a safer environment for small children riding in the rear seats, the sliding doors are equipped with a Child Protection Door Lock system. NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When the Child Protection Door Lock system is en- gaged, (even if the inside door lock is in the unlocked position) the door can be opened only by using the outside door handle, the RKE transmitter, the switches on the overhead console or the switches located on the trim panel just in front of the power sliding door.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 NOTE: WARNING! • After setting the Child Protection Door Lock system, Avoid trapping anyone in the vehicle in a collision. always test the door from the inside to make certain it Remember that the sliding doors can only be opened is in the desired position.
Page 54: Liftgate
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LIFTGATE On vehicles equipped with power locks, the liftgate can be unlocked using the Remote Keyless Entry (RKE) transmitter button, or by activating the power door lock switches located on the front doors. To open the liftgate, press the liftgate release handle located on the underside of the license plate bar and pull the liftgate open with one fluid motion.
Page 55: Power Liftgate - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Power Liftgate — If Equipped The power liftgate may be opened manually or by using the button on the Remote Keyless Entry (RKE) transmit- ter. Press the button on the transmitter twice within five seconds, to open the power liftgate.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power liftgate may be closed by pressing the button, and several audible beeps will occur to signal that the located in the upper left trim in the liftgate opening. liftgate is opening or closing. Pushing once will only close the liftgate.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 • During power operation, whether liftgate is fully open • If the power liftgate encounters multiple obstructions or fully closed, the liftgate chime will beep several within the same cycle, the system will automatically times indicating power operation is in progress.
Page 58: Occupant Restraints
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • An energy-absorbing steering column and steering OCCUPANT RESTRAINTS wheel Some of the most important safety features in your • Knee bolster for front passenger seat occupant vehicle are the restraint systems: •...
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 If you will be carrying children too small for adult-sized WARNING! seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold Infants in rear facing child restraints should never infant and child restraint systems.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a child from 1 to 12 years old (not in a rear facing child 5. If the air bag system in this vehicle needs to be seat) must ride in the front passenger seat, move the seat modified to accommodate a disabled person, contact as far back as possible and use the proper child restraint.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 WARNING! (Continued) WARNING! (Continued) • Being too close to the steering wheel or instrument • In a collision, you and your passengers can suffer panel during Advanced Front Air Bag deployment much greater injuries if you are not properly buck- could cause serious injury, including death.
Page 62: Lap/Shoulder Belts
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they WARNING! can reduce the seriousness of injuries in a collision. Some • It is dangerous to ride in a cargo area, inside or of the worst injuries happen when people are thrown from the vehicle.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 2. The seat belt latch plate is near the seatback of the WARNING! (Continued) front seats and next to your arm in the rear seats. • Wearing your belt in the wrong place could make Grasp the latch plate and pull out the belt.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause inter- nal injuries.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed posi- • A lap belt worn too high can increase the risk of tion.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Pull the strap down and secure the small latch plate of pushing anywhere on the anchorage. To move the an- the lap belt into the small buckle until you hear a “click”. chorage downward, squeeze the actuation buttons while simultaneously pushing down on the anchorage Position the shoulder belt on your chest so that it is...
Page 68: Seat Belts In Passenger Seating Positions
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE you will prefer a higher position. When you release the If the passenger seating position is equipped with an anchorage, try to move it up or down to make sure that ALR and is being used for normal usage: it is locked in position.
Page 69: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 position that has a belt with this feature. Children 12 WARNING! years old and under should always be properly re- • The belt and retractor assembly must be replaced if strained in the rear seat. the seat belt assembly Automatic Locking Retractor How To Engage The Automatic Locking Mode (ALR) feature or any other seat belt function is not...
Page 70: Seat Belt Pretensioners
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners Supplemental Active Head Restraints (AHR) The seat belts for both front seating positions are These head restraints are passive, deployable compo- equipped with pretensioning devices that are designed to nents, and vehicles with this equipment cannot be readily remove slack from the seat belt in the event of a collision.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Resetting Active Head Restraints (AHR) CAUTION! If the Active Head Restraints are triggered in a collision, All occupants, including the driver, should not oper- you must reset the head restraint on the driver’s and ate a vehicle or sit in a vehicle’s seat until the head front passenger seat.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Hand Positioning Points On AHR 1 — Downward Movement 2. Position the hands on the top of the deployed AHR at 2 — Rearward Movement a comfortable position. 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE AHR In Reset Position 3 — Final Downward Movement To Engage Locking Mechanism NOTE: • If you have difficulties or problems resetting the Active 4. The AHR front soft foam and trim half should lock into the back decorative plastic half.
Page 75: Enhanced Seat Belt Use Reminder System (Beltalert®)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Enhanced Seat Belt Use Reminder System After the sequence completes, the Seat Belt Reminder (BeltAlert®) Light remains illuminated until the respective seat belts are fastened. The driver should instruct all other occu- BeltAlert®...
Page 76: Seat Belts And Pregnant Women
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE BeltAlert® can be enabled or disabled by your autho- Seat Belt Extender rized dealer. Chrysler Group LLC does not recommend If a seat belt is too short, even when fully extended and deactivating BeltAlert®.
Page 77: Supplemental Restraint System (Srs) - Air Bags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Supplemental Restraint System (SRS) — Air Bags This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s Advanced Front Air Bag is mounted in the center of the steering wheel.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Driver and Front Passenger Advanced Front This vehicle may be equipped with Supplemental Side Air Bags are certified to the new Federal regulations for Air Bag Inflatable Curtains (SABIC) to protect the driver, Advanced Air Bags.
Page 79: Air Bag System Components
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 • Supplemental Side Air Bag Inflatable Curtains (SABIC) Air Bag System Components • Front and Side Impact Sensors Your vehicle may be equipped with the following air bag system components: • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, •...
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Air Bags (SAB) WARNING! Supplemental Seat-Mounted Side Air Bags (SAB) may • No objects should be placed over or near the air provide enhanced protection to help protect an occupant bag on the instrument panel, because any such during a side impact.
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 When the air bag deploys, it opens the seam between the NOTE: front and side of the seat’s trim cover. Each air bag • Should a vehicle rollover occur, the pretensioners deploys independently; a left side impact deploys the left and/or SAB and SABIC air bags on both sides of the air bag only and a right-side impact deploys the right air vehicle may deploy.
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Your vehicle is equipped with SABIC air bags, do • Your vehicle is equipped with left and right not have any accessory items installed which will Supplemental Side Air Bag Inflatable Curtain alter the roof, including adding a sunroof to your (SABIC), do not stack luggage or other cargo up vehicle.
Page 83: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Always sit upright as possible with your back against the improved protection for the driver and front passenger. seat back, use the seat belts properly, and use the Side air bags also work with seat belts to improve appropriate sized child restraint, infant restraint or occupant protection.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE collisions depending on several factors, including the Because air bag sensors measure vehicle deceleration severity and type of collision. Advanced Front Air Bags over time, vehicle speed and damage by themselves are are not expected to reduce the risk of injury in rear, side, not good indicators of whether or not an air bag should or rollover collisions.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 The ORC contains a backup power supply system that It also includes diagnostics that will illuminate the instru- may deploy the air bags even if the battery loses power or ment cluster Air Bag Warning Light if a malfunction is it becomes disconnected prior to deployment.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver And Passenger Advanced Front Air Bag The Advanced Front Air Bag gas is vented through the Inflator Units vent holes in the sides of the air bag. In this way, the air bags do not interfere with your control of the vehicle.
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Supplemental Seat-Mounted Side Air Bag (SAB) Supplemental Side Air Bag Inflatable Curtain Inflator Units (SABIC) Inflator Units The Supplemental Seat-Mounted Side Air Bags (SAB) are During collisions where the impact is confined to a designed to activate only in certain side collisions.
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Cut off fuel to the engine. Because air bag sensors estimate deceleration over time, vehicle speed and damage are not good indicators of • Flash hazard lights as long as the battery has power or whether or not an air bag should have deployed.
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 If A Deployment Occurs However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor The Advanced Front Air Bags are designed to deflate immediately.
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Air Bag System WARNING! WARNING! Deployed air bags and seat belt pretensioners can not protect you in another collision. Have the air bags, • Modifications to any part of the air bag system seat belt pretensioners, and the front seat belt retrac- could cause it to fail when you need it.
Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 Air Bag Warning Light WARNING! (Continued) • Do not attempt to modify any part of your air bag You will want to have the air bags ready to system. The air bag may inflate accidentally or may inflate for your protection in a collision.
Page 92: Event Data Recorder (Edr)
90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the speedometer, tachometer, or any engine EDR is designed to record data related to vehicle dynamics related gauges are not working, the Occupant Restraint and safety systems for a short period of time, typically 30 Controller (ORC) may also be disabled.
Page 93: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 These data can help provide a better understanding of Child Restraints the circumstances in which crashes and injuries occur. Everyone in your vehicle needs to be buckled up at all times, including babies and children. Every state in the NOTE: EDR data are recorded by your vehicle only if a United States, and every Canadian province, requires non-trivial crash situation occurs;...
Page 94 92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Before buying any restraint system, make sure that it has WARNING! a label certifying that it meets all applicable Safety Standards. You should also make sure that you can install In a collision, an unrestrained child can become a it in the vehicle where you will use it.
Page 95 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight or Age Recommended Type of Child Restraint Infants and Toddlers Children who are two years old or Either an Infant Carrier or a Convertible younger and who have not reached the Child Restraint, facing rearward in the height or weight limits of their child...
Page 96 94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints reach the highest weight or height allowed by their convertible child seat. Safety experts recommend that children ride rearward- facing in the vehicle until they are two years old or until WARNING! they reach either the height or weight limit of their rear facing child safety seat.
Page 97 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 have outgrown the rear-facing weight or height limit of WARNING! their rear-facing convertible child seat. Children should • Improper installation can lead to failure of an remain in a forward-facing child seat with a harness for as long as possible, up to the highest weight or height infant or child restraint.
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats 3. Does the shoulder belt cross the child’s shoulder between their neck and arm? Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend 4.
Page 99 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 Recommendations For Attaching Child Restraints Restraint Type Combined Use any attachment method shown with an “X” Below Weight of the LATCH – LATCH – Child + Child Lower Anchors Seat Belt + Top Lower Anchors Seat Belt Only Restraint...
Page 100: Things To Know Before Starting Your Vehicle
98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors and Tethers for Children (LATCH) has three vehicle anchor points for installing LATCH- Restraint System equipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
Page 101 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 99 LATCH Positions For Installing Child Restraints In This Vehicle Second Row Bench Lower Anchorage Symbol 2 anchorages per seating Second Row Captains Chairs position Lower Anchorage Symbol 2 anchorages per seating Top Tether Anchorage Symbol position Top Tether Anchorage Symbol...
Page 102 100 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint LATCH Positions What is the weight limit (child’s 65 lbs (29.5 kg) Use the LATCH anchorage system weight + weight of the child re- until the combined weight of the straint) for using the LATCH an- child and the child restraint is chorage system to attach the child...
Page 103 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 101 Can two child restraints be at- Never “share” a LATCH anchorage tached using a common lower with two or more child restraints. LATCH anchorage? If the center position does not have dedicated LATCH lower anchor- ages, use the seat belt to install a child seat in the center position next to a child seat using the...
Page 104 102 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 105 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 103 Locating The LATCH Anchorages In addition, there are tether strap anchors lo- cated behind each rear seatback, near to the floor. LATCH Anchorages (Third Row 60/40 Anchorages Shown) LATCH Anchorages (Third Row 60/40 Anchorage Shown)
Page 106: Commercial Cargo Vehicles (No
104 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH-compatible child restraint systems will be Center Seat LATCH – Commercial Cargo Vehicles equipped with a rigid bar or a flexible strap on each side. (No Factory Installed Rear Seats) — If Equipped Each will have a hook or connector to attach to the lower anchorage and a way to tighten the connection to the WARNING!
Page 107 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 105 Center Seat LATCH To Install A LATCH-compatible Child Restraint If a child restraint installed in the center position blocks 1. If the selected seating position has a Switchable Auto- the seat belt webbing or buckle for the outboard position, matic Locking Retractor (ALR) seat belt, stow the seat do not use that outboard position.
Page 108 106 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Attach the lower hooks or connectors of the child How To Stow An Unused ALR Seatbelt restraint to the lower anchorages in the selected seat- When using the LATCH attaching system to install a ing position.
Page 109 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 107 the seat belt tight around the child restraint so that it is WARNING! not necessary to use a locking clip. The ALR retractor can be “switched” into a locked mode by pulling all of the Improper installation of a child restraint to the webbing out of the retractor and then letting the webbing LATCH anchorages can lead to failure of the re-...
Page 110 108 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Systems for Installing Child Restraints in this Vehicle Second Row Bench Second Row Captains Chair...
Page 111 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 109 Lap/Shoulder Belt Systems What is the weight limit (child’s weight + Weight limit of the Always use the tether anchor when using weight of the child restraint) for using the Child Restraint the seat belt to install a forward facing Tether Anchor with the seat belt to attach a child restraint, up to the recommended...
Page 112 110 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint with a Switchable 5. To lock the seat belt, pull down on the shoulder part of Automatic Locking Retractor (ALR) the belt until you have pulled all the seat belt webbing out of the retractor.
Page 113 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 111 8. If the child restraint has a top tether strap and the Installing A Child Restraint With A Cinching seating position has a top tether anchorage, connect Latch Plate (CINCH) — If Equipped the tether strap to the anchorage and tighten the tether 1.
Page 114 112 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Finally, pull up on any excess webbing to tighten the Any seat belt system will loosen with time, so check the lap portion around the child restraint while you push belt occasionally, and pull it tight if necessary. the child restraint rearward and downward into the If the buckle or the cinching latch plate is too close to the vehicle seat.
Page 115 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 113 Installing Child Restraints Using The Top Tether 3. Attach the tether strap hook of the child restraint to Anchorage the top tether anchorage as shown in the diagram. 1. Look behind the seating position where you plan to install the child restraint to find the tether anchorage.
Page 116 114 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchorage position directly behind the child seat to secure a child restraint top tether strap.
Page 117: Commercial Cargo Vehicles (No Factory Installed Rear Seats) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 115 COMMERCIAL CARGO VEHICLES (NO FACTORY INSTALLED REAR SEATS) — IF EQUIPPED Commercial cargo vehicles are not designed for use as a family vehicle and are not intended for carrying children in the front passenger seat. However, if you must carry a child in a vehicle without a rear seat, the passenger seat should be moved to the full rearward position and the child must be in a proper restraint system based on its...
Page 118: Restraining Infants And Small Children In Commercial Cargo Vehicles
116 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Restraining Infants And Small Children In 3. Using the hook attached to the child restraint tether Commercial Cargo Vehicles strap, attach the child restraint tether strap to the metal anchor on the lower rear of the front passenger There are different sizes and types of restraints for seat.
Page 119: Engine Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 117 ENGINE BREAK-IN RECOMMENDATIONS conditions under which vehicle operations will occur. For the recommended viscosity and quality grades, refer to A long break-in period is not required for the engine and “Maintenance Procedures” in “Maintaining Your Ve- drivetrain (transmission and axle) in your vehicle.
Page 120: Safety Tips
118 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Exhaust Gas Transporting Passengers WARNING! NEVER TRANSPORT PASSENGERS IN THE CARGO Exhaust gases can injure or kill. They contain carbon AREA. monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can WARNING! eventually poison you.
Page 121: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 119 The best protection against carbon monoxide entry into Safety Checks You Should Make Inside The the vehicle body is a properly maintained engine exhaust Vehicle system. Seat Belts Whenever a change is noticed in the sound of the exhaust Inspect the belt system periodically, checking for cuts, system, when exhaust fumes can be detected inside the frays, and loose parts.
Page 122 120 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light Floor Mat Safety Information Always use floor mats designed to fit the footwell of your The light should come on and remain on for vehicle. Use only floor mats that leave the pedal area four to eight seconds as a bulb check when the unobstructed and that are firmly secured so that they ignition switch is first turned ON.
Page 123 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 121 WARNING! (Continued) WARNING! (Continued) • Never place or install floor mats or other floor • Always make sure that objects cannot fall into the coverings in the vehicle that cannot be properly driver footwell while the vehicle is moving.
Page 124: Periodic Safety Checks You Should Make Outside The Vehicle
122 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Tilt Mirrors In Reverse (Available With MIRRORS ......130 Memory Seat Only) —...
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Phone Call Features ....155 ▫ Heated Seats — If Equipped ....187 ▫...
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 ▫ Dimmer Controls .....224 DRIVER MEMORY SEAT — IF EQUIPPED ..214 ▫...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT/TELESCOPING STEERING COLUMN . . .232 PARKSENSE® REAR PARK ASSIST — IF EQUIPPED ......239 HEATED STEERING WHEEL —...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 ▫ Turning ParkView® On Or Off — Without ▫ Reprogramming A Single HomeLink® Navigation/Multimedia Radio ... .251 Button ......261 ▫...
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Venting Sunroof — Express ....268 ▫ Interior Bottle Holders ....278 ▫...
Page 131 RAM CARGO VAN FEATURES ... .294 ▫ Ram Cargo Van Load Floor ....294 SUN SCREENS — IF EQUIPPED ... .305...
Page 132: Mirrors
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 133: Automatic Dimming Mirror - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated.
Page 134: Outside Mirrors
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirrors Driver’s Outside Automatic Dimming Mirror — If Equipped To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight The driver’s outside mirror will automatically adjust for overlap of the view obtained on the inside mirror.
Page 135: Power Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Power Mirrors — If Equipped The power mirror controls consist of mirror select but- tons and a four-way mirror control switch. To adjust a The power mirror controls are located on the driver-side mirror, press either the L (left) or R (right) to select the door trim panel.
Page 136: Heated Mirrors - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Mirrors — If Equipped when the vehicle is shifted out of REVERSE position. Each stored memory setting will have an associated Tilt Mirrors in Reverse position. These mirrors are heated to melt frost or ice. This feature can be activated whenever you turn on the NOTE: The Tilt Mirrors in Reverse feature is not enabled rear window defroster (if equipped).
Page 137: Illuminated Vanity Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 • The mirrors come out of the unfolded position. NOTE: If the vehicle speed is greater than 10 mph (16 km/h) the folding feature will be disabled. • The mirrors shake and vibrate at normal driving If the mirrors are in the folded position, and vehicle speeds.
Page 138: Blind Spot Monitoring (Bsm) - If Equipped
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE BLIND SPOT MONITORING (BSM) — IF EQUIPPED The Blind Spot Monitoring (BSM) system uses two radar- based sensors, located inside the rear bumper fascia, to detect highway licensable vehicles (automobiles, trucks, motorcycles, etc.) that enter the blind spot zones from the rear/front/side of the vehicle.
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Automatic Transmission vehicles The BSM system sensors operate when the vehicle is in any forward gear or REVERSE and enters stand-by mode when the vehicle is in PARK. Manual Transmission vehicles The BSM system sensors operate when the vehicle is in any gear and enters stand-by mode when the Park Brake is engaged, the vehicle is not in REVERSE, and the vehicle is stationary.
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • The BSM system does NOT alert the driver about rapidly approaching vehicles that are outside the de- tection zones. • The BSM system detection zone DOES NOT change if your vehicle is towing a trailer. Therefore, visually verify the adjacent lane is clear for both your vehicle and trailer before making a lane change.
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Entering From The Side Vehicles that move into your adjacent lanes from either side of the vehicle. BSM Warning Light The BSM system monitors the detection zone from three different entry points (side, rear, front) while driving to see if an alert is necessary.
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Entering From The Rear Overtaking Traffic Vehicles that come up from behind your vehicle on either If you pass another vehicle slowly (with a relative speed of less than 15 mph (24 km/h) and the vehicle remains in the side and enter the rear detection zone with a relative blind spot for approximately 1.5 seconds, the warning light speed of less than 30 mph (48 km/h).
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on The BSM system will not alert you of objects that are stationary objects such as guardrails, posts, walls, foliage, traveling in the opposite direction of the vehicle in berms, etc.
