1. PRINT FIRMLY.
2. REMOVE WHITE COPY FOR CUSTOMER RECORDS.
ALAMO INDUSTRIAL WARRANTY REGISTRATION INFORMATION
A M
Alamo Model
Purchaser
Last Name
Street & No., RFD,
Box, &/or Apt. No.
City
Dealer
City
I have informed the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable, reviewed the
contents of the Operator's Manual including safety equipment, safe operation, and maintenance, reviewed the Safety Signs on
implement (and tractor if possible), and Purchaser's responsibility to train his operators in safe operation.
MOWERS: I have explained that Deflectors, Chain Guards, or Solid Skirts must be maintained in good repair and installed except
in areas where persons, vehicles, livestock, or other property will not be endangered by thrown objects and where such safety
equipment would prevent the mower's reasonable performance of its assigned task.
DRIVELINES: Make certain that all drivelines, gearbox, and other shields are in good repair and fastened securely in place to
prevent injuries from entanglement or thrown objects.
I have been instructed on the paragraphs above, received and have been instructed in the contents of the Operator's Manual including
safety signs, safety equipment, safe operation, maintenance, and the potential hazards of unauthorized alteration or modification of
the product. I have been informed of the warranty provisions and know that the warranty is not in effect until this form is received
by Alamo Group.
I understand the Mower Guarding statements above and the potential hazards of operating without such guards. I understand that the
operator is responsible for the safety of others in the area. I have examined the product and accept it as being complete and in
satisfactory condition with all required guards.
CUSTOMER COPY
PLEASE FILL OUT OWNER WARRANTY REGISTRATION INFORMATION
ABOVE, SIGN, AND DROP LAST COPY IN ANY MAILBOX.
TO PLACE THIS WARRANTY IN EFFECT,
THIS WARRANTY REGISTRATION MUST BE
FILLED OUT, SIGNED, AND MAILED WITHIN 30
DAYS OF DELIVERY DATE OF THIS MACHINE.
DEALER AND PURCHASER MUST SIGN.
ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL
WILL BE REFUSED UNTIL COMPLETED, SIGNED
WARRANTY REGISTRATION CARD IS ON FILE.
3. REMOVE YELLOW COPY FOR DEALERS RECORDS.
Serial No.
Dealer's Signature
Purchaser's Signature
IMPORTANT!
MONTH
Purchase Date
First Name
State or
Province
State or
Province
4. MAIL LAST CARD POSTAGE FREE.
DAY
YEAR
M.I.
ZIP
ZIP
Date
Date

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alamo Industrial AM7000

  • Page 1 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 2 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 3 THIS WARRANTY REGISTRATION MUST BE FILLED OUT, SIGNED, AND MAILED WITHIN 30 DAYS OF DELIVERY DATE OF THIS MACHINE. DEALER AND PURCHASER MUST SIGN. ATTENTION: ANY CLAIM SUBMITTED TO ALAMO INDUSTRIAL WILL BE REFUSED UNTIL COMPLETED, SIGNED WARRANTY REGISTRATION CARD IS ON FILE.
  • Page 4 PO BOX 549 Seguin, Texas 78156-9967 210-372-3551 Alamo Industrial provides a full line of field tested & proven lift-type, pull-type, boom-mounted, offset-mounted, & semi-mounted rotary, flail, & sickle bar mowers; tractor-mounted, three- section flail mowers; self-powered rotary & flail mowers; and shredders.
  • Page 5 AM7000 Rotary Mower Rev 03-13 P/N 00767100 Shown with Chain Guards (Optional Equipment) OPERATOR'S MANUAL with PARTS LISTING ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 830-372-9595 © Alamo Group Inc. 2013...
  • Page 6: Before You Start

    TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
  • Page 7: Table Of Contents

