CS1220XD - RAPID GET YOU GOING INSTRUCTIONS
Assemble and adjust for length (Twist surplus lead around stem).
Insert batteries.
Set the MODE SELECT (bottom right) to METER AUDIO DISC.
Set POWER ON/OFF TUNE (top left) to ON.
Set SENSITIVITY fully anticlockwise to the BATTERY CHECK position. The meter will
indicate in the right hand green sector if the batteries are OK.
Set SENSITIVITY to mid position (12 o'clock).
With the search head 1-2 cm from the ground, press and hold the RETUNE button (lower
mid) and adjust the TUNE control until a tone is just heard. Release the RETUNE button.
The CS1220XD is now ready for use. If the tone drifts from the threshold position press the
RETUNE button to reset the level.
You are now in a PROGRAMMED MODE. The other modes require more detailed
explanation found in the following pages.
IF A PROBLEM IS ENCOUNTERED REFER TO THE FULL INSTRUCTIONS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS1220XD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for C-SCOPE CS1220XD

Summary of Contents for C-SCOPE CS1220XD

  • Page 1 With the search head 1-2 cm from the ground, press and hold the RETUNE button (lower mid) and adjust the TUNE control until a tone is just heard. Release the RETUNE button. The CS1220XD is now ready for use. If the tone drifts from the threshold position press the RETUNE button to reset the level.

  • Page 2: Table Of Contents

    BATTERIES BATTERY CHECK CONTROLS AND WHAT THEY DO METHODS OF OPERATION GENERAL HINTS ACCESSORIES (OPTIONAL) AVAILABLE FROM C-SCOPE CHARGING BATTERIES THE IMPORTANCE OF THE RIGHT APPROACH SWEEPING TECHNIQUE METAL DETECTING AND THE ENGLISH LAW CODE OF CONDUCT FOR METAL DETECTOR USERS...
  • Page 3 Controls C-Scope CS1220XD Battery Compartment Upper Stem & Handle Grips Din Plug & Socket Stem Connecting Nut Cable Lower Stem Search Head Fastener Power On / Off Tuning Signal Meter Sensitivity Discrimination Ground Select Retune Discrimination Select Function...

  • Page 4: Introduction

    The CS1220XD is powered by eight AA batteries (not supplied) available from garages, department stores, etc. or a single 12v rechargeable pack from C-Scope. It is advisable to use standard alkaline batteries to start with. You can then evaluate the sort of use you give the detector and decide whether the investment in rechargeables is justified.

  • Page 5: Battery Check

    holder which is located in the battery compartment. To fit new batteries first check the power switch on the unit is switched to OFF. Then loosen the two captive screws located in the battery cover (do not fully remove these from the cover) and remove the cover. Inside is the battery holder.

  • Page 6: Controls And What They Do

    CONTROLS AND WHAT THEY DO On/Off Tune Retune button Sensitivity/Battery Check Ground Push Select button Function/Mode Select control Discrimination Discriminate Push Select button 8. Signal Meter Power On/Off Tune Switch (1) This rotary control switches the detector on and adjusts the level of audio tune to the user’s preference and the level of meter tune when in the Manual Control modes (see below).
  • Page 7 It is very unlikely that a valuable object will be rejected with the CS1220XD’s AUDIO or METER DISCRIMINATION modes.
  • Page 8 manufacture at the optimum level. The level is the same in switch positions GD1 and GD2. Discriminate D1 & D2 The Discriminate circuit can be set to the range GD1 or range GD2 using the FUNCTION switch. Range GD1 allows the user to select the level of Discrimination from iron to small silver foil.

  • Page 9: Methods Of Operation

    Signal strength - when in GD1 or GD2 and the ‘all metal’ Ground mode. METHODS OF OPERATION There are two main ways to use the CS1220XD: 1) Pre-programmed searching - for ease of use 2) Manual settings - for total flexibility on all sites Check the batteries are in good condition prior to searching.
  • Page 10 Meter Disc Meter Audio Disc This is the recommended mode when starting to use the CS1220XD and is best demonstrated by an air test (with the search head away from ground and all metal objects). Turn the FUNCTION control (3) to METER AUDIO DISC (fully clockwise) and adjust the SENSITIVITY control (2) to mid-position.
  • Page 11 This mode is similar to operate to the Meter Audio Disc. The only difference is the way the CS1220XD responds to metal objects. All detected metal objects will be indicated by an increase in loudness. The meter will indicate whether the target is accepted or rejected. In this mode the audio pitch is constant.
  • Page 12 to get maximum depth without problems associated with keeping the search head a constant height above the ground surface. When a target object has been located, note the location of the signal and take the search head to one side of the object (at least two to three feet), but ensuring you do not raise the search head from the ground.

  • Page 13: General Hints

    20%. Discriminating When used in the Ground Mode the CS1220XD will detect all metals and will not discriminate. However, in the Meter Disc and Meter Audio Disc Modes the CS1220XD has been programmed to operate at a fixed discriminate setting.

  • Page 14: Detection Range

    Detection Range Your CS1220XD is a top performance detector but adverse soil conditions can significantly reduce the depth of detection. Detection ranges will vary depending on the size of the object, the length of time an object has been buried, and the type of ground the object is buried in.

  • Page 15: Accessories (Optional) Available From C-Scope

    A shrink wrapped pack of 8 rechargeable nicad batteries to replace the standard batteries and holder. Battery charger: The C-Scope battery charger is designed to charge the rechargeable pack quickly and safely. Search head cover: This provides protection to the underside of the search head when detecting in muddy or stony...

  • Page 16: Charging Batteries

    CHARGING BATTERIES A battery charge socket is provided for use with the C-Scope battery charger (see Accessories) and is located under the protective cap in the battery housing. (The smaller of the two sockets.) Inserting the charger will automatically remove the power from the detector so the charger must be removed to do a battery check.

  • Page 17: Sweeping Technique

    against you finding it. On the other hand, if you pegged out the area scientifically and searched slowly and thoroughly, the odds of finding the ring would be very much more in your favour. Remember, BE PATIENT and WORK SLOWLY. Do not try to cover too large an area, restrict yourself to a small area and work through it thoroughly.

  • Page 18: Metal Detecting And The English Law

    is well to note here that the operator should not rush. This is one of the most common mistakes made by detector users. If you rush, you will not adequately cover the ground. METAL DETECTING AND THE ENGLISH LAW The rights of the finder fall into two distinct classes. The first relates to objects that have been recently lost, and the second to items of gold or silver which are subject, or might be subject, to the laws of the Treasure Trove.

  • Page 19: Code Of Conduct For Metal Detector Users

    2. Respect the Country Code. Do not leave gates open when crossing fields, and do not damage crops or frighten animals. 3. Do not leave a mess. It is simple to extract a coin or other small objects buried a few inches under the ground without digging a great hole.

  • Page 20: Troubleshooting

    Further Information If you experience any difficulty in operating your CS1220XD, or have any questions on the information in your CS1220XD Operating Instructions Manual, please do not hesitate to phone our Customer Service Department on (01233) 629181.
