Alamo Industrial BUILT SHARPER AM5000 Operator’s Manual With Parts Listing

Table of Contents

Advertisement

Quick Links

1. PRINT FIRMLY.
2. REMOVE WHITE COPY FOR CUSTOMER RECORDS.
ALAMO INDUSTRIAL WARRANTY REGISTRATION INFORMATION
A M
Alamo Model
Purchaser
Last Name
Street & No., RFD,
Box, &/or Apt. No.
City
Dealer
City
I have informed the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable, reviewed the
contents of the Operator's Manual including safety equipment, safe operation, and maintenance, reviewed the Safety Signs on
implement (and tractor if possible), and Purchaser's responsibility to train his operators in safe operation.
MOWERS: I have explained that Deflectors, Chain Guards, or Solid Skirts must be maintained in good repair and installed except
in areas where persons, vehicles, livestock, or other property will not be endangered by thrown objects and where such safety
equipment would prevent the mower's reasonable performance of its assigned task.
DRIVELINES: Make certain that all drivelines, gearbox, and other shields are in good repair and fastened securely in place to
prevent injuries from entanglement or thrown objects.
I have been instructed on the paragraphs above, received and have been instructed in the contents of the Operator's Manual including
safety signs, safety equipment, safe operation, maintenance, and the potential hazards of unauthorized alteration or modification of
the product. I have been informed of the warranty provisions and know that the warranty is not in effect until this form is received
by Alamo Group.
I understand the Mower Guarding statements above and the potential hazards of operating without such guards. I understand that the
operator is responsible for the safety of others in the area. I have examined the product and accept it as being complete and in
satisfactory condition with all required guards.
CUSTOMER COPY
PLEASE FILL OUT OWNER WARRANTY REGISTRATION INFORMATION
ABOVE, SIGN, AND DROP LAST COPY IN ANY MAILBOX.
TO PLACE THIS WARRANTY IN EFFECT,
THIS WARRANTY REGISTRATION MUST BE
FILLED OUT, SIGNED, AND MAILED WITHIN 30
DAYS OF DELIVERY DATE OF THIS MACHINE.
DEALER AND PURCHASER MUST SIGN.
ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL
WILL BE REFUSED UNTIL COMPLETED, SIGNED
WARRANTY REGISTRATION CARD IS ON FILE.
3. REMOVE YELLOW COPY FOR DEALERS RECORDS.
Serial No.
Dealer's Signature
Purchaser's Signature
IMPORTANT!
MONTH
Purchase Date
First Name
State or
Province
State or
Province
4. MAIL LAST CARD POSTAGE FREE.
DAY
YEAR
M.I.
ZIP
ZIP
Date
Date

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BUILT SHARPER AM5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alamo Industrial BUILT SHARPER AM5000

  • Page 1 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 2 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 3 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 4 PO BOX 549 Seguin, Texas 78156-9967 210-372-3551 Alamo Industrial provides a full line of field tested & proven lift-type, pull-type, boom-mounted, offset-mounted, & semi-mounted rotary, flail, & sickle bar mowers; tractor-mounted, three- section flail mowers; self-powered rotary & flail mowers; and shredders.
  • Page 5 AM5000 Rotary Mower Rev 03-13 P/N 00767094 OPERATOR'S MANUAL with PARTS LISTING ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 830-372-9595 © Alamo Group Inc. 2013...
  • Page 6: Before You Start

    TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS SAFETY SECTION Safety Information ..........................1-2 Safety Decal Location ........................... 1-6 INTRODUCTION SECTION Introduction ............................2-2 ASSEMBLY SECTION Shear Pin installation ..........................3-2 Shield Assembly ........................... 3-2 A-Frame Installation ..........................3-3 Tail Wheel Installation .......................... 3-3 Hydraulic Relief ............................ 3-4 Rear Axle Assembly ..........................
  • Page 9: Safety Section