Page 144: Rear Cross Path
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) system is not designed to detect pedestrians, bicy- clists, or animals. Even if your vehicle is equipped with the BSM system, always check your vehicle’s mirrors, glance over your shoulder, and use your turn signal before changing lanes.
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 NOTE: In a parking lot situation, oncoming vehicles can be obscured by vehicles parked on either side. If the sensors are blocked by other structures or vehicles, the system will not be able to alert the driver. When RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including reducing the radio volume.
Page 146: Modes Of Operation
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Modes Of Operation view mirror based on a detected object. However, when the system is operating in RCP, the system will respond Modes Of Operation With EVIC with both visual and audible alerts when a detected Three selectable modes of operation are available in the object is present.
Page 147: Uconnect® Phone - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 NOTE: NOTE: The BSM system will store the current operating mode when the vehicle is shut off. Each time the vehicle • Whenever an audible alert is requested by the BSM is started the previously stored mode will be recalled and system, the radio is also muted.
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For Uconnect® customer support: long as your phone is turned on and has been paired to the vehicle’s Uconnect® Phone. The Uconnect® Phone • U.S. residents - visit www.UconnectPhone.com or call allows up to seven mobile phones to be linked to the 1–877–855–8400.
Page 149: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Uconnect® Phone Button The Uconnect® Phone is fully integrated with the vehi- cle’s audio system. The volume of the Uconnect® Phone The radio or steering wheel controls (if can be adjusted either from the radio volume control equipped) will contain the two control buttons knob or from the steering wheel radio control (right (Uconnect®...
Page 150 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For certain operations, compound commands can be Help Command used. For example, instead of saying “Setup” and then If you need assistance at any prompt, or if you want to “Pair a Device”, the following compound command know your options at any prompt, say “Help”...
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 • For identification purposes, you will be prompted to To complete the pairing process, you will need to refer- ence your mobile phone Owner’s Manual. The give the Uconnect® Phone a name for your mobile Uconnect®...
Page 152: Understanding The Features Of Your Vehicle
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say Dial By Saying A Number the name of the person you want to call. For example, • Press the button to begin. you can say “John Doe”, where John Doe is a previ- •...
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 • When prompted, say the name of the new entry. Use of only in that language. In addition, if equipped and long names helps the Voice Command and it is recom- supported by your phone, Uconnect® Phone automati- mended.
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • A maximum of 1000 entries per phone will be down- Edit Uconnect® Phonebook Entries loaded and updated every time a phone is connected NOTE: Editing phonebook entries is recommended to the Uconnect® Phone. when the vehicle is not in motion.
Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 • After you enter the Phonebook Delete menu, you will After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in then be asked for the name of the entry that you wish the phonebook, call the number you just edited, or return to delete.
Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete/Erase “All” Uconnect® Phonebook Entries List All Names In The Uconnect® Phonebook • Press the • Press the button to begin. button to begin. • After the “Ready” prompt and the following beep, say •...
Page 157: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Phone Call Features Answer Or Reject An Incoming Call — Call Currently In Progress The following features can be accessed through the Uconnect® Phone if the feature(s) are available on your If a call is currently in progress and you have another mobile service plan.
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE in progress. To go back to the first call, refer to “Toggling Conference Call Between Calls” in this section. To combine two calls, refer When two calls are in progress (one active and one on to “Conference Call”...
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 active call is terminated by the phone far end, a call on Call Continuation hold may not become active automatically. This is cell Call continuation is the progression of a phone call on the phone-dependent.
Page 160: Uconnect® Phone Features
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect® Phone Features Emergency Assistance If you are in an emergency and the mobile phone is Language Selection reachable: To change the language that the Uconnect® Phone is • Pick up the phone and manually dial the emergency using: number for your area.
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 NOTE: WARNING! • The emergency number dialed is based on the country To use you Uconnect® Phone System in an emer- where the vehicle is purchased (911 for the U.S. and gency, your mobile phone must be: Canada and 060 for Mexico).
Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: You should program the desired Towing Assis- Working With Automated Systems tance phone number using the Voice Command system. This method is used in instances where one generally has To do this, press the button and say “Setup”, followed by to press numbers on the mobile phone keypad while “Towing Assistance”.
Page 163 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 “Send”, is also to be used for navigating through an NOTE: automated customer service center menu structure, and • You may not hear all of the tones due to mobile phone to leave a number on a pager. network configurations.
Page 164 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF using Uconnect® Phone. The status is given for network signal strength, phone battery strength, etc. Turning confirmation prompts off will stop the system from confirming your choices (e.g., the Uconnect® Phone Dialing Using The Mobile Phone Keypad will not repeat a phone number before you dial it).
Page 165: Advanced Phone Connectivity
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Mute/Un-Mute (Mute ON/OFF) from your Uconnect® Phone paired mobile phone to the Uconnect® Phone or vice versa, press the button When you mute the Uconnect® Phone, you will still be and say “Transfer Call”. able to hear the conversation coming from the other party, but the other party will not be able to hear you.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say “List Phones”. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect® Phone will play the phone names of all Uconnect®...
Page 167: Things You Should Know About Your Uconnect® Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 • Press the Things You Should Know About Your Uconnect® button and say the “Voice Training”, Phone “System Training”, or “Start Voice Training” com- mand. Uconnect® Phone Tutorial You can either press the Uconnect® Phone button to To hear a brief tutorial of the system features, press the restore the factory setting or repeat the words and button and say “Uconnect®...
Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Performance is maximized under: This will delete all phone pairing, phone book entries, and other settings in all language modes. The System will • low-to-medium blower setting, prompt you before resetting to factory settings. •...
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 • It is not recommended to store similar sounding names Far End Audio Performance in the Uconnect® Phonebook. • Audio quality is maximized under: • Phonebook (Downloaded and Uconnect® Phone Lo- • low-to-medium blower setting, cal) name recognition rate is optimized when the •...
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Uconnect® Phone will play the new text message for Recent Calls you. If your phone supports “Automatic Phonebook Down- load”, Uconnect® Phone can list your Outgoing, Incom- After reading a message, you can “Reply” or “Forward” ing and Missed Calls.
Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Uconnect® Phone will prompt you to say the name or 10. Thanks number of the person you wish to send the message to. 11. See You in 15 minutes List of Preset Messages: 12.
Page 172 170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Voice Text Reply Incoming Announcement ON/ Bluetooth® Communication Link Mobile phones have been found to lose connection to the Uconnect® Phone. When this happens, the connection Turning the Voice Text Reply Incoming Announcement can generally be reestablished by switching the phone OFF will stop the system from announcing the new off/on.
Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171...
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173...
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate (s) Primary Alternate (s) zero call cancel three confirmation prompts four continue five delete dial seven download eight edit nine emergency star (*) English plus (+) erase all pound (#) Espanol add location...
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Voice Commands Voice Commands Primary Alternate (s) Primary Alternate (s) help previous home record again language redial list names return to main menu return or main menu list phones select phone select mobile send mute set up...
Page 178: General Information
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information VOICE COMMAND — IF EQUIPPED This device complies with Part 15 of the FCC rules and Voice Command System Operation RSS 210 of Industry Canada. Operation is subject to the following conditions: The Uconnect®...
Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Pressing the Voice Command button while the WARNING! system is speaking is known as “barging in.” The system will be interrupted, and after the beep, you can add or Any voice commanded system should be used only change commands.
Page 180: Commands
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To hear the first available Menu, press the Voice Com- Main Menu mand button and say “Help” or “Main Menu”. Start a dialogue by pressing the Voice Command button. You may say “Main Menu” to switch to the Commands main menu.
Page 181 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 • “Menu Radio” (to switch to the radio menu) Radio AM • “Main Menu” (to switch to the main menu) To switch to the AM band, say “AM” or “Radio AM”. In this mode, you may say the following commands: Satellite Radio •...
Page 182 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Disc Mode Bluetooth® Streaming (BT) Mode To switch to Bluetooth® Streaming (BT) mode, say To switch to the disc mode, say “Disc”. In this mode, you “Bluetooth Streaming”. In this mode, you may say the may say the following commands: following commands: •...
Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 • “Play Memos” (to play previously recorded memos) — • “Main menu setup” or During the playback you may press the Voice Com- • “Switch to setup” mand button to stop playing memos. You pro- In this mode, you may say the following commands: ceed by saying one of the following commands: –...
Page 184: Voice Training
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training SEATS For users experiencing difficulty with the system recog- Seats are a part of the Occupant Restraint System of the nizing their voice commands or numbers the Uconnect® vehicle. Voice “Voice Training” feature may be used. WARNING! 1.
Page 185: Power Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Power Seats — If Equipped Some models may be equipped with eight-way power seats for the driver and front passenger. The power seat switches are located on the outboard side of the seat. The switches control the movement of the seat cushion and the seatback.
Page 186 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! • Adjusting a seat while driving may be dangerous. Do not place any article under a power seat or Moving a seat while driving could result in loss of impede its ability to move as it may cause damage to control which could cause a collision and serious the seat controls.
Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 Tilting The Seat Up Or Down WARNING! The angle of the seat cushion can be adjusted in four • Adjusting a seat while driving may be dangerous. directions. Pull upward or push downward on the front Moving a seat while driving could result in loss of or rear of the seat switch, the front or rear of the seat control which could cause a collision and serious...
Page 188: Power Lumbar - If Equipped
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 189: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 Heated Seats — If Equipped Vehicles Equipped With Remote Start On some models, the front and rear seats may be On models that are equipped with remote start, the equipped with heaters located in the seat cushions. driver’s heated seat can be programmed to come on during a remote start.
Page 190 188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE You can choose from HIGH, LOW or OFF heat settings. HIGH-level. If the HIGH-level setting is selected, the Amber indicator lights in each switch indicate the level of system will automatically switch to LOW-level after heat in use.
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 You can choose from HIGH, LOW or OFF heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for HIGH, one for LOW and none for OFF. Press the switch once to select HIGH-level heating.
Page 192: Manual Front/Second Row Seat Adjuster
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the HIGH-level setting is selected, the heater will provide a boosted heat level during the initial stages of operation. Then, the heat output will drop to the normal HIGH-level. If the HIGH-level setting is selected, the system will automatically switch to LOW-level after approximately 60 minutes of continuous operation.
Page 193: Manual Reclining Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 Manual Reclining Seats — If Equipped WARNING! For models equipped with manual reclining seats, the • Adjusting a seat while driving may be dangerous. recline lever is located on the outboard side of the seat. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.
Page 194: Head Restraints
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE normal position. Using body pressure, lean forward and WARNING! rearward on the seat to be sure the seatback has latched. The head restraints for all occupants must be prop- WARNING! erly adjusted prior to operating the vehicle or occu- pying a seat.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. This system is designed to help prevent or reduce the extent of injuries to the driver and front passenger in certain types of rear impacts.
Page 196 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Active Head Restraint (Normal Position) Active Head Restraint (Tilted) NOTE: • The head restraints should only be removed by quali- fied technicians, for service purposes only. If either of the head restraints require removal, see your autho- rized dealer.
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 • In the event of deployment of an Active Head Re- WARNING! (Continued) straint, refer to “Occupant Restraints/Resetting Active • Active Head Restraints may be deployed if they are Head Restraints (AHR)” in “Things To Know Before struck by an object such as a hand, foot or loose Starting Your Vehicle”...
Page 198: Stow 'N Go® Seating - If Equipped
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints — Third Row The head restraint in the center position can be raised and lowered for tether routing. Refer to “Occupant Re- straints” in “Things To Know Before Starting Your Ve- hicle”...
Page 199 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 NOTE: Seat will not stow in the storage bin unless the 5. Pull upward on the seatback recliner lever located on armrests are raised. the outboard side of the seat. 4. Slide the storage bin locking mechanism to the “LOCK”...
Page 200 198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Non-Adjustable Head Restraint Automatic Folding Seatback The seat will automatically tumble into position for easy storage.
Page 201 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 Tumbled Second Row Seat Seat In Storage Bin 6. Push the seat into the storage bin. 7. Close the storage bin cover. CAUTION! The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover.
Page 202 200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Lift the seatback to the full upright position. WARNING! 4. Return the head restraint to its upright position, close In a collision, serious injury could result if the seat the storage bin cover and slide the storage bin locking storage bin covers are not properly latched.
Page 203 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 Raising The Seatback Raising The Head Restraint 2. Return the head restraint to the upright position. 3. Pull up on the seatback recliner lever on the outboard side of the seat to fold head rest and seatback and tumble seat forward.
Page 204: Quad Seats - If Equipped
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Easy Entry Second Row The seat will automatically fold into position for easy entry into the third row. The second row Stow ’n Go® seats allow easy entry to the third row seat or rear cargo area. WARNING! Pull up on the seatback recliner lever on the outboard In the event of a collision you could be injured if the...
Page 205 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 206 204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold-Flat To fold the seat, lift the recliner lever to the full upward position and push the seatback forward until it rests on the seat cushion. Recline Lever WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 207 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 Easy Entry For passengers seated in the third row, there is a pull strap located on the outboard side of the seat near the The Quad seats can be tilted forward for easy entry into bottom of the seat back.
Page 208: Second Row Bench Seat - If Equipped
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Removal Second Row Bench Seat — If Equipped The Quad seats can be removed if additional storage is While the bench seat does not stow in the floor, it is needed. With the seat in the easy entry position, lift the removable for added cargo space.
Page 209: Third Row Power Recline - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 indicator button pops up when the seat is unlocked. The upward until the lock indicator button returns into the seat assembly can now be removed from the vehicle and handle. moved on its Easy Out® Rollers. WARNING! If not properly latched, the bench seats could become loose.
Page 210: Third Row Power Folding Seat - If Equipped
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Lower the head restraint by pulling on the release strap marked “1” located on the outboard side of the head restraint. Third Row Power Seat Switch Third Row Power Folding Seat — If Equipped A one-touch power folding seat switch is located in the Head Restraint Release Strap “1”...
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 the following positions using the switch bank located on the left rear trim panel: One Touch Folding Seat Third Row The rear switch bank allows multiple power folding and unfolding positions for the third row seats. Rear Panel Power Switch Bank Left and right third row seats can be folded individually 1 —...
Page 212: Manually Folding Third Row Seats - If Equipped
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Manually Folding Third Row Seats — If Equipped • Disconnect the center shoulder belt from the small 1. Lower the center head restraint down to the seatback buckle and lower the head restraints before attempting by pushing the button on the guide and pushing the to fold/stow the power third row seats.
Page 213 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 Head Restraint Release Strap “1” Release Strap “2” 3. Pull release strap marked “2” located on the rear of the 4. Pull release strap marked “3” to release the anchors. seat to lower the seatback.
Page 214 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Release Strap “3” Release Strap “4” 5. Pull release strap marked “4” and tumble the seat rearward into the storage bin.
Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 2. Pull release strap marked “2” to unlock the recliner. 3. Pulling strap “4” releases the seatback to return to its full upright position. 4. Raise the head restraint to its upright position. WARNING! In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor...
Page 216: Plastic Grocery Bag Retainer Hooks
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tailgate Mode Plastic Grocery Bag Retainer Hooks Retainer hooks which will hold plastic grocery bag 1. Pull release strap “3”, then pull release strap “4” to handles are built into the seatbacks of all rear seats and rotate the entire seat rearward.
Page 217: Setting Memory Positions And Linking Rke Transmitter To Memory
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 Setting Memory Positions And Linking RKE Transmitter To Memory NOTE: Each time the SET (S) button and a numbered button (1 or 2) is pressed, you erase the memory settings for that button and store a new one. 1.
Page 218 216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Turn on the radio and set the radio station presets (up 11. Select “Remote Linked to Memory” in the Electronic to 10 AM and 10 FM stations can be set). Vehicle Information Center (EVIC) and enter “Yes”. Refer to “Electronic Vehicle Information Center 6.
Page 219 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 To recall the memory setting for driver two, press MEMORY 3. Press and release the memory SET (S) button located button 2 on the driver’s door or the UNLOCK button on the on the driver’s door. A chime will sound signaling that RKE transmitter linked to Memory Position 2.
Page 220: Easy Entry/Exit Seat (Available With Memory Seat Only)
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Once programmed, all RKE transmitters linked will return to its previously set position when you to memory can be easily enabled or disabled at one time. insert the key into the ignition switch and turn it out of Refer to “Electronic Vehicle Information Center (EVIC)/ the LOCK position.
Page 221: To Open And Close The Hood
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 NOTE: The Easy Entry/Easy Exit feature can be enabled or disabled through the programmable features in the Electronic Vehicle Information Center (EVIC). If your vehicle is not equipped with an EVIC, your dealership can activate/deactivate this feature for you.
Page 222 220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Safety Lever Location Hood Prop Rod Use the hood prop rod to secure the hood in the open CAUTION! position. To prevent possible damage, do not slam the hood to close it. Lower the hood until it is open approxi- mately 12 in (30 cm) and then drop it.
Page 223: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 CAUTION! (Continued) secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged. WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision.
Page 224: Automatic Headlights - If Equipped
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped vehicles equipped with an automatic headlight system. Refer to “Electronic Vehicle Information Center (EVIC)/ This system automatically turns your headlights on or off Customer-Programmable Features” in “Understanding based on ambient light levels. To turn the system on, turn Your Instrument Panel”...
Page 225: Lights-On Reminder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 The headlight delay time is programmable on vehicles Daytime Running Lights — If Equipped equipped with an EVIC. Refer to “Electronic Vehicle The headlights on your vehicle will illuminate when the Information Center (EVIC)/Customer-Programmable engine is started and the transmission is in any gear Features”...
Page 226: Dimmer Controls
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dimmer Controls Interior Lighting On The dimmer switch is located next to the headlight Rotate the left dimmer control completely upward to the switch. second detent (extreme top position) to turn on the interior lights.
Page 227 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 NOTE: The key must be out of the ignition switch or the The Halo control switch is located to the right of the ignition switch must be in the OFF position for this dimmer switch.
Page 228: Multifunction Lever
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Multifunction Lever The multifunction lever controls the: • Turn Signals The multifunction lever is located on the left side of the steering column. • Headlight Beams Low/High • Flash-To-Pass (Optical Horn) • Front and Rear Wipers — Washer Functions Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show...
Page 229: Lane Change Assist
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 Turn Signal Warning Flash-To-Pass If the vehicle electronics sense that the vehicle has You can signal another vehicle with your headlights by traveled at over 18 mph (29 km/h) for about 1 mile lightly pulling the multifunction lever toward you.
Page 230: Windshield Wiper And Washers
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPER AND WASHERS NOTE: Always remove any buildup of snow that pre- vents the windshield wiper blades from returning to the The wipers and washers are operated by a switch within off position. If the windshield wiper switch is turned off the multifunction lever.
Page 231: Intermittent Wiper System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Intermittent Wiper System Windshield Washers Use the intermittent wiper when weather conditions To use the Washer, push on the end of the lever to the make a single wiping cycle with a variable pause be- second detent and hold while spray is desired.
Page 232: Rear Wiper And Washer
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Wiper And Washer The sensitivity of the system is adjustable from the multifunction lever. Wiper sensitivity position 3 has been Rotating the rotary ring to the first detent activates the calibrated for best overall wiping sensitivity. If the opera- rear intermittent wipers.
Page 233 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 • The Rain Sensing feature can be turned on and off • Neutral Wipe Inhibit — The Rain Sensing feature will through the EVIC (if equipped). Refer to “Electronic not operate when the ignition is ON, and the transmis- Vehicle Information Center (EVIC)/Personal Settings sion shift lever is in the NEUTRAL position, and the (Customer-Programmable Features)”...
Page 234 232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT/TELESCOPING STEERING COLUMN To unlock the steering column, push the lever downward (toward the floor). To tilt the steering column, move the This feature allows you to tilt the steering column steering wheel upward or downward as desired. To upward or downward.
Page 235: Heated Steering Wheel - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 HEATED STEERING WHEEL — IF EQUIPPED The heated steering wheel switch is located on the switch bank below the climate controls. There are also soft-keys The steering wheel contains a heating element that helps in the radio screen that will activate the heated steering warm your hands in cold weather.
