SPECTRACOOL™

Air Conditioner

n17 Model
INSTRUCTION MANUAL
© 2015 Pentair Equipment Protection
89117329
Rev. G
P/N 89117329

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N17 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pentair N17

Summary of Contents for Pentair N17

  • Page 1: Air Conditioner

    SPECTRACOOL™ Air Conditioner n17 Model INSTRUCTION MANUAL © 2015 Pentair Equipment Protection 89117329 Rev. G P/N 89117329...

  • Page 2: Table Of Contents

    Refrigerant Loss ...................................... 21 TROUBLE SHOOTING .................................22 Basic Air Conditioning Trouble Shooting Check List ..........................22 Symptoms and Possible Causes: ................................23 WARRANTY ....................................26 RETURN AND REPAIR POLICY ................................26 LIMITATION OF LIABILITY..................................27 © 2015 Pentair Equipment Protection 89117329 - 2 -...

  • Page 3: Receiving The Air Conditioner

    Damage evident upon receipt should be noted on the freight bill. Damage should be brought to the attention of the delivering carrier -- NOT to Pentair Equipment Protection -- within 15 days of delivery. Save the carton and packing material and request an inspection. Then file a claim with the delivering carrier.

  • Page 4: Installation Instructions

    24 VAC terminal strip by noting the locations on the correct wiring diagram. 7. Set thermostat for required cabinet temperature. Refer to Sequence of Operation on page 6 for thermostat adjustment and operation. DIMENSIONAL DRAWINGS DESIGN DATA 115/230 AND 460 VOLT © 2015 Pentair Equipment Protection 89117329 - 4 -...
  • Page 5 89089862 Surface Mount Figure 1 Cutout Drawing © 2015 Pentair Equipment Protection 89117329 - 5 -...

  • Page 6: Technical Information

    The unit will remain electrified when the door switch is operated with the evaporator fan continuing to operate, and potentially, if temperatures are low enough, the heater may continue to operate on outdoor models. © 2015 Pentair Equipment Protection 89117329 - 6 -...

  • Page 7: Refrigerant Properties Chart (R134A)

    29.4 -23.3 32.2 -20.6 113.3 -17.8 37.8 40.6 -12.2 43.3 146.7 -9.4 46.1 157.5 -6.7 18.5 48.9 -3.9 51.7 -1.1 54.4 197.5 57.2 213.3 62.8 246.7 45.5 65.6 263.8 12.8 51.5 © 2015 Pentair Equipment Protection 89117329 - 7 -...

  • Page 8: 1000 Btu/Hr. Unit Characteristics

    4.0 / 4.4 2.7 / 2.7 1.4 / 1.4 Compressor RLA/LRA 2.3 / 18.5 1.6 / 13.2 1.6 / 13.2 Evaporator Fan RLA .30/.28 .15/.15 .15/.15 Condenser Fan RLA .30/.28 .15/.15 .15/.15 © 2015 Pentair Equipment Protection 89117329 - 8 -...

  • Page 9: 2000 Btu/Hr. Unit Characteristics

    7.2 / 7.1 3.1 / 3.1 1.6 / 1.6 Compressor RLA/LRA 4.9 / 27.5 2.5 / 13 2.5 / 13 Evaporator Fan RLA .30/.28 .15/.15 .15/.15 Condenser Fan RLA .30/.28 .15/.15 .15/.15 © 2015 Pentair Equipment Protection 89117329 - 9 -...

  • Page 10: Functional Data

    80-100 0.9-1.2 13-27 11-22 65-80 4.3-5.6 11-26 9-20 N170216GXXX 80-100 4.4-5.8 14-31 11-25 65-80 2.1-2.6 15-27 8-20 N170226GXXX 80-100 2.2-2.9 15-33 5-20 65-80 1.1-1.3 15-27 8-20 N170246GXXX 80-100 1.1-1.5 15-33 5-20 © 2015 Pentair Equipment Protection 89117329 - 10 -...

  • Page 11: Wire Diagrams And Schematics

    WIRE DIAGRAMS AND SCHEMATICS 1000 BTU/HR. 115V/230V GENERIC WIRE DIAGRAM (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 11 -...