    SAFETY DANGER! There are obvious and hidden potential hazards in the operation of this mower. REMEMBER! This machine is often operated in rough terrain conditions and in heavy weeds. The Blades of this mower can throw can throw objects for a great distance at very high speeds. Serious injury or even death may occur unless care is taken to insure the safety of the operator, bystanders, or passersby in the area.
  • Page 10 SAFETY WARNING! Do not modify or alter or permit anyone to modify or alter this equipment or any of its components or any equipment function without first consulting your Equipment Dealer. The operator and all support personnel should wear hard hats, safety shoes, and safety glasses at WARNING! all times for protection from injury by falling objects and items thrown by the machine.
  • Page 11 SAFETY DANGER! Never clean or adjust PTO-driven equipment with the tractor engine running. WARNING! Never allow riders on either tractor or mower. Falling off can kill. Operate the mower only with a tractor equipped with an approved roll-over-protective system (ROPS). DANGER! Always wear seat belts.
  • Page 12 SAFETY CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMANENT HEARING LOSS! Tractors with or without Mowers attached can often be noisy enough to cause permanent, partial hearing loss. We recommend that you wear hearing protection on a full-time basis if the noise in the Operator’s position exceeds 80db.
  • Page 13: Safety Decal Location

    SAFETY DECAL LOCATION AM5000 LIFT TYPE AM5000 PULL TYPE ITEM PART NO. LEVEL DESCRIPTION 00725746 PELIGRO! Get Safety Translated 00749117 DANGER! Multiple Hazard 00756004 ((1)) DANGER! Driveline Shield Missing 00756005 ((1)) DANGER! Rotating Driveline 00769736 WARNING! Use/Repair Shields & Guards 00769737 DANGER! Blades/Thrown Objects...
  • Page 14 DECALS 1- 00725746 11 - D103 7 - 00756494 4- 00756005 3- 00756004 8- 02925100 10 - 00763977 AM5000 14- 00767095 2- 00749117 - Not Shown 15- Serial Plate 13- 02960766 (See Inside Front Cover of Manual) AM5000/11-94 Safety Section 1-7 ©...
  • Page 15 DECALS 5 - 00769736 6 - 00769737 12- 00757139 AM5000/11-94 Safety Section 1-8 © 1994 Alamo Group Inc.
  • Page 16: Introduction Section

    INTRODUCTION This Rotary Mower is designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize, instruct, and train. The Assembly Section instructs the owner/ operator in the correct assembly of the Mower using standard and optional equipment.
  • Page 17 INTRODUCTION Your ALAMO AM5000 mower is designed for light-duty cutting such as pasture mowing, weed, and grass control. With a reasonable amount of preventive maintenance, your Mower will provide years of dependable service. DANGER For Non-Agricultural use, OSHA, ASAE, SAE, and ANSI standards require the use of Chain Guards, Deflectors, or Solid Skirts at all times.
  • Page 18: Attention Owner/Operator

    INTRODUCTION ATTENTION OWNER/OPERATOR BEFORE OPERATING THIS MACHINE: 1. Carefully read the Operator’s Manual, completely understand the Safety Messages and instructions, and know how to operate correctly both the tractor and Mower. 2. Fill out the Warranty Card in full. Be sure to answer all questions, including the Serial Number of the Mower.
  • Page 19: Dealer Set-Up Instructions

    ASSEMBLY DEALER SET-UP INSTRUCTIONS Set up mower as received from factory with these instructions. Refer to complete check list when set -up is finished. Select a suitable working area. Open parts box and lay out parts to make location easy. Refer to Parts Lists in Section 6 of manual and packing list.
  • Page 20: A-Frame Installation

    ASSEMBLY LIFT TYPE A-FRAME INSTALLATION (FIGURE 4). 1. Attach “A” Frames (1) to inside of welded hitch brackets on Mainframe, insert Hitch Pin (12), flatwasher (11), lockwasher (14) and install nut (13). 2. Install lift straps (3) on intside of top rails on mainshield (behind gearbox mount)and attach with 1/2" x 1-1/2" bolts (10) and locknuts (9).
  • Page 21 ASSEMBLY HYDRAULIC RELIEF ASSEMBLY (P/N 3570) FIGURE 5 Hydraulic Relief Assembly (3570), also known as check chain, is available for attachment to front of cutter as an accessory. Check chains are used to control cut height and especially allows cutter to always be lowered to the same preset cut height.
  • Page 22: Rear Axle Assembly

    ASSEMBLY PULL TYPE REAR AXLE ASSEMBLY 2, 3, 15, 16 1. Insert lugs welded on rear axle (1) between Main Frame flats. Install bushings (15) in lugs on axle. Install bolts (2) with flatwashers (16) against bushings (15). Install locknuts (3). Figure 6 2.
  • Page 23: Front And Rear Deflectors And Chain Guards