Page 236: Adjustable Pedals - If Equipped
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Vehicles Equipped With Remote Start WARNING! (Continued) On models that are equipped with remote start, the • Do not place anything on the steering wheel that heated steering wheel can be programmed to come on insulates against heat, such as a blanket or steering during a remote start.
Page 237 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 • The pedals cannot be adjusted when the vehicle is in REVERSE or when the Electronic Speed Control Sys- tem is on. The following messages will be displayed on vehicles equipped with the Electronic Vehicle Informa- tion System (EVIC) if the pedals are attempted to be adjusted when the system is locked out (“Adjustable Pedal Disabled —...
Page 238: Electronic Speed Control - If Equipped
236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Electronic Speed Control buttons are located on the CAUTION! right side of the steering wheel. Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls.
Page 239: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 240: To Deactivate
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Deactivate To Vary The Speed Setting A soft tap on the brake pedal, pushing the CANCEL When the Electronic Speed Control is set, you can in- button, or normal brake pressure while slowing the crease speed by pushing the RES (+) button.
Page 241: To Accelerate For Passing
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 Pressing the SET (-) button once will result in a 1 mph WARNING! (1.6 km/h) decrease in set speed. Each subsequent tap of the button results in a decrease of 1 mph (1.6 km/h). Electronic Speed Control can be dangerous where the system cannot maintain a constant speed.
Page 242: Parksense® Sensors
240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense® will retain the last system state (enabled or ParkSense® Warning Display disabled) from the last ignition cycle when the ignition is The ParkSense® Warning screen will only be displayed if changed to the ON/RUN position. Sound and Display is selected from the Customer- Pro- grammable Features section of the Electronic Vehicle ParkSense®...
Page 243: Parksense® Display
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 ParkSense® Display When the vehicle is in REVERSE, the warning display will turn ON indicating the system status. ParkSense® Warning Display Park Assist System ON...
Page 244 242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Park Assist System OFF Slow Tone The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 245 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 Fast Tone Continuous Tone...
Page 246 244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Rear Distance Greater than...
Page 247: Enabling/Disabling Parksense
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 Enabling/Disabling ParkSense® Service The ParkSense® Rear Park Assist System ParkSense® can be enabled and disabled through the Customer-Programmable Features section of the EVIC. During vehicle start up, when the ParkSense® Rear Park The available choices are: OFF, Sound Only, or Sound and Assist System has detected a faulted condition, the Display.
Page 248: Cleaning The Parksense® System
246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If “PARKSENSE UNAVAILABLE WIPE REAR SEN- ParkSense® System Usage Precautions SORS” appears in the Electronic Vehicle Information NOTE: Center (EVIC) make sure the outer surface and the • Ensure that the rear bumper is free of snow, ice, mud, underside of the rear fascia/bumper is clean and clear of snow, ice, mud, dirt or other obstruction and then cycle dirt and debris to keep the ParkSense®...
Page 249 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 • ParkSense®, when on, will MUTE the radio when it is • On vehicles equipped with a tailgate, ParkSense® sounding a tone. should be disabled when the tailgate is in the lowered or open position and the vehicle is in REVERSE. A •...
Page 250 248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! WARNING! (Continued) • Before using ParkSense®, it is strongly recom- • Drivers must be careful when backing up even mended that the ball mount and hitch ball assem- when using ParkSense®. Always check carefully bly is disconnected from the vehicle when the behind your vehicle, look behind you, and be sure vehicle is not used for towing.
Page 251: Parkview® Rear Back Up Camera - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 PARKVIEW® REAR BACK UP CAMERA — IF When the vehicle is shifted out of REVERSE, the rear EQUIPPED camera mode is exited and the navigation or audio screen appears again. Your vehicle may be equipped with the ParkView® Rear Back Up Camera that allows you to see an on-screen When displayed, static grid lines will illustrate the width image of the rear surroundings of your vehicle whenever...
Page 252: Turning Parkview® On Or Off - With Navigation/Multimedia Radio
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! (Continued) • To avoid vehicle damage, the vehicle must be Drivers must be careful when backing up even when driven slowly when using ParkView® to be able to using the ParkView® Rear Back Up Camera. Always stop in time when an obstacle is seen.
Page 253: Turning Parkview® On Or Off - Without Navigation/Multimedia Radio
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 4. Enable or disable the rear camera feature by selecting OVERHEAD CONSOLES the “enable rear camera in reverse” soft-key. Front Overhead Console 5. Press the “save” soft-key. Two versions of the overhead console are available. The base front overhead console model featured fixed incan- Turning ParkView®...
Page 254: Courtesy/Interior Lighting
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If your vehicle is equipped with Remote Keyless Entry (RKE) the lights will also turn on when the UNLOCK button on the RKE transmitter is pressed. The courtesy lights also function as reading lights. Press in on each lens to turn these lights on while inside the vehicle.
Page 255: Sunglass Storage (Non-Sunroof Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 Sunglass Storage (Non-Sunroof Only) The door will slowly rotate to the full open position. At the front of the overhead console, a compartment is provided for the storage of two pairs of sunglasses. From the closed position, press the door latch to open the compartment.
Page 256: Rear Courtesy/Reading Lights - If Equipped
254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Courtesy/Reading Lights — If Equipped The overhead console has two sets of courtesy lights. The lights turn on when a front door, a sliding door or the liftgate is opened. If your vehicle is equipped with Remote Keyless Entry (RKE) the lights will also turn on when the UNLOCK button on the RKE transmitter is pressed.
Page 257: Rear Overhead Consoles - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 Reading Lights Overhead Compartment Features Rear Overhead Consoles — If Equipped 1 — DVD* 5 — Storage 2 — Rear HVAC 6 — DVD* The rear overhead storage system is available in two 3 —...
Page 258: Garage Door Opener - If Equipped
256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Console Halo Lighting The rear overhead console has recessed halo lighting around the perimeter of the console base. This feature provides additional lighting options while traveling and is controlled by the headlight switch. Refer to “Lights/ Halo Lights —...
Page 259: Before You Begin Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 For more efficient programming and accurate transmis- sion of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink® system.
Page 260: Programming A Rolling Code
258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming A Rolling Code For programming garage door openers that were manu- factured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener.
Page 261 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) 5. At the garage door opener motor (in the garage), away from the HomeLink® button you wish to pro- locate the “LEARN” or “TRAINING” button. This can gram while keeping the HomeLink®...
Page 262: Programming A Non-Rolling Code
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If the garage door opener/device does not acti- 3. Simultaneously press and hold both the Homelink® vate, press the button a third time (for two seconds) to button you want to program and the hand-held trans- complete the training.
Page 263: Reprogramming A Single Homelink® Button
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 Reprogramming A Single HomeLink® Button Canadian/Gate Operator Programming To reprogram a channel that has been previously trained, For programming transmitters in Canada/United States follow these steps: that require the transmitter signals to “time-out” after several seconds of transmission.
Page 264 262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE It may be helpful to unplug the device during the cycling 4. Watch for the HomeLink® indicator to change flash process to prevent possible overheating of the garage rates. When it changes, it is programmed. It may take door or gate motor.
Page 265: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 Reprogramming A Single HomeLink® Button Using HomeLink® To reprogram a channel that has been previously trained, To operate, press and release the programmed follow these steps: HomeLink® button. Activation will now occur for the programmed device (i.e., garage door opener, gate opera- 1.
Page 266: Troubleshooting Tips
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips WARNING! If you are having trouble programming HomeLink®, • Your motorized door or gate will open and close here are some of the most common solutions: while you are programming the universal trans- •...
Page 267: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 General Information NOTE: • The transmitter has been tested and it complies with This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following FCC and IC rules. Changes or modifications not ex- two conditions: pressly approved by the party responsible for compli- ance could void the user’s authority to operate the...
Page 268: Power Sunroof - If Equipped
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof switch is located between the sun • Never leave children unattended in a vehicle, and visors on the overhead console. do not leave the key in the ignition switch. Occu- pants, particularly unattended children, can be- come entrapped by the power sunroof while oper- ating the power sunroof switch.
Page 269: Opening Sunroof - Express
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 Opening Sunroof — Express position. The sunroof will close fully and stop automati- cally. This is called “Express Close”. During Express Press the switch rearward and release it within one-half Close operation, any movement of the switch will stop second.
Page 270: Sunshade Operation
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Venting Sunroof — Express Wind Buffeting Press and release the Vent button within one half second Wind buffeting can be described as the perception of and the sunroof will open to the vent position. This is pressure on the ears or a helicopter-type sound in the called “Express Vent”, and it will occur regardless of ears.
Page 271: Ignition Off Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 Ignition Off Operation Sunroof Fully Closed For Vehicles Not Equipped With The Electronic Vehicle Press the switch forward and release to ensure that the sunroof is fully closed. Information Center (EVIC) The power sunroof switch will remain active for 45 ELECTRICAL POWER OUTLETS —...
Page 272 270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. •...
Page 273 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 Removable Console Outlet Super Console Outlets On vehicles equipped with the Super Console the power The outlet in the rear quarter panel near the liftgate and outlets are located under the retractable cover. To access the upper outlet in the instrument panel are both con- the power outlets push down on the cover and slide it trolled by the ignition switch.
Page 274 272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The power outlets include tethered caps, labeled with a key or battery symbol indicating the power source. The power outlet, located on the lower instrument panel, is powered directly from the battery. Items plugged into this power outlet may discharge the battery and/or prevent the engine from starting.
Page 275 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of outlet power from the vehicle’s battery, even when not in should be inserted into any 12 Volt outlet.
Page 276: Power Inverter - If Equipped
274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. Improper use of the power outlet can cause damage. POWER INVERTER —...
Page 277: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 This outlet can power cellular phones, electronics and WARNING! other low power devices requiring power up to 150 Watts. Certain high-end video games, such as Playsta- To avoid serious injury or death: • Do not insert any objects into the receptacles. tion3 and XBox360 will exceed this power limit, as will •...
Page 278: Instrument Panel Cupholders
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Instrument Panel Cupholders variety of container types and sizes. Press down on the container to engage the cupholder retention features. The instrument panel cupholders are located in a pull-out drawer just above the lower storage bin. Super Console —...
Page 279: Premium Console Cupholders - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 For rear passengers two cupholders are located in the Premium Console Cupholders — If Equipped pull-out drawer, located in the back of the Super Console. On models equipped with premium center consoles, Pull the drawer out to the first position to use the there are four cupholders located on the top of the cupholders.
Page 280: Interior Bottle Holders
278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Bottle Holders There are four bottle holders located in the interior. One bottle holder is molded into each front interior door trim panels, and one bottle holder is molded into each side sliding interior door trim panel.
Page 281: Smoker's Package Kit - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 Smoker’s Package Kit — If Equipped STORAGE With the optional authorized dealer-installed Smoker’s Glove Compartments Package Kit, a removable ash receiver is inserted into one Upper and lower glove compartments are located on the of the two cupholders in the center front instrument passenger side of the instrument panel.
Page 282 280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Upper Glove Compartment Lower Glove Compartment To open the upper compartment, press in on the button, To open the lower compartment pull out on the release located on the left side of the upper door. The door will handle.
Page 283: Door Trim Panel Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281 Door Trim Panel Storage Front Door Storage Both interior front door panels have multiple pockets for storage. Driver Seatback Storage — If Equipped The driver’s seatback has a primary storage pocket on all models and an optional secondary mesh pocket.
Page 284: Umbrella Holder
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Umbrella Holder Second Row Seat Storage Bins — If Equipped An umbrella holder has been conveniently molded into The seat storage bins are located on the floor in front of the left front door entry scuff molding. the second row seats.
Page 285 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283 CAUTION! NOTE: The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover. WARNING! In a collision, serious injury could result if the seat storage bin covers are not properly latched.
Page 286: Storage Bin Safety Warning
284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Storage Bin Safety Warning WARNING! (Continued) Carefully follow these warnings to help prevent personal • Do not operate the storage bin covers while the injury or damage to your vehicle: vehicle is in motion. •...
Page 287: Coat Hooks
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285 Coat Hooks Coat hooks are located along the headliner for the second and third row seating positions. The coat hook load limit is 10 lbs (4.5 kg). Exceeding the recommended load limit can cause the coat hooks to break or disengage from the vehicle.
Page 288: Console Features
286 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONSOLE FEATURES There are three consoles available: Basic, Premium and Super. WARNING! Do not operate this vehicle with a console compart- ment lid in the open position. Cellular phones, music players, and other handheld electronic devices should be stowed while driving.
Page 289: Basic Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287 Basic Console To Remove The Basic Floor Console Basic Console features consist of the following: 1. Remove the front anchor cup plug and clip. • The basic console profile allows vehicle occupants to 2.
Page 290: Premium Console - If Equipped
288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Four cupholders with dishwasher safe liners for clean- 4. Reinstall the clip first and then while pushing down- ward on the console with slight pressure, reinstall the ing. The cupholders can accept plastic bottles, large cover plug.
Page 291 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289 The top and center console sections slide forward and rearward to provide added user comfort. A one-piece cup holder insert for both cavities can easily be removed for cleaning. The cupholders will also accommodate large size cups and 20 oz (.6 L) bottles.
Page 292 290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Console Position 2 Console Position 3 Dual Storage Bins Position 4 shows the complete console in its rearmost position. Again, lifting second latch handle at the front of Position 3 shows the top portion of the console in a the console, allows complete access to a lower storage bin rearward position.
Page 293 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291 To Remove The Premium Floor Console 1. Pull up on the bottom release handle in the front of the console. 2. Lift the rear of the console up several inches/ centimeters. 3. Pull rearward to disengage from floor and remove console.
Page 294: Super Console - If Equipped
292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Push down on the rear of the console until it is seated in the rear floor bracket. 5. Pull up on the console to be sure it is firmly latched. WARNING! In an accident, serious injury could result if the removable floor console is not properly installed.
Page 295 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 293 NOTE: The front cupholder light ring and pass through lighting is controlled by a dimming switch located on the instrument panel, refer to “Lights” in “Understanding The Features Of Your Vehicle” for further information. Located in the back of the super console is a storage drawer and cupholders for the rear passengers.
Page 296: Ram Cargo Van Features
294 UNDERSTANDING THE FEATURES OF YOUR VEHICLE RAM CARGO VAN FEATURES Ram Cargo Van Load Floor The Ram Cargo Van receives a structural aluminum rear load floor. Two load floor options are available, the standard floor with a flat aluminum surface and non skid...
Page 297 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 295 Standard Load Floor Deluxe Load Floor Storage Bin Locations (Rear View)
Page 298: Rear Window Features
296 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control (Mode) knob. Press this button to turn on the rear window defroster and the heated outside mirrors (if equipped). An indicator in the button will illuminate when the rear window defroster is on.
Page 299 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 297 NOTE: CAUTION! • You can turn off the heated mirror feature at anytime Failure to follow these cautions can cause damage to by pressing the rear window defroster switch a second the heating elements: time.
Page 300: Load Leveling System - If Equipped
298 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LOAD LEVELING SYSTEM — IF EQUIPPED ROOF LUGGAGE RACK — IF EQUIPPED The automatic load leveling system will provide a level- The crossbars on your vehicle are delivered stowed riding vehicle under most passenger and cargo loading within the roof rack side rails.
Page 301: Deploying The Crossbars
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 299 NOTE: • Crossbars are error-proofed and cannot be deployed or stowed in the incorrect positions. • To help control wind noise, stow the crossbars in the side rails when they are not in use. Deploying the Crossbars To deploy the crossbars, completely loosen the thumb screws at both ends of the crossbar and lift the crossbar...
Page 302 300 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Use care when removing and handling the crossbars to prevent damage to the vehicle. Bend the crossbar supports at each end, taking care to keep hand clear of pivoting joint. Slide the thumb screw down.
Page 303 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 301 Stowed Position Deployed Position Then, position the crossbars across the roof. NOTE: The crossbars are identical and can be placed in any two of the three deploy positions.
Page 304 302 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Deploy Positions – Choose Two Of Three Crossbar To Side Rail Installation Make sure the directional arrows on the crossbars align Once the crossbars are set into position, tighten the with the directional arrows on the side rails. Set the thumb screws completely.
Page 305 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 303 Stowing the Crossbars Reverse the procedure to stow the crossbars, again, taking care to keep hand clear of pivoting joint. Crossbars are identical and can be stowed in either rail nest. Once the crossbars are stowed, tighten the thumb screws completely.
Page 306 304 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity of 150 lb (68 kg). Always distribute heavy loads as evenly as possible and secure the load appropri- ately.
Page 307: Sun Screens - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 305 CAUTION! (Continued) WARNING! • Long loads which extend over the windshield, such Cargo must be securely tied before driving your vehicle. as wood panels or surfboards, or loads with large Improperly secured loads can fly off the vehicle, par- frontal area should be secured to both the front and ticularly at high speeds, resulting in personal injury or rear of the vehicle.
Page 308 306 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sun Screen Retracted Sun Screen Extended Gently pull up on the tab to raise the sun screen. To lower the sun screen, gently lift the tab upward to Continue pulling the sun screen until the tab is near the disengage the hooks, and feed the screen back into the top of the window.
Page 309 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Oil Change Required ....339 INSTRUMENT PANEL FEATURES ..312 ▫...
Page 310 308 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Operation Instructions — CD MODE for Uconnect® 730N/430/430N CD/DVD/HDD/ NAV — IF EQUIPPED ....353 CD and MP3 Audio Play ....369 ▫...
Page 311 UNDERSTANDING YOUR INSTRUMENT PANEL 309 ▫ Play Mode ......383 ▫ Play A DVD Using The VES™ Player (If Equipped).
Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Headphones Operation ....412 ▫ Listening To Audio With The Screen Closed . . .422 ▫ Blu-ray Headphones Operation ... .413 ▫...
Page 313 UNDERSTANDING YOUR INSTRUMENT PANEL 311 ▫ Rear Manual Climate Control — ▫ Vacation/Storage .....458 If Equipped ......443 ▫...
Page 314: Instrument Panel Features
312 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Vents 5 — Upper Glove Compartment 9 — Storage Bin 13 — Hood Release 2 — Instrument Cluster 6 — Lower Glove Compart- 10 — Cup Holders 14 — Dimmer Switch ment 3 —...
Page 315: Instrument Cluster - Base
UNDERSTANDING YOUR INSTRUMENT PANEL 313 INSTRUMENT CLUSTER — BASE...
Page 316: Instrument Cluster - Premium
314 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — PREMIUM...
Page 317: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 315 INSTRUMENT CLUSTER DESCRIPTIONS If the vehicle is driven more than 1 mile (1.6 km) with either turn signal on, a continuous chime will sound to 1. Tachometer alert you to turn the signal off. If either indicator flashes This gauge measures engine revolutions per minute at a rapid rate, check for a defective outside light bulb.
Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL odometer needs to be repaired or serviced, the repair Message Display Area technician should leave the odometer reading the same When the appropriate conditions exist, the following as it was before the repair or service. If s/he cannot do so, odometer messages will display: then the odometer must be set at zero, and a sticker must be placed in the door jamb stating what the mileage was...
Page 319 UNDERSTANDING YOUR INSTRUMENT PANEL 317 NOTE: Some of the above warnings will be displayed in noFUSE the Electronic Vehicle Information Center Display Area If the vehicle diagnostic system determines that the located in the instrument cluster. Ignition Off Draw (IOD) fuse is improperly installed, or Refer to ”Electronic Vehicle Information Center (EVIC) damaged, a “noFUSE”...
Page 320 318 UNDERSTANDING YOUR INSTRUMENT PANEL Unless reset, this message will continue to display each Electronic Vehicle Information Center (EVIC) Display — time you turn the ignition switch to the ON/RUN If Equipped position. To turn off the message temporarily, press and The Electronic Vehicle Information Center (EVIC) fea- release the STEP button on the steering wheel.