    Gearbox Service Instructions ....................... 5-6 Slip Clutch Service ..........................5-9 Storage ..............................5-10 Torque Chart ............................5-11 Maintenance Check List ........................5-12 PARTS SECTION ............................6-1 Parts Ordering Guide ........................... 6-2 Parts Table of Contents ........................6-3 AM7000/11-94 ©1994 Alamo Group Inc.
  • Page 8 Do not let the Blades turn when the Mower Deck is raised for turning. This exposes the Cutting WARNING! Blades which creates a potentially serious hazard and could cause serious injury or even death by objects thrown from the Blades. AM7000/11-94 Safety Section 1-2 © 1994 Alamo Group Inc.
  • Page 9 Do not mount or dismount the tractor while the tractor is mowing. Mount or dismount the tractor only when it is completely stopped. Never leave the mower in the raised transport position. Mower could fall causing injury to anyone DANGER! who might inadvertently be under mower. AM7000/11-94 Safety Section 1-3 © 1994 Alamo Group Inc.
  • Page 10 Do not turn sharp enough to get severe "knocking" or vibration in the Driveline which will cause ac- WARNING! celerated wear and breakage of drive train components which may cause injury from the seperated Driveline sections. AM7000/11-94 Safety Section 1-4 © 1994 Alamo Group Inc.
  • Page 11 Refer also to Safety Messages and operation instruction in each of the appropriate sections of the Tractor and Mower Manuals. Pay close attention to the Safety Signs affixed to the Tractor and Mower. AM7000/11-94 Safety Section 1-5 © 1994 Alamo Group Inc.
  • Page 12: Safety Section

    540 RPM Operation 00757139 LOGO ALAMO by TK (5.5 x 19.5) 02960766 LOGO ALAMO (4 x 5) 00767108 NAME AM7000 Name Decal SRL PLT Serial Plate * Furnished by the Tractor Manufacturer AM7000/11-94 Safety Section 1-6 © 1994 Alamo Group Inc.
  • Page 13 1- 00725746 11 - D103 7 - 00756494 4- 00756005 3- 00756004 8- 02925100 10 - 00763977 AM7000 14- 00767108 2- 00749117 - Not Shown 15- Serial Plate 13- 02960766 (See Inside Front Cover of Manual) AM7000/11-94 Safety Section 1-7...
  • Page 14 DECALS 5 - 00769736 6 - 00769737 12- 00757139 AM7000/11-94 Safety Section 1-8 © 1994 Alamo Group Inc.
  • Page 15: Introduction Section

    Mower with this Signal Word are Black and Yellow. WARNING Serious injury or possible death! Decals are Black and Orange. DANGER Imminent death/critical injury. Decals are Red and White. AM7000/11-94 Introduction Section 2-2 ©1994 Alamo Group Inc.
  • Page 16 INTRODUCTION Your ALAMO AM7000 mower is designed for light-duty cutting such as pasture mowing, weed, and grass control. With a reasonable amount of preventive maintenance, your Mower will provide years of dependable service. DANGER For Non-Agricultural use, OSHA, ASAE, SAE, and ANSI standards require the use of Chain Guards, Deflectors, or Solid Skirts at all times.
  • Page 17: Attention Owner/Operator

    AND MAY CAUSE PREMATURE OR CATASTROPHIC FAILURE WHICH COULD RESULT IN SERIOUS INJURY OR DEATH. IF YOU HAVE ANY QUESTIONS CONCERNING THE REPAIR PARTS YOU ARE USING, CONTACT ALAMO, P. O. BOX 549, SEGUIN, TX 78156. 02925100 AM7000/11-94 Introduction Section 2-4 ©1994 Alamo Group Inc.
  • Page 18: Dealer Set-Up Instructions

    Figure 2. Tighten the locknuts (2) alternately until they have reached the proper torque. Refer to Torque Chart. GEARBOX SLIPCLUTCH FIGURE 2. Driveline Slip Clutch Attachment AM7000/11-94 Assembly Section 3-2 ©1994 Alamo Group Inc.
  • Page 19: A-Frame

    Install 5/8 x 1-1/4 capscrew (#23) into rear hole in toggle and retain with lockwasher and nut. NOTE: Capscrew when installed must be on top of rear braces. Attach upper hitch pin (#24 & #25) to A-frame flats (#10 & #11). FIGURE 3. A-Frame Attachment AM7000/11-94 Assembly Section 3-3 ©1994 Alamo Group Inc.
  • Page 20: Hydraulic Relief

    FIGURE 4. Hydraulic Relief Assemlby 1. Check Chain 2. Chain Lug 3. Bolt 4. Nut 5. Lockwasher 6. Hitch Bracket 7. Tractor top Link 8. 1" capscrew x req’d. length 9. Tractor Top Link Mtg. AM7000/11-94 Assembly Section 3-4 ©1994 Alamo Group Inc.
  • Page 21 (#6) with holes in legs of clevis (#11) and insert 5/8 x 4-1/2 capscrew (#12). Retain using lockwasher (#13) and hex nut (#14). 5. Asembly should now be complete. Tighten all capscrews per torques given in Proper Torque for Fasteners Chart. FIGURE 5. Gauage Wheel Mainframe Assemlby AM7000/11-94 Assembly Section 3-5 ©1994 Alamo Group Inc.
  • Page 22 SKID SHOES (For bolting to regular skid shoes) Installation Instruction: Use Skid Shoe (#4) as template. Drill 7/16" diameter holes. Attach with bolt, lockwasher, and nut (#1,2, & 3). FIGURE 8 Figure 8. AM7000/11-94 Assembly Section 3-6 ©1994 Alamo Group Inc.
  • Page 23: Operation Section