    ASSEMBLY FRONT AND REAR DEFLECTORS AND CHAIN GUARDS Front & Rear Deflectors are standard equipment. The Front and Rear Chain Guards are Extra Equipment and are recommended to be used at all times to prevent injury caused by flying objects when mowing with persons or roadways in the area. The Front Chain Guard should be attached by using four 1/2"...
  • Page 24: Operation Section

    OPERATION The safe operation of this machine is the responsibility of the operator. The operator should be familiar with the cutter and tractor and all safety practices before starting operation. This cutter is designed primarily for weed and grass control in pastures and along highway right-of-ways. It is equipped with suction Blades. Recommended cutting speed for most conditions is from 2 to 5 mph.
  • Page 25: Tractor Preparation

    OPERATION TRACTOR PREPARATION - Lift Type Ballast An implement code of 7.85 has been assigned to the fully-equipped Lift-Type SE5 mower so that you can determine the tractor front ballast requirements. Refer to your tractor Operator's manual for the code number and ballasting requirements.
  • Page 26 OPERATION ATTACHING MOWER TO TRACTOR - PULL TYPE Block the mower wheels in place and use the Parking Jack to raise to the Tongue Clevis to the correct attaching height. Adjust the tractor drawbar to proper length to provide dimensions shown in figure 2 for proper Driveline attachment at 540 RPM PTO speed as indicated on the Mower.
  • Page 27: Parking Jack

    OPERATION FIGURE 4. Parking Jack PARKING JACK NOTE: Always place jack foot on firm surface or place board under jack for support. When removing parking jack from tongue, place on storage bracket on left side of main frame. Driveline Attachment to Tractor 1.
  • Page 28: Cutting Height Adjustment

    OPERATION CUTTING HEIGHT ADJUSTMENT WARNING Avoid personal injury! Be sure tractor engine is off, key is removed, and ALLOW BLADES TO STOP TURNING before dismounting to make adjustments. Important: Avoid very low cutting heights. Striking the ground with blades gives the most damaging shock loads a cutter can encounter and will cause damage to cutter and drive.
  • Page 29: Starting & Stopping

    OPERATION STARTING & STOPPING CUTTER Power for operating cutter is supplied from tractor PTO. Refer to your tractor manual instructions for engaging and disengaging the PTO. Always engage the PTO at low engine rpm. Always operate at recommended PTO speed of 540 RPM. Learn how to stop tractor and cutter quickly in case of an emergency.
  • Page 30: Detaching & Storing

    OPERATION DETACHING AND STORING Lower the Mower to the Gound. Park the Tractor with the transmission in the correct gear (Automatic Transmission--Park; Standard Transmission--Neutral). Set the parking brake, shut off the engine, and remove the key. Wait until the PTO stops rotating before getting down from the tractor. Disconnect the Driveline from the tractor PTO.
  • Page 31 OPERATION Pull Type With the PTO NOT TURNING, slowly drive the tractor with cutter attached through sharpest turn possible and watch shaft movement. With the PTO NOT TURNING, slowly drive the tractor with Cutter attached through the most severe terrain conditions expected and watch Shaft movement.
  • Page 32: Transporting

    OPERATION If you have a condition where your tractor will be going up a steep incline with your mower still on the flat area or coming down the opposite incline, you have a potential problem. Figure 10. The correct preventive measure is to instruct the operator to cross this kind of terrain at an angle.
  • Page 33: Offset Adapter

    OPERATION OFFSET ADAPTER (FIGURE 11) Fasten the Offset Adapter Tube to the three-Point Lift Lugs using the hitch Pin Holes. Fasten the Adjustable Leg to the right Lug to offset the Mower to the right. Fasten the Adjustable Leg to the left Lug to offset the Mower to the Left.
  • Page 34: Trouble Shooting Guide

    OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Excessive Vibration 1. Check Gearbox bolts. Tighten if loose. 2. Check for loose nuts on Tighten if loose. bladeholder and blades. 3. Check for bent output shaft. Replace shaft if bent. If shaft is bent, oil will normally leak from bottom seal.
  • Page 35 OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Not Cutting Clean 1. Blades dull. Sharpen or replace blades. 2. Carrier RPM too low. Use correct PTO speed and check for correct gearbox ratio. See specifications. 3. Cutter not level. See Cutting Height Adjustment.
  • Page 36 OPERATION TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Gearbox Noisy 1. Rough Gears. Run in or change gears. 2. Worn Bearings. Replace bearing. Gearbox Leaking 1. Damaged oil seal. Replace seal. 2. Bent Shaft. Replace oil seal and shaft. 3.
  • Page 37: Lubrication

    MAINTENANCE Before operating your Rotary Cutter, make sure it is properly lubricated and thoroughly inspected. Only a minimum of time and effort is required to regularly lubricate and maintain this machine to provide long life and trouble free operation. WARNING! Always disengage the PTO before raising the Rotary Cutter for transporting or making adjustments.
  • Page 38: Gearbox

    MAINTENANCE FILL CHECK FIGURE 2. Gearbox Lubrication GEARBOX The gearbox should be full (18 ounces).54 liters and not require additional lubricant unless the box is cracked or a seal is leaking. It is recommended that the 1/8" oil level plug (Figure 2) be removed after every 10 hours of operation.
  • Page 39: Driveline

    MAINTENANCE DRIVELINE LUBRICATION Grease Fittings are located on the Cross Assembly of each U-Joint and on the telescoping tubes. Grease the U-Joint after each 8 hours of use. Figure 3. Do not force grease through the Needle Cup Assemblies. Grease the telescoping tubes after every 8 hours use. To grease profile tube, disconnect drive from PTO and pull halves apart.
  • Page 40: Blade Servicing

    MAINTENANCE WARNING! When attaching PTO yoke to tractor PTO shaft, it is important that spring-activated locking collar slides freely and locking balls are seated in groove on PTO shaft. A loose shaft could slip off and result in personal injury or damage to cutter. BLADE SERVICING Inspect blades before each use to determine that they are properly installed and in good condition.
  • Page 41: Blade Carrier Removal

    MAINTENANCE BLADE REMOVAL To remove blades for sharpening or replacement, remove the cover plate on deck of cutter near gear box. Remove lock nut from blade bolt. NOTE: Inspect lock nut after removal and replace if threads are damaged. Always replace nut when replacing blade bolt. When installing blades be sure and check blade bolt pivot di- ameter for wear.
  • Page 42: Seasonal Clutch Maintenance

    MAINTENANCE There are two Friction Discs in the Slip Clutch. These should be checked weekly for oil or grease, wearing, and moisture which could cause corrosion on the Drive Plates. 1-5/16" STANDARD FRICTION DISC (TYP) SPRING BOLT WITH NUT FIGURE 6. Slip Clutch Maintenance SEASONAL CLUTCH MAINTENANCE It is important that the clutches slip when an obstacle or load heavier than the clutch setting is encountered.
  • Page 43: Storage

    MAINTENANCE STORAGE Your rotary cutter represents an investment from which you should get the greatest possible benefit. Therefore, when the season is over, the cutter should be thoroughly checked and prepared for storage so that a minimum amount of work will be required to put it back into operation for the next season. The following are suggested storage procedures: 1.
  • Page 44: Gearbox Service

    MAINTENANCE GEARBOX SERVICE INSTRUCTIONS GEARBOX DISASSEMBLY (Figure 8) 1. Remove 6 capscrews (Ref.#16) from input shaft bearing housing (Ref. #13). 2. Tap around circumference of bearing housing (Ref. #13) to loosen housing and shims. Then (Ref. #9) pull complete shaft and housing assembly (See Fig. 8) out of main housing. 3.
  • Page 45 MAINTENANCE INPUT SHAFT (Figure 9) DISASSEMBLY AND ASSEMBLY 1. Remove snap ring (Ref. #11) and then remove bearing housing (Ref. #13) by holding end of shaft which does not have a cross hole or splines and tap opposite end of shaft on solid surface. Shock force will remove housing from bearing (Ref.#4).
  • Page 46 MAINTENANCE DISASSEMBLY OUTPUT SHAFT (FIG 10) 1. Install slotted nut (Ref 18, Figure 8) onto shaft and then tap shaft end on solid surface to remove lower bearing and spacer. 2. remove snap ring (Ref #7) and then repeat above procedure to remove upper bearing. ASSEMBLY 1A.
  • Page 47 MAINTENANCE MAIN GEARBOX 1. Remove bearing (Ref. #8 Figure 8) from inside main housing. A special slide hammer puller (PROTO No. 4056) or equal may be required to remove bearing. Press in new bearing using driving tube or pipe with approximate same OD.
  • Page 48: Parts Ordering Guide

