ONSIP
OINT03D
Rev.1.2 (April, 2012)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OINT03D and is the answer not in the manual?

Questions and answers

Related Manuals for Speco OINT03D

Summary of Contents for Speco OINT03D

  • Page 1 ’ ’ ONSIP OINT03D Rev.1.2 (April, 2012)
  • Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing OINT03D. Especially keep the device out of reach from children. Do not disassemble OINT03D. No After Service is assumed when disassembled. Use only the power adapter provided with OINT03D.
  • Page 3 ’ ’ Caution Any changes or modifications to this device could void the warranty. Revision History Date Revision Details 2011-11-01 First manual revision creation. 2012-04-20 Rev.1.2 (April, 2012)

  • Page 4: Table Of Contents

    Contents Contents..................4 1. Introduction ................6 1.1. Overview ....................6 1.2. Specification ....................7 1.3. Applications of OINT03D ................9 2. Product Description ..............10 2.1. Contents ....................10 2.2. Product Preview ..................11 2.3. Physical description .................. 12 2.4.
  • Page 5 6-5. Exposure Setting .................. 36 6-6. White Balance (White Bal) Setting ............38 6-7. WDR Setting ..................39 6-8. Backlight Setting .................. 40 6-9. SPECO DNR Setting ................42 6-10. Day/Night Setting ................43 6-11. Special Setting ................... 45 6-12. RETURN Setting ................. 50...

  • Page 6: Introduction

    PC or smart device. Real time 2-way communication is available through bidirectional audio communication feature. Designed to be a stand-alone streaming audio & video transmission device, OINT03D can be applied to various application area such as video security, remote video monitoring, distance education, video conference or internet broadcasting system.

  • Page 7: Specification

    Arbitrary shape with independent sensitivity Upgrade Firmware upgrade over IP network Administration Remote administration over IP network Web Viewer Simple viewing over internet explorer Client & Viewer Speco-NVR Standard CMS software Dynamic IP support DDNS support Supported Security Video/Audio stream encryption Rev.1.2 (April, 2012)
  • Page 8 ’ ’ ID and Password protection IP filtering for restricting administrative access for audio and bi-audio Sync to PC Synchronize to PC Time management Manual Manual time setting Internet Time Server Synchronize to Time Server Active-X SDK support HTTP Source filter Rev.1.2 (April, 2012)

  • Page 9: Applications Of Oint03D

    ’ ’ 1.3. Applications of OINT03D  Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.)  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting  Weather and environmental observation...

  • Page 10: Product Description

    2. Product Description 2.1. Contents The product package contains followings: Contents Description Remarks OINT03D IP camera OINT03D main unit Power Adaptor 12VDC Adaptor (option) Tools and Mounting Screws Screws, L-type wrench Software & User’s Guide Quick Reference Guide Quick installation guide...

  • Page 11: Product Preview

    ’ ’ 2.2. Product Preview CMS Software OINT03D IP-Installer (NVR) PC software to view and record the A/V streaming data transmitted Weather proof PC software to allocate an IP from IP camera. Bullet IP Camera address to the IP Camera...

  • Page 12: Physical Description

    ’ ’ 2.3. Physical description 2.3.1. External View Figure 2-1. External view of OINT03D 2.3.2. Connector information Power Sensor-In Audio-In Audio-Out Figure 2-2. Connector information Rev.1.2 (April, 2012)
  • Page 13 ’ ’ OSD control Focus control Factory default Figure 2-3. Factory Default switch and Video output connector Rev.1.2 (April, 2012)

  • Page 14: Functional Description

     100Base-T 100Mbps Ethernet connector (RJ-45)  Alarm In/Out and Audio In Used for connecting alarm sensor, microphone and speaker to OINT03D. Description LINE OUT (+) 1 V p-p audio signal output for amplified speaker. MIC/LINE GND (-) Ground for audio signals.
  • Page 15 ’ ’ Photo Coupler NO/NCType Open CollectorType Sensor1+ Sensor Sensor Device Device Sensor1- +12V Sensor Sensor Power Power Supply Supply Figure 2-4. SENSOR input and connection of the sensor  Factory Default Switch A switch provided for returning the IP camera to factory default state. Open the dome cover to access the switch.