    A loose shaft could slip off and result in personal injury or damage to cutter. When attaching PTO yoke to tractor PTO shaft, it is important that spring activated locking collar slides freely and locking balls are seated in groove on PTO shaft. AM7000/11-94 Operation Section 4-2 ©1994 Alamo Group Inc.
  • Page 24: Driveline Length Check Procedure

    Round off all sharp edges and remove burrs. Grease sliding profiles. Figure 2. 1-9/16" FIGURE 2. Driveline length adjustment. WARNING! Driveline profile engagement must always exceed 12" at any operating position. AM7000/11-94 Operation Section 4-3 ©1994 Alamo Group Inc.
  • Page 25: Cutting Height Adjustment

    Avoid personal injury. When attempting to stop a tractor which does not have live PTO, the momentum created by the blade carrier of a rotary cutter can cause the tractor to be pushed forward. DO NOT operate this cutter unless tractor has live or independent PTO. AM7000/11-94 Operation Section 4-4 ©1994 Alamo Group Inc.
  • Page 26: Cutting Speed

    Remember, sharp blades produce cleaner cuts and use less power. Before cutting, analyze the area to determine the best cutting procedure. consider the height and type of material and the terrain type: hilly, level or rough. AM7000/11-94 Operation Section 4-5 ©1994 Alamo Group Inc.
  • Page 27: Detaching & Storing

    CAUTION! Be sure that the tractor Lift Lever is locked into the “transport” detent before attempting to transport the Mower. Make certain that atleast 20% of tractor weight is on front tires. AM7000/11-94 Operation Section 4-6 ©1994 Alamo Group Inc.
  • Page 28: Trouble Shooting Guide

    1. Low on lubricant. Fill to level plug. 2. Improper type lubricant. Replace with proper lubricant. 3. Excessive trash build-up Remove trash. around gearbox. 4. Bearing or gears set up Consult your Dealer. improperly. AM7000/11-94 Operation Section 4-7 ©1994 Alamo Group Inc.
  • Page 29 Instructions. Blade Bolts Loosen 1. Bolts not tightened. Tighten bolts to 350 ft.lbs. 2. Bolt hole elongated or Replace Bushing or oversized. Blade Carrier. 3. Locknut worn out. Replace Locknut. AM7000/11-94 Operation Section 4-8 ©1994 Alamo Group Inc.
  • Page 30 5. Clutch linings badly Repair clutch per worn or plates warped. maintenance section of manual. Blade Wears Too Fast 1. Cutting in sandy conditions. Increase cutting height. 2. Cutting in rocky conditions. Increase cutting height. AM7000/11-94 Operation Section 4-9 ©1994 Alamo Group Inc.
  • Page 31: Maintenance Section

    Gear box-1/2 full (NLGI 000EP) Check Daily Tail Wheel Pivot Arm 8 hours Driveline slip sleeve 8 hours Tail Wheel Hub 8 hours Pivot Points (SAE 30 WT). 8 hours FIGURE 1. Lubrication Locations. AM7000/11-94 Maintenance Section 5-2 ©1994 Alamo Group Inc.
  • Page 32: Gearbox

    Tailwheel Beam at Caster Pivot Point. Figure 4. Grease after every 10 hours use to provide maximum trouble free service. FIGURE 3. Tailwheel Hub Lubrication FIGURE 4. Tailwheel Beam Lubrication. AM7000/11-94 Maintenance Section 5-3 ©1994 Alamo Group Inc.
  • Page 33: Universal Joints

    Figure 5. Always sharpen blades by grinding. DO NOT heat and pound out edge. Do not sharpen blade to a razor edge, but leave a 1/16" blunt edge. Do not sharpen back side of blade. FOLLOW ORIGINAL PATTERN 1/16" MAINTAIN CORNER FIGURE 5 Blade Sharpening AM7000/11-94 Maintenance Section 5-4 ©1994 Alamo Group Inc.
  • Page 34: Blade Removal