    PARTS ORDERING GUIDE The following instructions are offered to help eliminate needless delay and error in processing purchase orders for the equipment in this section. 1. The Parts Section is prepared in logical sequence and grouping of parts that belong to the basic machine featured in this manual.
  • Page 49: Parts Table Of Contents

    PARTS TABLE OF CONTENTS Tongue Assembly ......................6-4 Level Rod Assembly...................... 6-5 Dishpan Assembly ......................6-6 Axle Assembly ....................... 6-7 Gearbox Assembly ......................6-8 Deflectors ........................6-10 Chain Guard Assemblies ....................6-11 Driveline Pull Type ......................6-12 Slipclutch (00762242) ....................6-13 Driveline Lift Type Slip Clutch ..................
  • Page 50: Tongue Assembly

    TONGUE ASSEMBLY ITEM PART NO. DESCRIPTION 00766275 Tongue Weldment 7092 Jack 7A114916 Bolt 15B1400 Flatwasher 423013 Bushing 5JRC1490 Locknut 00764515 Chain AM5000/11-94 Parts Section 6-4 © 1994 Alamo Group Inc.
  • Page 51: Level Rod Assembly

    LEVEL ROD ASSEMBLY ITEM PART NO. DESCRIPTION 00761056 Level Rod Weldment 00760820 00761046 Trunion 00761267 Spacer 00761037 Adjuster Weldment 02931300 Bolt 511016 Bushing 00037200 15B1200 Flatwasher SAFETY SHIELD ASSEMBLY ITEM PART NO. DESCRIPTION 7541 Shield 7540 Bracket 00002700 Flatwasher 5F8130 Wingnut 00764259 Chain...
  • Page 52: Dishpan Assembly

    DISH PAN ASSEMBLY P/N00761358 ITEM PART NO. QTY. DESCRIPTION 00761357 Dish Pan Weldment 00761319 Suction Blade 00761402 Blade Bolt 00761535 Washer 00750226 Locknut AM5000/11-94 Parts Section 6-6 © 1994 Alamo Group Inc.
  • Page 53: Axle Assembly

    AXLE ASSEMBLY ITEM PART NO. DESCRIPTION 00761038 Axle Weldment 02931300 Bolt 511016 Bushing 00037200 00753013 Bolt 00001800 Locknut TLM 1/2 NC PLC 5JRC16140 00765337 Spacer 0891030300 Pin Weldment 00756760 Wheel & Tire Assy (Semi-Solid) 0891030200 Wheel & Tire Assy (Laminated) 00761034 Adjuster Support 00760820...
  • Page 54: Gearbox Assembly

    GEAR BOX ASSEMBLY 0711050100 AM5000/11-94 Parts Section 6-8 © 1994 Alamo Group Inc.
  • Page 55 GEAR BOX ASSEMBLY 0711050100 ITEM PART NO. DESCRIPTION 00563900 Main Housing 00764949 Front Housing 00757683 Bearing Retainer Cap 00564700 Shaft, Input 00564000 Shaft & Pinion Gear 00564600 Input Gear 00564800 Ball Bearing 00563700 Ball Bearing 00757682 Bearing Spacer 00564400 Shims 00760929 Gasket .25 00760928...
  • Page 56: Front Deflector

    DEFLECTORS FRONT DEFLECTOR Assembly P/N 00758340 ITEM PART NO. DESCRIPTION 00758253 Flap - Deflector 02035800 Washer 00011100 Flatwasher 00011400 Bolt 00015800 Locknut REAR DEFLECTOR Assembly P/N 00761558 ITEM PART NO. DESCRIPTION 00761629 Deflector (Center) 00761633 Bar (Center) 15B800 Washer 00750959 Hex Head Capscrew 00001800 Locknut TLM 1/2 NC PLC...
  • Page 57: Chain Guard Assemblies

