Page 1
This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. C01- Cover ® ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 210-372-3551 Email: parts@alamo-industrial.com $0.00...
Page 2
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of acci- dents.
Page 3
In order to reduce accidents and enhance the safe operation of mowers, Alamo Industrial, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
Page 4
Alamo Industrial Division is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual...
(SGM-13) PARTS INFORMATION Alamo Industrial mowers use b alanced and matched system c omponents f or b lade carriers, b lades, c utter- shafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Alamo Industrial s pecifications. Non-genuine "will fit" p arts do not consistently meet these specifications.
NOTE: Alamo Industrial supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Alamo Industrial cares about the safety of its cus- tomers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 24
LENGTH 17 (for 17' Boom) LENGTH 20 (for 20' Boom) LENGTH 23 (for 23' Boom) LENGTH 28 (for 28' Boom) SER PLT A-BOOM Serial Plate 00756059 WARNING Warning Oil Leak 00763524 ATTENTION Do Not Swing Boom to Rear 00769377 NOTICE...
Page 34
SAFETY Name LOGO - Alamo Industrial P/N 00757140 Peligro Translation, If you do not know how to read English, ple ase fin d so meone who knows how to read English. P/N 00725746 WARNING! Pinch Points P/N 02962764 DANGER! Crushing and Pinch Points.
Page 95
INTRODUCTION Your A-Boom Mower is designed for heavy-duty cutting in limited access a reas such as highway, park, rural roadsides, overhead growth, ditches, levees, and other such grass and limb control uses in generally hard -to- reach areas. DIRECTION Throughout this Manual front and rear, left and right are determined by the normal direction of travel, the same as driving an automobile.
Pictures contained in this section are intended to be used as a visual aid to assist in explaining the operation of a A-Boom and are not specific to a A-Boom. Some pictures may show sh ields removed to enhance visual clarity.
OPERATION 8.OPERATING THE CONTROL VALVES The A-Boom has two control valves. One is the on-off switch to the cutter motor and the other is the position control valve. ON-OFF Switch (Mower Valve) - To operate the mower, pull the switch while the tractor is running. The push- pull operator will remain in the ON position PULLED or the OFF position PUSHED until the operator desires to start or stop the mower.
Page 121
If you have any questions concerning safety of operation, contact your dealer or ALAMO INDUSTRIAL. This valve is located on the Main Frame of the unit. These are fastened together in a bank of five valves. Their use will be explained in the following pages of this manual.
HEAD: The A-Boom must be serviced daily to achieve the best operation and longest life. Two pumps of a good qual- ity grease from a hand grease gun in all grease fittings should be sufficient. NOTE: Lubricate flail roller bearing until lubricant can be seen coming out between roller and bearing housing.
MAINTENANCE Hydraulic Oil, Filters, and Components Filters and Oil - Change the return filter tank and suction filters after the first 100 hours of operation. Change the filters again at 500 hours or every 12 months. Change the oil after the first 400 hours or operation. After that, continue to change the oil every 800 hours or every 12 months.
Also remember that any other protectant must be compatible with hydraulic fluid. Alamo Industrial is not responsible for rust or pit- ting of the cylinder rod due to weather exposure or impacts from normal operation or mounting. If hydraulic cyl- inders and or the cylinder rods are damaged as a result of the rods rusting or pitting, the hydr aulic cylinders and rods will not be covered under warranty by Alamo Industrial.
MAINTENANCE PROPER TORQUE FOR FASTENERS The chart lists the correct tightening torque for fasteners. When bolts are to be tightened or replaced, refer to this char t to deter mine the g rade o f bolts an d the proper tor que except when sp ecific tor que valu es ar e assigned in manual text.
MAINTENANCE SPINDLE SERVICE PROCEDURE 02960553B and 02960553C Remove blade bar or pan. Remove hydraulic motor. Remove spindle assembly from mower deck. Drain remaining lubricant from housing. Using a 3/16" cape chisel, bend out the staking indentations on each side of the bearing adjusting nut. To do this, place the chisel in the groove and parallel to the shaft.
MAINTENANCE In a clockwise pattern, rotate each bolt 1/4 turn (see Figure 3). Continue turning the bolts 1/4 turn at a time (maximum of 3 turns), until the special shanked bolts (P/N 02964353) will thread into the spindle. Remove the original bolts and replace them with the shanked bolts. Screw the shanked bolts in until they contact the bearing ring.
Page 152
MAINTENANCE Tools needed: Hand tools Hydraulic press Inch pound torque wrench Seal Installers Bearing drivers (do not use punches Adjusting nut socket to install bearings) 2-3/4" ID x 8" long, 16 Ga. tubing Note: This procedure should not be attempted in the field due to the need for tools normally only found in the shop.
MAINTENANCE ROLLER BEARING REPLACEMENT Securely support mower while removing and installing roller assembly. If installing a roller with pre assembled bearing and bracket assemblies, remove the old roller, proceed to step 1. Remove roller and both bearing and bracket assemblies from mower. Lift the mower only high enough to remove the roller assembly.
MAINTENANCE TIMBER CAT HEAD Lubrication/Daily Checks (Figure Mnt-0007) Lubricate the grease fittings on top of the blade bar every 4 hours. See Figure Mnt-0007. Every 8 hou rs, lubr icate the cylinder gre ase fittin g through the top slot in the cover. See Figure Mnt- 0007.
MAINTENANCE Buzzbar Head BLADES For best performance, have blades set and sharpened when they begin to dull. Blades can be touched up with a grinder or file between sharpenings. To extend the life of the blade, remove resin accumulations. When the resin builds up, the blades will "burn" in the cut, causing the blades to overhea t and warp.
Page 156
MAINTENANCE Belt Tension Adjustment (Figure Mnt-B-0010) Loosen nuts on the 4 studs and the jam nut. Use a hand wrench or socket to tension the belts. Never use power or air equipment to tighten belt! This could cause damage to belt, sheave, shaft and bearings Once the belts begin to tighten, small adjustments will produce large changes in tension.
Page 157
MAINTENANCE Lubrication: Grease each spindle with on e pu mp of high qua lity lithium grease weekly . More th an o ne pu mp is unnecessary and will cause a mess when extra grease squirts out of the relief. Grease fittings are on front of machine, just above the blades.
MAINTENANCE Flail Axe Head Belt Tension: When installing new belt s, tighten belts to obt ain a 16 lb. Belt Deflec tor Force at 7/16" deflection. Af ter a few hours of operation to allow the belts to seat into the sheave grooves recheck and adjust as needed to obtain an 8 to 1 2 lb.
MAINTENANCE General Information on Flail Mower Vibration FLAIL MOWERS INFORMATION BULLETIN NO. 5 EXCESSIVE VIBRATION Vibration is a MONSTER and if allowed to continue unchecked, can cause the complete break-up of a machine in a very short time. A properly operated Flail Mower will produce very little vibration. If vibration does occur, the mower should be stopped and the trouble corrected, as warranty does not cover failures resulting from continued operation after something happens to cause the mower to vibrate excessively.
Page 160
MAINTENANCE The cutter shaft will run out of balance if: Wire, rope, string, rags, etc., around the cutter shaft, are holding the knives in a folded back position. Remove such foreign objects and be sure all knives are free to swing to the extended position. Knives are missing or broken.
Page 162
LIMITED WARRANTY LIMITED WARRANTIES 1.01. Alamo Industrial warrants for one year from the purchase dat e to the original non-commercial, governme ntal, or municip al purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser 1.02.
Page 163
TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes th ese minimum safety require- ments of tractor operators: REQUIRED OF THE OWNER:...
