CAUTION
Insert the barrel type connector end of the AC power cord into the external power supply connector.
1.
2.
Insert the female end of the power cord into the internal power supply connector.
3.
Verify that the AC power cord included with your router is compatible with local standards. If it is not, con-
tact Patton to replace it with a compatible power cord.
4.
Connect the male end of the power cord to an appropriate power outlet.
5.
Wait until the Power LED stops blinking and remains constantly lit. Now the SmartNode is ready
to configure.
2.0 Configuring your SmartNode
Refer to the following manuals (available online at www.patton.com/manuals) for detailed information
about installing, configuring, operating, and troubleshooting the SmartNode:
SmartNode Model 4970 Series User Manual:
•
SmartNode Model 4980/4990 Series User Manual:
•
SmartNode 4970/4980/4990 Series Quick Start Guide
Electrostatic Discharge (ESD) can damage equipment and impair electrical
circuitry. It occurs when electronic printed circuit cards are improperly
handled and can result in complete or intermittent failures. Do the follow-
ing to prevent ESD:
• Always follow ESD prevention procedures when removing and replac-
ing cards.
• Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the chassis
frame to safely channel unwanted ESD voltages to ground.
• To properly guard against ESD damage and shocks, the wrist strap
and cord must operate effectively. If no wrist strap is available,
ground yourself by touching the metal part of the chassis.
1.0 Power up the SmartNode
www.patton.com/manuals/SN4970.pdf
www.patton.com/manuals/SN4980-90.pdf