  • Page 16: Accessories For Installation

    ’ ’ 2.5. Accessories for installation Figure 2-6. Accessories for installation of OINT03D. Rev.1.2 (April, 2012)

  • Page 17: On Site Installation

    ’ ’ 3. On Site Installation Use Cables and conduits that are suitable for the installation and that are compliant to IP-67. Particular attention should be paid in the installation so that no moisture is allowed to penetrate into the unit through the cables or conduits during the life time of the product.

  • Page 18: Getting Started

    Brief information for first time operation of OINT03D is provided in this chapter. 4.1. PC Requirement Audio/Video streaming data received from OINT03D can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below:...

  • Page 19: Quick Installation Guide

    4.2. Quick Installation Guide 1. Connect PC and OINT03D to network. 1) Prepare a PC to run programs for the installation and video connection (PC is needed to assign IP address to OINT03D) Connect OINT03D as shown in dotted line in Figure 4-1. The DC power is applied through DC adaptor.
  • Page 20 ’ ’ 2. Install Speco-NVR Speco-NVR is a multi-channel CMS program for to IP camera or Video server. Install Speco-NVR on remote PC to connect to these products. It is needed to assign connection information to Speco-NVR program before connection.
  • Page 21 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits from the drop down list in ⑤. You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥ is deactivated.
  • Page 22 3. Remote video connection to OINT03D 1) Connection through Web Viewer Web Viewer offers simplest way of video connection to OINT03D. For video connection, enter the IP address of OINT03D in the URL window of Internet Explorer as: Can be omitted the default [e.g.] Port 80...
  • Page 23 SAVE button. You can see the live video when you click the live view button as below. When you exit Speco-NVR, you have to input the ID/PW, admin/1234. Details for the Speco-NVR can be found in [Speco-NVR User’s Guide].
  • Page 24 ’ ’ 4. Additional settings through connection to the Admin Page All the parameters of new IP camera fallows factory default values. For more sophisticated target application it is needed to change parameters. The admin page can be connected through ”http://IP_address:HTTP_port_number”/admin.htm It is needed to enter ID and password of the administrator.

  • Page 25: Trouble Shooting

    ’ ’ 5. Trouble Shooting 5.1. No power is applied  In case of DC adaptor If PoE is not applied, the power and network connection should be made through separate cables. It is recommended to use DC adaptor supplied by provider for the feeding of the power. In case of replacing the DC power supply, make sure that the power supply meets with the power requirement of the IP camera to prevent damage or malfunction.

  • Page 26: Cannot Connect To The Video

    ’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC: Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”...

  • Page 27: Windows Vista Or Windows 7

    5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in Speco-NVR and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
  • Page 28 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.2 (April, 2012)
  • Page 29 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.2 (April, 2012)

  • Page 30: Technical Assistance

    ’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.

  • Page 31: Appendix - Osd Menu Control

    ’ ’ 6. Appendix - OSD menu control To control OSD menu, there are two methods. First is Video setup page in Administration Tool using Internet Browser as below. Rev.1.2 (April, 2012)
  • Page 32 ’ ’ Scond is OSD menu controller on camera as below. Rev.1.2 (April, 2012)

  • Page 33: Osd

    ’ ’ 6-1. OSD All camera functions are menu driven for easy use. 6-2. Preset Mode 1. Preset : INDOOR / OUTDOOR / LOW LIGHT / HALLWAY / LOBBY / ELEVATOR. - Used for a quick and easy setup for the installation environment. 6-3.
  • Page 34 ’ ’ 4. To finish the setting, select 'RETURN' and press the Function Setup switch. ☞ NOTE ■ An item with the ◀ icon also has sub menus. To select a sub menu, select an item with the icon and press the Function Setup switch.

  • Page 35: Lens Setting

    ’ ’ 6-4. Lens Setting Using this function, you can control the screen brightness. 1. When the SETUP menu screen is displayed, select 'LENS' by using the Function Setup switch so that the arrow indicates 'LENS'. 2. DC: You can adjust the minimum shutter and maximum value of ESC shutter mode. ☞...

  • Page 36: Exposure Setting

    ’ ’ 6-5. Exposure Setting 1. When the SETUP menu screen is displayed, select 'EXPOSURE' by using the Function Setup Switch. 2. Select a desired mode using the Function Setup switch. ◆ SHUTTER : You can select either auto or manual shutter. * --- : Shutter speed is fixed at 1/60sec(1/50sec) * ESC : Select this to control the shutter speed automatically.
  • Page 37 ’ ’ * LOW : Allows automatic gain control from 5.3dB to 32dB. * HIGH : Allows automatic gain control from 5.3dB to 37dB. ◆ INTENSIFY : When it is night or dark, the camera automatically detects then light level and maintains a clear picture if this mode is activated.

