Summary of Contents for Alamo Industrial BUILT SHARPER AM4000

  • Page 1 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 2 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 3 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 4 PO BOX 549 Seguin, Texas 78156-9967 830-372-3551 Alamo Industrial provides a full line of field tested & proven lift-type, pull-type, boom-mounted, offset-mounted, & semi-mounted rotary, flail, & sickle bar mowers; tractor-mounted, three- section flail mowers; self-powered rotary & flail mowers; and shredders.
  • Page 5 AM4000 Rotary Mower Rev 03-13 P/N 00767090 OPERATOR'S MANUAL with PARTS LISTING ALAMO INDUSTRIAL Post Office Box 549 Seguin, Texas 78156 830-372-3551 © Alamo Group Inc. 2013...
  • Page 6: Before You Start

    TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS SAFETY SECTION ............................. 1-1 Safety Information ..........................1-2 Safety Decal Location ........................... 1-5 INTRODUCTION SECTION ........................2-1 ASSEMBLY SECTION ..........................3-1 Driveline Installation ..........................3-2 A-Frame ..............................3-3 Chain guards ............................3-4 Hydraulic Relief ............................. 3-5 OPERATION SECTION ..........................4-1 Tractor Preparation ..........................
  • Page 8 SAFETY DANGER! There are obvious and hidden potential hazards in the operation of this mower. REMEMBER! This machine is often operated in rough terrain conditions and in heavy weeds. The Blades of this mower can throw can throw objects for a great distance at very high speeds. Serious injury or even death may occur unless care is taken to insure the safety of the operator, bystanders, or passersby in the area.
  • Page 9 SAFETY WARNING! Do not modify or alter or permit anyone to modify or alter this equipment or any of its components or any equipment function without first consulting your Equipment Dealer. WARNING! The operator and all support personnel should wear hard hats, safety shoes, and safety glasses at all times for protection from injury by falling objects and items thrown by the machine.
  • Page 10 SAFETY DANGER! Never clean or adjust PTO-driven equipment with the tractor engine running. WARNING! Never allow riders on either tractor or mower. Falling off can kill. Operate the mower only with a tractor equipped with an approved roll-over-protective system DANGER! (ROPS).
  • Page 11 SAFETY CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMANENT HEARING LOSS! Tractors with or without Mowers attached can often be noisy enough to cause permanent, partial hearing loss. We recommend that you wear hearing protection on a full-time basis if the noise in the Operator’s position exceeds 80db.
  • Page 12: Safety Section

    SAFETY DECAL LOCATION ITEM PART NO. LEVEL DESCRIPTION 00725746 PELIGRO! Get Safety Translated 00749117 DANGER! Multiple Hazard 00756004 ((1)) DANGER! Driveline Shield Missing 00756005 ((1)) DANGER! Rotating Driveline 00769736 WARNING! Use/Repair Shields & Guards 00769737 DANGER! Blades/Thrown Objects 00756494 DANGER! Driveline hazards 02925100 CAUTION!
  • Page 13 DECALS 1- 00725746 11 - D103 7 - 00756494 4- 00756005 3- 00756004 8- 02925100 10 - 00763977 AM4000 14- 00767091 2- 00749117 - Not Shown 15- Serial Plate 13- 02960766 (See Inside Front Cover of Manual) AM4000/11-94 Safety Section 1-7 ©...
  • Page 14 DECALS 5 - 00769736 6 - 00769737 12- 00757139 AM4000/11-94 Safety Section 1-8 © 1994 Alamo Group Inc.
  • Page 15: Introduction Section

    INTRODUCTION This Rotary Mower is designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize, instruct, and train. The Assembly Section instructs the owner/ operator in the correct assembly of the Mower using standard and optional equipment.
  • Page 16 INTRODUCTION Your ALAMO AM4000 mower is designed for light-duty cutting such as pasture mowing, weed, and grass control. With a reasonable amount of preventive maintenance, your Mower will provide years of dependable service. DANGER For Non-Agricultural use, OSHA, ASAE, SAE, and ANSI standards require the use of Chain Guards, Deflectors, or Solid Skirts at all times.
  • Page 17: Attention Owner/Operator

    INTRODUCTION ATTENTION OWNER/OPERATOR BEFORE OPERATING THIS MACHINE: 1. Carefully read the Operator’s Manual, completely understand the Safety Messages and instructions, and know how to operate correctly both the tractor and Mower. 2. Fill out the Warranty Card in full. Be sure to answer all questions, including the Serial Number of the Mower.
  • Page 18: Dealer Set-Up Instructions

