  • Page 1 ’s m a n u a l NVR-5304POE...

  • Page 2: Important Safeguards And Warnings

    NVR-5304POE User’s manual ver.1.1 IMPORTANT SAFEGUARDS AND WARNINGS EMC (2004/108/EC) and LVD (2006/95/EC ) Directives CE Marking Our products are manufactured to comply with requirements of following directives and national regulations implementing the directives:  Electromagnetic compatibility EMC 2004/108/EC. ...
  • Page 3 11. You cannot allow any metal objects get inside the recorder. It might cause serious damage. If a metal object gets inside the device contact the authorised Novus service immediately. 12. The manufacturer does not bear responsibility for damage or loss of data stored on HDDs or other media occurred during the usage of the product.

  • Page 4: Table Of Contents

    NVR-5304POE User’s manual ver.1.1 TABLE OF CONTENTS TABLE OF CONTEST ..................... 4 1. FOREWORD INFORMATION ................6 1.1. Network recorder’s technical data ..............6 1.2. Main characteristic ..................7 1.3. Package contents ..................... 7 2. STARTING THE DEVICE .................. 8 2.1.
  • Page 5 NVR-5304POE User’s manual ver.1.1 TABLE OF CONTENTS 5.3. Network ......................34 5.3.1. Network setting ................34 5.3.2. DDNS setting ................. 35 5.3.3. NTP setting ..................36 5.3.4. E-mail setting ................. 37 5.3.5. Management platform ..............37 5.4. Alarm ......................38 5.4.1.

  • Page 6: Foreword Information

    NVR-5304POE User’s manual ver.1.1 FOREWORD INFORMATION 1. FOREWORD INFORMATION 1.1. Network recorder’s technical data NVR-5304POE VIDEO / AUDIO Network Camera up to 4 channel in resolution 1920x1080(video + audio) Camera/Protocol suport NOVUS, ONVIF, RTSP Main (split screen, full screen, sequence):...

  • Page 7: Main Characteristic

    Company is not responsible for incompatibility problems resulting from cameras of other brands than NOVUS, which are using ONVIF protocol. If you are using ONVIF protocol cameras other than NOVUS brand it is recommended to test for each time whether required functions work correctly.

  • Page 8: Starting The Device

    WARNING! In order to find information regarding the compatible models of HDDs and their maximum capacities, please contact Novus distributor or check the information presented at www.novuscctv.com. AAT HOLDING Company is not responsible for any problems resulting from using not recommended hard drives.
  • Page 9 NVR-5304POE User’s manual ver.1.1 STARTING THE DEVICE In order to mount HDD, please unscrew two screws on the NVR back side as depicted below and remove top cover Move cable tapes to the top, insert HDD under the cable and place HDD in dedicated place.

  • Page 10: Power Connection

    NVR-5304POE User’s manual ver.1.1 STARTING THE DEVICE Install the top cover on the NVR and screw it back. 2.3. Connecting power adapter. Please connect provided DC 48V adaptor in the rear power port of the NVR like depicted below. POWER SWITCH 48 V DC ADAPTER To start the unit turn on the power switch on back panel.

  • Page 11: Connecting Monitor

    NVR-5304POE User’s manual ver.1.1 STARTING THE DEVICE 2.4. Connecting monitor This product supports following interfaces for main monitor: HDMI, VGA. For HDMI and VGA outputs following resolutions are supported: 800x600, 1024x768, 1280x1024, 1366x768, 1440x900, 1920x1080 After changing resolution you have to confirm it by clicking YES. In case of monitor does not display anything please wait 8 seconds, then previous resolution will be restored.

  • Page 12: Peripheral Device Connection

    NVR-5304POE User’s manual ver.1.1 NVR OPERATING 2.6. Peripheral device connection  Connecting audio ports Audio output signal normally are above 200mV 1kΩ. You can connect the low impedance earphone, or power amplifier with the external speakers.  Connecting USB devices NVR has 2 x USB 2.0 ports for external Flash memory, mouse connection and other USB compatible...

  • Page 13: System Operation

    NVR-5304POE User’s manual ver.1.1 NVR OPERATING 3.3. System operations To start NVR plug power cable and switch on power button. The power led turns on. After booting, the video output default to multi-window output mode. By default NVR is using English language interface.
  • Page 14 NVR-5304POE User’s manual ver.1.1 NVR OPERATING  Save changes by clicking OK button  New confirmation window will appear, choose YES to confirm Now NVR will start again with new language. To manipulate or access menus of the NVR, you should log in again. Move cursor to the top or click...

