4-2

Jumper Setting

6
5
4
3
No. Jumper Code
SATA_DOM4 (SATA
1.
port 4 DOM Jumper)
SATA_DOM5
2.
(SATA 5 DOM Jumper)
CLR_CMOS
3.
(Clearing CMOS Jumper)
CAUTION! If a SATA type hard drive is connected to the system, please ensure the jumper is
closed and set to 2-3 pins (Normal mode), in order to reduce any risk of hard disk damage.
8
7
2
1
Pin No.
1
2
3
Pin No.
1
2
3
1-2 Close: Normal operation (Default setting)
2-3 Close: Clear CMOS data
9
Jumper Setting
Definition
P5V
SATA4 Pin7
GND
Definition
P5V
SATA5 Pin7
GND
- 37 - Hardware Installation