    ASSEMBLY DEALER SET-UP INSTRUCTIONS Set up mower as received from factory with these instructions. Refer to complete check list when set -up is finished. Select a suitable working area. Open parts box and lay out parts to make location easy. Refer to Parts Lists in Section 6 of manual and packing list.
  • Page 19: A-Frame

    ASSEMBLY A-FRAME INSTALLATION (FIGURE 3). 1. Attach “A” Frames (1) to inside of welded hitch brackets on Mainframe, insert Hitch Pin (12), Bushing (15), flatwasher (11), lockwasher (14) and install nut (13). 2. Install the lift straps (3) on inside of top rails on mainshield (behind gearbox mount) and attach with 1/2" x 1- 1/2"...
  • Page 20 ASSEMBLY Deflectors are standard equipment. The Front and Rear Chain Guards are Extra Equipment and are recommended to be used at all times to prevent injury caused by flying objects. The Front Chain Guard should be attached by using four 1/2" Hex. Hd. Capscrews, Washers, and Nuts as shown in Figure 4.
  • Page 21: Hydraulic Relief

    ASSEMBLY HYDRAULIC RELIEF ASSEMBLY (P/N 3570) FIGURE 6 Hydraulic Relief Assembly (3570), also known as check chain, is available for attachment to front of cutter as an accessory. Check chains are used to control cut height and especially allows cutter to always be lowered to the same preset cut height.
  • Page 22: Mower Preparation

    OPERATION The safe operation of this machine is the responsibility of the operator. The operator should be familiar with the cutter and tractor and all safety practices before starting operation. This cutter is designed primarily for weed and grass control in pastures and along highway right-of-ways. It is equipped with suction Blades. Recommended cutting speed for most conditions is from 2 to 5 mph.
  • Page 23: Attaching Mower To Tractor

    OPERATION ATTACHING MOWER TO TRACTOR Back the tractor up to the Shredder so that the lower Draft Arms are in alignment with the Shredder lower Lift Pins. Stop the engine, lock the brakes or place the tractor in park. Connect the tractor and Stabilizer Bars to the lower Lift Pins.
  • Page 24: Starting & Stopping Cutter

    OPERATION STARTING & STOPPING CUTTER Power for operating cutter is supplied from tractor PTO. Refer to your tractor manual instructions for engaging and disengaging the PTO. Always engage the PTO at low engine rpm. Always operate at recommended PTO speed of 540 RPM. Learn how to stop tractor and cutter quickly in case of an emergency.
  • Page 25: Detaching And Storing

    OPERATION WARNING! Avoid personal injury. Pick up all rocks and other debris before cutting. Enter new areas carefully. Cut material higher the first time to allow cutter to clear unseen objects. Never assume an area is clear. Always check. Extremely tall grass should be cut twice. Raise cutter and cut twice the desired height. Cut the second time at desired height at 90 degrees to first pass.
  • Page 26 OPERATION CHECK PTO LENGTH Hold the Driveline halves next to each other in the shortest working position and mark them according to FIG- URE 2 below (40mm=1-9/16"). Shorten inner and outer guard tubes equally. Shorten inner and outer sliding profiles by the same amount that the shield tubes were shortened. Round off all sharp edges and removes burrs.
  • Page 27 OPERATION BEFORE OPERATING OR TRANSPORTING THIS MOWER: Always display this SMV emblem (Figure 3) on the rear of the tractor transporting this mower where it is clearly visible to oncoming traffic. Prominent display of this symbol will help the operator avoid accidents which could cause injury or possibly death.
  • Page 28 OPERATION OFFSET ADAPTER (FIGURE 4) Fasten the Offset Adapter Tube to the three-Point Lift Lugs using the hitch Pin Holes. Fasten the Adjustable Leg to the right Lug to offset the Mower to the right. Fasten the Adjustable Leg to the left Lug to offset the Mower to the Left.
  • Page 29: Blade Carrier

    OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Excessive Vibration 1. Check Gearbox bolts. Tighten if loose. 2. Check for loose nuts on Tighten if loose. bladeholder and blades. 3. Check for bent output shaft. Replace shaft if bent. If shaft is bent, oil will normally leak from bottom seal.
  • Page 30 OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Not Cutting Clean 1. Blades dull. Sharpen or replace blades. 2. Carrier RPM too low. Use correct PTO speed and check for correct gearbox ratio. See specifications. 3. Cutter not level. See Cutting Height Adjustment.
  • Page 31 OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Gearbox Noisy 1. Rough Gears. Run in or change gears. 2. Worn Bearings. Replace bearing. Gearbox Leaking 1. Damaged oil seal. Replace seal. 2. Bent Shaft. Replace oil seal and shaft. 3.
  • Page 32: Lubrication Information

