KitchenAid KSOX 9020 Instructions For Use Manual

KitchenAid KSOX 9020 Instructions For Use Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UK
GB

Instructions for use

Advertisement

Table of Contents
loading

Related Manuals for KitchenAid KSOX 9020

Summary of Contents for KitchenAid KSOX 9020

  • Page 1: Instructions For Use

    Instructions for use...

  • Page 3: Table Of Contents

    Outdoor grill safety EC Declaration of conformity Important safety instructions Installation requirements Installation instructions Gas connection Injector table Installation of the regulator Change the main grill burner valves injectors Check and adjust the burners Outdoor grill use Using your rotisserie (optional accessory) Tips for outdoor grilling Cleaning and maintenance Troubleshooting guide...

  • Page 4: Outdoor Grill Safety

    Outdoor grill safety Your safety and the safety of others are very important. We have provided many important safety message in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others.

  • Page 5: Important Safety Instructions

    Important safety instructions WARNING: To reduce the risk of fire, electrical shock, injury to persons, or damage when using the outdoor cooking gas appliance, follow basic precautions, including the following: • Do not install portable or built-in outdoor cooking gas appliances in or on a recreational vehicle, portable trailer, boat or in any other moving installation.

  • Page 6: Installation Requirements

    Important safety instructions DISPOSAL FOR PACKING MATERIAL The packing material is 100% recyclable and is marked with the recycle symbol . The various parts of the packing must therefore be disposed of responsibly and in full compliance with local authority regulations governing waste disposal.
  • Page 7 Installation requirements WARNING Fire Hazard Do not use grill near combustible materials. Do not store combustible materials near grill. Doing so can result in fire. Select a location that provides minimum exposure to wind. The location should be away from strong draft areas.
  • Page 8 Installation requirements Electrical requirements WARNING Electrical shock hazard Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in fire, or electrical shock. It is recommended that a separate circuit servicing only this grill be provided. The rating plate, with the technical data, the serial number and the marking is positioned where you can see it on the back of the appliance.

  • Page 9: Installation Instructions

    Installation instructions Freestanding Outdoor Grill Installation WARNING Excessive Weight Hazard Use two or more people to move and install the grill. Failure to do so can result in back or other injury. BEFORE INSTALLING AND USING THE BARBECUE YOU SHOULD CLEAN ITS INNER PARTS TO REMOVE ANY MANUFACTURING RESIDUES.
  • Page 10 Installation instructions Remove Packaging Material Inside the Grill 1. Cut the tiedowns holding the grates together. 2. Remove condiment shelf, warming shelf and grill grates from inside the grill and remove packaging material. 3. Remove foam block and wrap from inside the grill. A Foam block B Foam wrap 4.

  • Page 11: Gas Connection

    Installation instructions Freestanding gas barbecue with wheels Freestanding gas barbecue with wheels It has two fixed wheels and two pivoting wheels with brakes. It acts as a cylinder - holder compartment but depending on its width can be fitted with drawers or extra compartments. A cylinder not more than 50 cm tall (with the pressure regulator mounted) can be housed under the trolley support surface.
  • Page 12 Gas connection Connection to the gas cylinder IMPORTANT: The appliance is already adjusted for operation with LPG. Just connect to the rubber pipe Max length 1.5m in line with the local standard with gaskets and clips supplied which will be supplier by the gas cylinder supplied when purchasing the gas cylinder itself, following the procedure described below.

  • Page 13: Injector Table

    Injector table I3B/P(30), Gas categories I2E+ I3B/P(50) I3+(28-30/37) Model Pressure 20mbar 25mbar 29mbar 37mbar 50mbar 20mbar Main grill 1.90mm 1.90mm 1.27mm 1.27mm 1.08mm 1.90mm Back Injector 1.57mm 1.57mm 1.01mm 1.01mm 0.86mm 1.57mm burner KSOX 9020 Side 1.55mm 1.55mm 1.01mm 1.01mm 0.86mm 1.55mm burner...

  • Page 14: Installation Of The Regulator

    Installation of the regulator 1. Turn off the main gas supply valve. 2. Disconnect 20 lb LP gas fuel tank (if present). 3. Turn off all burner control valves. 4. Remove rear cover and 2 screws. 5. Use an adjustable wrench to remove the LP connector from the brass elbow.

