Sanyo FXD-780GDSS Service Manual page 27

Full panel detachable high power fm/am stereo receiver compact disc player
Hide thumbs

Advertisement

Ref.No.
PartsNo.
AJ201
TK196510300
C201, C317
TK157A1020J
C202, C207
TK157A1030J
C204
TK15715R00J
C205, C206
TK157A1530J
C208, C256
TK15713300J
C209
TK15C2107HR
C211, C303
TK157A1030J
C251, C253
TK15C3106HR
C252, C302
TK15712210J
C254
TK15715610J
C255, C314
TK15711500J
C257, C305
TK157C1040J
C304, C401
TK15711010J
C306, C405
TK15C6105CR
C307
TK157A1030J
C308, C318
TK15712210J
C309
TK157A5620J
C310
TK157A1520J
C311, C409
TK157A4730J
C312, C313
TK157C1040J
C315
TK15711500J
C316, C322
TK157C1040J
C319
TK15712210J
C320, C323
TK157A1020J
C321, C390
TK15C2107CR
C351
TK15C3106CR
C353
TK15713R00J
C354
TK15714700J
C355
TK157C1050J
C381, C382
TK157A1220J
C383, C384
TK157A1220J
C385, C386
TK157A3330J
C387, C632
TK157A2230J
C388
TK157A1530J
C391, C392
TK157C1040J
C393, C394
TK157C1040J
C395, C396
TK157C1040J
C403, C416
TK15C6225HR
C406, C412
TK15C6105HR
C407, C420
TK157A1220J
C408, C421
TK157A1050J
C410, C411
TK157A1540E
C413, C426
TK15C3106HR
C414, C419
TK15C6105CR
C418, C710
TK15711010J
C422
TK157A4730J
C423, C424
TK157A1540E
C425, C506
TK15C6105CR
MAIN CIRCUIT BOARD FOR FXD-780RDS/XE
Description
ANT JACK ASSY
CAPACITOR, CHIP, 1000PF 50V
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 5PF 50V
CAPACITOR, CHIP, 0.015UF 25V
CAPACITOR, CHIP, 33PF 50V
CE-RC3-100M10-T58
CAPACITOR, CHIP, 0.01UF 50V
CE-RC3-10M16-T58
CAPACITOR, CHIP, 220PF 50V
CAPACITOR, CHIP, 560PF 50V
CAPACITOR, CHIP, 15PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 100PF 50V
CE-RC2-1M50-T58
CAPACITOR, CHIP, 0.01UF 50V
CAPACITOR, CHIP, 220PF 50V
CAPACITOR, CHIP, 5600PF 50V
CAPACITOR, CHIP, 1500PF 50V
CAPACITOR, CHIP, 0.047UF 16V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 15PF 50V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 220PF 50V
CAPACITOR, CHIP, 1000PF 50V
CE-RC2-100M10-T58
CE-RC2-10M16-T58
CAPACITOR, CHIP, 3PF 50V
CAPACITOR, CHIP, 47PF 50V
CAPACITOR, CHIP, 1UF 10V
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, CHIP, 333 B
CAPACITOR, CHIP, 0.022UF 25V
CAPACITOR, CHIP, 0.015UF 25V
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 0.1U
CAPACITOR, CHIP, 0.1U
CE-RC3-2.2M50-T58
CE-RC3-1M50-T58
CAPACITOR, CHIP, 1200PF 50V
CAPACITOR, CHIP, 1UF 10V
CAPACITOR, CHIP, 0.15UF 25V
CE-RC3-10M16-T58
CE-RC2-1M50-T58
CAPACITOR, CHIP, 100PF 50V
CAPACITOR, CHIP, 0.047UF 16V
CAPACITOR, CHIP, 0.15UF 25V
CE-RC2-1M50-T58
— 25 —
