Penguin Computing Relion 900 Technical Manual page 36

Item
1 SW_ID
2 MLAN
3 USB3_LAN1
4 USB3_LAN2
5 QSFP_CAGE
6 COM1_VGA
7 F_USB3
8 PS2_USB3
9 ATX1
10 PMBUS
11 LAN4_ACT
12 LAN3_ACT
13 COM2
14 SYS_FAN5
15 P12V_AUX2
16 BP_1
17 FP_1
18 CPU1_FAN
19 DIMM_P1_E0
20 DIMM_P1_E1
21 DIMM_P1_F0
22 DIMM_P1_F1
23 SYS_FAN4
24 SYS_FAN3
25 CPU1
26 P12V_AUX1
27 DIMM_P1_H1
28 DIMM_P1_H0
29 DIMM_P1_G1
30 DIMM_P1_G0
31 DIMM_P0_A0
32 DIMM_P0_A1
33 DIMM_P0_B0
34 DIMM_P0_B1
35 SYS_FAN2
36 CPU0
37 SYS_FAN1
38 DIMM_P0_D1
39 DIMM_P0_D0
Code
ID switch button
BMC Management LAN port
LAN1 port (top) / USB 3.0 ports (bottom)/
R130-134 Only
LAN2 port (top) / USB 3.0 ports (bottom)/
R130-134 Only
QSFP LAN port/R130-234 Only
Serial port (top)/VGA port (buttom)
USB 3.0 header
PS/2 connector (top)/USB 3.0 ports (buttom)
24 pin main power connector
PMBus connector
LAN4 active LED header (QSFP Port #2)
LAN3 active LED header (QSFP Port #1)
Serial port cable header
System fan connector#5
8 pin power connector (for secondary CPU)
HDD back plane board header
Front panel header
CPU1 fan connector (for Secondary CPU)
Channel 1 slot 0 (for secondary CPU)
Channel 1 slot 1 (for secondary CPU)
Channel 2 slot 0 (for secondary CPU)
Channel 2 slot 1 (for secondary CPU)
System fan connector#4
System fan connector#3
Intel LGA2011 Socket R3 (Secondary CPU)
8 pin power connector (for primary CPU)
Channel 4 slot 1 (for secondary CPU)
Channel 4 slot 0 (for secondary CPU)
Channel 3 slot 1 (for secondary CPU)
Channel 3 slot 0 (for secondary CPU)
Channel 1 slot 0 (for primary CPU)
Channel 1 slot 1 (for primary CPU)
Channel 2 slot 0 (for primary CPU)
Channel 2 slot 1 (for primary CPU)
System fan connector#2
Intel LGA2011 Socket R3 (Primary CPU)
System fan connector#1
Channel 4 slot 1 (for primary CPU)
Channel 4 slot 0 (for primary CPU)
Description
- 35 - Hardware Installation
