SPEEDZONE
PR0 CYCLOCOMPUTER
Congratulations on your purchase! You are now the owner of the world's most
advanced cyclocomputer. Your Specialized SpeedZone® Pro is the first cycling
computer to feature wireless digital transmitters for both speed and cadence
sensing. Additionally, it incorporates a revolutionary new display screen that
allows you to view five functions simultaneously. The SpeedZone® Pro has been
designed to provide the best combination of performance, features, durability
and ease of use.
TOP Button
3
(Backlight/Start/Stop)
Average Speed Needle
12
(Flashing)
9
Speed Indication Bezel
6
Digital Display Area
Wheel Option Indicator
7
2
SET Button
Current Speed Needle
10
4
Analog Clock
11
Maximum Speed Needle
5
Dot-Matrix Display Area
Km/h
8
MPH or KM/H Indicator
MODE Button
1
1
Advertisement
Related Manuals for Specialized Speedzone Sport CR2032
Summary of Contents for Specialized Speedzone Sport CR2032
- Page 1 PR0 CYCLOCOMPUTER Congratulations on your purchase! You are now the owner of the world’s most advanced cyclocomputer. Your Specialized SpeedZone® Pro is the first cycling computer to feature wireless digital transmitters for both speed and cadence sensing. Additionally, it incorporates a revolutionary new display screen that allows you to view five functions simultaneously.
-
Page 2: Battery Installation And Replacement
Use a coin to unthread the battery cap from the computer. Install the battery (model CR2032, Specialized P/N 481-3004) with the positive pole (+) facing upward. Carefully thread the battery cap back onto the case with a... - Page 3 Install the battery WHEEL (speed transmitter) icon or a (model CR2032, CRANK (cadence transmitter) icon. It Specialized P/N 481- is very important that you mount them 3004) with the positive pole in the correct locations on your bicy- (+) facing upward. (See cle.
- Page 4 Your SpeedZone Pro comes pre-con- screw. The clearance between the figured with a strap to fit standard (Specialized P/N 4812-3100) from your Specialized dealer. To install the 31.8mm diameter strap onto your SpeedZone Pro, remove the two Philips head screws from the bottom...
-
Page 5: Important Installation Note
FIGURE 7. FIGURE 8. SECURING HARDWARE FASTEN MAGNET TO CRANK ARM until the "wheel option" indicator process that must be done only when flashes while spinning the wheel. you first install your SpeedZone® Pro and any time you replace the battery IMPORTANT INSTALLATION NOTE: in the transmitter. -
Page 6: Operation And Programming
vided screw. For the best signal OPERATION AND PROGRAMMING reception, adjust angle of the trans- mitter so that it is vertical (See figure When your SpeedZone® Pro has not 7). It is not necessary, or desirable to detected any speed input for 30 min- aim the transmitter at the computer. - Page 7 lines the mode/side-mode sequence. "MODE" button to scroll through the Once a particular mode has been languages. When the selected lan- entered, its values can be reset or guage is displayed (default language adjusted by pressing and holding the is English), press the "SET" button "SET "...
- Page 8 Odometer Mode by pressing "MODE" mileage. (See figure 10) Easy Calibration Mode Your SpeedZone® Pro has been pre- Stem programmed with the following 14 Specialized tire sizes: 26 X 1.0 Wheel 26 X 1.25 Circumference 26 X 1.5 FIGURE 12. ROLL OUT ILLUSTRATION.
- Page 9 PROGRAMMING SCREEN computer. (See figure 12). You may also use the following quick- reference chart: Generic Tire Size Chart This chart is for non-Specialized tires 26 X 1.75 26 X 2.0 26 X 2.1 Km/h FIGURE 14. CLOCK MODE...
- Page 10 three seconds. The display will now to program the wheel #2 tire size and show the currently selected tire size tap the "SET" button to exit circumfer- for wheel option #1. (See figure 13). ence programming mode. If necessary scroll through the prepro- grammed tire sizes by tapping both 5.
- Page 11 Pro will record the lap time. After the TIMER has been stopped (by pressing the "TOP" button) the previous twelve lap times can be reviewed by press- ing "SET" button. Additionally, the computer will display the total time when LPTOT is shown. 7.
- Page 12 hour and in meters when speed is screen. To set the Distance measure in kilometers per hour. Countdown, hold the "SET" button for three seconds. The hour digit will 10. Altitude ClimbedMaximum begin flashing. Press the "MODE" The Altitude Climbed function on your Button until the desired number SpeedZone®...
- Page 13 to 99.9 M/h (99.9 Km/h) with a reso- lution of 0.1 M/h (0.1 Km/h) Auto Start/Stop Timer (ATM)- In ATM mode the timer function records the actual time spent riding. It operates only when there is speed input and is displayed In the Digital Display Area of the screen Km/h FIGURE 17.
- Page 14 Km/h FIGURE 19. TRIP DISTANCE SCREEN FIGURE 20. ODOMETER SCREEN Trip Distance (DST)- Odometer (ODO)- Trip distance mode will record up to The odometer will record the total dis- 999.99 miles or kilometers and then tance traveled up to 99,999 miles or roll to zero.
-
Page 15: Troubleshooting
(An accessory handle- Display is blank: bar mount is available from your Change the battery or press the AC Specialized dealer. P/N 4812-4020) button on the bottom of the case Backlight- Display shows partial digits: The backlight feature of your Press the AC button on the bottom of SpeedZone®... - Page 16 Specialized® SpeedZone® Pro cyclocom- available from your Specialized deal- puter that the product is free from defects er or by visiting the Specialized of material and workmanship under nor- S-store at WWW.SPECIALIZED.COM mal use and service for a period of two (2) years from the date of the original purchase.
- Page 17 TIONS OR USE CONTRARY TO THAT workmanship under normal use or serv- INTENDED BY THE MANUFACTURER. ice, Specialized Bicycle Components Inc. EXCEPT TO THE EXTENT PROHIBITED BY will, at its sole option, repair or replace APPLICABLE LAW, ANY IMPLIED WAR- the product without charge;...
