Identifying the Parts

1) On Off/ Sensitivity control
2) Iron Vol. control
3) Pinpoint switch
4) Disc Vol. control
5) Disc control
6) Ground control
7) Control box mounting clip
8) Loudspeaker
9) Battery compartment
10) 8 x AA battery holder
11) Battery contacts
12) Search-head socket
13) Headphone socket
14) Control box
15) Hand grip
16) Upper stem
17) Arm support
18) Detector rest
19) Stem lock
20) Lower stem
21) Interchangeable Search-head
22) Search-head fixing screw and wing-nut
23) Search-head lead
2
23
9
14
CS6MX
7
15
16
10
9
14
6
2
1
17
18
12
11
7
5
3
8
4