Page 321 UNDERSTANDING YOUR INSTRUMENT PANEL 319 If the ABS light is on, the brake system should be serviced more of your tires is significantly under-inflated. Accord- as soon as possible to restore the benefits of Anti-Lock ingly, when the low tire pressure telltale illuminates, you brakes.
Page 322 320 UNDERSTANDING YOUR INSTRUMENT PANEL illuminated. This sequence will continue upon subse- CAUTION! quent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the sys- The TPMS has been optimized for the original tem may not be able to detect or signal low tire pressure equipment tires and wheels.
Page 323 UNDERSTANDING YOUR INSTRUMENT PANEL 321 9. Malfunction Indicator Light (MIL) CAUTION! The Malfunction Indicator Light (MIL) is part of Prolonged driving with the Malfunction Indicator an onboard diagnostic system, called OBD, that Light (MIL) on could cause damage to the engine monitors engine and automatic transmission con- control system.
Page 324 322 UNDERSTANDING YOUR INSTRUMENT PANEL 10. Electronic Stability Control (ESC) Activation/ NOTE: Malfunction Indicator Light — If Equipped • The “ESC Off Indicator Light” and the “ESC The “ESC Activation/Malfunction Indicator Activation/Malfunction Indicator Light” come on mo- Light” in the instrument cluster will come on mentarily each time the ignition switch is turned to when the ignition switch is turned to the ON/RUN.
Page 325 UNDERSTANDING YOUR INSTRUMENT PANEL 323 11. Electronic Stability Control (ESC) OFF Indicator 14. Fuel Gauge Light — If Equipped The pointer shows the level of fuel in the fuel tank when This light indicates the Electronic Stability Con- the ignition switch is in the ON/RUN position. trol (ESC) is off.
Page 326 324 UNDERSTANDING YOUR INSTRUMENT PANEL 16. Shift Lever Indicator 17. Vehicle Security Light — If Equipped The Shift Lever Indicator is self-contained within the This light will flash at a fast rate for approxi- instrument cluster. It displays the gear position of the mately 15 seconds, when the vehicle security automatic transmission.
Page 327 UNDERSTANDING YOUR INSTRUMENT PANEL 325 In this case, the light will remain on until the condition WARNING! has been corrected. If the problem is related to the brake booster, the ABS pump will run when applying the brake Driving a vehicle with the red brake light on is and a brake pedal pulsation may be felt during each stop.
Page 328 326 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is 20. Temperature Gauge applied with the ignition switch in the ON/RUN posi- The temperature gauge shows engine coolant tempera- tion. ture. Any reading within the normal range indicates that the engine cooling system is operating satisfactorily.
Page 329 UNDERSTANDING YOUR INSTRUMENT PANEL 327 22. Charging System Light WARNING! This light shows the status of the electrical charg- A hot engine cooling system is dangerous. You or ing system. The light should come on when the others could be badly burned by steam or boiling ignition switch is first turned to ON/RUN and remain on coolant.
Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Oil Pressure Warning Light If the light turns on while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, This light indicates low engine oil pressure. The shift the transmission into NEUTRAL and idle the ve- light should turn on momentarily when the engine is hicle.
Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 If the light remains lit with the engine running, your If the overheating continues, it may become necessary to vehicle will usually be drivable; however, see an autho- stop the vehicle and run the engine at idle with the rized dealer for service as soon as possible.
Page 332: Electronic Vehicle Information Center (Evic) - If Equipped
330 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER This system conveniently allows the driver to select a (EVIC) — IF EQUIPPED variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the The Electronic Vehicle Information Center (EVIC) fea- following: tures a driver-interactive display that is located in the...
Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 The system allows the driver to select information by UP Button pressing the following buttons mounted on the steering Press and release the UP button to scroll up- wheel: ward through the main menus (Fuel Economy, Vehicle Info, Tire PSI, Cruise, Messages, Units, System Setup) and sub-menus.
Page 334: Electronic Vehicle Information Center (Evic) Displays
332 UNDERSTANDING YOUR INSTRUMENT PANEL BACK Button The main display area will normally display the main menu or the screens of a selected feature of the main Press the BACK button to scroll back to a menu. The main display area also displays pop up previous menu or sub-menu.
Page 335 UNDERSTANDING YOUR INSTRUMENT PANEL 333 • Unstored Messages When the appropriate conditions exist, the EVIC displays This message type is displayed indefinitely or until the the following messages: condition that activated the message is cleared. Examples • Key in ignition of this message type are Turn Signal On (if a turn signal •...
Page 336 334 UNDERSTANDING YOUR INSTRUMENT PANEL • Vehicle Not in Park • LOW WASHER FLUID • Press Brake Pedal and Push Button to Start • Oil Change Required • Door(s) Ajar (with a single chime, if vehicle is in • Left Front Turn Signal Light Out motion) •...
Page 337: Evic White Telltale Lights
UNDERSTANDING YOUR INSTRUMENT PANEL 335 • Blind Spot System Not Available — This message is EVIC White Telltale Lights displayed to indicate the Blind Spot Monitor (BSM) This area will show reconfigurable white caution tell- system is temporarily unavailable due to sensor block- tales.
Page 338: Evic Amber Telltale Lights
336 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control SET • Loose Gascap Indicator This light will turn on when the electronic If the vehicle diagnostic system determines speed control is SET. For further information, that the fuel filler cap is loose, improperly refer to “Electronic Speed Control”...
Page 339: Evic Red Telltale Lights
UNDERSTANDING YOUR INSTRUMENT PANEL 337 EVIC Red Telltale Lights Do not operate the vehicle until the cause is corrected. This light does not show how much oil is in the engine. This area will show reconfigurable red telltales. These The engine oil level must be checked under the hood. telltales include: •...
Page 340 338 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Throttle Control (ETC) Light • Engine Temperature Warning Light This light informs you of a problem with the This light warns of an overheated engine condi- Electronic Throttle Control (ETC) system. The tion. As temperatures rise and the gauge ap- light will come on when the ignition is first proaches H, this indicator will illuminate and a single turned ON and remain on briefly as a bulb...
Page 341: Oil Change Required
UNDERSTANDING YOUR INSTRUMENT PANEL 339 • Transmission Temperature Warning Light WARNING! This light indicates that the transmission fluid If you continue operating the vehicle when the temperature is running hot. This may occur Transmission Temperature Warning Light is illumi- with severe usage, such as trailer towing. If this nated you could cause the fluid to boil over, come in light turns on, safely pull over and stop the contact with hot engine or exhaust components and...
Page 342: Fuel Economy
340 UNDERSTANDING YOUR INSTRUMENT PANEL Unless reset, this message will continue to display each Fuel Economy time you turn the ignition switch to the ON/RUN Press and release the UP or DOWN button until “Fuel position. To turn off the message temporarily, press and Economy”...
Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 NOTE: Significant changes in driving style or vehicle loading will greatly affect the actual drivable distance of the vehicle, regardless of the DTE displayed value. When the DTE value is less than 30 miles (48 km) estimated driving distance, the DTE display will change to a “LOW FUEL”...
Page 344: Vehicle Speed
342 UNDERSTANDING YOUR INSTRUMENT PANEL Vehicle Speed Trip A Press and release the UP or DOWN button until “Vehicle Shows the total distance traveled for Trip A since the last Speed” displays highlighted in the EVIC and press the reset. SELECT button.
Page 345: Tire Psi
UNDERSTANDING YOUR INSTRUMENT PANEL 343 Tire PSI Vehicle Info (Customer Information Features) Press and release the UP or DOWN button until “Tire Press and release the UP or DOWN button until “Vehicle PSI:” displays highlighted in the EVIC. Press the SELECT Info”...
Page 346: Messages
344 UNDERSTANDING YOUR INSTRUMENT PANEL Messages # NOTE: The system will display the last known outside temperature when starting the vehicle and may need to Select from Main Menu using the UP or DOWN buttons. be driven several minutes before the updated tempera- This feature shows the number of stored warning mes- ture is displayed.
Page 347 UNDERSTANDING YOUR INSTRUMENT PANEL 345 Manual Compass Calibration Compass Variance If the compass appears erratic and the CAL indicator Compass Variance is the difference between Magnetic does not appear in the EVIC display, you must put the North and Geographic North. To compensate for the compass into the Calibration Mode manually, as follows: differences the variance should be set for the zone where the vehicle is driven, per the zone map.
Page 348: Customer-Programmable Features (System Setup)
346 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press the DOWN button until the “Compass Variance” message is displayed in the EVIC, then press the SELECT button. The last variance zone number dis- plays in the EVIC. 4. Press and release the SELECT button until the proper variance zone is selected, according to the map.
Page 349 UNDERSTANDING YOUR INSTRUMENT PANEL 347 Press and release the UP or DOWN button until System route, mile by mile, turn-by-turn until the final destina- Setup is highlighted in the main menu of the EVIC. Then tion is reached. To make your selection, press and release press the SELECT button to enter the System Setup the SELECT button until a check-mark appears next to sub-menu.
Page 350 348 UNDERSTANDING YOUR INSTRUMENT PANEL Refer to “Rear Park Assist System” in “Understanding the doors will unlock on the first press of the RKE The Features Of Your Vehicle” for system function and transmitter UNLOCK button. To make your selection, operating information.
Page 351 UNDERSTANDING YOUR INSTRUMENT PANEL 349 Remote Start Comfort Sys. – If Equipped and release the SELECT button until a check-mark ap- pears next to the feature showing the system has been When this feature is selected and the remote start is activated or the check-mark is removed showing the activated, the heated steering wheel and driver heated system has been deactivated.
Page 352 350 UNDERSTANDING YOUR INSTRUMENT PANEL a check-mark appears next to the feature showing the your selection, press and release the SELECT button until system has been activated or the check-mark is removed a check-mark appears next to the setting, showing that showing the system has been deactivated.
Page 353 UNDERSTANDING YOUR INSTRUMENT PANEL 351 Intermittent Wiper Options — If Equipped highlighted, then press and release the SELECT button until a check-mark appears next to the setting, showing When ON is selected, the system will automatically that the setting has been selected. activate the windshield wipers if it senses moisture on the windshield.
Page 354 352 UNDERSTANDING YOUR INSTRUMENT PANEL next to the feature showing the system has been activated Tilt Mirror In Reverse – If Equipped or the check-mark is removed showing the system has When this feature is selected and the vehicle is placed in been deactivated.
Page 355: Uconnect® 730N/430/430N Cd/Dvd/Hdd
UNDERSTANDING YOUR INSTRUMENT PANEL 353 mode, in this mode the Blind Spot Monitor (BSM) will Compass Variance show a visual alert in the outside mirrors as well as an Refer to “Compass Display” for more information. audible alert when the turn signal is on. When “Blind Turn Menu Off Spot Alert Off”...
Page 356: Uconnect® 130
354 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect® 130 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping.
Page 357 UNDERSTANDING YOUR INSTRUMENT PANEL 355 TIME Button RW/FF Press the TIME button to alternate display of the time Pressing the RW (Rewind) or FF (Fast Forward) buttons and radio frequency. causes the tuner to search for the next frequency in the direction of the arrows.
Page 358 356 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a third AM/FM Button time and TREBLE will display. Turn the TUNE/SCROLL Press the buttons to select either AM or FM mode. control knob to the right or left to increase or decrease the SET/RND Button —...
Page 359: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 357 and 12 FM stations to be stored into pushbutton memory. Operation Instructions — CD MODE For CD And The stations stored in SET 2 memory can be selected by MP3 Audio Play pressing the pushbutton twice. NOTE: Every time a preset button is used, a corresponding •...
Page 360 358 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio CAUTION! (Continued) ON, the unit will switch from radio to CD mode and • Dual-media disc types (one side is a DVD, the begin to play when you insert the disc.
Page 361: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 359 SEEK Button AM/FM Button Press the right SEEK button for the next selection on the Press the button to select either AM or FM mode. CD. Press the left SEEK button to return to the beginning SET/RND Button (Random Play Button) of the current selection, or return to the beginning of the Press this button while the CD is playing to activate...
Page 362 360 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) display the file name and folder name, and will assign a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 363 UNDERSTANDING YOUR INSTRUMENT PANEL 361 Supported MP3 File Formats MPEG Specifi- Sampling Fre- Bit Rate (kbps) cation quency (kHz) The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 MPEG-1 Audio 48, 44.1, 32 320, 256, 224, extension may cause playback problems.
Page 364: Operation Instructions - Auxiliary Mode
362 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files Operation Instructions - Auxiliary Mode When a medium containing MP3 data is loaded, the The auxiliary (AUX) jack is an audio input jack, which radio checks all files on the medium. If the medium allows the user to plug in a portable device, such as an contains a lot of folders or files, the radio will take more MP3 player, or iPod®, and utilize the vehicle’s audio...
Page 365: Uconnect® 130 With Satellite Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 363 Uconnect® 130 WITH SATELLITE RADIO Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON/RUN or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio.
Page 366 364 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Press and release the SEEK buttons to search for the next Uconnect Phone” message will display on the radio listenable station in AM/FM mode.
Page 367 UNDERSTANDING YOUR INSTRUMENT PANEL 365 Clock Setting Procedure starting at Step 2. For vehicles not equipped with satellite radio, press the SETUP button and then follow the above 1. Press and hold the TIME button until the hours blink. procedure, starting at Step 2. 2.
Page 368 366 UNDERSTANDING YOUR INSTRUMENT PANEL Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob a fifth time and FADE will display. Turn the TUNE/SCROLL control Push the rotary TUNE/SCROLL control knob and BASS knob to the left or right to adjust the sound level between will display.
Page 369 UNDERSTANDING YOUR INSTRUMENT PANEL 367 Toggle the MUSIC TYPE button to select the following 16-Digit Character Dis- Program Type format types: play Oldies Oldies 16-Digit Character Dis- Program Type Personality Persnlty play Public Public No program type or un- None defined Rhythm and Blues R &...
Page 370 368 UNDERSTANDING YOUR INSTRUMENT PANEL By pressing the SEEK button when the Music Type icon is AM/FM Button displayed, the radio will be tuned to the next frequency Press the button to select either AM or FM mode. station with the same selected Music Type name. The SET/RND Button —...
Page 371: Operation Instructions - Cd Mode For
UNDERSTANDING YOUR INSTRUMENT PANEL 369 and 12 FM stations to be stored into pushbutton memory. Operation Instructions — CD MODE for CD and The stations stored in SET 2 memory can be selected by MP3 Audio Play pressing the pushbutton twice. NOTE: Every time a preset button is used, a corresponding •...
Page 372 370 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON/RUN and the CAUTION! (Continued) radio ON, the unit will switch from radio to CD mode • Dual-media disc types (one side is a DVD, the and begin to play when you insert the disc. The display other side is a CD) should not be used, and they can will show the track number, and index time in minutes cause damage to the player.
Page 373: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 371 SEEK Button AM/FM Button Press the right SEEK button for the next selection on the Press the button to select either AM or FM mode. CD. Press the left SEEK button to return to the beginning SET/RND Button (Random Play Button) of the current selection, or return to the beginning of the Press this button while the CD is playing to activate...
Page 374 372 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) display the file name and folder name, and will assign a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 375 UNDERSTANDING YOUR INSTRUMENT PANEL 373 Supported MP3 File Formats MPEG Specifi- Sampling Fre- Bit Rate (kbps) cation quency (kHz) The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 MPEG-1 Audio 48, 44.1, 32 320, 256, 224, extension may cause playback problems.
Page 376: List Button (Cd Mode For Mp3 Play)
374 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a When a medium containing MP3 data is loaded, the single-session disc, enable the “Disc at Once” option radio checks all files on the medium.
Page 377: Info Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 375 INFO Button (CD Mode for MP3 Play) Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. Pressing the INFO button repeatedly will scroll through the following TAG information: Song Title, Artist, File NOTE: The AUX device must be turned on and the Name, and Folder Name (if available).
Page 378 376 UNDERSTANDING YOUR INSTRUMENT PANEL sports, news, entertainment, and programming for chil- Electronic Serial Number/Sirius Identification dren, directly from its satellites and broadcasting studios. Number (ESN/SID) Please have the following information available when NOTE: Sirius service is not available in Hawaii and has calling: limited coverage in Alaska.
Page 379 UNDERSTANDING YOUR INSTRUMENT PANEL 377 Selecting Uconnect® (Satellite) Mode Reception Quality Press the SAT button until SAT appears in the display. A Satellite reception may be interrupted due to one of the CD may remain in the radio while in the Satellite radio following reasons: mode.
Page 380 378 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect® (Satellite) INFO Button Mode Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- NOTE: The ignition switch must be in the ON/RUN or able).
Page 381 UNDERSTANDING YOUR INSTRUMENT PANEL 379 MUSIC TYPE Button SETUP Button Pressing this button once will turn on the Music Type Pressing the SETUP button allows you to select the mode for five seconds. Pressing the MUSIC TYPE button following items: or turning the TUNE/SCROLL control knob within five •...
Page 382: Operating Instructions (Uconnect® Phone) - If Equipped
380 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second channel to each pushbutton by Operating Instructions (Uconnect® Phone) — If repeating the above procedure with this exception: Press Equipped the SET button twice and SET 2 will show in the display Refer to “Uconnect®...
Page 383: Connecting The Ipod® Or External Usb Device
UNDERSTANDING YOUR INSTRUMENT PANEL 381 iPod® control supports Mini, 4G, Photo, Nano, 5G iPod® Connecting The iPod® Or External USB Device and iPhone® devices. Some iPod® software versions Use the connection cable to connect an iPod® or external may not fully support the iPod® control features. Please USB device to the vehicle’s USB connector port which is visit Apple’s website for software updates.
Page 384: Using This Feature
382 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The glove compartment will have a position Using This Feature where the iPod® or consumer electronic audio device By using an iPod® cable, or an external USB device to cable can be routed through without damaging the cable connect to the USB port: when closing the lid.
Page 385: Controlling The Ipod® Or External Usb Device Using Radio Buttons
UNDERSTANDING YOUR INSTRUMENT PANEL 383 • Turning it clockwise (forward) by one click, while Controlling The iPod® Or External USB Device Using Radio Buttons playing a track, skips to the next track or press the VR button and say Next Track . To get into the iPod®/USB/MP3 control mode and •...
Page 386 384 UNDERSTANDING YOUR INSTRUMENT PANEL • Use the << SEEK and SEEK>> buttons to jump to the • Press the SCAN button to use iPod®/USB/MP3 de- previous or next track. Pressing the SEEK>> button vice scan mode, which will play the first 10 seconds of during play mode will jump to the next track in the each track in the current list and then forward to the list, or press the VR button and say Next or Previous...
Page 387: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 385 • During all List modes, the iPod® displays all lists in List Or Browse Mode “wrap-around” mode. So if the track is at the bottom During Play mode, pressing any of the buttons described of the list, just turn the wheel backward (counter- below, will bring up List mode.
Page 388 386 UNDERSTANDING YOUR INSTRUMENT PANEL • LIST button: The LIST button will display the top CAUTION! level menu of the iPod® or external USB device. Turn • Leaving the iPod® or external USB device (or any the TUNE control knob to list the top-menu item to be selected and press the TUNE control knob.
Page 389: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 387 Bluetooth Streaming Audio (BTSA) Selecting A Different Audio Device Music can be streamed from your cellular phone to the 1. Press the PHONE button to begin. Uconnect® phone system. 2. After the Ready prompt and following the beep, say Controlling BTSA Using Radio Buttons Setup , then say Select Audio Devices .
Page 390: Uconnect® Multimedia - Video
388 UNDERSTANDING YOUR INSTRUMENT PANEL Browse Browsing is not available on a Bluetooth Streaming Audio (BTSA) device. Only the current song that is playing will display info. UCONNECT® MULTIMEDIA — VIDEO ENTERTAINMENT SYSTEM (VES™) — If Equipped Getting Started • Screen(s) located in the overhead console: Unfold the overhead LCD screen(s) by pushing the button on the overhead console behind the screen(s).
