TX AUX (serial) port

The AUX port is an RS232 serial port
that allows extension of RS232 signals up
to a baud rate of 115200. The port has
software flow control, but no hardware
flow control.
To connect the AUX port
1 Connect a suitable serial 'null-modem' cable (see
vacant serial port on your computer and the AUX port on the right hand side of the
ALIF rear panel.
Serial (null-modem) link
from your computer
Appendix F for pin-out) between a
A U
X

TX power in

Each ALIF unit is supplied with a power
adapter and country-specific power cord.
When all other connections have been
made, connect and switch on the power
adapter unit.
To apply power in
1 Attach the output lead from the power adapter to the
the unit.
Power cord
from adapter
2 Connect the IEC connector of the supplied country-specific power cord to the socket
of the power adapter.
3 Connect the power cord to a nearby main supply socket.
Note: Both the unit and its power supply generate heat when in operation and will become
warm to the touch. Do not enclose them or place them in locations where air cannot circulate
to cool the equipment. Do not operate the equipment in ambient temperatures exceeding 40
Do not place the products in contact with equipment whose surface temperature exceeds 40
socket on the rear panel of
5V
I N D
U S
O O
E O
R
N L
Y
O P
T
Note: Ensure that
Options switches 1
1
and 2 are both in the
5 V
'OFF' (up) position
2 . 5
1
A
to enable normal
operation of the unit.
See Options switches
for details.
o C.
C.
o
