Ref.No.
PartsNo.
C501, C502
TK15C6474CR
C503, C504
TK15C6474CR
C505, C508
TK15C6105HR
C507
TK15C6105CR
C509
TK15C3476HR
C510
TK15C3226CR
C511
TK15C6224HR
C512, C641
TK157C1040J
C513
TK15C3338K0
C515, L702
TK165300006
C581
TK15C6474CR
C611, C633
TK15C2107CR
C618, C703
TK15C2227HR
C631
TK15C3107CR
C634
TK15C3106HR
C704, C709
TK157A1020J
C705, C706
TK157C1040J
C707
TK15711200J
C708
TK15711000J
C711, C712
TK15711010J
C713, C717
TK157C1040J
C714
TK157A4720J
C715
TK157A2240J
D351, D661
TK131001901
D601
TK132014800
D602
TK131001801
D611, D641
TK134014611
D621
TK134014511
D662
TK134018111
D706
TK141030510
D709, D710
TK134030601
D713, D714
TK198300101
D716
TK134014731
D721
TK134033603
ET201
TK37314B0
F251
TK176419100
F301
TK175309034
F701
TK176419700
IC251
TK112332303
IC301
TK112308400
IC351
TK111816403
IC381
TK111887303
IC401
TK112341303
IC501
TK111868300
IC631
TK111893A00
IC701
TK119556100
J243
TK165200006
L301, L701
TK172024834
L351
TK172024634
MAIN CIRCUIT BOARD FOR FXD-780RDS/XE
Description
CE-RC2-0.47M50-T58
CE-RC2-0.47M50-T58
CE-RC3-1M50-T58
CE-RC2-1M50-T58
CE-RC3-47M16-T58
CE-RC2-22M16-T58
CE-RC3-0.22M50-T58
CAPACITOR, CHIP, 0.1U
CE-RE3-3300M16
RESISTOR, CHIP, 0OHM 1/16W
CE-RC2-0.47M50-T58
CE-RC2-100M10-T58
CE-RC3-220M10-T58
CE-RC2-100M16-T58
CE-RC3-10M16-T58
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 12PF 50V
CAPACITOR, CHIP, 10PF 50V
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 4700PF 50V
CAPACITOR, CHIP, 0.22UF 10V
DIODE, 1SS133T
DIODE, 1N5401
DIODE, 1SS145T
DIODE, ZENER, MTZJ9.1T-C
DIODE, ZENER, MTZJ5.6T-C
DIODE, ZENER, MTZJ8.2T-B
LED, HL-BZ30105/1ID
DIODE, ZENER, BZX55-C6V2
JUMPER 5MM (INSERT)
DIODE, ZENER, MTZJ10T-B
DIODE, ZENER, UDZS6.8B
BL ASSY RF33RN
X'TAL, HQS-3H3-04332-16
CERAMIC FILTER, FCR16.93M2GT3-FT
X'TAL, HQS-3H-06300-14
IC, LC72723M-CT
IC, CXD2587Q
IC, CXA1821M-CT
IC, LA6556-CT
IC, LC75421M-CT
IC, LA4743B
IC, KIA7806API
IC, UPD178078GF-XXX-3
RESISTOR, CHIP, 0OHM 1/10W
COIL, EL0305RA-220J-FT
COIL, EL0305RA-100J-FT
— 26 —