Page 391: Blu-Ray Player
UNDERSTANDING YOUR INSTRUMENT PANEL 389 • Turn on the Player (if equipped on Dual Screen Sys- Blu-ray Player tem) by pushing the Power button, located on the far Play A Blu-ray Disc left, or by pressing the button on the Remote Control. To view a Blu-ray insert the disc into the Blu-ray VES™...
Page 392: Play Video Games
390 UNDERSTANDING YOUR INSTRUMENT PANEL Using the Remote Control • Select an audio channel (Channel 1 for 2nd row screen and Channel 2 for 3rd row screen), then press the source key and select VES™ Disc from the menu. • Press popup/menu key to navigate disc menu and options.
Page 393 UNDERSTANDING YOUR INSTRUMENT PANEL 391 When connecting an external source to the AUX input, be sure to follow the standard color coding for the VES™ jacks: NOTE: Certain high-end video games, such as Playsta- tion3 and XBox360 will exceed the power limit of the vehicle’s Power Inverter.
Page 394 392 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Touch the Rear VES soft-key to display the Rear VES 3. Touch the 1 soft-key and then touch either AUX 1 or Controls. If a channel list is displayed, press the HIDE AUX 2 in the VES column (depending which AUX LIST soft-key to display the Rear VES Controls screen.
Page 395: Listen To An Audio Source On Channel 2 While A Video Is Playing On Channel 1
UNDERSTANDING YOUR INSTRUMENT PANEL 393 Listen To An Audio Source On Channel 2 While A Video Is Playing On Channel 1 Ensure the Remote Control and Headphone switch is on Channel 2. Using The Remote Control 1. Press the SOURCE button on the Remote Control and the Mode Select Screen will display, unless a video is playing then only a small banner will appear on the bottom of the screen.
Page 396 394 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Touch the Rear VES soft-key to display the Rear VES 3. To listen to an audio source on Channel 2 while a Controls. If a channel list is displayed, press the HIDE video is playing on Channel 1, touch the 2 soft-key and LIST soft-key to display the Rear VES Controls screen.
Page 397: Dual Video Screen
UNDERSTANDING YOUR INSTRUMENT PANEL 395 Dual Video Screen 3. To watch a DVD on Screen 1 for second row passen- gers, ensure the Remote Control and Headphone NOTE: Typically there are two different ways to operate switch is on Channel 1. the features of the Video Entertainment System (VES™).
Page 398 396 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • Channel/Screen 1 select mode information is shown on the left side of the screen. • Channel/Screen 2 select mode information is shown on the right side of the screen. • The VES™ will retain the last setting when turned off. Using The Touch-Screen Radio Controls 1.
Page 399 UNDERSTANDING YOUR INSTRUMENT PANEL 397 NOTE: • To view a DVD on the radio press the RADIO/MEDIA hard-key, on the radio faceplate, then touch the DISC tab soft-key and then the VIEW VIDEO soft-key. • Viewing a DVD on the Touch-Screen radio screen is not available in all states/provinces.
Page 400: Understanding Your Instrument Panel
398 UNDERSTANDING YOUR INSTRUMENT PANEL Play A DVD Using The VES™ Player (If Equipped) Using The Remote Control 1. Press the SOURCE button on the Remote Control. 1. Insert the DVD with the label facing up. The VES™ player automatically selects the appropriate mode 2.
Page 401 UNDERSTANDING YOUR INSTRUMENT PANEL 399 NOTE: • Channel/Screen 1 select mode information is shown on the left side of the screen. • Channel/Screen 2 select mode information is shown on the right side of the screen. • The VES™ will retain the last setting when turned off. Using The Touch-Screen Radio Controls 1.
Page 402 400 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • To view a DVD on the radio press the RADIO/MEDIA hard-key, on the radio faceplate, then touch the DISC tab soft-key and then the VIEW VIDEO soft-key. • Viewing a DVD on the Touch-Screen radio screen is not available in all states/provinces.
Page 403: Play A Blu-Ray Disc Using The Blu-Ray Player (If Equipped)
UNDERSTANDING YOUR INSTRUMENT PANEL 401 Play A Blu-ray Disc Using The Blu-ray Player (If Using The Remote Control Equipped) 1. Press the SOURCE button on the Blu-ray player Re- 1. Insert the Blu-ray disc with the label facing up. The mote Control.
Page 404 402 UNDERSTANDING YOUR INSTRUMENT PANEL Using The Touch-Screen Radio Controls NOTE: • To view a Blu-ray Disc on the radio press the RADIO/ 1. Press the MENU hard-key on the radio faceplate. MEDIA hard-key, on the radio faceplate, then touch 2.
Page 405: Listen To An Audio Source While A Video Is Playing
UNDERSTANDING YOUR INSTRUMENT PANEL 403 Listen To An Audio Source While A Video Is Playing Ensure the Remote Control and Headphone switch are on the same channel. If watching a video on Screen 1 (second row), then Channel 2 could be used for audio. If watching a video on Screen 2 (third row), then Channel 1 could be used for audio.
Page 406 404 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Touch the Rear VES soft-key to display the Rear VES 3. To listen to an audio source on Channel 2 while a Controls. If a channel list is displayed, press the HIDE video is playing on Channel 1, touch the 2 soft-key and LIST soft-key to display the Rear VES Controls screen.
Page 407: Important Notes For Dual Video Screen System
UNDERSTANDING YOUR INSTRUMENT PANEL 405 • Selecting a video source on Channel 2, the video Important Notes For Dual Video Screen System source will display on the third row screen or Screen 2 • VES is able to transmit two channels of stereo audio and can be heard on Channel 2.
Page 408: Ves™ Remote Control - If Equipped
406 UNDERSTANDING YOUR INSTRUMENT PANEL VES™ Remote Control – If Equipped 2. Channel Selector Indicators – When a button is pressed, the currently affected channel or channel button is illuminated momentarily. 3. Light – Turns the remote control backlighting on or off. The remote backlighting turns off automatically after five seconds.
Page 409 UNDERSTANDING YOUR INSTRUMENT PANEL 407 / Prev – In radio modes, press to select to the 10. PROG Up/Down / Rewind/skip back and fast fwd/ previous station. In disc modes, press to advance to skip forward – When listening to a radio mode, the start of the current or previous audio track or pressing PROG Up selects the next preset and press- video chapter.
Page 410 408 UNDERSTANDING YOUR INSTRUMENT PANEL 12. SLOW – If Equipped – Press to slow playback of a 16. BACK – When navigating in menu mode, press to DVD disc. Press play ( ) to resume normal play. return to the previous screen. When navigating a DVDs disc menu, the operation depends on the disc’s 13.
Page 411: Blu-Ray Player Remote Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 409 Blu-ray Player Remote Control – If Equipped 2. Channel Selector Indicators – When a button is pressed, the currently affected channel or channel button is illuminated momentarily. 3. SOURCE – Press to enter Source Selection screen. 4.
Page 412 410 UNDERSTANDING YOUR INSTRUMENT PANEL – Press and release to jump to the next available – Press and release to jump to the previous audio track or video chapter. Press and hold to fast audio track or video chapter. Press and hold to fast forward through the current audio track or video rewind through the current audio track or video chapter.
Page 413: Remote Control Storage
UNDERSTANDING YOUR INSTRUMENT PANEL 411 Remote Control Storage The video screen(s) come with a built in storage compart- ment for the remote control which is accessible when the screen is opened. To remove the remote, use your index finger to pull and rotate the remote towards you. Do not try to pull the remote straight down as it will be very difficult to remove.
Page 414: Locking The Remote Control
412 UNDERSTANDING YOUR INSTRUMENT PANEL • Replace the batteries, making sure to orient them Locking The Remote Control according to the polarity diagram shown. All remote control functionality can be disabled as a • Replace the battery compartment cover. parental control feature. •...
Page 415: Blu-Ray Headphones Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 413 Blu-ray Headphones Operation The headphones receive two separate channels of audio using an infrared transmitter from the video screen. Front seat occupants receive some headphone audio coverage to allow them to adjust the headphone volume for the young rear seat occupants that may not be able to do so for themselves.
Page 416: Controls
414 UNDERSTANDING YOUR INSTRUMENT PANEL Controls The headphone power indicator and controls are located on the right ear cup. NOTE: The rear video system must be turned on before sound can be heard from the headphones. To conserve battery life, the headphones will automatically turn off approximately three minutes after the rear video system is turned off.
Page 417: Replacing The Headphone Batteries
UNDERSTANDING YOUR INSTRUMENT PANEL 415 NOTE: 4. When the Mode Selection menu appears on screen, use the cursor buttons on the remote control to navi- • When both switches are on Channel 1, the Remote is gate to the available modes and press the OK button to controlling Channel 1 and the headphones are tuned to select the new mode.
Page 418: Unwired® Stereo Headphone Lifetime Limited Warranty
416 UNDERSTANDING YOUR INSTRUMENT PANEL Unwired® Stereo Headphone Lifetime Limited What Does This Warranty Not Cover? This warranty Warranty does not cover any damage or defect that results from misuse, abuse or modification of the Product other than Who Does This Warranty Cover? This warranty covers by Unwired.
Page 419: System Information
UNDERSTANDING YOUR INSTRUMENT PANEL 417 What Will Unwired® Do? Unwired®, at its option, will System Information repair or replace any defective Product. Unwired® re- Shared Modes serves the right to replace any discontinued Product with This allows the VES™ to output radio sources to the a comparable model.
Page 420: Information Mode Display
418 UNDERSTANDING YOUR INSTRUMENT PANEL The VES™ has the ability to switch tuner (AM/FM), Information Mode Display SEEK, SCAN, TUNE, and recall presets in radio modes as long as it is not in shared mode. When in shared disc mode both the radio and the VES™ have control of the video functions.
Page 421: Numeric Keypad Menu
UNDERSTANDING YOUR INSTRUMENT PANEL 419 4. Channel 2 Mode Numeric Keypad Menu 5. Channel 2 Shared Status 6. Channel 2 Audio Only/Mute 7. Channel 1 ENTER/OK Button Action 8. Channel 2 ENTER/OK Button Action 9. Clock 10. Video Lock 11. Not Available / Error Numeric Keypad Menu When the display for either Channel 1 or Channel 2 shows DIRECT TUNE, pressing the remote control’s OK...
Page 422: Station List Menu
420 UNDERSTANDING YOUR INSTRUMENT PANEL makes it easy to enter a specific tuner frequency, satellite Station List Menu channel, or track number. To enter the desired digit: When listening to Satellite audio, pressing the remote control’s POP UP/MENU button displays a list of all 1.
Page 423: Disc Menu
UNDERSTANDING YOUR INSTRUMENT PANEL 421 Disc Menu Display Settings When watching a video source (DVD Video with the disc in Play mode, Aux Video, etc.), pressing the remote control’s SETUP button activates the Display Settings menu. These settings control the appearance of the video on the screen.
Page 424: Listening To Audio With The Screen Closed
422 UNDERSTANDING YOUR INSTRUMENT PANEL Listening To Audio With The Screen Closed Disc Formats To listen to only audio portion of the channel with the The VES™ DVD player is capable of playing the follow- screen closed: ing types of discs (12 cm or 8 cm diameter): •...
Page 425 UNDERSTANDING YOUR INSTRUMENT PANEL 423 The Blu-Ray player is capable of the playing the follow- DVD Audio Support ing types of discs (12 cm diameter): When a DVD-Audio disc is inserted in the VES™ DVD • BD: BDMV (Profile 1.1), BDAV (Profile 1.1), player, the DVD-Audio title on the disc is played by default (most DVD-Audio discs also have a Video title, •...
Page 426 424 UNDERSTANDING YOUR INSTRUMENT PANEL • The player recognizes a maximum of 512 files and 99 If you record a disc using a personal computer, there may be cases where the VES™ DVD player may not be able to folders per CD-R and CD-RW disc. play some or the entire disc, even if it is recorded in a •...
Page 427 UNDERSTANDING YOUR INSTRUMENT PANEL 425 • Other compression formats such as AAC, MP3 Pro, Compressed Audio Files (MP3 and WMA) Ogg Vorbis, and ATRAC3 will not play. The DVD The DVD player is capable of playing MP3 (MPEG-1 player will automatically skip the file and begin play- Audio Layer 3) and WMA (Windows Media Audio) files ing the next available file.
Page 428 426 UNDERSTANDING YOUR INSTRUMENT PANEL Disc Errors The DVD player may shut down during extremely hot conditions, such as when the vehicle’s interior tempera- If the DVD player is unable to read the disc, a Disc Error ture is above 120°F. When this occurs, the DVD player message is displayed on the VES™...
Page 429: Display
UNDERSTANDING YOUR INSTRUMENT PANEL 427 Display All of the Language settings have a special Other setting to accommodate languages other than Japanese or Eng- Other Language Setup lish. These languages are selected using a special four- digit code. To enter a new language code, activate the DVD Setup Menu.
Page 430 428 UNDERSTANDING YOUR INSTRUMENT PANEL • Using the remote control Up and Down cursor but- Rating and Password Setup tons, select a digit for the current position. After The Rating and Password settings work together to selecting the digit, press the remote control’s Right control the types of DVDs that your family watches.
Page 431 UNDERSTANDING YOUR INSTRUMENT PANEL 429 Not all DVD discs encode a Rating, so it is still possible that discs designed for adult audiences can still play without requiring a password. The default rating is Level 8 (play all discs without a password) and the default password is 0000.
Page 432 430 UNDERSTANDING YOUR INSTRUMENT PANEL • After the four-digit password is entered, press the To set the password, activate the DVD Setup Menu and follow these additional instructions: remote control’s ENTER/OK button. If the password is correct, the set password screen is displayed. •...
Page 433 UNDERSTANDING YOUR INSTRUMENT PANEL 431 To set the rating, activate the DVD Setup Menu and follow these additional instructions: • Using the remote control’s Left and Right cursor buttons, select the Rating tab. • Highlight Change Rating , and then press the remote control’s ENTER/OK button.
Page 434: Product Agreement
432 UNDERSTANDING YOUR INSTRUMENT PANEL • THIS PRODUCT IS LICENSED UNDER THE AVC Product Agreement PATENT PORTFOLIO LICENSE FOR THE PER- Software SONAL AND NON-COMMERCIAL USE OF A CON- This product contains software licensed under GNU SUMER TO (i) ENCODE VIDEO IN COMPLIANCE General Public License (GPL) or GNU Lesser General WITH THE AVC STANDARD ( AVC VIDEO ) Public License (LGPL), etc.
Page 435 UNDERSTANDING YOUR INSTRUMENT PANEL 433 AND/OR (ii) DECODE VC-1 VIDEO THAT WAS Center at http://www.cinavia.com. To request additional ENCODED BY A CONSUMER ENGAGED IN A PER- information about Cinavia by mail, send a postcard with SONAL NON-COMMERCIAL ACTIVITY your mailing address to: Cinavia Consumer Information AND/OR WAS OBTAINED FROM A VIDEO PRO- Center, P.O.
Page 436 434 UNDERSTANDING YOUR INSTRUMENT PANEL • Manufactured under license under U.S. Patent #’s: your device setup menu. Go to vod.divx.com for more 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & information on how to complete your registration. other U.S. and worldwide patents issued & pending. DivX®, DivX Certified®...
Page 437: Steering Wheel Audio Controls - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 435 STEERING WHEEL AUDIO CONTROLS — IF The remote sound system controls are located on the rear EQUIPPED surface of the steering wheel, at the three and nine o’clock positions. The right-hand rocker switch has a pushbutton in the center, and controls the volume and mode of the sound system.
Page 438: Radio Operation
436 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation CD/DVD/BLU-RAY DISC MAINTENANCE Pressing the top of the switch will SEEK up for the next To keep a CD/DVD/Blu-ray disc in good condition, take listenable station, and pressing the bottom of the switch the following precautions: will SEEK down for the next listenable station.
Page 439: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 437 NOTE: If you experience difficulty in playing a particular CLIMATE CONTROLS disc, it may be damaged (i.e., scratched, reflective coating The Climate Control system allows you to regulate the removed, a hair, moisture or dew on the disc) oversized, temperature, amount, and direction of air circulating or have protection encoding.
Page 440 438 UNDERSTANDING YOUR INSTRUMENT PANEL When the front control is in any position other than rear, the front control operates all the rear functions. The rear airflow modes will mirror the front unit opera- tion. Rear Panel mode is automatically selected when the front control is in the Panel mode.
Page 441 UNDERSTANDING YOUR INSTRUMENT PANEL 439 2. Rear Blower Control — If Equipped NOTE: For vehicles equipped with Remote Start, the climate controls will not function during Remote Start • Use this control to regulate the amount of air forced operation if the blower control is left in the “O” (Off) through the rear system in any mode you select.
Page 442 440 UNDERSTANDING YOUR INSTRUMENT PANEL 6. Mix Mode 8. Electronic Rear Window Defrost Air is directed through the floor, defrost and side Press this button to turn on the rear window window demist outlets. This setting works best in defroster and the heated outside mirrors (if cold or snowy conditions that require extra heat at the equipped).
Page 443 UNDERSTANDING YOUR INSTRUMENT PANEL 441 9. Recirculation Control Button CAUTION! Press this button to choose between outside air Failure to follow these cautions can cause damage to intake or recirculation of the air inside the the heating elements: vehicle. An indicator light will illuminate when •...
Page 444 442 UNDERSTANDING YOUR INSTRUMENT PANEL • In cold or damp weather, the use of the Recirculation NOTE: If your air conditioning performance seems mode will cause windows to fog on the inside because lower than expected, check the front of the A/C con- of moisture buildup inside the vehicle.
Page 445: Rear Manual Climate Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 443 NOTE: There is a difference in temperature (in any Rotate the temperature control knob to the desired tem- conditions other than full cold or full hot), between the perature. Also, make sure to select only Panel, Bi-Level or upper and lower outlets for added comfort.
Page 446 444 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Blower Control The primary control for the rear blower is on the front climate control unit, located on the instrument panel. Only when the front control for the rear blower is in the REAR position do the second row seat occupants have control of the rear blower speed.
Page 447 UNDERSTANDING YOUR INSTRUMENT PANEL 445 Rear Mode Control CAUTION! (Continued) Headliner Mode just behind the sliding door. Do not block or place objects directly in front of the inlet grille or heater Air comes from the outlets in the headliner. Each outlets.
Page 448: Automatic Temperature Control (Atc) - If Equipped
446 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) — If The Three-Zone ATC system automatically maintains the Equipped interior comfort level desired by the driver and all passen- gers. The system automatically adjusts the air temperature, • Front Three-Zone ATC allows both driver and front the airflow volume, amount of outside air recirculation and passenger seat occupant, and rear seat occupants to the airflow direction.
Page 449 UNDERSTANDING YOUR INSTRUMENT PANEL 447 1. Air Conditioning (A/C) Button 6. Auto Indicator Press and release to change the current Air Conditioning This indicates when the system is in Auto mode. (A/C) setting, the indicator illuminates when A/C is ON. 7.
Page 450 448 UNDERSTANDING YOUR INSTRUMENT PANEL 10. Rear Control Button 13. Climate Control OFF Button Provides toggle operation between front control screen Press and release to turn the Climate Control OFF. If the and rear control screen. Push the button to activate the control is OFF, press any button to turn the control ON.
Page 451 UNDERSTANDING YOUR INSTRUMENT PANEL 449 16. Recirculation Control Button Automatic Operation Press and release to change the current setting, the 1. Press the AUTO button on the front ATC Panel and the indicator illuminates when ON. words Front Auto will illuminate in the front ATC display, along with two temperatures for the driver 17.
Page 452 450 UNDERSTANDING YOUR INSTRUMENT PANEL 3. When the system is set up for your comfort level, it is To provide you with maximum comfort in the automatic not necessary to change the settings. You will experi- mode, during cold start-ups, the blower fan will remain ence the greatest efficiency by simply allowing the on low until the engine warms up.
Page 453 UNDERSTANDING YOUR INSTRUMENT PANEL 451 • Air Conditioning (A/C) Controlling The Rear Climate Controls From The Front ATC Panel The Air Conditioning (A/C) button allows the operator The Three-Zone ATC system allows for adjustment of the to manually activate or deactivate the air conditioning rear climate controls from the front ATC panel.