    CHAIN GUARD ASSEMBLIES 2,4,7 FRONT CHAIN GUARD Assembly P/N 0891101000 ITEM PART NO. DESCRIPTION 0891101100 Chain Guard Weldment 00752680 Bolt 0901100102 Mounting Flat 00001800 Locknut TLM 1/2 NC PLC 0731371001 0731361104 Chain Links 15B800 Washers 4,5,6 REAR CHAIN GUARD Assembly P/N 00761557 ITEM PART NO.
  • Page 58 PULL TYPE DRIVELINE P/N 00761057 ITEM PART NO. DESCRIPTION 00761437 Yoke, Shear Pin 00761438 Cross Journal Set 00761439 Outer Tube Assembly 00761440 Inner Tube Assembly 00761441 Collar Kit 00761442 Complete Collar Yoke 00761443 Half Implement Shaft w/Shielding 00761444 Half Tractor Shaft w/Shielding 00761445 Half Implement Shield 00761446...
  • Page 59: Slipclutch (00762242)

    SLIPCLUTCH (LIFT) P/N 00762242 ITEM PART NO. DESCRIPTION 00762249 Bolt 00762250 Spring 00762247 Outer Flange 00762248 Friction Disc 00762243 Body - Friction Clutch 00762251 Spacer 00762244 Yoke Friction 00762252 Dirt Shield AM5000/11-94 Parts Section 6-13 © 1994 Alamo Group Inc.
  • Page 60 LIFT TYPE SLIP CLUTCH DRIVELINE P/N 00759318 ITEM PART NO. DESCRIPTION 00759177 Shield Half (Outer) 00759526 Standard Cone 00759527 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00762242 Slip Clutch Assembly 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube) 00759166...
  • Page 61 LIFT TYPE SHEAR BOLT DRIVELINE ITEM PART NO. DESCRIPTION 00759161A Driveline Assy 00761079A Complete Shield 00759920A Shield Half (Outer) 00762574 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00759162 Outer Yoke (Shear Bolt) 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube)
  • Page 62: Three-Point Hitch Assembly

    THREE-POINT HITCH ASSEMBLY 4,5,6 9,10,11,12 ITEM PART NO. DESCRIPTION 00764839 “A” Frame Leg 00767949 Bar Toplink 00765331 Lift Strap 00757953 Bushing Spacer 02025700 Bolt 00037200 Hex Locknut 00001800 Locknut TLM 1/2 NC PLC 00748823 Bolt 15B1400 Washer, Type “A” 00603500 Wrist Pin 00603600 Hex Nut...
  • Page 63 3-POINT OFFSET ADAPTER P/N 0702310000 ITEM PART NO. DESCRIPTION 0702310100 Adapter Mainframe 0702310001 Brace Bar 0702310300 Brace Lug and Chain 0702310200 Adjustable Lift Lug 511027 Wrist Pin 7A14924 Bolt 15B1400 Washer 423013 Bushing 5JRC1490 Locknut Retaing Pin 02030400 Bolt 00001300 Lockwasher 00001200 Hex Nut...
  • Page 64: Tailwheel Assembly

    TAILWHEEL ASSEMBLY 10,11 ITEM PART NO. DESCRIPTION 0891030100 Caster Fork Weldment 0891030300 Spindle Bolt Weldment 5JRC16140 Locknut 0891020100 Tailwheel Beam Weldment 00036900 Cotter Pin 15B2000 Type “A” Washer 10318000 Hex Hd. Capscrew 00001800 Locknut TLM 1/2 NC PLC 00750311 Hex Hd. Capscrew 00695100 Nut, Toplock 5/8 NC PLC 02961453...
  • Page 65: Hydraulic Relief Assembly P/N 3570

    HYDRAULIC RELIEF ASSEMBLY P/N 3570 ITEM PART NO. DESCRIPTION 8709 Chain Assembly 8708 Bracket 02845500 Bolt 00695100 Nut, Toplock 5/8 NC PLC AM5000/11-94 Parts Section 6-19 © 1994 Alamo Group Inc.
  • Page 66 PARTS TABLE OF CONTENTS Tongue Assembly ......................6-4 Level Rod Assembly ...................... 6-6 Dishpan Assembly ......................6-7 Discontinued - Dishpan Assembly .................. 6-8 Axle Assembly ....................... 6-9 Gearbox Assembly ......................6-10 Deflectors ........................6-12 Chain Guard Assemblies ....................6-13 Discontinued - Rear Deflector & Rear Chain Guard ............6-14 Driveline Pull Type......................
  • Page 67: Tongue Assembly

