3-4
Rear System LAN LEDs
R130-134
R130-234
No.
Name
Port 1 Link/
Activity LED
1.
(1000/10G
LAN Port)
Port 1 Link/
Activity LED
2.
(1000/10G
LAN Port)
1GbE
3.
Speed LED
1GbE
4.
Link/
Activity LED
Color
Status
On
Green
Blink
Off
On
Green
Blink
Off
Yellow
On
Green
On
N/A
Off
On
Green
Blink
N/A
Off
3
4
1
2
Link between system and network
or no access
Data transmission or receiving is occurring
No data transmission or receiving is occurring
Link between system and network
or no access
Data transmission or receiving is occurring
No data transmission or receiving is occurring
1 Gbps data rate
100 Mbps data rate
10 Mbps data rate
Link between system and
network or no access
Data transmission or receiving is occurring
No data transmission or receiving is occurring
- 31 -
3
4
3
3
Description
Hardware Installation
4
4