  • Page 15: Change The Main Grill Burner Valves Injectors

    Change the main grill burner valves injectors 1. Manually remove all of the grates, sear plate, and main burners. 2. Remove the 2 screws that hold the burner in place. Remove gas burner from the grill. A Two screws 3. Use 6 mm socket and wrench or 6 mm nut driver to remove the brass injectors from the end of the gas valves.
  • Page 16 Change the main grill burner valves injectors Change the Side burner injectors 1. Remove the side burner grates. 2. Remove the burner caps. The caps are interlocked to the burner base. Twist and lift the burner caps to remove. 3. Use 10 mm socket and wrench or 10 mm nut driver to remove the brass injectors from inside the burner base.

  • Page 17: Check And Adjust The Burners

    Change the main grill burner valves injectors Hook up to Natural gas and Leak Test 1. Use pipe wrench to connect certified 1.3 cm gas supply pipe to inlet side of regulator from Natural gas supply according to local codes requirements. Use pipe thread sealant that is certified for use with LP gas at connections where required.

  • Page 18: Outdoor Grill Use

    Outdoor grill use The grill you have purchased may have some or all of the features listed. The locations and appearances of the features shown here may not match those of your model. Using Your Outdoor Grill WARNING Explosion Hazard Do not store the fuel tank in a garage or indoors.
  • Page 19 IMPORTANT: If the burner does not light immediately, turn the burner knob to OFF and wait 5 minutes before re-lighting. If any burners do not light after attempting to light them manually, contact the KitchenAid Customer Service Center. See the "After sales-service" section.
  • Page 20 IMPORTANT: If the burner does not light immediately, turn the burner knob to OFF and wait 5 minutes before relighting. If any burners do not light after attempting to light them manually, contact the KitchenAid Customer Service Center. See the "After sales-service" section.

  • Page 21: Using Your Rotisserie (Optional Accessory)

    Using your rotisserie (optional accessory) A rotisserie kit can be purchased as an accessory for the grill. IMPORTANT: you can only use a KitchenAid Rotisserie A Rotisserie motor B Spit rod C Rotisserie fork D Rotisserie burner For best cooking results, do not use main grill burners when using the rotisserie.
  • Page 22 Using your rotisserie (optional accessory) Manually Lighting the Rotisserie Burner 1. Do not lean over the grill. 2. Remove the manual lighting extension (see following illustration) and attach a match to the split ring. 3. Strike the match to light it. 4.
  • Page 23 Using your rotisserie (optional accessory) ROTISSERIE CHART Use a portable meat thermometer to check internal doneness of the food. Turn off rotisserie burner when meat thermometer reads 5°C lower than desired internal temperature. Continue rotating, hood closed, for 10 minutes before carving. Timing is affected by weather conditions such as wind and outside temperature.

  • Page 24: Tips For Outdoor Grilling

    Tips for outdoor grilling WARNING Food Poisoning Hazard Do not let food sit for more than one hour before or after cooking. Doing so can result in food poisoning or sickness. Before Grilling • Thaw food items before grilling. • Preheat grill on high (use all grill burners) 10 minutes. The hood must be closed during preheating. There is no need to use the back rotisserie burner for preheating.
  • Page 25 Tips for outdoor grilling Indirect cooking After preheating the grill, with burner set at maximum and with the cooking cover closed, position the food on the side of the grill nearest, but not over the lit burner. With the 90 cm barbecue, light the side burners and place the food on the central grill.

  • Page 26: Cleaning And Maintenance

    Cleaning and maintenance IMPORTANT: Before cleaning, make sure all controls are off and the grill is cool. Always follow label instructions on cleaning products. For routine cleaning, wash with soap and water using a soft cloth or sponge. Rinse with clean water and dry at once with a soft, lint-free cloth to avoid spots and streaks.
  • Page 27 Cleaning and maintenance SIDE BURNER CAPS AND GRATE Cleaning Method: • Clean with a brass bristle brush. • Wash grate using mild detergent, warm water and degreaser. • Rinse with clean water and dry with soft, lint-free cloth. U-SHAPED BURNERS Cleaning Method: •...

  • Page 28: Troubleshooting Guide

    Cleaning and maintenance Cleaning Method: • Use mild detergent, a soft cloth and warm water. • Rinse and dry. CONTROL PANEL GRAPHICS IMPORTANT: To avoid damage to control panel graphics, do not use steel wool, abrasive cleaners or oven cleaner. Do not spray cleaner directly onto panel.

  • Page 29: After-Sales Service

    KITCHENAID ® appliance. To locate factory specified parts in your area, call us or your nearest KitchenAid designated service center. Whirlpool Europe s.r.l. Via G. Borghi 27 - 21025 Comerio (Va)
  • Page 32 Printed in Italy 06/10 5019 704 02018/C...
