Page 2
INSTALLATION • Remove the components from the side of the handlebar intended for the installation of the display mount. • Fig. 1: Install the display mount and rotate into position A . • Tighten until the mount does not slip easily B . Do not overtighten.
Page 3
BATTERY REPLACEMENT • Fig 2: Use a very small flat head screwdriver to lift up the edge of the battery cap, then gently lift the battery out of the cap. • Fig 3: Replace the display unit battery with a new CR 2032 coin cell battery, place the new battery into the cap with the text facing inside the cap E .
Page 4
1. DISPLAY FEATURES Data Field 1 Speed units Battery indicator Clock Speed comparator Data Field 2 Mode (Data Field 2) Left Button Right Button...
Page 5
2. MAIN SCREENS Low battery Sleep Mode Clear data Show odometer H Battery icon turns on (coin cell battery low). J Clear function data (hold left button for 2 seconds). K Show odometer data (hold right button for 2 seconds). I No Signal or key for 30 min.
Page 6
• Fig 3: The sensor uses a 23A battery G . To access the battery, rotate the cap using a coin or flat head screwdriver. 3. LEGEND Change mode / value Press left button quickly Change mode / value Press right button quickly Reset function data Press left button for two (2) seconds Show odometer...
Page 7
4. SPEED SENSOR INSTALLATION L Adjust the magnet position so the magnet is aligned with the line on the bottom of the edge of the sensor. Position with 1/32 - 1/8 in (1-3mm) of separation. DO NOT overtighten the magnet. M The sensor should be mounted with the battery door cap toward the ground, with no more than 24”...
Page 10
5. DEFAULT PAGE SETTINGS/NAVIGATION • There are 4 preset pages, each of which displays a different combination of information. • The pages can be navigated using the left / right buttons. N To clear the Distance, Average speed, Timer and Max speed data, press the left button for two (2) seconds.
Page 12
6. SYSTEM SETUP TIME 12/24 MINUTE DIAMETER TIRE SIZE HOUR UNITS...
Page 13
REGULATORY STATEMENTS RoHS: Specialized Bicycle Components, Inc. certifies that this product and its packaging are in compliance with European Union Directive 2011/65/EU on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronics Equipment, commonly known as RoHS.
Page 14
6. SYSTEM SETUP (custom tire size) • When selecting the custom (CUST) W option from the wheel diameter options, Data Field 2 will flash. Enter the tire circumference size in millimeters. To scroll quickly, press and hold the left button to scroll down or the right button to scroll up.
Page 15
15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229 0000133769_UM_R4, 09/19 We may occasionally issue updates and addendums to this document. Please periodically check www.specialized.com or contact Rider Care to make sure you have the latest information. Info: ridercare@specialized.com / 877-808-8154...