Page 454 452 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Mode Display This display shows the current Mode selection. 2. Rear Temperature Display This display shows the temperature setting for the rear seat occupants. 3. Blower Control Display This display shows the current Blower speed selection. 4.
Page 455 UNDERSTANDING YOUR INSTRUMENT PANEL 453 Rear Mode Control Rear Automatic Temperature Control (ATC) — If Equipped Headliner Mode The rear ATC system has floor air outlets at the rear of the Air comes from the outlets in the headliner. Each right side sliding door, and overhead outlets at each of these outlets can be individually adjusted to outboard rear seating position.
Page 456 454 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Press the Rear Temperature Lock button on the front ATC panel. This turns off the Rear Temperature Lock icon in the rear temperature knob. 2. Rotate the Rear Blower, Rear Temperature and the Rear Mode Control knobs to suit your comfort needs. 3.
Page 457 UNDERSTANDING YOUR INSTRUMENT PANEL 455 NOTE: Rear Blower Control • It is not necessary to move the temperature settings for The rear blower control knob can be manually set to off, or any fixed blower speed, by rotating the knob from low cold or hot vehicles.
Page 458 456 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Temperature Control Rear Mode Control • Auto Mode To change the temperature in the rear of the vehicle, rotate the temperature knob counterclockwise to lower The rear system automatically maintains the correct the temperature, and clockwise to increase the tempera- mode and comfort level desired by the rear seat occu- ture.
Page 459 UNDERSTANDING YOUR INSTRUMENT PANEL 457 • Bi-Level Mode Recirculation Control Air comes from both the headliner outlets and the When outside air contains smoke, odors, or high humid- floor outlets. ity, or if rapid cooling is desired, you may wish to recirculate interior air by pressing the Recir- NOTE: In many temperature positions, the Bi-Level culation control button.
Page 460: Summer Operation
458 UNDERSTANDING YOUR INSTRUMENT PANEL Summer Operation Procedures” in “Maintaining Your Vehicle” for proper coolant selection. Use of the air Recirculation mode The engine cooling system must be protected with a during Winter months is not recommended, because it high-quality antifreeze coolant to provide proper corro- may cause window fogging.
Page 461: Window Fogging
UNDERSTANDING YOUR INSTRUMENT PANEL 459 Window Fogging enter the plenum, they could plug the water drains. In Winter months, make sure the air intake is clear of ice, Vehicle windows tend to fog on the inside in mild, rainy slush, and snow. and/or humid weather.
Page 462: Operating Tips Chart
460 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Chart...
Page 463: Starting And Operating
STARTING AND OPERATING CONTENTS ▫ Brake/Transmission Shift Interlock System . . .471 STARTING PROCEDURES ....465 ▫ Automatic Transmission ....465 ▫...
Page 464 462 STARTING AND OPERATING ▫ Tire Identification Number (TIN)...507 POWER STEERING .....485 ▫...
Page 465 STARTING AND OPERATING 463 ▫ Compact Spare Tire – If Equipped ..520 FUEL REQUIREMENTS ....537 ▫...
Page 466 464 STARTING AND OPERATING ▫ Selection Of Engine Oil For Flexible Fuel VEHICLE LOADING ....548 Vehicles (E-85) And Gasoline Vehicles ..545 ▫...
Page 467: Starting Procedures
STARTING AND OPERATING 465 STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the • Do not leave the key fob in or near the vehicle, or inside and outside mirrors, fasten your seat belt, and if in a location accessible to children.
Page 468: Extreme Cold Weather (Below -20°F Or −29°C)
466 STARTING AND OPERATING 3. If the engine fails to start, the starter will disengage If The Engine Fails To Start automatically in 10 seconds. If this occurs, turn the ignition switch to the OFF position, wait 10 to 15 WARNING! seconds, then repeat the “Normal Starting”...
Page 469: After Starting
STARTING AND OPERATING 467 If the engine has been flooded, it may start to run, but not WARNING! (Continued) have enough power to continue running when the key • If the vehicle has a discharged battery, booster fob is released. If this occurs, continue cranking with the cables may be used to obtain a start from a booster accelerator pedal pushed all the way to the floor.
Page 470: Engine Block Heater - If Equipped
468 STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED AUTOMATIC TRANSMISSION The engine block heater warms the engine, and permits CAUTION! quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a Damage to the transmission may occur if the follow- grounded, three-wire extension cord.
Page 471 STARTING AND OPERATING 469 WARNING! WARNING! (Continued) • Unintended movement of a vehicle could injure • It is dangerous to shift out of PARK or NEUTRAL those in or near the vehicle. As with all vehicles, if the engine speed is higher than idle speed. If you should never exit a vehicle while the engine is your foot is not firmly pressing the brake pedal, the running.
Page 472: Key Ignition Park Interlock
470 STARTING AND OPERATING Key Ignition Park Interlock WARNING! (Continued) This vehicle is equipped with a Key Ignition Park Inter- • Never leave children alone in a vehicle, or with lock which requires the transmission to be in PARK access to an unlocked vehicle. Allowing children to before the ignition switch can be turned to the full OFF be in a vehicle unattended is dangerous for a (key removal) position.
Page 473: Brake/Transmission Shift Interlock System
STARTING AND OPERATING 471 Brake/Transmission Shift Interlock System Fuel Economy (ECON) Mode This vehicle is equipped with a Brake Transmission Shift The Fuel Economy (ECON) mode can improve the vehi- Interlock System (BTSI) that holds the transmission cle’s overall fuel economy during normal driving condi- shifter in PARK unless the brakes are applied.
Page 474: Six-Speed Automatic Transmission
472 STARTING AND OPERATING When the Fuel Economy (ECON) Mode is engaged, the Six-Speed Automatic Transmission vehicle control systems will change the following: The transmission gear position display (located in the • The transmission will upshift sooner and downshift instrument cluster) indicates the transmission gear range. later.
Page 475: Gear Ranges
STARTING AND OPERATING 473 The transmission shift lever has only PARK, REVERSE, NEUTRAL, and DRIVE shift positions. Manual down- shifts can be made using the Electronic Range Select (ERS) shift control (described later in this section). Mov- ing the shift lever to the left or right (–/+) while in the DRIVE position will select the highest available transmis- sion gear, and will display that gear in the instrument cluster as 6, 5, 4, 3, 2, 1.
Page 476 474 STARTING AND OPERATING PARK WARNING! This range supplements the parking brake by locking the • Never use the PARK position as a substitute for the transmission. The engine can be started in this range. parking brake. Always apply the parking brake Never attempt to use PARK while the vehicle is in fully when parked to guard against vehicle move- motion.
Page 477 STARTING AND OPERATING 475 WARNING! (Continued) WARNING! (Continued) • It is dangerous to shift out of PARK or NEUTRAL • Unintended movement of a vehicle could injure if the engine speed is higher than idle speed. If those in or near the vehicle. As with all vehicles, your foot is not firmly pressing the brake pedal, the you should never exit a vehicle while the engine is vehicle could accelerate quickly forward or in re-...
Page 478 476 STARTING AND OPERATING • Look at the transmission gear position display and WARNING! (Continued) verify that it indicates the PARK position. • Allowing children to be alone in a vehicle unat- • With brake pedal released, verify that the shift lever tended is dangerous for a number of reasons.
Page 479 STARTING AND OPERATING 477 REVERSE WARNING! This range is for moving the vehicle backward. Shift into Do not coast in NEUTRAL and never turn off the REVERSE only after the vehicle has come to a complete ignition to coast down a hill. These are unsafe stop.
Page 480 478 STARTING AND OPERATING DRIVE During cold temperatures, transmission operation may be modified depending on engine and transmission This range should be used for most city and highway temperature as well as vehicle speed. This feature im- driving. It provides the smoothest upshifts and down- proves warm up time of the engine and transmission to shifts, and the best fuel economy.
Page 481 STARTING AND OPERATING 479 PARK, REVERSE, and NEUTRAL will continue to oper- NOTE: Even if the transmission can be reset, we recom- ate. The Malfunction Indicator Light (MIL) may be illu- mend that you visit your authorized dealer at your minated.
Page 482 480 STARTING AND OPERATING You can switch between DRIVE and ERS mode at any To exit ERS mode, simply press and hold the shift lever to vehicle speed. When the shift lever is in the DRIVE the right (+) until “D” is once again displayed in the position, the transmission will operate automatically, instrument cluster.
Page 483 STARTING AND OPERATING 481 NOTE: To select the proper gear position for maximum Torque Converter Clutch deceleration (engine braking), tap the shift lever to the A feature designed to improve fuel economy has been left (-) repeatedly as the vehicle slows. The transmission included in the automatic transmission on your vehicle.
Page 484: Driving On Slippery Surfaces
482 STARTING AND OPERATING DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.
Page 485: Driving Through Water
STARTING AND OPERATING 483 DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
Page 486 484 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause damage • Driving through standing water limits your vehi- to your vehicle’s drivetrain components. Always cle’s traction capabilities. Do not exceed 5 mph inspect your vehicle’s fluids (i.e., engine oil, trans- (8 km/h) when driving through standing water.
Page 487: Power Steering
STARTING AND OPERATING 485 • Upon initial start-up in cold weather, the power steer- POWER STEERING ing pump may make noise for a short amount of time. The standard power steering system will give you good This is due to the cold, thick fluid in the steering vehicle response and increased ease of maneuverability system.
Page 488: Power Steering Fluid Check
486 STARTING AND OPERATING Power Steering Fluid Check WARNING! Checking the power steering fluid level at a defined Fluid level should be checked on a level surface and service interval is not required. The fluid should only be with the engine off to prevent injury from moving checked if a leak is suspected, abnormal noises are parts and to ensure accurate fluid level reading.
Page 489: Parking Brake
STARTING AND OPERATING 487 PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied and place the shift lever in the PARK position. The foot operated parking brake is positioned below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully.
Page 490 488 STARTING AND OPERATING NOTE: WARNING! • When the parking brake is applied and the automatic • When leaving the vehicle, always remove the key transmission is placed in gear, the “Brake Warning fob from the ignition and lock your vehicle. Light”...
Page 491: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 489 ABS is activated during braking under certain road or CAUTION! stopping conditions. ABS-inducing conditions can in- clude ice, snow, gravel, bumps, railroad tracks, loose If the Brake System Warning Light remains on with debris, or panic stops. the parking brake released, a brake system malfunc- tion is indicated.
Page 492 490 STARTING AND OPERATING WARNING! WARNING! (Continued) • The capabilities of an ABS-equipped vehicle must • The Anti-Lock Brake System contains sophisti- never be exploited in a reckless or dangerous cated electronic equipment that may be susceptible manner, which could jeopardize the user’s safety or to interference caused by improperly installed, or the safety of others.
Page 493: Anti-Lock Brake Warning Light
STARTING AND OPERATING 491 Anti-Lock Brake Warning Light If the “Anti-Lock Brake Warning Light” is on, the brake system should be serviced as soon as possible to restore the benefits of anti-lock brakes. If the “Anti-Lock Brake The “Anti-Lock Brake Warning Light” moni- Warning Light”...
Page 494: Electronic Brake Control System
492 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM system will apply the brake of the spinning wheel. This will allow more engine torque to be applied to the wheel Your vehicle is equipped with an advanced electronic that is not spinning. This feature remains active even if brake control system that includes the Traction Control the ESC is in the “Partial Off”...
Page 495: Brake Assist System (Bas)
STARTING AND OPERATING 493 the system, you must apply continuous braking pressure WARNING! (Continued) during the stopping sequence. Do not reduce brake pedal • The TCS cannot prevent collisions, including those pressure unless braking is no longer desired. Once the resulting from excessive speed in turns, or hydro- brake pedal is released, the BAS is deactivated.
Page 496: Electronic Stability Control (Esc)
494 STARTING AND OPERATING Electronic Stability Control (ESC) the intended path, ESC applies the brake of the appro- priate wheel to assist in counteracting the oversteer or The Electronic Stability Control (ESC) enhances direc- understeer condition. tional control and stability of the vehicle under various •...
Page 497 STARTING AND OPERATING 495 ESC On WARNING! (Continued) This mode is the normal operating mode for ESC on resulting from loss of vehicle control due to inappro- two-wheel drive vehicles. Whenever the vehicle is priate driver input for the conditions. Only a safe, started, the ESC system will be in this mode.
Page 498 496 STARTING AND OPERATING traction. To turn ESC on again, momentarily press the NOTE: To improve the vehicle’s traction when driving “ESC Off” switch. This will restore the normal “ESC On” with snow chains, or starting off in deep snow, sand or mode of operation.
Page 499 STARTING AND OPERATING 497 light remains on after several ignition cycles, and the NOTE: vehicle has been driven several miles (kilometers) at • The “ESC Activation/Malfunction Indicator Light” speeds greater than 30 mph (48 km/h), see your autho- and the “ESC OFF Indicator Light” come on momen- rized dealer as soon as possible to have the problem tarily each time the ignition switch is turned ON.
Page 500: Trailer Sway Control (Tsc)
498 STARTING AND OPERATING Trailer Sway Control (TSC) Malfunction Indicator Light” will flash, the engine power may be reduced and you may feel the brakes being TSC uses sensors in the vehicle to recognize an exces- applied to individual wheels to attempt to stop the trailer sively swaying trailer and will take the appropriate from swaying.
Page 501: Hill Start Assist (Hsa)
STARTING AND OPERATING 499 Hill Start Assist (HSA) HSA Activation Criteria The HSA system is designed to assist the driver when The following criteria must be met in order for HSA to starting a vehicle from a stop on a hill. HSA will maintain activate: the level of brake pressure the driver applied for a short •...
Page 502 500 STARTING AND OPERATING HSA will work in REVERSE and all forward gears when “Electronic Vehicle Information Center (EVIC)” in “Un- the activation criteria have been met. The system will not derstanding Your Instrument Panel” for further informa- activate if the vehicle is placed in NEUTRAL or PARK. tion.
Page 503 STARTING AND OPERATING 501 7. Press the “ESC Off” switch (located in the lower Towing With HSA switch bank below the climate controls) four times HSA will provide assistance when starting on a grade within 20 seconds. The “ESC Activation/Malfunction when pulling a trailer.
Page 504: Tire Safety Information
502 STARTING AND OPERATING TIRE SAFETY INFORMATION WARNING! (Continued) Tire Markings • HSA is not a parking brake. If you stop the vehicle on a hill without putting the transmission in PARK and using the parking brake, it will roll down the hill and could cause a collision with another ve- hicle or object.
Page 505 STARTING AND OPERATING 503 NOTE: tires is the same as for P-Metric tires except for the letters “LT” that are molded into the sidewall preced- • P (Passenger) - Metric tire sizing is based on U.S. ing the size designation. Example: LT235/85R16. design standards.
Page 506 504 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 507 STARTING AND OPERATING 505 EXAMPLE: R = Construction code — R means radial construction — D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol —...
Page 508 506 STARTING AND OPERATING EXAMPLE: Load Identification: ..blank..= Absence of any text on the sidewall of the tire indicates a Standard Load (SL) tire Extra Load (XL) = Extra load (or reinforced) tire Light Load (LL) = Light load tire C, D, E, F, G = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load—...
Page 509: Tire Identification Number (Tin)
STARTING AND OPERATING 507 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on The TIN may be found on one or both sides of the tire, the outboard side, then you will find it on the inboard however, the date code may only be on one side.
Page 510 508 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 ABCD = Code used by the tire manufacturer (one to four digits) 03 = Number representing the week in which the tire was manufactured (two digits) — 03 means the 3rd week 01 = Number representing the year in which the tire was manufactured (two digits) —...
Page 511: Tire Terminology And Definitions
STARTING AND OPERATING 509 Tire Terminology And Definitions Term Definition The vehicle B-Pillar is the structural member of the body located B-Pillar behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 512: Tire Loading And Tire Pressure
510 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
Page 513 STARTING AND OPERATING 511 To determine the maximum loading conditions of your 3) tire size designed for your vehicle vehicle, locate the statement “The combined weight of 4) cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 514 512 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: cargo and luggage load capacity. For example, if • The following table shows examples on how to calcu- “XXX” amount equals 1,400 lbs (635 kg) and there will late total load, cargo/luggage, and towing capacities be five 150 lb (68 kg) passengers in your vehicle, the of your vehicle with varying seating configurations...
Page 515 STARTING AND OPERATING 513...
Page 516: Tires - General Information
514 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 517 STARTING AND OPERATING 515 Ride Comfort And Vehicle Stability WARNING! (Continued) Proper tire inflation contributes to a comfortable ride. • Unequal tire pressures from one side of the vehicle Over-inflation produces a jarring and uncomfortable to the other can cause the vehicle to drift to the ride.
Page 518: Tire Inflation Pressures
516 STARTING AND OPERATING Tire Inflation Pressures been driven for at least three hours, or driven less than 1 mile (1.6 km) after a three hour period. The cold tire At least once a month: inflation pressure must not exceed the maximum infla- •...
Page 519: Tire Pressures For High Speed Operation
STARTING AND OPERATING 517 Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) WARNING! during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. High speed driving with your vehicle under maxi- mum load is dangerous.
Page 520: All Season Tires - If Equipped
518 STARTING AND OPERATING Tire Repair All Season Tires – If Equipped If your tire becomes damaged, it may be repaired if it All Season tires provide traction for all seasons (spring, meets the following criteria: summer, fall and winter). Traction levels may vary be- tween different all season tires.
Page 521: Snow Tires
STARTING AND OPERATING 519 Snow Tires While studded tires improve performance on ice, skid and traction capability on wet or dry surfaces may be Some areas of the country require the use of snow tires poorer than that of non-studded tires. Some states pro- during the winter.
Page 522: Compact Spare Tire - If Equipped
520 STARTING AND OPERATING Compact Spare Tire – If Equipped WARNING! The compact spare is for temporary emergency use only. Compact spares are for temporary emergency use You can identify if your vehicle is equipped with a only. With these spares, do not drive more than compact spare by looking at the spare tire description on 50 mph (80 km/h).
Page 523: Limited-Use Spare - If Equipped
STARTING AND OPERATING 521 your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Limited-use spares are for emergency use only. In- stallation of this limited-use spare tire affects vehicle Limited-Use Spare –...
Page 524: Tire Spinning
522 STARTING AND OPERATING Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires spin your vehicle’s wheels above 30 mph (48 km/h) or to help you in determining when your tires should be for longer than 30 seconds continuously without stop- replaced.
Page 525: Life Of Tire
STARTING AND OPERATING 523 These indicators are molded into the bottom of the tread WARNING! grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the Tires and the spare tire should be replaced after six tread wear indicators, the tire should be replaced.
Page 526 524 STARTING AND OPERATING Information placard or the Vehicle Certification Label for WARNING! the size designation of your tire. The Load Index and • Do not use a tire, wheel size or rating other than Speed Symbol for your tire will be found on the original equipment tire sidewall.
Page 527: Tire Chains (Traction Devices)
STARTING AND OPERATING 525 TIRE CHAINS (TRACTION DEVICES) WARNING! (Continued) Use of traction devices require sufficient tire-to-body • Failure to equip your vehicle with tires having clearance. Follow these recommendations to guard adequate speed capability can result in sudden tire against damage: failure and loss of vehicle control.
Page 528 526 STARTING AND OPERATING WARNING! CAUTION! (Continued) • Install device as tightly as possible and then re- Using tires of different size and type (M+S, Snow) tighten after driving about ½ mile (0.8 km). between front and rear axles can cause unpredictable •...
Page 529: Tire Rotation Recommendations
STARTING AND OPERATING 527 TIRE ROTATION RECOMMENDATIONS The suggested rotation method is the “rearward cross” shown in the following diagram. This rotation pattern The tires on the front and rear of your vehicle operate at does not apply to some directional tires that must not be different loads and perform different steering, driving, reversed.
Page 530: Tire Pressure Monitor System (Tpms)
528 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low pressure warning The TPMS will warn the driver of a low tire pressure threshold for any reason, including low temperature based on the cold inflation tire placard pressure require- effects, or natural air pressure loss through the tire.