    MAINTENANCE Before operating your Rotary Cutter, make sure it is properly lubricated and thoroughly inspected. Only a minimum of time and effort is required to regularly lubricate and maintain this machine to provide long life and trouble free operation. WARNING! Always disengage the PTO before raising the Rotary Cutter for transporting or making adjustments.
  • Page 33 MAINTENANCE FILL CHECK FIGURE 2. Gearbox Lubrication GEARBOX The gearbox should be full (18 ounces).54 liters and not require additional lubricant unless the box is cracked or a seal is leaking. It is recommended that the 1/8" oil level plug (Figure 2) be removed after every 10 hours of operation.
  • Page 34: Lubrication

    MAINTENANCE DRIVELINE LUBRICATION Grease Fittings are located on the Cross Assembly of each U-Joint and on the telescoping tubes. Grease the U-Joint after each 8 hours of use. Figure 3. Do not force grease through the Needle Cup Assemblies. Grease the telescoping tubes after every 8 hours use. To grease profile tube, disconnect drive from PTO and pull halves apart.
  • Page 35: Blades

    MAINTENANCE WARNING! When attaching PTO yoke to tractor PTO shaft, it is important that spring-activated locking collar slides freely and locking balls are seated in groove on PTO shaft. A loose shaft could slip off and result in personal injury or damage to cutter. BLADE SERVICING Inspect blades before each use to determine that they are properly installed and in good condition.
  • Page 36: Blade Carrier Removal

    MAINTENANCE BLADE REMOVAL To remove blades for sharpening or replacement, remove the cover plate on deck of cutter near gear box. Remove lock nut from blade bolt. NOTE: Inspect lock nut after removal and replace if threads are damaged. Always replace nut when replacing blade bolt. When installing blades be sure and check blade bolt pivot di- ameter for wear.
  • Page 37: Storage

    MAINTENANCE STORAGE Your rotary cutter represents an investment from which you should get the greatest possible benefit. Therefore, when the season is over, the cutter should be thoroughly checked and prepared for storage so that a minimum amount of work will be required to put it back into operation for the next season. The following are suggested storage procedures: 1.
  • Page 38 MAINTENANCE GEARBOX SERVICE INSTRUCTIONS GEARBOX DISASSEMBLY (Figure 8) 1. Remove 6 capscrews (Ref.#16) from input shaft bearing housing (Ref. #13). 2. Tap around circumference of bearing housing (Ref. #13) to loosen housing and shims. Then (Ref. #9) pull complete shaft and housing assembly (See Fig. 8) out of main housing. 3.
  • Page 39 MAINTENANCE INPUT SHAFT (Figure 9) DISASSEMBLY AND ASSEMBLY 1. Remove snap ring (Ref. #11) and then remove bearing housing (Ref. #13) by holding end of shaft which does not have a cross hole or splines and tap opposite end of shaft on solid surface. Shock force will remove housing from bearing (Ref.#4).
  • Page 40 MAINTENANCE DISASSEMBLY OUTPUT SHAFT (FIG 10) 1. Install slotted nut (Ref 18, Figure 8) onto shaft and then tap shaft end on solid surface to remove lower bearing and spacer. 2. Remove snap ring (Ref #7) and then repeat above procedure to remove upper bearing. ASSEMBLY 1A.
  • Page 41 MAINTENANCE MAIN GEARBOX 1. Remove bearing (Ref. #8 Figure 8) from inside main housing. A special slide hammer puller (PROTO No. 4056) or equal may be required to remove bearing. Press in new bearing using driving tube or pipe with approximate same OD.
  • Page 42: Parts Section

    PARTS ORDERING GUIDE The following instructions are offered to help eliminate needless delay and error in processing purchase orders for the equipment in this section. 1. The Parts Section is prepared in logical sequence and grouping of parts that belong to the basic machine featured in this manual.
  • Page 43 TABLE OF CONTENTS Three Point Hitch Assembly ....................6-4 Driveline Assembly ......................6-5 Gearbox Assembly ......................6-6 Dish Pan Assembly ......................6-7 Front Deflector Assembly ....................6-8 Rear Deflector Assembly ....................6-8 Front Chain Guard Assembly .................... 6-9 Rear Chain Guard Assembly..................... 6-9 Tail Wheel Assembly ......................
  • Page 44: Three Point Hitch Assembly

