Ref.No.
PartsNo.
C512, C601
TK157C1040J
C513
TK15C3338K0
C515, J501
TK165300006
C551
TK15091060J
C581
TK15C6474CR
C582
TK157B1040E
C611, C633
TK15C2107CR
C631
TK15C3107CR
C634
TK15C3106HR
C641, C704
TK157C1040J
C703
TK15C2227HR
C706, C707
TK15711010J
C709, C717
TK157A1020J
C710
TK157A1030J
C711, C712
TK157C1040J
C713
TK15712200J
C714
TK15712700J
C715
TK157C1040J
C716
TK15C6225CR
C725
TK157A1020J
D351, D481
TK131001901
D482, D612
TK131001901
D601
TK132014800
D602
TK131001801
D611
TK134018131
D621
TK134014511
D641
TK134014611
D661
TK131001901
D662
TK134018111
D709, D710
TK13403310D
ET201
TK37315B0
F301
TK175309034
F701
TK176418805
IC301
TK112308400
IC351
TK111816403
IC381
TK111887303
IC401
TK112341303
IC501
TK111868300
IC631
TK111893A00
IC701
TK119554100
J250
TK165200006
J251
TK165100006
L301, L352
TK172024834
L351
TK172024634
L601
TK174301800
L701
TK172024834
L703
TK177103906
P301
TK1981353AQ
P501
TK26563210
MAIN CIRCUIT BOARD FOR FXD-780GD/SS, BK.SS
Description
CAPACITOR, CHIP, 0.1U
CE-RE3-3300M16
RESISTOR, CHIP, 0OHM 1/16W
CI-1608CH101J100-CT
CE-RC2-0.47M50-T58
CAPACITOR, CHIP, 0.1UF 25V
CE-RC2-100M10-T58
CE-RC2-100M16-T58
CE-RC3-10M16-T58
CAPACITOR, CHIP, 0.1U
CE-RC3-220M10-T58
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 22PF 50V
CAPACITOR, CHIP, 27PF 50V
CAPACITOR, CHIP, 0.1U
CE-RC2-2.2M50-T58
CAPACITOR, CHIP, 1000PF 50V
DIODE, 1SS133T
DIODE, 1SS133T
DIODE, 1N5401
DIODE, 1SS145T
DIODE, ZENER, MTZJ8.2T-C
DIODE, ZENER, MTZJ5.6T-C
DIODE, ZENER, MTZJ9.1T-C
DIODE, 1SS133T
DIODE, ZENER, MTZJ8.2T-B
DIODE, ZENER, BZX55-C6V8-D8
BL ASSY RF33SS
CERAMIC FILTER, FCR16.93M2GT3-FT
X'TAL, HQST-3H-04500-14
IC, CXD2587Q
IC, CXA1821M-CT
IC, LA6556-CT
IC, LC75421M-CT
IC, LA4743B
IC, KIA7806API
IC, UPD178024GC-214
RESISTOR, CHIP, 0OHM 1/10W
RESISTOR, CHIP, 0OHM 1/8W
COIL, EL0305RA-220J-FT
COIL, EL0305RA-100J-FT
TRANSFORMER, TT-OL-5047-R2
COIL, EL0305RA-220J-FT
CORE, FCM1608K-301T03
POST-TKC-W26P-B1
CONNECTOR
— 22 —