  • Page 15: Startup Configuration

    NVR-5304POE User’s manual ver.1.1 NVR OPERATING 3.4. Startup configuration Prior to using NVR for the first time, initial setup is strongly advised. Before you connect the IP cameras to the NVR, please set up network and stream parameters of IP cameras in the right way.
  • Page 16 NVR-5304POE User’s manual ver.1.1 NVR OPERATING Optionally if you are going to connect NVR to the Internet (for remote access, sending email, etc) set up  DEFAULT GATEWAY,  FIRST and SECOND DNS. You can alternatively check DHCP mode (DHCP server is required in this method in target network) then all settings will be set up automatically.
  • Page 17 NVR-5304POE User’s manual ver.1.1 NVR OPERATING VI. Press SEARCH button to display all cameras present in network. After some time list of cameras appears. ADD ALL CHANNEL SEARCH BUTTON LIST BUTTON SEARCH RESULT WINDOW CHANNEL SETTING WINDOW To add required camera to the system TICK it on the list. Selected camera will be added to first empty channel.
  • Page 18 NVR-5304POE User’s manual ver.1.1 NVR OPERATING VII. Next you have to fill user name and password for each camera that you add to the NVR. Please double click at CHANNEL LIST “A” or select required channel from the CHANNEL dropdown menu ”B”. Next check if all settings for this channel are correct, fill username and password “C”...

  • Page 19: Nvr Menu

    4. NVR MENU 4.1. Live monitoring Novus network video recorders features a multilingual OSD menu allowing for adjusting the settings of the device. Available languages are: English, Polish, and others As soon as the NVR completes its initialization process, it will enter the real-time monitoring image.
  • Page 20 NVR-5304POE User’s manual ver.1.1 NVR MENU Click the right key of mouse to bring the MAIN MENU bar All rights reserved © AAT Holding sp. z o.o.

  • Page 21: Searching And Playing Recorded Video

    NVR-5304POE User’s manual ver.1.1 NVR MENU 4.2. Searching and playing recorded video To start the PLAYBACK MENU click icon. Then following window appears: VIDEO PLAYBACK WINDOW CHANNEL SELECTION SEARCH BUTTON PLAYBACK GRAPH WITH BUTTONS RECORDING CALLENDAR 1. From the CHANNEL SELECT tick the channel which you want to search the recording, it will auto search the recording .

  • Page 22: Backup

    NVR-5304POE User’s manual ver.1.1 NVR MENU Description of playback buttons:  Pause/Play: pause the current playback image.  Stop: Stop the playing video.  Slow: Slow down the playback speed. (there are: 1/2, 1/4, 1/8, 1/16 times)  Fast: Accelerate playback. (there are: 2, 4, 8, 16 times) ...

  • Page 23: Ptz

    NVR-5304POE User’s manual ver.1.1 NVR MENU 4.4. PTZ PTZ button opens new window which allows to control the operations of a selected PTZ camera. To start the PTZ click icon. Then following window will shown Use it to adjust the pan, tilt, zoom and focus of the camera. You can also run and set Preset etc.

  • Page 24: Capture

    NVR-5304POE User’s manual ver.1.1 NVR MENU 4.6. Capture If you would like to save some single image from camera click icon at the preview channel can capture the channel image. Image file will be stored at hard disk. Note: Capture works only with cameras supporting this functions.

  • Page 25: Nvr Configuration

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5. NVR CONFIGURATION Setting menu allow to configure various NVRs parameters. 5.1. Device menu allows to check NVR information and configure the settings of date/time, system management, and peripheral device. 5.1.1. Device Info - check and modify the basic information of the NVR Following function are available: ...

  • Page 26: Device Version

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Protocol - enable / disable various IP cameras protocols.  Device Time - set up current time and date, confirm by MODIFY button.  Time and date format - allows to select different time and date formats 5.1.2.

  • Page 27: Dst Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.1.4. DST setting -user can specify the DST (Daylight Saving Time) settings. To ensure proper operation, set FROM time as last Sunday of March, 1:00 AM UTC. Clocks are moved forward at time defined in DST Bias. Set the TO time as last Sunday of October, 1:00 UTC.

  • Page 28: Video Parameters

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Time and date format - allows to select different time / date formats and enable visibility of it remotely in camera, associated to the selected channel.  OSD Position: menu allows to select any position for the OSD remotely in associated camera.