    THREE-POINT HITCH ASSEMBLY 4,5,6 9,10,11,12,13 ITEM PART NO. DESCRIPTION 00764839 “A” FrameLeg 00757949 Bar Toplink 00765325 Lift Strap 00757953 Bushing Spacer 02025700 Bolt 00037200 Locknut 00001800 Locknut TLM 1/2 NC PLC 00748823 Bolt 15B1400 Washer, Type “A” 00603500 Wrist Pin 00603600 Hex Nut 00012200...
  • Page 45 LIFT TYPE DRIVELINE P/N 00759161A ITEM PART NO. DESCRIPTION 00759177A Shield Half (Outer) 00762574 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00759162 Outer Yoke (Shear Bolt) 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube) 00759166 Inner Tube 00759173A...
  • Page 46 GEARBOX P/N 00761655 ITEM PART NO. DESCRIPTION 00564700 Input Shaft 00564200 Seal 00563700 Ball Bearing 00564300 Input Cap 00564400 Gasket 00752481 Input Gear 00564100 Retaining Ring 00563900 Housing 00564800 Bearing 00752480 Output Pinion & Shaft 00757682 Bearing Spacer 00760928 Gasket .25 00760929 Gasket .10 02161100...
  • Page 47: Dish Pan Assembly

    DISH PAN ASSEMBLY ITEM PART NO. DESCRIPTION 00761551 Dish Pan Weldment 00761532 Suction Blade 00761402 Blade Bolt 00761535 Washer 00750226 Locknut Parts Section 6-7 AM4000/11-94 ©1994 Alamo Group Inc.
  • Page 48: Front Deflector Assembly

    DEFLECTORS FRONT DEFLECTOR ASSEMBLY P/N 00758338 ITEM PART NO. DESCRIPTION 00758249 Deflector 02035800 Woodwasher 00011100 Flatwasher 00011400 Hex Head Capscrew 00015800 Locknut REAR DEFLECTOR Assembly P/N 00761603 ITEM PART NO. DESCRIPTION 00761598 Deflector (Center) 00761599 Bar (Center) 15B800 Washer 00750959 Hex Head Capscrew 00001800 Locknut TLM 1/2 NC PLC...
  • Page 49: Front Chain Guard Assembly

    CHAIN GUARD ASSEMBLIES 2,4,7 FRONT CHAIN GUARD Assembly P/N 0911100000 ITEM PART NO. DESCRIPTION 0911100100 Chain Guard Weldment 00752680 Bolt 0901100102 Mounting Flat 00001800 Locknut TLM 1/2 NC PLC 0758341004 0731361104 Chain Links 15B800 Washers 4,5,6 REAR CHAIN GUARD Assembly P/N 00761601 ITEM PART NO.
  • Page 50: Tailwheel Assembly

    TAILWHEEL ASSEMBLY ITEM PART NO. DESCRIPTION 0911030100 Caster Fork Weldment 0841050300 Wheel and Tire Assembly 0911030300 Spindle Bolt Weldment 00749136 Locknut 0911020100 Tailwheel Beam Weldment 00036900 Cotter Pin 15B2000 Washer 00753013 Bolt 00001800 Locknut TLM 1/2 NC PLC 00750311 Bolt 00695100 Nut, Toplock 5/8 NC PLC 00756077...
  • Page 51: Hydraulic Relief Assembly

    HYDRAULIC RELIEF ASSEMBLY ITEM PART NO. DESCRIPTION 8709 Chain Assembly 8708 Bracket 02845500 Bolt 00695100 Nut, Toplock 5/8 NC PLC AM4000/11-94 Parts Section 6-11 ©1994 Alamo Group Inc.
  • Page 52 3-POINT OFFSET ADAPTER P/N 0702310000 ITEM PART NO. DESCRIPTION 0702310100 Adapter Mainframe 0702310001 Brace Bar 0702310300 Brace Lug and Chain 0702310200 Adjustable Lift Lug 511027 Wrist Pin 7A14924 Bolt 15B1400 Washer 423013 Bushing 5JRC1490 Locknut Retaing Pin 02030400 Bolt 00001300 Lockwasher 00001200 Hex Nut...
  • Page 53 LIMITED WARRANTY 1. LIMITED WARRANTIES 1.01.Alamo warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship. 1.02.Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be defective under normal use and service due to defects in material or workmanship.
  • Page 54 In addition to the standard Limited Warranty, Alamo Group provides one year (12 months), (6 months for Commercial/Industrial Users) Limited Warranty on the Driveline components provided that these components have been properly main- tained and lubricated that and have not been subjected to abused or mis-use In addition to the standard Limited Warranty shown on the preceding page, Alamo Group provides A THREE YEAR LIMITED WARRANTY on GEARBOX components* provided that these components have been properly maintained and lubricated and have not been subjected to abuse or mis-use...
  • Page 55 AM4000 OMWPL PUB 11-94 P/N 00767090 Printed U.S.A.