    TONGUE ASSEMBLY ITEM PART NO. DESCRIPTION 00766275 Tongue Weldment 7092 Jack 7A114916 Bolt 15B1400 Flatwasher 423013 Bushing 5JRC1490 Locknut 00764515 Chain AM5000/11-94 Parts Section 6-4 © 1994 Alamo Group Inc.
  • Page 68: Level Rod Assembly

    LEVEL ROD ASSEMBLY ITEM PART NO. DESCRIPTION 00761056 Level Rod Weldment 00760820 00761046 Trunion 00761267 Spacer 00761037 Adjuster Weldment 02931300 Bolt 511016 Bushing 00037200 15B1200 Flatwasher SAFETY SHIELD ASSEMBLY ITEM PART NO. DESCRIPTION 7541 Shield 7540 Bracket 00002700 Flatwasher 5F8130 Wingnut 00764259 Chain...
  • Page 69: Dishpan Assembly

    DISH PAN ASSEMBLY P/N00761358 ITEM PART NO. QTY. DESCRIPTION 00761357 Dish Pan Weldment 00761319 Suction Blade 00761402 Blade Bolt 00761535 Washer 00750226 Locknut AM5000/11-94 Parts Section 6-6 © 1994 Alamo Group Inc.
  • Page 70: Axle Assembly

    AXLE ASSEMBLY ITEM PART NO. DESCRIPTION 00761038 Axle Weldment 02931300 Bolt 511016 Bushing 00037200 00753013 Bolt 00001800 Locknut TLM 1/2 NC PLC 5JRC16140 00765337 Spacer 0891030300 Pin Weldment 00756760 Wheel & Tire Assy (Semi-Solid) 0891030200 Wheel & Tire Assy (Laminated) 00761034 Adjuster Support 00760820...
  • Page 71: Gearbox Assembly

    GEAR BOX ASSEMBLY 0711050100 AM5000/11-94 Parts Section 6-8 © 1994 Alamo Group Inc.
  • Page 72 GEAR BOX ASSEMBLY 0711050100 ITEM PART NO. DESCRIPTION 00563900 Main Housing 00764949 Front Housing 00757683 Bearing Retainer Cap 00564700 Shaft, Input 00564000 Shaft & Pinion Gear 00564600 Input Gear 00564800 Ball Bearing 00563700 Ball Bearing 00757682 Bearing Spacer 00564400 Shims 00760929 Gasket .25 00760928...
  • Page 73: Deflectors

    DEFLECTORS FRONT DEFLECTOR Assembly P/N 00758340 ITEM PART NO. DESCRIPTION 00758253 Flap - Deflector 02035800 Washer 00011100 Flatwasher 00011400 Bolt 00015800 Locknut REAR DEFLECTOR Assembly P/N 00761558 ITEM PART NO. DESCRIPTION 00761629 Deflector (Center) 00761633 Bar (Center) 15B800 Washer 00750959 Hex Head Capscrew 00001800 Locknut TLM 1/2 NC PLC...
  • Page 74: Chain Guard Assemblies

    CHAIN GUARD ASSEMBLIES 2,4,7 FRONT CHAIN GUARD Assembly P/N 0891101000 ITEM PART NO. DESCRIPTION 0891101100 Chain Guard Weldment 00752680 Bolt 0901100102 Mounting Flat 00001800 Locknut TLM 1/2 NC PLC 0731371001 0731361104 Chain Links 15B800 Washers REAR CHAIN GUARD 4,5,6 Assembly P/N 00761557 ITEM PART NO.
  • Page 75 PULL TYPE DRIVELINE P/N 00761057 ITEM PART NO. DESCRIPTION 00761437 Yoke, Shear Pin 00761438 Cross Journal Set 00761439 Outer Tube Assembly 00761440 Inner Tube Assembly 00761441 Collar Kit 00761442 Complete Collar Yoke 00761443 Half Implement Shaft w/Shielding 00761444 Half Tractor Shaft w/Shielding 00761445 Half Implement Shield 00761446...
  • Page 76: Slipclutch (00762242)

