CS6Pi - RAPID GET YOU GOING INSTRUCTIONS
1.
Assemble and adjust for length (twist surplus lead around stem).
2.
Insert batteries.
3.
Set FREQUENCY to BATT. CHECK position.
4.
Turn detector on by setting THRESHOLD to position 1.
The meter needle should be in the green section of the scale if the batteries are OK.
5.
Adjust the FREQUENCY to mid scale 4-5.
6.
Adjust THRESHOLD to obtain audio threshold then back off slightly so that no
tone is heard.
7.
You will find all metals within the search head range including some iron and trash
PROVIDING THE SEARCH HEAD IS SLOWLY MOVING OVER THE
TARGET (not stationary).
IF A PROBLEM IS ENCOUNTERED REFER TO THE FULL INSTRUCTIONS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS6PI and is the answer not in the manual?

Questions and answers

Related Manuals for C-SCOPE CS6PI

Summary of Contents for C-SCOPE CS6PI

  • Page 1 CS6Pi - RAPID GET YOU GOING INSTRUCTIONS Assemble and adjust for length (twist surplus lead around stem). Insert batteries. Set FREQUENCY to BATT. CHECK position. Turn detector on by setting THRESHOLD to position 1. The meter needle should be in the green section of the scale if the batteries are OK.

  • Page 2: Table Of Contents

    CONTROLS AND WHAT THEY DO OPERATING YOUR CS6Pi IMPORTANT CONSIDERATIONS DETECTION RANGE DETERMINING THE TARGET SIZE AND DEPTH ACCESSORIES (OPTIONAL) AVAILABLE FROM C-SCOPE CHARGING BATTERIES THE IMPORTANCE OF THE RIGHT APPROACH SWEEPING TECHNIQUE METAL DETECTING AND THE ENGLISH LAW CODE OF CONDUCT FOR METAL DETECTOR USERS...
  • Page 3 Controls C-Scope CS6Pi CS6Pi Battery Compartment Upper Stem & Handle Grip Din Plug & Socket Stem Locking Nut Cable Lower Stem Search Head Fastener Power On/Off & Threshold Signal Meter Frequency...

  • Page 4: Introduction

    To protect your investment complete both sections of the enclosed guarantee card and return the reply paid portion to C-Scope (UK only). This is particularly important in order to obtain the free second year parts guarantee. Please retain the original packing box. In the event that your detector should ever require to be serviced, this package will be most suitable for postal protection.

  • Page 5: Battery Check

    Rechargeable batteries will not read as high into the green as standard batteries even when fully charged. They also give less indication of discharge on the meter during use. Checking The Batteries CS6Pi BATT. CHECK CONTROLS AND WHAT THEY DO The CS6Pi has been designed to offer simplicity of use with high, reliable performance.

  • Page 6: Operating Your Cs6Pi

    When the frequency control is turned fully anti-clockwise the battery check position is reached. Batteries should be changed if the reading fails to reach the green area on the scale. The CS6Pi is a low current drain design and typical battery life will be 25 hours of intermittent use. iii.

  • Page 7: Important Considerations

    For this reason we consider that the CS6Pi is not suitable for use on sites with a high level of iron contamination.

  • Page 8: Accessories (Optional) Available From C-Scope

    CHARGING BATTERIES A battery charge socket is provided for use with the C-Scope battery charger (see Accessories) and is located under the protective cap in the battery housing. (The smaller of the two sockets.) Inserting the charger will automatically remove the power from the detector so the charger must be removed to do a battery check.
  • Page 9 should begin with research some time before the day of the actual search. The extent and thoroughness of your research will be one of the major factors in the success of your detecting. You should aim to get as complete an understanding as possible of the local history and geography.

  • Page 10: Sweeping Technique

    SWEEPING TECHNIQUE For extremely small object searching, such as coins, rings, nuggets, etc. lower the search coil to within 1 inch of the ground. Sweeping the coil from side to side in a straight line in front of you. Keep the coil at a constant height as you sweep from side to side. Move the coil at a rate of 0.5 metre per second.

  • Page 11: Care Of Your Detector

    2. Respect the Country Code. Do not leave gates open when crossing fields, and do not damage crops or frighten animals. 3. Do not leave a mess. It is simple to extract a coin or other small objects buried a few inches under the ground without digging a great hole.

  • Page 12: Further Information

    FURTHER INFORMATION If you experience any difficulty in operating your CS6Pi, or have any questions on the information in your CS6Pi Operating Instructions Manual, please do not hesitate to phone our Customer Service Department on (01233) 629181.