    IMPORTANT: Always recheck gear box output shaft slotted blade carrier retaining nut torque after a few hours operation. WARNING! Avoid personal injury. Do not work under cutter without support blocks to keep frame from falling. AM7000/11-94 Maintenance Section 5-5 ©1994 Alamo Group Inc.
  • Page 35: Gearbox Service Instructions

    5. The gearbox is now disassembled into five (5) sub-assemblies: 1. Input shaft assembly 2. Output shaft assembly 3. Lower bearing retainer assembly 4. Main housing assembly 5. Input shaft bearing housing AM7000/11-94 Maintenance Section 5-6 ©1994 Alamo Group Inc.
  • Page 36 INPUT SHAFT BEARING HOUSING 1. Remove seal (#19) and bearing cup (#13). Press new cup and seal back in place. (See SEAL INSTALLATION RECOMMENDATIONS). 2. Press oil seal flush with front side of bearing housing. AM7000/11-94 Maintenance Section 5-7 ©1994 Alamo Group Inc.
  • Page 37 Permatex and reinstall and torque capscrews. 4. Remove 1/2" pipe plug (#20) and fill gearbox with proper lubricant. 5. Install pipe plug and gearbox assembly is complete. INDICATOR CHECK POINT FIGURE 7 AM7000/11-94 Maintenance Section 5-8 ©1994 Alamo Group Inc.
  • Page 38: Slip Clutch Service

    There are four Friction Discs in the Slip Clutch. These should be checked weekly for oil or grease, wearing, and moisture which could cause corrosion on the Drive Plates. 1-5/16" STANDARD FRICTION DISC (TYP) CLUTCH PLATE SPRING BOLT WITH NUT FIGURE 8. Slip Clutch Maintenance AM7000/11-94 Maintenance Section 5-9 ©1994 Alamo Group Inc.
  • Page 39: Seasonal Clutch Maintenance

    5. Store the cutter in a clean, dry place with the cutter housing resting on blocks. 6. Use spray touch-up enamel where necessary to prevent rust and maintain the appearance of the cutter. MAKE EVERY DAY A HOLIDAY FROM ACCIDENTS AM7000/11-94 Maintenance Section 5-10 ©1994 Alamo Group Inc.
  • Page 40: Proper Torque For Fasteners

    425 (576) 160 (217) 445 (603) 685 (929) 250 (339) 670 (908) 1030 (1396) 1-1/8 330 (447) 910 (1234) 1460 (1979) 1-1/4 480 (651) 1250 (1695) 2060 (2793) FIGURE 9. Torque Chart AM7000/11-94 Maintenance Section 5-11 ©1994 Alamo Group Inc.
  • Page 41: Pre-Delivery Check List

    During inspection, check that all nuts and bolts are secure and clevis pins are properly cotter pinned. Check condition of blades and security of attachment. DANGER! Install chain guards if operating with persons or livestock in the area or close to highways or buildings. AM7000/11-94 Maintenance Section 5-12 ©1994 Alamo Group Inc.
  • Page 42: Parts Section

    The use of inferior replacement parts may cause premature or catastrophic failure which could result in serious injury or death. Direct any questions regarding parts to: Alamo P.O. Drawer 549 Seguin, Texas 78156 830-372-3080 AM7000/11-94 Parts Section 6-2 © 1994 Alamo Group Inc.
  • Page 43 Gearbox Assembly ............................6-8 Blade Carrier Assembly ..........................6-9 Guage Wheel Mainframe Assembly ......................6-10 Skid Shoe Assembly ............................ 6-12 Deflector Assemblies ........................... 6-13 Chain Guard Assemblies ..........................6-14 Hydraulic Relief Asembly ..........................6-15 AM7000/11-94 Parts Section 6-3 © 1994 Alamo Group Inc.
  • Page 44: A-Frame Assembly

    Hitch Ear Bushing 2062H Hitch Pin - Cat II 9216 Washer 8119 Top Link Bushing 8659 Top Link 00009500 Bolt 00752658 Bolt 00037200 Locknut 8663 Top Link Bushing 7518 Rear Brace 02845500 Bolt AM7000/11-94 Parts Section 6-4 © 1994 Alamo Group Inc.
  • Page 45: Shield Assembly

