2-1
Removing Chassis Cover
Before you remove or install the system cover
• Make sure the system is not turned on or connected to AC power.
Follow these instructions to remove the system cover:
1.
Loosen and remove the thumbscrew securing the front chassis cover.
2.
Press the the indentation located at two sides of the cover.
3.
Slide the cover horizontally to the back and remove the cover in the direction of the arrow.
- 17 -
Hardware Installation