  • Page 38: White Balance (White Bal) Setting

    ’ ’ 6-6. White Balance (White Bal) Setting Use the White Balance function to adjust the screen color. 1. When the SETUP menu screen is displayed, select 'White Bal' by using the function Setup switch so that the arrow indicates 'White Bal'. 2.

  • Page 39: Wdr Setting

    ’ ’ 6-7. WDR Setting WDR illuminates darker spots of an image while retaining the same light level for brighter spots to even out the overall brightness of images with high contrast between bright and dark spots. 1. When the SETUP menu screen is displayed, select 'WDR' by using the switch so that the arrow indicates 'WDR'.

  • Page 40: Backlight Setting

    ’ ’ 6-8. Backlight Setting Unlike conventional cameras, the 650Line Intensifier3™ Series are designed to deliver a distinctive subject and background at the same time, even when the subject is backlight, by using the features of the proprietary W-V DSP chip. 1.
  • Page 41 ’ ’ ☞ NOTE ■ Because there can be a difference in the effectiveness of HLC according to the amount of light area in the screen, optimize the installation angle for the best HLC performance. ■ When dark, the HLC is only activated when a bright light exceeding a specific size in NIGHT ONLY mode. ■...

  • Page 42: Speco Dnr Setting

    ◆ OFF : Deactivates SPECO DNR. Noise is not reduced. ◆ ON : Activates SPECO DNR so that noise is reduced. 3. Set the SPECO DNR mode to 'ON' and press the Function Setup switch. Then you can adjust the noise reduction level.

  • Page 43: Day/Night Setting

    ’ ’ 6-10. Day/Night Setting You can display pictures in color or black and white. 1. When the SETUP menu screen is displayed, select 'DAY/NIGHT'by using the Function Setup switch so that the arrow indicates 'DAY/NIGHT'. 2. Select a desired mode using the Function Setup Switch according to the picture display you want. ◆...
  • Page 44 ’ ’ - BURST MODE : You can turn on or off the burst signal on B/W mode. - DURATION : You can select brightness of illumination about changing the day/night mode. - DWELLTIME : You can select the duration time about changing the day/night mode. →3s, 5s, 7s, 10s, 15s, 20s, 30s, 40, 60s * The day/night switching point of the camera can be adjusted.

  • Page 45: Special Setting

    ’ ’ 6-11. Special Setting 1. When the SETUP menu screen is displayed, select 'SPECIAL' by using the Function Setup switch so that the arrow indicates 'SPECIAL'. 2. Select a desired mode using the Function Setup switch. Rev.1.2 (April, 2012)
  • Page 46 ’ ’ ◆ IMAGE ADJ. : 1) When the SETUP menu screen is displayed, select 'IMAGE ADJ' by using the Function Setup switch so that the arrow indicates 'IMAGE ADJ'. 2) Select a desired mode using the Function Setup switch. * V-REV : You can flip the picture vertically on the screen.
  • Page 47 ’ ’ ◆ CAM TITLE: If you enter a title, the title will appear on the monitor. 1) If the SPECIAL menu screen is displayed, use the Function Setup switch so that the arrow indicates 'CAM TITLE'. 2) Set it to 'ON' by using the Function Setup switch. 3) Press the Function Setup switch.
  • Page 48 ’ ’ ☞ NOTE ■ When the CAM TITLE menu is ‘OFF’, no title will be displayed on the monitor screen even if you enter one. ■ Only English is available in this mode. ■ If you move the cursor to CLR and press the Function Setup switch, all the letters are deleted. To edit a letter, change the cursor to the bottom left arrow and press the Function Setup switch.
  • Page 49 ’ ’ indicates ‘MOTION DET’. 2) Set up the mode using the Function Setup switch. - SENSITIVITY: You can select up to 8 MD areas. When SENSITIVITY number is high, motion detection sensitivity is increased to recognize even small movement. - AREA MODE: Determines whether to use the MD area selected in SENSITIVITY.

  • Page 50: Return Setting

    ’ ’ 6-12. RETURN Setting Select a desired RETURN mode using the Function Setup Switch. - SAVE: Save the current settings and RETURN the MAIN SETUP menu. - NOT SAVE: Do not save the current settings and RETURN the MAIN SETUP menu. - RESET: Resets the camera settings to the factory defaults.