    SLIPCLUTCH (LIFT) P/N 00762242 PART NO. DESCRIPTION I T I T I T I T I TEM 00762249 Bolt 00762250 Spring 00762247 Outer Flange 00762248 Friction Disc 00762243 Body - Friction Clutch 00762251 Spacer 00762244 Yoke Friction 00762252 Dirt Shield AM5000/11-94 Parts Section 6-13 ©...
  • Page 77: Slip Clutch (8910)

    LIFT TYPE SLIP CLUTCH DRIVELINE P/N 00759318 ITEM PART NO. DESCRIPTION 00759177 Shield Half (Outer) 00759526 Standard Cone 00759527 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00762242 Slip Clutch Assembly 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube) 00759166...
  • Page 78 LIFT TYPE SHEAR BOLT DRIVELINE P/N 00759161A ITEM PART NO. DESCRIPTION 00759177A Shield Half (Outer) 00762574 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00759162 Outer Yoke (Shear Bolt) 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube) 00759166 Inner Tube...
  • Page 79 LIFT TYPE SHEAR BOLT DRIVELINE P/N 00759161A ITEM PART NO. DESCRIPTION 00759177A Shield Half (Outer) 00762574 Outer Tube Bearing 00756005 Driveline Shield Warning Label 00756231 Cross Assembly 00759162 Outer Yoke 00759517 Grease Fitting 00759164 Inner Tube Yoke 00759165 Roll Pin (Inner Tube) 00759166 Inner Tube 00759173A...
  • Page 80: Three-Point Hitch Assembly

    THREE-POINT HITCH ASSEMBLY 4,5,6 9,10,11,12 ITEM PART NO. DESCRIPTION 00764839 “A” Frame Leg 00767949 Bar Toplink 00765331 Lift Strap 00757953 Bushing Spacer 02025700 Bolt 00037200 Hex Locknut 00001800 Locknut TLM 1/2 NC PLC 00748823 Bolt 15B1400 Washer, Type “A” 00603500 Wrist Pin 00603600 Hex Nut...
  • Page 81 3-POINT OFFSET ADAPTER P/N 0702310000 ITEM PART NO. DESCRIPTION 0702310100 Adapter Mainframe 0702310001 Brace Bar 0702310300 Brace Lug and Chain 0702310200 Adjustable Lift Lug 511027 Wrist Pin 7A14924 Bolt 15B1400 Washer 423013 Bushing 5JRC1490 Locknut Retaing Pin 02030400 Bolt 00001300 Lockwasher 00001200 Hex Nut...
  • Page 82: Tailwheel Assembly

    TAILWHEEL ASSEMBLY 10,11 ITEM PART NO. DESCRIPTION 0891030100 Caster Fork Weldment 0891030300 Spindle Bolt Weldment 5JRC16140 Locknut 0891020100 Tailwheel Beam Weldment 00036900 Cotter Pin 15B2000 Type “A” Washer 10318000 Hex Hd. Capscrew 00001800 Locknut TLM 1/2 NC PLC 00750311 Hex Hd. Capscrew 00695100 Nut, Toplock 5/8 NC PLC 02961453...
  • Page 83 HYDRAULIC RELIEF ASSEMBLY P/N 3570 ITEM PART NO. DESCRIPTION 8709 Chain Assembly 8708 Bracket 02845500 Bolt 00695100 Nut, Toplock 5/8 NC PLC AM5000/11-94 Parts Section 6-20 © 1994 Alamo Group Inc.
  • Page 84 LIMITED WARRANTY 1. LIMITED WARRANTIES 1.01.Alamo warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship. 1.02.Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be defective under normal use and service due to defects in material or workmanship.
  • Page 85 In addition to the standard Limited Warranty, Alamo Group provides one year (12 months), (6 months for Commercial/Industrial Users) Limited Warranty on the Driveline components provided that these components have been properly main- tained and lubricated that and have not been subjected to abused or mis-use In addition to the standard Limited Warranty shown on the preceding page, Alamo Group provides A THREE YEAR LIMITED WARRANTY on GEARBOX components* provided that these components have been properly maintained and lubricated and have not been subjected to abuse or mis-use...
  • Page 86 P/N 00767094 AM5000 OMWPL PUB 11-94 Printed U.S.A.