  • Page 29: Schedule Recording

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.2.3. Schedule Recording - setting of different types of record plan for each channel. After selecting CHANNEL following parameters are available:  Enable Recording: Tick the checkbox will start recording.  All Day Recording: For using one type of recording tick the checkbox and select one of following: schedule, motion, alarm, motion or alarm, motion and alarm.

  • Page 30: Motion

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.2.4. Motion - menu allows to configure the built-in camera motion detection function. After selecting CHANNEL following parameters are available:  Enable Motion Detection: Tick the checkbox will enable detection functionality.  Area settings: select the motion detection area, press the left mouse button and drag to the area which you want to set motion detection, click OK.

  • Page 31: Video Lost

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Linkage: select the reaction way for current which you need. Available reaction are: Audio warning (NVR internals buzzer), Email, Specified alarm output activation, Alarm on monitor and Alarm List, Trigger recording. By using COPY TO button you can copy current settings to other required channel.

  • Page 32: Tampering Alarm

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.2.6. Tampering alarm - menu allows to configure the built-in camera tampering detection function. After selecting CHANNEL following parameters are available:  Enable Video Tampering: Tick the checkbox will enable detection functionality.  Area settings: select the detection area, press the left mouse button and drag to the area which you want to set, click OK to confirm.

  • Page 33: Video Mask

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.2.7. Video Mask - menu allows to define masking zone on selected video channels. After selecting CHANNEL following parameters are available:  Enable Video Mask: Tick the checkbox will enable detection functionality.  Area settings: select the masking area, press the left mouse button and drag to the area which you want to set, click OK to confirm.

  • Page 34: Network

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.3. Network - menu allow to configure network parameters of the device including email, DDNS and NTP setting . 5.3.1. Network setting - configuration of basic network parameters of the device. Following parameters are available: ...

  • Page 35: Ddns Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Advance: additional menu contains:  Enable PPPOE: you can enable the PPPOE service: Input the PPPOE user name, password dynamic address of the device  Enable UPnP feature: will enable UPnP discovery function Note: Correct settings of IP address and subnet mask are necessary for proper operation of an IP camera.

  • Page 36: Ntp Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Server Name and Port: values are set automatically after selecting Server Type  User Name: requires entering the user’s name registered in the DDNS database.  Password requires entering the DDNS-registered password. ...

  • Page 37: E-Mail Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.3.4. Email setting - menu responsible for Email account configuration  Email Address: input the sender email address.  Password: input the sender email password.  PWD Confirm: confirm the password.  SSL: tick to enable SSL authorization.

  • Page 38: Alarm

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.4. Alarm - menu allow to define various events, and specify the conditions to notify the user. 5.4.1. Alarm input - configuration of the alarm sensor and specify the operation of the sensor if an event occurs.

  • Page 39: Alarm Output

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Linkage: select the reaction way for current which you need. Available reaction are: Audio warning (NVR internals buzzer), Email, Specified alarm output activation, Alarm on monitor and Alarm List, Trigger recording, PTZ Linkage.

  • Page 40: Exception

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Delay: set the time reaction of it.  Arm Schedule: set the time intervals when alarm is active. For detailed description of Arm Schedule please check Alarm input chapter. Note: Not every camera model and network protocol allow to change all camera settings remotely.

  • Page 41: Account

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.5. Account - menu allows to configure the settings regarding user management, as well as user and group permissions 5.5.1. Account Setting - You can add a user accounts and set up various permissions of them.
  • Page 42 NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION To set up a user privilege:  Select user on a list and click USER PRIVILEGE button.  In new window please choose required access values for local and remote operation.  When done, click OK.

  • Page 43: User Online

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.5.2. User online - menu display information about local / remote user which are currently logged in. All rights reserved © AAT Holding sp. z o.o.

  • Page 44: System

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.6. System - menu allows to configure the HDD, system management, and peripheral device. 5.6.1. Device Log - You can search the logs according to different types and different date and time, as shown in the above picture.

  • Page 45: Hdd Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.6.3. HDD Setting - menu allow to format the HDD and view the HDD capacity, the free space and status etc Format - format the hard disk. Note that formatting the HDD will delete all video data and logs.

  • Page 46: Auto Reboot

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  Click UPGRADE  The progress bar displays the progress of the firmware upgrade process.  When the upgrade is complete press OK reboot the system. Caution: Please contact your local distributor prior to software upgrade.

