Installing the Franker Roller

Note: This step only applies to CheXpress CX30s that have the optional franker configuration. Follow these
instructions when installing the franker roller for the first time, or when replacing an empty franking roller.
Step 1: Remove the Main Scanner Cover. Open
the Exit Door located at the rear of the scanner.
Locate the Spring Loaded Arm.
Step 3: Holding the Franker Roller (as shown),
slide the Roller onto the Post.
Step 2: Swing out and hold the Spring Loaded
Arm open (as shown).
The Franker Roller will slide onto a Post that is
part of the Spring Loaded Arm.
Step 4: Confirm that the Franker Roller is fully
seated onto the Post. The top of the Post should
be level with the Franker Roller (as shown).
The Tab on the Spring Loaded Arm should be
touching the metal Plunger (as shown). Close the
Exit Door and replace the Main Scanner Cover.
®
