Sanyo FXD-780GDSS Service Manual page 29

Ref.No. PartsNo.
L352 TK198300101
L601 TK174301800
P301 TK1981353AQ
P501 TK26563210
P502 TK26563690
P701 TK1981312AC
Q201, Q202 TK120020703
Q351 TK122081533
Q542, Q543 TK120020403
Q583, Q641 TK120020703
Q601 TK122132621
Q602, Q632 TK120015503
Q611 TK124185811
Q612, Q621 TK120014601
Q631 TK122132611
Q633 TK124146801
Q642 TK120015503
Q643 TK124237500
Q661 TK12324121B
Q701 TK126158103
Q702, Q703 TK120027203
R201, R315 TK165310306
R202, R767 TK165356106
R203, R327 TK165347106
R204 TK165310006
R205 TK16524R706
R206 TK165368206
R207 TK165382306
R208 TK1691734D9
R209 TK165327206
R251 TK165333006
R301, R308 TK165322306
R303, R311 TK165333306
R304, R305 TK165327306
R306, R307 TK165339306
R309, R388 TK165322306
R310 TK165313306
R312 TK165312406
R313, R314 TK165333306
R316, R701 TK165310406
R317 TK165310506
R318, R352 TK165310306
R319, R320 TK165333206
R321, R322 TK165315306
R323, R324 TK165315306
R325, R326 TK165315306
R351 TK165222006
R353, R501 TK165310306
R354, R355 TK165356406
MAIN CIRCUIT BOARD FOR FXD-780RDS/XE
Description
JUMPER 5MM (INSERT)
TRANSFORMER, TT-OL-5047-R2
POST-TKC-W26P-B1
CONNECTOR
CONN YKC21-4800
POST-TMD-L12X-B1
TRANSISTOR, DTA124EKAT
TRANSISTOR, 2SB815T-B6, B7
TRANSISTOR, DTC143TKAT
TRANSISTOR, DTA124EKAT
TRANSISTOR, 2SB1326T-R
TRANSISTOR, DTC124EKAT
TRANSISTOR, 2SD1858T-Q, R
TRANSISTOR, KTC3199T-Y, GR
TRANSISTOR, 2SB1326T-Q, R
TRANSISTOR, 2SD1468ST-R, S
TRANSISTOR, DTC124EKAT
TRANSISTOR, 2SD2375-Q, P
TRANSISTOR, 2SC2412KT-Q, R
TRANSISTOR, 2SK1581T
TRANSISTOR, RK7002
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 560OHM 1/16W
RESISTOR, CHIP, 470OHM 1/16W
RESISTOR, CHIP, 10OHM 1/16W
RESISTOR, CHIP, 4.7OHM 1/10W
RESISTOR, CHIP, 6.8KOHM 1/16W
RESISTOR, CHIP, 82KOHM 1/16W
RESISTOR, SEMI-FIXED, NVZ6TLT-204B-RT
RESISTOR, CHIP, 2.7KOHM 1/16W
RESISTOR, CHIP, 33OHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 27KOHM 1/16W
RESISTOR, CHIP, 39KOHM 1/16W
RESISTOR, CHIP, 22KOHM 1/16W
RESISTOR, CHIP, 13.0KOHM 1/16W
RESISTOR, CHIP, 120KOHM 1/16W
RESISTOR, CHIP, 33KOHM 1/16W
RESISTOR, CHIP, 100KOHM 1/16W
RESISTOR, CHIP, 1MOHM 1/16W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 3.3KOHM 1/16W
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 15KOHM 1/16W
RESISTOR, CHIP, 22OHM 1/10W
RESISTOR, CHIP, 10KOHM 1/16W
RESISTOR, CHIP, 560KOHM 1/16W
— 27 —