  • Page 12: 1000 Btu/Hr. 115V/230V Generic Wire Diagram (Actual Unit Options May Vary)

    1000 BTU/HR. 115V/230V GENERIC WIRE DIAGRAM (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 12 -...

  • Page 13: 2000 Btu/Hr. 115V/230V Generic Wire Diagram (Actual Unit Options May Vary)

    2000 BTU/HR. 115V/230V GENERIC WIRE DIAGRAM (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 13 -...

  • Page 14: 2000 Btu/Hr. 115V/230V Generic Schematic (Actual Unit Options May Vary)

    2000 BTU/HR. 115V/230V GENERIC SCHEMATIC (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 14 -...

  • Page 15: 1000 Btu/Hr. 460V Generic Wire Diagram (Actual Unit Options May Vary)

    1000 BTU/HR. 460V GENERIC WIRE DIAGRAM (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 15 -...

  • Page 16: 1000 Btu/Hr. 460V Generic Schematic (Actual Unit Options May Vary)

    1000 BTU/HR. 460V GENERIC SCHEMATIC (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 16 -...

  • Page 17: 2000 Btu/Hr. 460V Generic Wire Diagram (Actual Unit Options May Vary)

    2000 BTU/HR. 460V GENERIC WIRE DIAGRAM (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 17 -...

  • Page 18: 2000 Btu/Hr. 460V Generic Schematic (Actual Unit Options May Vary)

    2000 BTU/HR. 460V GENERIC SCHEMATIC (ACTUAL UNIT OPTIONS MAY VARY) © 2015 Pentair Equipment Protection 89117329 - 18 -...

  • Page 19: Service Data

    Fan, Condenser 12101201SP 12101202SP 12101202SP Fan, Evaporator 12101201SP 12101202SP 12101202SP Relay, Compressor Start 89111992SP 89111995SP 89111995SP Overload, Compressor 89111994SP 89111997SP 89111997SP Thermostat, SPDT, 55100F 10106116SP 10106116SP 10106116SP Transformer, Input Power 101006111SP © 2015 Pentair Equipment Protection 89117329 - 19 -...

  • Page 20: Maintenance

    1. Flush the filter with warm water from the exhaust side to the intake side. DO NOT USE CAUSTICS. 2. After flushing, allow filter to drain. Placing it with a corner down will assure complete drainage. © 2015 Pentair Equipment Protection 89117329...

  • Page 21: Condenser And Evaporator Air Movers

    CAUTION Operation of the air conditioner in areas containing airborne caustics or chemicals can rapidly deteriorate filters, condenser coils, blowers and motors, etc. Contact Pentair Equipment Protection for special recommendations. REFRIGERANT LOSS Each air conditioner is thoroughly tested prior to leaving the factory to insure against refrigeration leaks. Shipping damage or microscopic leaks not found with sensitive electronic refrigerant leak detection equipment during manufacture may require repair or recharging of the system.

  • Page 22: Trouble Shooting

    (replace front cover for safety). This will activate the switch in the thermostat. Turn the power on and if all fans and the compressor come on, the thermostat needs to be replaced. © 2015 Pentair Equipment Protection 89117329 - 22 -...

  • Page 23: Symptoms And Possible Causes

    Short in system Drain plugged Drain tube kinked Getting water in enclosure Enclosure not sealed (allowing humidity in) Mounting gasket damaged For additional technical support, contact Pentair Equipment Protection at 800-896-2665. © 2015 Pentair Equipment Protection 89117329 - 23 -...
  • Page 24 NOTES © 2015 Pentair Equipment Protection 89117329 - 24 -...
  • Page 25 NOTES © 2015 Pentair Equipment Protection 89117329 - 25 -...

  • Page 26: Warranty

    Pentair Equipment Protection approval. Pentair Equipment Protection must be notified of a claim in writing not later than fourteen (14) days from the date when Buyer has become aware of such occurrence, or where the defect is such that it may cause damage, immediately, such notice containing a description of how the defect manifests itself.

  • Page 27: Limitation Of Liability

    B. All returns to Pentair Equipment Protection must be securely packed, using original cartons if possible. All returns must have the RMA number visible on the outside of the carton. Pentair Equipment Protection is not responsible for material damaged in transit. Any refrigerant-bearing Goods must be shipped upright for return.
  • Page 28 Pentair Equipment Protection 2100 Ho man Way Minneapolis, MN 55303 USA +1.763.422.2211 +1.763.576.3200 PentairProtect.com © 2015 Pentair Equipment Protection 89117329 Rev. G P/N 89117329...