Page 531 STARTING AND OPERATING 529 For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) tire placard • The TPMS has been optimized for the original pressure of 35 psi (241 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 30 psi (207 equipment tires and wheels.
Page 532: Base System
530 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, NOTE: and the TPMS will monitor the actual tire pressure in • The TPMS is not intended to replace normal tire care the tire. and maintenance, or to provide warning of a tire failure or condition.
Page 533 STARTING AND OPERATING 531 Tire Pressure Monitoring Low Tire Pressure NOTE: The vehicle may need to be driven for up to 20 Warnings minutes above 15 mph (24 km/h) to receive this infor- mation. The “Tire Pressure Monitoring Telltale Light” The “Tire Pressure Monitoring Telltale Light”...
Page 534 532 STARTING AND OPERATING 3. Accumulation of excessive snow and/or ice around 3. After driving for up to 20 minutes above 15 mph the wheels or wheel housings. (24 km/h), the “Tire Pressure Monitoring Telltale Light” will flash on and off for 75 seconds and then 4.
Page 535: Premium System - If Equipped
STARTING AND OPERATING 533 Premium System – If Equipped TPMS Low Pressure Warnings The TPMS uses wireless technology with wheel rim- The “Tire Pressure Monitoring Telltale Light” will illumi- mounted electronic sensors to monitor tire pressure lev- nate in the instrument cluster, and an audible chime will els.
Page 536 534 STARTING AND OPERATING NOTE: The vehicle may need to be driven for up to 20 message will not be present, and a pressure value will be minutes above 15 mph (24 km/h) to receive this infor- displayed instead of dashes. A system fault can occur by mation.
Page 537 STARTING AND OPERATING 535 message is then followed by a graphic display with 3. After driving the vehicle for up to 20 minutes above pressure values still shown. This indicates that the pres- 15 mph (24 km/h), the “Tire Pressure Monitoring sure values are still being received from the TPM sensors Telltale Light”...
Page 538 536 STARTING AND OPERATING 5. Once you repair or replace the original road tire, and General Information reinstall it on the vehicle in place of the compact spare, This device complies with Part 15 of the FCC rules and the TPMS will update automatically. In addition, the RSS 210 of Industry Canada.
Page 539: Fuel Requirements
STARTING AND OPERATING 537 FUEL REQUIREMENTS high speeds can cause damage and immediate service is required. Poor quality gasoline can cause problems such 3.6L Engine as hard starting, stalling, and hesitations. If you experi- ence these symptoms, try another brand of gasoline This engine is designed to meet all emis- before considering service for the vehicle.
Page 540: Reformulated Gasoline
538 STARTING AND OPERATING Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner DO NOT use gasoline containing Methanol or gaso- burning gasoline referred to as “Reformulated Gasoline.” line containing more than 10% Ethanol. Use of these Reformulated gasolines contain oxygenates and are spe- blends may result in starting and driveability prob- cifically blended to reduce vehicle emissions and im-...
Page 541: E-85 Usage In Non-Flex Fuel Vehicles
STARTING AND OPERATING 539 • change the engine oil and oil filter E-85 Usage In Non-Flex Fuel Vehicles • disconnect and reconnect the battery to reset the Non-FFV vehicles are compatible with gasoline contain- ing 10% ethanol (E10). Gasoline with higher ethanol engine controller memory content may void the New Vehicle Limited Warranty.
Page 542: Materials Added To Fuel
540 STARTING AND OPERATING therefore, you should ask your gasoline retailer whether Fuel System Cautions the gasoline contains MMT. MMT is prohibited in Federal and California reformulated gasoline. CAUTION! Materials Added To Fuel Follow these guidelines to maintain your vehicle’s performance: All gasoline sold in the United States is required to •...
Page 543: Carbon Monoxide Warnings
STARTING AND OPERATING 541 Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives, which are now being WARNING! sold as octane enhancers, is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentrations Follow the precautions below to prevent carbon of methanol.
Page 544: Flexible Fuel - If Equipped
542 STARTING AND OPERATING WARNING! (Continued) • Guard against carbon monoxide with proper main- tenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. FLEXIBLE FUEL —...
Page 545: Ethanol Fuel (E-85)
STARTING AND OPERATING 543 Ethanol Fuel (E-85) E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank.
Page 546: Fuel Requirements
544 STARTING AND OPERATING Fuel Requirements NOTE: • Use seasonally adjusted E-85 fuel (ASTM D5798). With If your vehicle is E-85 compatible, it will operate on unleaded gasoline with an octane rating of 87, or E-85 non-seasonally adjusted E-85 fuel, you may experience fuel, or any mixture of these two fuels.
Page 547: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
STARTING AND OPERATING 545 Selection Of Engine Oil For Flexible Fuel Vehicles Starting (E-85) And Gasoline Vehicles The characteristics of E-85 fuel make it unsuitable for use FFV vehicles operated on E-85 require specially formu- when ambient temperatures fall below 0°F (-18°C). In the lated engine oils.
Page 548: Replacement Parts
546 STARTING AND OPERATING Replacement Parts ADDING FUEL Many components in your Flexible Fuel Vehicle (FFV) are Fuel Filler Cap (Gas Cap) designed to be compatible with ethanol. Always be sure The gas cap is located behind the fuel filler door on the that your vehicle is serviced with correct ethanol com- left side of the vehicle.
Page 549 STARTING AND OPERATING 547 NOTE: The driver’s side sliding door cannot be opened WARNING! while the fuel door is open. This feature operates only • Never have any smoking materials lit in or near the when the sliding door is fully closed prior to opening the fuel door.
Page 550: Loose Fuel Filler Cap Message
548 STARTING AND OPERATING • Tighten the fuel filler cap until you hear a “clicking” properly tightened. Refer to “Onboard Diagnostic Sys- sound. This is an indication that the fuel filler cap is tem” in “Maintaining Your Vehicle” for further informa- properly tightened.
Page 551 STARTING AND OPERATING 549 The label contains the following information: Gross Axle Weight Rating (GAWR) • Name of manufacturer The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles •...
Page 552 550 STARTING AND OPERATING Rim Size Overloading This is the rim size that is appropriate for the tire size The load carrying components (axle, springs, tires, listed. wheels, etc.) of your vehicle will provide satisfactory service as long as you do not exceed the GVWR and the Inflation Pressure front and rear GAWR.
Page 553: Trailer Towing
STARTING AND OPERATING 551 Loading TRAILER TOWING To load your vehicle properly, first figure out its empty In this section you will find safety tips and information weight, axle-by-axle and side-by-side. Store heavier items on limits to the type of towing you can reasonably do down low and be sure you distribute their weight as with your vehicle.
Page 554 552 STARTING AND OPERATING exceed the GVWR. Refer to “Vehicle Loading/Vehicle rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica- Certification Label” in “Starting and Operating” for tion Label” in “Starting and Operating” for further further information. information. Gross Trailer Weight (GTW) WARNING! The GTW is the weight of the trailer plus the weight of all It is important that you do not exceed the maximum...
Page 555 STARTING AND OPERATING 553 Trailer Sway Control Weight-Distributing Hitch The trailer sway control can be a mechanical telescoping A weight-distributing system works by applying lever- link that can be installed between the hitch receiver and age through spring (load) bars. They are typically used the trailer tongue that typically provides adjustable fric- for heavier loads to distribute trailer tongue weight to the tion associated with the telescoping motion to dampen...
Page 556 554 STARTING AND OPERATING WARNING! • An improperly adjusted weight-distributing hitch system may reduce handling, stability, braking performance, and could result in a collision. • Weight-distributing hitch systems may not be com- patible with surge brake couplers. Consult with an authorized hitch and trailer manufacturer or a reputable authorized Recreational Vehicle dealer for additional information.
Page 557 STARTING AND OPERATING 555 With Weight-Distributing Hitch (Correct) Improper Adjustment Of Weight-Distributing Hitch (Incorrect)
Page 558 556 STARTING AND OPERATING Trailer Hitch Classification Trailer Hitch Classification Definitions The following chart provides the industry standard for Class III - Heavy Duty 5,000 lbs (2 268 kg) the maximum trailer weight a given trailer hitch class can Class IV - Extra Heavy 10,000 lbs (4 540 kg) tow and should be used to assist you in selecting the Duty...
Page 559 STARTING AND OPERATING 557 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. GCWR (Gross Engine/ Max. GTW (Gross Max. Tongue Combined Weight Frontal Area Transmission Trailer Weight) Weight Rating) 3.6L/Automatic...
Page 560 558 STARTING AND OPERATING NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to “Tire Safety Information”...
Page 561 STARTING AND OPERATING 559 NOTE: Remember that everything put into or on the CAUTION! trailer adds to the load on your vehicle. Also, additional • Do not tow a trailer at all during the first 500 miles factory-installed options or dealer-installed options must be considered as part of the total load on your vehicle.
Page 562 560 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the hook retainers of the vehicle hitch.
Page 563 STARTING AND OPERATING 561 • Check the trailer tires for proper tire inflation pres- WARNING! (Continued) sures before trailer usage. • Total weight must be distributed between the tow • Check for signs of tire wear or visible tire damage vehicle and the trailer such that the following four before towing a trailer.
Page 564 562 STARTING AND OPERATING • An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.
Page 565 STARTING AND OPERATING 563 Towing Requirements – Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven- pin wiring harness.
Page 566: Towing Tips
564 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE gear can be selected when towing. However, if frequent shifting occurs while in DRIVE, use the Electronic Range Select (ERS) shift control to select a lower gear range.
Page 567 STARTING AND OPERATING 565 or frequent trailer towing.” Refer to the “Maintenance Cooling System Schedule” for the proper maintenance intervals. To reduce potential for engine and transmission over- heating, take the following actions: Electronic Speed Control – If Equipped • Do not use in hilly terrain or with heavy loads. City Driving •...
Page 568: Recreational Towing (Behind Motorhome, Etc.)
566 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground All Models Flat Tow NONE NOT ALLOWED Dolly Tow Front Rear NOT ALLOWED On Trailer...
Page 569: Recreational Towing - All Models
STARTING AND OPERATING 567 Recreational Towing – All Models CAUTION! Recreational towing is allowed ONLY if the front wheels DO NOT flat tow this vehicle. Damage to the drive- are OFF the ground. This may be accomplished using a train will result. tow dolly or vehicle trailer.
Page 571: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS ▫ Jacking Instructions ....580 HAZARD WARNING FLASHERS ...570 ▫...
Page 572: Hazard Warning Flashers
570 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located in the In any of the following situations, you can reduce the lower center area of the instrument panel. potential for overheating by taking the appropriate ac- tion.
Page 573: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES 571 JACKING AND TIRE CHANGING CAUTION! WARNING! Driving with a hot cooling system could damage your vehicle. If temperature gauge reads “H”, pull • Do not attempt to change a tire on the side of the over and stop the vehicle.
Page 574: Jack Location
572 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 575: Spare Tire Removal
WHAT TO DO IN EMERGENCIES 573 Spare Tire Removal The spare tire is stowed inside a protective cover located under the center of the vehicle between the front doors by means of a cable winch mechanism. The “spare tire drive” nut is located on the floor, under a plastic cap at the front of the floor console or under front super console forward bin liner.
Page 576: To Access Spare Tire Winch Drive Nut
574 WHAT TO DO IN EMERGENCIES To Access Spare Tire Winch Drive Nut To access the spare tire winch drive nut and lower the spare tire, you will need to refer to one of the following center console configurations. Super Console For vehicles equipped with the Super Console, the spare tire winch assembly drive nut is located beneath the console.
Page 577 WHAT TO DO IN EMERGENCIES 575 2. Open the front drawer to expose the storage compart- Premium/Base/Cargo Center Console ment. Pull the Winch Cover assembly plug (if equipped) to access the winch drive nut. 3. Remove the liner from the console’s storage compart- ment to access the spare tire winch drive nut.
Page 578: Spare Tire Tools
576 WHAT TO DO IN EMERGENCIES Spare Tire Tools The tool pouch contains three pieces and can be as- sembled into a spare tire hook; to remove the compact spare tire/cover assembly from under the vehicle, or a Winch T-handle; to raise/lower the compact spare tire/ cover assembly.
Page 579: Spare Tire Removal Instructions
WHAT TO DO IN EMERGENCIES 577 Spare Tire Removal Instructions The spare tire is located under the vehicle beneath the center console area. Assembling The Spare Tire Hook A — Spare Tire Hook/T-handle B — Extension 1 C — Extension 2 Spare Tire And Cover 1.
Page 580 578 WHAT TO DO IN EMERGENCIES 2. Rotate the nut to the left until the winch mechanism stops turning freely. This will allow enough slack in the cable to allow you to pull the spare tire out from underneath the vehicle. CAUTION! The winch mechanism is designed for use with the winch T-handle only.
Page 581: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 579 4. Stand the tire/cover assembly upright and remove the Preparations For Jacking wheel spacer by squeezing the winch retaining tabs 1. Park the vehicle on a firm, level surface. Avoid ice or together. Push the retainer through the spare tire to slippery areas.
Page 582: Jacking Instructions
580 WHAT TO DO IN EMERGENCIES 6. Block both the front and rear of the wheel diagonally Jacking Instructions opposite the jacking position. For example, if changing the right front WARNING! tire, block the left rear wheel. Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: •...
Page 583 WHAT TO DO IN EMERGENCIES 581 WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. If you need to get under a raised vehicle, take it to a Jack Warning Label service center where it can be raised on a lift.
Page 584 582 WHAT TO DO IN EMERGENCIES 2. There are two jack engagement locations on each side CAUTION! of the vehicle body. These locations are on the sill flange of the vehicle body. Do not attempt to raise the vehicle by jacking on locations other than those indicated.
Page 585 WHAT TO DO IN EMERGENCIES 583 Front jack location is on the sill flange of the vehicle body NOTE: In some situations the jack may need to be and is located 6 in (150 mm) from door edge. placed on its side in order to be pushed under the vehicle. Return the jack to its correct orientation once it is under the vehicle.
Page 586 584 WHAT TO DO IN EMERGENCIES 4. Raise the vehicle by turning the jack screw to the right, 5. Remove the wheel lug nuts, for vehicles with wheel using the swivel wrench. Raise the vehicle only until covers, remove the cover from the wheel by hand. Do the tire just clears the surface and enough clearance is not pry the wheel cover off.
Page 587 WHAT TO DO IN EMERGENCIES 585 NOTE: Do not install the wheel cover on the compact spare. 7. Lower the vehicle by turning the jack screw to the left. 8. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for increased leverage.
Page 588 586 WHAT TO DO IN EMERGENCIES 9. Lower the jack to its fully-closed position. 11. Stow the cable and wheel spacer before driving the vehicle. Reassemble the winch handle extensions to form a “T” and fit the winch T-handle over the drive WARNING! nut.
Page 589: Securing The Spare Tire
WHAT TO DO IN EMERGENCIES 587 Securing The Spare Tire CAUTION! 1. Assemble the winch handle extensions to form a The winch mechanism is designed for use with the T-handle and fit the winch T-handle over the drive winch T-handle only. Use of an air wrench or other nut.
Page 590 588 WHAT TO DO IN EMERGENCIES 4. Using the winch T-handle, rotate the drive nut to the CAUTION! right until the compact spare tire/cover assembly is drawn into place against the underside of the vehicle. The compact spare tire/cover assembly must be used when the compact spare tire is stored.
Page 591: Road Tire Installation
WHAT TO DO IN EMERGENCIES 589 Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle. 2. To ease the installation process for steel wheels with wheel covers, install two lug nuts on the mounting studs which are on each side of the valve stem.
Page 592 590 WHAT TO DO IN EMERGENCIES 3. Align the valve notch in the wheel cover with the 5. Lower the vehicle to the ground by turning the jack valve stem on the wheel. Install the cover by hand, handle counterclockwise. snapping the cover over the two lug nuts.
Page 593 WHAT TO DO IN EMERGENCIES 591 Vehicles Without Wheel Covers 3. Lower the vehicle to the ground by turning the jack handle counterclockwise. 1. Mount the road tire on the axle. 4. Finish tightening the lug nuts. Push down on the 2.
Page 594: Jump-Starting
592 WHAT TO DO IN EMERGENCIES JUMP-STARTING CAUTION! If your vehicle has a discharged battery it can be jump- Do not use a portable battery booster pack or any started using a set of jumper cables and a battery in other booster source with a system voltage greater another vehicle or by using a portable battery booster than 12 Volts or damage to the battery, starter motor,...
Page 595: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 593 Preparations For Jump-Start WARNING! The battery in your vehicle is located on the left side of • Take care to avoid the radiator cooling fan when- the engine compartment. ever the hood is raised. It can start anytime the ignition switch is ON.
Page 596: Jump-Starting Procedure
594 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park CAUTION! the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. Failure to follow these procedures could result in damage to the charging system of the booster vehicle WARNING! or the discharged vehicle.
Page 597 WHAT TO DO IN EMERGENCIES 595 8. Disconnect the opposite end of the positive (+) jumper WARNING! cable from the positive (+) post of the booster battery. Do not connect the cable to the negative post (-) of the 9. Disconnect the positive (+) end of the jumper cable discharged battery.
Page 598: Freeing A Stuck Vehicle
596 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE NOTE: Press the ESC Off switch, to place the Electronic Stability Control (ESC) system in Partial Off mode If your vehicle becomes stuck in mud, sand or snow, it before rocking the vehicle. Refer to “Electronic Brake can often be moved using a rocking motion.
Page 599: Shift Lever Override
WHAT TO DO IN EMERGENCIES 597 SHIFT LEVER OVERRIDE WARNING! If a malfunction occurs and the shift lever cannot be Fast spinning tires can be dangerous. Forces gener- moved out of the PARK position, you can use the ated by excessive wheel speeds may cause damage, or following procedure to temporarily move the shift lever: even failure, of the axle and tires.
Page 600 598 WHAT TO DO IN EMERGENCIES 4. Press and maintain firm pressure on the brake pedal. 5. Insert the screwdriver or similar tool into the access hole, and push and hold the override release lever forward. 6. Move the shift lever to the NEUTRAL position. 7.
Page 601: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES 599 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. Towing Condition Wheels OFF the Ground ALL MODELS Flat Tow NONE If transmission is operable: • Transmission in NEUTRAL Wheel lift Rear •...
Page 602 600 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle. Use only tow bars and other • Do not use sling type equipment when towing. equipment designed for this purpose, following equip- ment manufacturer’s instructions.
Page 603 WHAT TO DO IN EMERGENCIES 601 The manufacturer recommends towing your vehicle with CAUTION! all four wheels OFF the ground using a flatbed. If flatbed equipment is not available, and the transmission is Towing faster than 25 mph (40 km/h) or farther than operable, the vehicle may be flat towed (with all four 15 mi (24 km) with front wheels on the ground can wheels on the ground) under the following conditions:...
Page 605 MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Air Cleaner Filter ....614 ENGINE COMPARTMENT — 3.6L ..605 ▫ Exhaust System ..... .614 ONBOARD DIAGNOSTIC SYSTEM —...
Page 606 604 MAINTAINING YOUR VEHICLE ▫ Appearance Care And Protection From ▫ Fog Lamps ......652 Corrosion ......633 ▫...
Page 607: Engine Compartment - 3.6L
MAINTAINING YOUR VEHICLE 605 ENGINE COMPARTMENT — 3.6L 1 — Air Filter 6 — Engine Coolant Reservoir 2 — Power Steering Fluid Reservoir 7 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 8 — Engine Oil Fill 4 — Battery 9 —...
Page 608: Onboard Diagnostic System - Obd Ii
606 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 609: Loose Fuel Filler Cap Message
MAINTAINING YOUR VEHICLE 607 Loose Fuel Filler Cap Message EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a In some localities, it may be a legal requirement to pass “gASCAP”...
