Extron electronics DTP T HWP 232D Setup Manual

DTP T HWP/UWP 232/332 D • Setup Guide
This setup guide provides instructions for an experienced installer to set up and operate the Extron DTP T HWP D and
DTP T UWP D family of Twisted Pair (TP) wallplate extenders.
AUTO SW
AUDIO IN AUDIO IN
HDCP
1
HDMI IN VGA IN
CONFIG
IR OUT
G
S
Extron
DTP T UWP 232 D Tx
Transmitter
AUTO SW
AUDIO IN AUDIO IN
HDCP HDCP
1 1
HDMI IN 2 HDMI IN
CONFIG
IR OUT
G
S
Extron
DTP T HWP 232 D Tx
Transmitter
Installation
Step 1 — Disconnect Power
Disconnect all equipment power sources.
Step 2 — Prepare the Mounting Surface
ATTENTION:
•
Installation and service must be performed by
authorized personnel.
•
L'installation et l'entretien doivent être effectués par le
personnel autorisé uniquement.
•
The unit must be installed in accordance with the
National Electrical Code and with local electrical and
safety codes.
•
L'unité doit être installée conformément au National
Electric Code et aux normes électriques et de sécurité
locales.
NOTE: Use a wall box with a depth of at least 3.0 inches (7.6 cm). Alternatively, the included mud ring (MR 200) can be
used. For more information, see the full product user guide at www.extron.com.
Place the wall box against the installation surface and mark the opening guidelines.
a.
TIP: Use a level to mark the opening.
Cut out the material from the marked area.
b.
Secure the wall box to the wall stud with 10-penny nails or #8 or #10 screws, leaving the front edge flush with the
c.
surface.
Run all required cables (see steps 3, 4, and 5) and secure them with cable clamps.
d.
TIP: In order to fit the unit in the junction box, do not install boots on TP cables and RJ-45 connectors.
INPUTS INPUTS OUTPUTS
MENU
1 2 3 4 5 6 7 8
SIGNAL
1 2 3 4 5 6 7 8 A B C
CONFIG HDCP
ENTER
Extron
IN1608 SA
INPUTS OUTPUTS AUDIO INPUTS
OVER DTP
RS-232 IR L 1 R L 3 R L 5 R
1
3 5 C A
7 Tx Rx G Tx Rx 8
SIG LINK SIG LINK SIG LINK
CONFIGURABLE OVER DTP OVER DTP
100-240V ~ -- A MAX 2
HDMI HDMI RS-232 IR RS-232 IR HDMI L 2 R L 4 R L 6 R
4 6 B
DTP IN Tx Rx G Tx Rx DTP IN Tx Rx G Tx Rx DTP OUT
50/60 Hz
IN1608
XTP DTP 24 Cable
230'
VOLUME
IN1608
SCALING PRESENTATION SWITCHER
AMPLIFIED OUTPUT
2x25W(8Ω)/2x50W(4Ω)
L R
OUTPUTS
1 2
CLASS 2 WIRING
REMOTE
IPCP 505
+48V LAN COM
MIC/LINE VARIABLE RTS
SWITCHED FLEX 100
2 L R RESET RS-232 12VDC IR/S RELAY I/O eBUS
CTS
1 2 LIMIT 1 2 3 4 1 2 3 4 1 2 ACT LIMIT LINK
+48V R TX TX
Tx Rx G IR
ACT
RX RX
3 4 OVER 1 2 3 4 5 6 7 8 5 6 7 8 5 6 7 8 3 4 OVER
IPCP 505
Ethernet
SIG LINK
OUTPUTS
POWER
AUDIO
12V
L R
0.7A MAX
DTP IN
DTP HDMI 230 Rx
HDMI
Wall Stud
Screws or
Nails
Wall opening is
flush with edge of box.
Cable
Clamp
Signal Output
Cable
Network
TLP 1000TV
Projector
IN
D IO
SW A U
TO
AU
C P
H D A IN
1 V G
IN
D IO
A U
IN
M I
G
H D N FI
C O
O U T
IR G
S
Extron
DTP T UWP 232 D
Decora Faceplate
