Identifying the Parts

1) On Off/ Sensitivity control
2) Ground Level control
3) Pinpoint/ Discrimination 1/ Discrimination 2 switch
4) All-Metal/ Discrimination Level control 1
5) Discrimination Level control 2
6) Control box mounting clip
7) Loudspeaker
8) Battery compartment
9) 8 x AA battery holder
10) Battery contacts
11) Search-head socket
12) Headphone socket
13) Control box
14) Hand grip
15) Upper stem
16) Arm support
17) Detector rest
18) Stem lock
19) Lower stem
20) Interchangeable Search-head
21) Search-head fixing screw and wing-nut
22) Search-head lead
2
18
22
8
13
CS4MX
6
14
15
9
8
12
3
2
1
16
17
11
10
6
5
7
4