    SHIELD ASSEMBLY ITEM PART NO. DESCRIPTION 7541 Shield 7540 Hood Bracket 00002700 Washer 00001200 00011100 Flatwasher 00764259 Chain 4405 Cotter Pin AM7000/11-94 Parts Section 6-5 © 1994 Alamo Group Inc.
  • Page 46 Locking Collar for Outer Tube 00754331 Locking Collar for Inner Tube 00754330 Bolt - Nylon , Safety Shield 00761217 Complete Shield (Both Halves) 00761215 Outer Shield Half 00761216 Inner Shield Half 00761075 Centering Spring AM7000/11-94 Parts Section 6-6 © 1994 Alamo Group Inc.
  • Page 47 00754203 Pressure Plate 00754201 Inner Plate 00754202 Clutch Lining 00754300 Clutch Body 00752903 Bolt and Nut Set 00754314 Plate with Holes 00754301 Spacer 00754302 Yoke 00754303 Clutch Spring 00754304 Dirt Shield AM7000/11-94 Parts Section 6-7 © 1994 Alamo Group Inc.
  • Page 48: Gearbox Assembly

    00748520 Gasket 0.3 00748520 Gasket 0.15 00748520 Gasket 0.1 00752155 Output Cap 00753743 Lockwasher 00748823 Capscrew 00753634 Seal 00753631 Pipe Plug (Not Shown) 00759053 Spacer AR - As Required AM7000/11-94 R 5-8-95 Parts Section 6-8 © 1994 Alamo Group Inc.
  • Page 49: Blade Carrier Assembly

    8251 Blade Bolt Service Kit 5JRC16140 Locknut 9216 Washer 00758579 Blade Washer 6192 Washer - Hub 00606100 Slotted Nut 00606000 Cotter Key 8264 Blade Bolt Kit (Includes items #3 & #4) AM7000/11-94 Parts Section 6-9 © 1994 Alamo Group Inc.
  • Page 50 GAUGE WHEEL MAINFRAME ASSEMBLY 13,20 AM7000/11-94 Parts Section 6-10 © 1994 Alamo Group Inc.
  • Page 51 Tire & Wheel Assy. 00766361 Spacer - Wheel Hub 00762747 Gauge Wheel Fork 0013600 Seal 00013701 Bearing 0291030300 Spindle Bolt Weldment 5JRC16140 Locknut 00756750 Tire & Wheel 4 x 8 w/cups AM7000/11-94 Parts Section 6-11 © 1994 Alamo Group Inc.
  • Page 52: Skid Shoe Assembly

    SKID SHOE ASSEMBLY ITEM PART NO. DESCRIPTION 8312 Skid Shoes 8277 Plow Bolt 03101646 Lockwasher 00013901 00011100 Flatwasher AM7000/11-94 Parts Section 6-12 © 1994 Alamo Group Inc.
  • Page 53: Deflector Assemblies

    00011100 Flat Washer 00023100 Bolt 00015800 Locknut ITEM PART NO. DESCRIPTION 00758574 Rear Deflector 00758576 Rear Deflector Bar 00011100 Flatwasher 7196 Bolt 00015800 Locknut 00758575 Side Deflector 00758577 Side Deflector Bar AM7000/11-94 Parts Section 6-13 © 1994 Alamo Group Inc.
  • Page 54: Chain Guard Assemblies

    PART NO. DESCRIPTION 00999314 Bolt 02957941 Locknut 2467 Chain Rod Center 2545 Cotter Key 1417 Chain 4499 Chain Rod 7532 Rear Left Bracket 7531 Rear Right Bracket 7530 Rear Center Bracket AM7000/11-94 Parts Section 6-14 © 1994 Alamo Group Inc.
  • Page 55: Hydraulic Relief Asembly

    HYDRAULIC RELIEF ASSEMBLY ITEM PART NO. DESCRIPTION 8710 Carrier Chain Adj. Strap 8711 Chain Assembly 02845500 Bolt 00010400 00010300 Lockwasher AM7000/11-94 Parts Section 6-15 © 1994 Alamo Group Inc.
  • Page 56 LIMITED WARRANTY 1. LIMITED WARRANTIES 1.01.Alamo warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship. 1.02.Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be defective under normal use and service due to defects in material or workmanship.
  • Page 57 In addition to the standard Limited Warranty, Alamo Group provides one year (12 months), (6 months for Commercial/Industrial Users) Limited Warranty on the Driveline components provided that these components have been properly main- tained and lubricated that and have not been subjected to abused or mis-use In addition to the standard Limited Warranty shown on the preceding page, Alamo Group provides A THREE YEAR LIMITED WARRANTY on GEARBOX components* provided that these components have been properly maintained and lubricated and have not been subjected to abuse or mis-use...
  • Page 58 AM7000 OMWPL PUB 11-94 P/N 00767110 Printed U.S.A.
