Quick Start Guide - CVEQ1 Series, cont'd
Step 7
While watching the display, adjust the video gain and equalization
by using the rotary Gain and Equalize controls. An oscilloscope can
be used to achieve a more precise adjustment. See "Top/Side Panel
Features and Adjustments" in chapter 2.
Step 8
For the CVEQ1 AAP or CVEQ1 WM,
A. Disconnect the line driver's power supply at the source end (not
at the line driver).
B.
Disconnect the input and output devices' power.
C. For the CVEQ1 WM, secure the faceplate onto the UL-approved
electrical wall box in the wall or furniture.
For the CVEQ1 AAP, secure the wallplate/faceplate that the
CVEQ1 AAP is attached to onto the UL-approved electrical wall
box in the wall or furniture.
D. Restore power to the line driver and to input and output devices.
www.camboard.de
CVEQ1 Series • Quick Start Guide
QS-2
CAMBOARD Electronics
Table of Contents
Chapter 1 • Introduction
Appendix A • Specifications
Appendix B • Dimensions and Templates
All trademarks mentioned in this manual are the properties of their respective owners.
Tel. 07131 911201
Fax 07131 911203
......................................................... 1-1
...................................................................................... 1-2
................................................................... 2-2
.............................................. 2-11
Part Numbers,
,
ce-info@camboard.de
CVEQ1 Series • Table of Contents
... 1-2
................ 2-1
..... 2-2
................................ 2-5
...... 2-6
............... 2-8
............................................. 2-10
................... B-1
68-544-01 Rev. C
09 05
v
