  • Page 1 9000 quickstart Guide 800.788.5572 DuraLabel.com...

  • Page 2: Minimum System Requirements

    Operating System: Windows XP SP2 or later, Vista, Windows 7, Windows 8 or 8.1 Memory: 128MB RAM Hard Drive: 100MB Additional Requirements: IT Administrator Privileges Graphic Products , DuraLabel , PathFinder , Toro and Lobo are Registered Trademarks of Graphic Products, Inc.

  • Page 3: Table Of Contents

    Using a USB Cable Using a Parallel Cable 5. Configuring Printer Drivers Continuous Vinyl Printing Instructions Die-cut Label Printing Instructions B Mark Label Printing Instructions 6. Installing Labeling Software DuraSuite Labeling Software LabelForge Labeling Software Contents | DuraLabel.com | 800.788.5572...

  • Page 4: Introduction

    It’s designed to get you printing as quickly as possible. Call us at 800.788.5572 if you have any questions about your new DuraLabel 9000 Printer. We’re here to help! | 1.

  • Page 5: Equipment Checklist

    2. Equipment Checklist The following items are included in your DuraLabel 9000 package: □ DuraLabel 9000 Printer □ DuraLabel 9000 Installation CD: Printer driver, DuraSuite software, LabelForge software, symbols, label templates, and technical manuals. □ DuraLabel 9000 QuickStart Guide □...

  • Page 6: Loading The Printer

    3. Loading the Printer DuraLabel ribbon and vinyl supplies have been optimized for compatibility and print quality. Only authorized DuraLabel supplies from Graphic Products will print correctly with the DuraLabel 9000 Printer. Loading Vinyl Supply IMPORtAnt! Always turn the power OFF when loading supplies. Always wait at least 5 seconds before turning power back ON.
  • Page 7 Pull the vinyl supply over the black platen roller and through the printed label opening. Supply Print Head Guides Mechanism Adjustable Media Guides Platen Roller Supply Bar Printed Label Opening Media Guide FIGURE 5 3.1 Loading Vinyl Supply | DuraLabel.com | 800.788.5572...

  • Page 8: Loading Ribbon

    FIGURE 1 Guides for 4.33" ribbon FIGURE 2 Guides for 8.66" ribbon Slide an empty supply core onto the front ribbon rewind spindle, flush against the ribbon guide. | 3.2 Loading Ribbon DuraLabel.com | 800.788.5572...
  • Page 9 Hold the green Print Head Release Lever back while pushing down on the print head. Press firmly until the print head locks into position. Close the printer cover. Turn the printer ON. Print Head Mechanism Print Head Release Lever FIGURE 5 3.2 Loading Ribbon | DuraLabel.com | 800.788.5572...

  • Page 10: Connecting The Printer

    4. Connecting the Printer Connect the power supply. Connect the DuraLabel 9000 to your PC using a USB or parallel cable. Turn on the DuraLabel 9000. If using a USB cable, follow instructions in Section 4.2, Using a USB Cable.

  • Page 11: Using A Usb Cable

    You may need IT administrator privileges to perform this installation. If Found new Hardware announcement appears, select no, not at this time. Insert the DuraLabel 9000 Installation CD in your computer’s disk drive. A DuraLabel 9000 startup screen appears. nOtE: If the CD does not run automatically, go to Start >...

  • Page 12: Using A Parallel Cable

    Skip this step if using a USB cable. IMPORtAnt! You may need IT administrator privileges to perform this installation. Insert the DuraLabel 9000 Installation CD in your computer’s disk drive. A DuraLabel 9000 startup screen appears. nOtE: If the CD does not run automatically, go to Start > Computer and double-click on the DL icon.

  • Page 13: Configuring Printer Drivers

    Your DuraLabel 9000 printer drivers are preset to several print values. Please be aware that changing a preset value is not fully supported by all software programs. For best results, make changes to preset values from the Devices and Printers window.

  • Page 14: Die-Cut Label Printing Instructions

    The printer will begin to feed supply as it calibrates. To change driver settings, follow directions in Section 4.2.2, Driver Settings, in the DuraLabel 9000 User Guide. B Mark Label Printing Instructions Label supply must be calibrated to print B Mark labels. Using the menu on the left side of the front of your printer: Press the Menu button.

  • Page 15: Installing Labeling Software

    NFPA Diamond, RTK, GHS and custom labels, quickly and easily. To install, from the DuraLabel 9000 startup screen, click on DuraSuite Label Software and follow the directions that appear. Refer to the DuraSuite Labeling Software User Guide for additional information.