  • Page 47: Recovery Configuration

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.6.6. Recovery configuration - menu responsible for saving and restoring default NVR settings  Export Configuration: Save NVR settings to a storage device, connected to the USB port.  Import Configuration: Load settings from a storage device connected to the USB port to the ...

  • Page 48: Record

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.7. Record - menu allows to quick change of recording behaviour. From the MAIN MENU click icon and set following parameters: Close - disable any recording at each of selected channel. Manual - enable continuous manual recording at each of selected channel.
  • Page 49 NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION TV adjust - calibration of output video size and location. Display - settings of brightest, contrast, saturation and other monitor values. Resolution - select the resolution most corresponding to the used monitor. Enable SEQ - tick will enable camera image sequence.

  • Page 50: Image Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.9. Image Setting - Menu allow to adjust image parameters for selected channel From the MAIN MENU click icon and set parameters for selected camera image. Available parameters are brightest, contrast, saturation and hue.

  • Page 51: Ip Channel Setting

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.10. IP channel Setting 5.10.1. Manual - menu allow to add and manage IP cameras connection. Note: For suggested values for IP camera setting please refer to the “Cameras Capability Table - appendix A" which is an integral part of this manual. If you will set wrong values some problems may appear: the NVR cannot search the IP camera, the stream cannot be connected, the image is not fluent, the image quality is bad and so on.
  • Page 52 NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  SEARCH PANEL - use it for search and add cameras to the NVR. Press SEARCH button to find all cameras present in network. After some time cameras list will appear. CHANNEL SEARCH ADD ALL...
  • Page 53 NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION  CHANNEL SETTING WINDOW - allow to set up network connection parameters. To modify network connections setting please double click at CHANNEL LIST “A” or select required channel from the CHANNEL dropdown menu ”B”.

  • Page 54: Synchronization Time

    NVR-5304POE User’s manual ver.1.1 NVR CONFIGURATION 5.10.2. Synchronization time - Menu allows to manage remote camera time synchronisation to the local NVR time. Following options are available:  Automatic synchronisation - cameras time will be adjusted each time when necessary.

  • Page 55: Network Operations Utilizing Web Broswer

    NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER 6. NETWORK OPERATIONS UTILIZING WEB BROSWER Network Video Recorder features the possibility of controlling video data using network connections and web browser (Internet Explorer is recommended). 6.1. Recommended PC specification for web browser connections Requirements below apply to connection with an NVR, assuming smooth image display 4 channel in 1920x1080 resolution and 25 fps speed.
  • Page 56 NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER  Click the given link and press Run button. If security warning window will be displayed press Run button. Web browser will download the applet for displaying images from the camera.

  • Page 57: Configuration Of Remote Access

    NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER You can also add the camera’s IP address to “trusted zone” and set lowest security level for it. In addition, when working in Windows Vista/7 the ActiveX applet may be blocked by Windows Defender or User account control.

  • Page 58: Live Monitoring Interface

    NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER 6.4. Live monitoring interface After successful logging into a user interface using IE web browser, the following window opens: MENU BAR VIDEO WINDOW MAIN MENU Whole interface is very similar to interface displayed on NVRs monitor.
  • Page 59 NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER Click the right key of mouse to bring the MAIN MENU bar * Feature available in the future All rights reserved © AAT Holding sp. z o.o.

  • Page 60: Searching And Playing Recorded Video

    NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER Searching and playing recorded video 6.5. To start the PLAYBACK MENU click icon. Then following window appears: VIDEO PLAYBACK WINDOW CHANNEL SELECTION SEARCH BUTTON PLAYBACK GRAPH WITH BUTTONS RECORDING CALLENDAR 1. From the CHANNEL SELECT tick the channel which you want to search the recording, it will auto search the recording .

  • Page 61: Backup

    NVR-5304POE User’s manual ver.1.1 NETWORK OPERATIONS UTILIZING WEB BROSWER Description of playback buttons:  Pause/Play: pause the current playback image.  Stop: Stop the playing video.  Slow: Slow down the playback speed. (there are: 1/2, 1/4, 1/8, 1/16 times) ...
  • Page 62 2014-08-07 MB AN AAT Holding sp. z o.o., 431 Pulawska St., 02-801 Warsaw, Poland tel.: +4822 546 07 00, fax: +4822 546 07 59 www.novuscctv.com...