Page 610 608 MAINTAINING YOUR VEHICLE Your vehicle has a simple ignition key-actuated test, 4. Approximately 15 seconds later, one of two things will which you can use prior to going to the test station. To happen: check if your vehicle’s OBD II system is ready, you must •...
Page 611: Replacement Parts
MAINTAINING YOUR VEHICLE 609 Regardless of whether your vehicle’s OBD II system is available which include detailed service information for ready or not, if the MIL is illuminated during normal your vehicle. Refer to these Service Manuals before vehicle operation you should have your vehicle serviced attempting any procedure yourself.
Page 612: Maintenance Procedures
610 MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES CAUTION! (Continued) The pages that follow contain the required maintenance • Your vehicle has been built with improved fluids services determined by the engineers who designed your that protect the performance and durability of your vehicle.
Page 613 MAINTAINING YOUR VEHICLE 611 check the engine oil level is about five minutes after a Change Engine Oil fully warmed engine is shut OFF or before starting the The oil change indicator system will remind you that it is engine after it has sat overnight. time to take your vehicle in for scheduled maintenance.
Page 614 612 MAINTAINING YOUR VEHICLE American Petroleum Institute (API) Engine Oil Engine Oil Viscosity – 3.6L Engine Identification Symbol SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature This symbol means that the oil has starting and vehicle fuel economy.
Page 615: Engine Oil Filter
MAINTAINING YOUR VEHICLE 613 Materials Added To Engine Oil Engine Oil Filter The manufacturer strongly recommends against the ad- The engine oil filter should be replaced with a new filter dition of any additives (other than leak detection dyes) to at every engine oil change.
Page 616: Engine Air Cleaner Filter
614 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter used to assure most efficient service. MOPAR® engine air cleaner filters are a high quality filter and are recom- Refer to the “Maintenance Schedule” for the proper mended. maintenance intervals. Exhaust System WARNING! The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust...
Page 617 MAINTAINING YOUR VEHICLE 615 WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions control and can eventually poison you.
Page 618: Maintenance-Free Battery
616 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 619 MAINTAINING YOUR VEHICLE 617 WARNING! CAUTION! • Battery fluid is a corrosive acid solution and can • It is essential when replacing the cables on the burn or even blind you. Do not allow battery fluid battery that the positive cable is attached to the to contact your eyes, skin, or clothing.
Page 620: Air Conditioner Maintenance
618 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer approved by the manufacturer for your air condi- at the start of each warm season. This service should tioning system.
Page 621 MAINTAINING YOUR VEHICLE 619 Refrigerant Recovery And Recycling The A/C air filter is located in the fresh air inlet behind the glove box. Perform the following procedure to re- R-134a Air Conditioning Refrigerant is a hydrofluoro- place the filter: carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product.
Page 622 620 MAINTAINING YOUR VEHICLE 6. Install the A/C air filter with the arrow on the filter pointing toward the floor. When installing the filter cover, make sure the retaining tabs fully engage the cover. CAUTION! The A/C air filter is identified with an arrow to indicate airflow direction through the filter.
Page 623: Body Lubrication
MAINTAINING YOUR VEHICLE 621 Body Lubrication Windshield Wiper Blades Locks and all body pivot points, including such items as Clean the rubber edges of the wiper blades and the seat tracks, door hinge pivot points and rollers, liftgate, windshield periodically with a sponge or soft cloth and a tailgate, sliding doors and hood hinges, should be lubri- mild nonabrasive cleaner.
Page 624 622 MAINTAINING YOUR VEHICLE Adding Washer Fluid WARNING! The fluid reservoir for the windshield washers and the Commercially available windshield washer solvents rear window washer is shared. It is located in the engine are flammable. They could ignite and burn you. Care compartment and should be checked at regular intervals.
Page 625: Cooling System
MAINTAINING YOUR VEHICLE 623 Cooling System applicable). If the engine coolant (antifreeze) is dirty, the system should be drained, flushed, and refilled with WARNING! fresh OAT coolant (conforming to MS-12106) only by an authorized dealer. Check the front of the A/C condenser •...
Page 626: Maintaining Your Vehicle
624 MAINTAINING YOUR VEHICLE Cooling System – Drain, Flush, And Refill CAUTION! If the engine coolant (antifreeze) is dirty or contains • Mixing of engine coolant (antifreeze) other than visible sediment, have an authorized dealer clean and specified Organic Additive Technology (OAT) en- flush with OAT coolant (antifreeze) (conforming to MS- gine coolant (antifreeze), may result in engine 12106).
Page 627 MAINTAINING YOUR VEHICLE 625 Adding Coolant CAUTION! (Continued) Your vehicle has been built with an improved engine • Do not use water alone or alcohol-based engine coolant (OAT coolant conforming to MS-12106) that coolant (antifreeze) products. Do not use additional allows extended maintenance intervals.
Page 628 626 MAINTAINING YOUR VEHICLE • Mix a minimum solution of 50% OAT engine coolant NOTE: Mixing engine coolant (antifreeze) types is not that meets the requirements of Chrysler Material Stan- recommended and can result in cooling system damage. dard MS-12106 and distilled water. Use higher concen- If HOAT and OAT coolant are mixed in an emergency, trations (not to exceed 70%) if temperatures below have a authorized dealer drain, flush, and refill with OAT...
Page 629 MAINTAINING YOUR VEHICLE 627 Disposal Of Used Engine Coolant WARNING! Used ethylene glycol-based engine coolant (antifreeze) is • The warning words “DO NOT OPEN HOT” on the a regulated substance requiring proper disposal. Check cooling system pressure cap are a safety precaution. with your local authorities to determine the disposal Never add engine coolant (antifreeze) when the rules for your community.
Page 630 628 MAINTAINING YOUR VEHICLE The radiator normally remains completely full, so there is Points To Remember no need to remove the radiator cap unless checking for NOTE: When the vehicle is stopped after a few miles/ engine coolant (antifreeze) freeze point or replacing cool- kilometers of operation, you may observe vapor coming ant.
Page 631: Brake System
MAINTAINING YOUR VEHICLE 629 • If frequent engine coolant (antifreeze) additions are Brake System required, the cooling system should be pressure tested In order to assure brake system performance, all brake for leaks. system components should be inspected periodically. • Maintain engine coolant (antifreeze) concentration at a Refer to the “Maintenance Schedule”...
Page 632 630 MAINTAINING YOUR VEHICLE Master Cylinder – Brake Fluid Level Check Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts” in “Main- The fluid level in the master cylinder should be checked taining Your Vehicle” for further information. when performing underhood services, or immediately if the “Brake System Warning Light”...
Page 633: Automatic Transmission
MAINTAINING YOUR VEHICLE 631 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contaminate moisture, use only new brake fluid or fluid that has the brake fluid. Brake seal components could be been in a tightly closed container.
Page 634 632 MAINTAINING YOUR VEHICLE important to maintain the transmission fluid at the Special Additives correct level using the recommended fluid. No chemical The manufacturer strongly recommends against using flushes should be used in any transmission; only the any special additives in the transmission. approved lubricant should be used.
Page 635: Corrosion
MAINTAINING YOUR VEHICLE 633 Fluid Level Check Fluid And Filter Changes The fluid level is preset at the factory and does not Under normal operating conditions, the fluid installed at require adjustment under normal operating conditions. the factory will provide satisfactory lubrication for the Routine fluid level checks are not required, therefore the life of the vehicle.
Page 636 634 MAINTAINING YOUR VEHICLE hot or cold weather and other extreme conditions will Washing have an adverse effect on paint, metal trim, and under- • Wash your vehicle regularly. Always wash your ve- body protection. hicle in the shade using MOPAR® Car Wash, or a mild car wash soap, and rinse the panels completely with The following maintenance recommendations will enable clear water.
Page 637 MAINTAINING YOUR VEHICLE 635 • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is • Do not use abrasive or strong cleaning materials considered the responsibility of the owner. such as steel wool or scouring powder that will •...
Page 638 636 MAINTAINING YOUR VEHICLE Wheel And Wheel Trim Care CAUTION! All wheels and wheel trim, especially aluminum and Do not use scouring pads, steel wool, a bristle brush, chrome plated wheels, should be cleaned regularly with or metal polishes. Do not use oven cleaner. These a mild soap and water to prevent corrosion.
Page 639 MAINTAINING YOUR VEHICLE 637 • For tough stains, apply MOPAR® Total Clean, or a Cleaning Interior Trim mild soap solution to a clean, damp cloth and remove Interior trim should be cleaned starting with a damp stain. Use a fresh, damp towel to remove soap residue. cloth, a damp cloth with MOPAR®...
Page 640 638 MAINTAINING YOUR VEHICLE liquid. Please do not use polishes, oils, cleaning fluids, To minimize the possibility of scratching the lenses and solvents, detergents, or ammonia-based cleaners to clean reducing light output, avoid wiping with a dry cloth. To your leather upholstery. Application of a leather condi- remove road dirt, wash with a mild soap solution fol- tioner is not required to maintain the original condition.
Page 641 MAINTAINING YOUR VEHICLE 639 When cleaning the rear view mirror, spray cleaner on the Seat Belt Maintenance towel or rag that you are using. Do not spray cleaner Do not bleach, dye, or clean the belts with chemical directly on the mirror. solvents or abrasive cleaners.
Page 642: Cleaning The Instrument Panel Cupholders
640 MAINTAINING YOUR VEHICLE Cleaning The Instrument Panel Cupholders Installation Place the liner into the cupholder drawer and press the Removal liner into place so that the retention tabs seat into the Pull the flexible liner from the cupholder drawer starting corresponding openings in the drawer.
Page 643 MAINTAINING YOUR VEHICLE 641 CAUTION! • When installing the Totally Integrated Power Mod- ule cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in a electrical system failure.
Page 644 642 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse 40 Amp — Power Folding Seat 30 Amp — Antilock Brakes Green Pink Valve/Stability Control System 30 Amp — Power Liftgate Pink Module 40 Amp —...
Page 645 MAINTAINING YOUR VEHICLE 643 Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse 30 Amp — Power Sliding Door 20 Amp — Powertrain Control Pink Module/Anti–Theft Blue Module Trans Module – If Range Equipped 60 Amp —...
Page 646 644 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 20 Amp Front Fog Lamps — 20 Amp Power Outlet #2 Yellow Yellow (BATT/ACC SE- LECT) – Center — 20 Amp Front/Rear Axle Seat or with Con- Yellow...
Page 647 MAINTAINING YOUR VEHICLE 645 Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 15 Amp Ignition Off Draw — 20 Amp Instrument Cluster, Blue — Video System, Yellow SIREN, Clock Mod- Satellite Radio, ule, Multi-Function DVD, Hands-Free Control Switch –...
Page 648 646 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 10 Amp Airbag Module/ — 15 Amp Instrument Cluster Occupant Classifi- Blue Interior Light, cation Module Switch Bank, Steer- ing Column Mod- —...
Page 649 MAINTAINING YOUR VEHICLE 647 Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 25 Amp Rear Wiper — 10 Amp Occupant Classifi- Natural cation Module — 20 Amp Fuel Pump, Diesel — 15 Amp Rear Wiper Mod- Yellow Lift Pump –...
Page 650 648 MAINTAINING YOUR VEHICLE Car- Car- Mini- Mini- Cavity tridge Description Cavity tridge Description Fuse Fuse Fuse Fuse — 10 Amp Park Assist, Heater — 20 Amp Power Outlet #3 Climate Control Yellow (Instrument Panel Module, Headlamp or with Console Wash, Compass, Center) Rear Camera, Door...
Page 651: Vehicle Storage
MAINTAINING YOUR VEHICLE 649 VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 Interior Bulbs days, you may want to take steps to protect your battery. You may do the following: Bulb Number • Remove the 60 Amp cartridge in the Totally Integrated Center &...
Page 652 650 MAINTAINING YOUR VEHICLE Exterior Bulbs Bulb Number Bulb Number Instrument Cluster PC74 Lamps Headlamp Liftgate Lamp(s) Fog Lamp – If Equipped PSX24W Overhead Console Read- PC579 Front Side Marker, Park/ 3757A or PY27/7W ing Lamps Turn Signal Removable Console Rear Tail, Stop, Turn Sig- LED (Serviced at Autho- Lamp –...
Page 653: Bulb Replacement
MAINTAINING YOUR VEHICLE 651 BULB REPLACEMENT CAUTION! Headlamps Do not touch the new bulb with your fingers. Oil 1. Raise the hood to access the rear of the headlamp contamination will severely shorten bulb life. If the housing. bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol.
Page 654: Fog Lamps
652 MAINTAINING YOUR VEHICLE Fog Lamps CAUTION! NOTE: Access to the fog lamp bulb is from the rear of Do not touch the new bulb with your fingers. Oil the fascia. On the left rear side of the fascia, remove the contamination will severely shorten bulb life.
Page 655: Rear Tail, Stop, Turn Signal, Side Marker And Backup Lamps
MAINTAINING YOUR VEHICLE 653 Rear Tail, Stop, Turn Signal, Side Marker And Backup Lamps 1. Raise the liftgate. 2. Remove the tail lamp assembly by removing the two screws from the inboard side. Use a fiber stick or similar tool to gently pry the light on the outboard side to disengage the two ball studs.
Page 656: Center High-Mounted Stop Lamp (Chmsl)
654 MAINTAINING YOUR VEHICLE 3. Twist the socket and remove from the lamp assembly. License Lamp The license plate lamp is located under the tailgate light 4. Pull the bulb to remove it from the socket. bar and above the license plate. 5.
Page 657: Fluid Capacities
MAINTAINING YOUR VEHICLE 655 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, API Certi- 6 Quarts 5.6 Liters fied) Cooling System * 3.6L Engine (MOPAR® Antifreeze/ 13.4 Quarts 12.6 Liters Engine Coolant 10 Year/150,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level.
Page 658: Fluids, Lubricants And Genuine Parts
656 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of Chrysler Ma- terial Standard MS-12106. Engine Oil We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Ma-...
Page 659: Chassis
MAINTAINING YOUR VEHICLE 657 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission We recommend you ONLY use MOPAR® ATF+4® Automatic Transmission Fluid. Failure to use ATF+4® fluid may affect the function or performance of your transmission. Brake Master Cylinder We recommend you use MOPAR®...
Page 661 MAINTENANCE SCHEDULES CONTENTS MAINTENANCE SCHEDULE ... . .660 ▫ Maintenance Chart ....661...
Page 662 660 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE than your authorized dealer, the message can be reset by referring to the steps described under “Electronic Vehicle Your vehicle is equipped with an automatic oil change Information Center (EVIC)/Oil Change Required” in indicator system. The oil change indicator system will “Understanding Your Instrument Panel”...
Page 663 MAINTENANCE SCHEDULES 661 Required Maintenance Intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Refer to the maintenance schedules on the following • Inspect engine cooling system protection and page for the required maintenance intervals. hoses. At Every Oil Change Interval As Indicated By Oil •...
Page 664 662 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect the brake linings, replace as necessary. Adjust parking brake on vehicles equipped with four wheel disc brakes.
Page 665 MAINTENANCE SCHEDULES 663 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace engine air filter. Replace cabin/air conditioning filter. Replace spark plugs (3.6L en- gine). ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first.
Page 666 664 MAINTENANCE SCHEDULES Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change automatic transmission fluid and filter if using your ve- hicle for any of the following: po- lice, taxi, fleet, or frequent trailer towing. Change automatic transmission fluid and filter.
Page 667 MAINTENANCE SCHEDULES 665 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 669: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ....669 Speech Impaired (TDD/TTY) ... . .671 ▫...
Page 670 668 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... . .675 PUBLICATION ORDER FORMS ... .674 ▫...
Page 671: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 669 SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 672: Chrysler Group Llc Customer Center
670 IF YOU NEED CONSUMER ASSISTANCE Warranty service must be done by an authorized dealer. Any communication to the manufacturer’s customer cen- We strongly recommend that you take the vehicle to an ter should include the following information: authorized dealer. They know your vehicle the best, and •...
Page 673: In Mexico Contact
IF YOU NEED CONSUMER ASSISTANCE 671 In Mexico contact: Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered Av. Prolongacion Paseo de la Reforma, 1240 by Bell Canada. For TTY teletypewriter users, dial 711 Sante Fe C.P.
Page 674: Warranty Information
672 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service WARNING! contract that is not the manufacturer’s service contract. It is not responsible for any service contract other than the Engine exhaust, some of its constituents, and certain manufacturer’s service contract.
Page 675: Mopar® Parts
IF YOU NEED CONSUMER ASSISTANCE 673 MOPAR® PARTS campaign. However, NHTSA cannot become involved in individual problems between you, your authorized MOPAR® fluids, lubricants, parts, and accessories are dealer, and the manufacturer. available from an authorized dealer. They are recom- mended for your vehicle in order to help keep the vehicle To contact NHTSA, you may either call the Auto Safety operating at its best.
Page 676 674 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals To order the following manuals, you may use either the Diagnostic Procedure Manuals are filled with diagrams, website or the phone numbers listed below. Visa, Mas- charts and detailed illustrations. These practical manuals tercard, American Express, and Discover orders are ac- make it easy for students and technicians to find and fix cepted.
Page 677 IF YOU NEED CONSUMER ASSISTANCE 675 Call toll free at: Treadwear • 1–800–890–4038 (U.S.) The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled condi- • 1–800–387–1143 (Canada) tions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
Page 678 676 IF YOU NEED CONSUMER ASSISTANCE excessive temperature can lead to sudden tire failure. The WARNING! grade C corresponds to a level of performance, which all passenger car tires must meet under the Federal Motor The traction grade assigned to this tire is based on Vehicle Safety Standard No.
Page 679 INDEX...
Page 680 678 INDEX Adding Engine Coolant (Antifreeze) ... .625 Air Conditioning System, Zone Control..437 Adding Fuel ......546 Air Pressure, Tires.
Page 681 INDEX 679 Automatic Transmission ....468 B-Pillar Location ......510 Adding Fluid .
Page 682 680 INDEX Carbon Monoxide Warning ....118 Clock ........355 Cargo Area Features .
Page 683 INDEX 681 Coolant Pressure Cap (Radiator Cap) ...626 Dealer Service......609 Cooling System.
Page 684 682 INDEX E-85 Fuel .......542 Break-In Recommendations ....117 Economy (Fuel) Mode .
Page 685 INDEX 683 Enhanced Accident Response Feature ... .86 Turn Signal ......122 Entry System, Illuminated .
Page 686 684 INDEX Power Steering ......486 Light ....... .327 Fluids, Lubricants and Genuine Parts .
Page 687 INDEX 685 Gasoline, Reformulated .....538 Hazard Warning Flasher ....570 Gauges Headlights Coolant Temperature .
Page 688 686 INDEX Hook, Coat......285 Introduction ......4 Ignition .
Page 689 INDEX 687 Life of Tires ......523 Fog ....... . .223 Liftgate .
Page 690 688 INDEX Security Alarm (Theft Alarm) ....324 Maintenance Free Battery....616 Service .
Page 691 INDEX 689 Mode Checking ......610 Fuel Saver ......340 Disposal .
Page 692 690 INDEX Paint Care ......633 Windows ......39 Panic Alarm .
Page 693 INDEX 691 Reclining Front Seats ..... . .191 Rotation, Tires ......527 Recorder, Event Data .
Page 694 692 INDEX Inspection ......119 Settings, Personal ......346 Pretensioners .
Page 695 INDEX 693 Steering Tachometer......315 Power .......485 Telescoping Steering Column .
Page 696 694 INDEX Life of Tires ......523 Towing ....... .551 Load Capacity .
Page 697 INDEX 695 Trailer Weight ......557 Upholstery Care ......637 Transmission .
Page 698 696 INDEX Water Windshield Defroster..... . .120 Driving Through ......483 Windshield Washers .
Page 699 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 700 Chrysler Group LLC 13MZZ-126-AE Printed in U.S.A. 5th Edition...

RAM 2013 Cargo VAN Owner's Manual

Introduction

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Quick Links

Chapters

Related Manuals for RAM 2013 Cargo VAN

Summary of Contents for RAM 2013 Cargo VAN
