Olympic Heavy Duty
Accessory Rack
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Olympic Olympic Heavy Duty and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hammer Strength Olympic Olympic Heavy Duty

Summary of Contents for Hammer Strength Olympic Olympic Heavy Duty

  • Page 1 Olympic Heavy Duty Accessory Rack Owner’s Manual...

  • Page 2: Assembly Instructions

    OHD Accessory Rack 1. Assembly Instructions Item Description Upright Left Base 1/2” x 4.25” Bolt Plastic Dome Washer 1/2” I.D. Washer 1/2” Nylock Nut Right Base Bracket Center Cross Brace Left Adjustment Rack 3/8” x 3.5” Hex Screw 3/8” I.D. Washer 3/8”...
  • Page 3 1. Assemble one UPRIGHT (1) and the LEFT BASE (2) using two 1/2” X 4.25” BOLTS (3), two 1/2” PLASTIC DOMED WASHERS (4), two 1/2” I.D. WASHERS (5) and two 1/2” NYLOCK NUTS (6) as shown. Tighten the BOLTS and NUTS securely. Do not overtighten the BOLTS and NUTS. NOTE: Be sure the flush-ground surface UPRIGHT (1) is positioned to face the inward as shown.
  • Page 4 OHD Accessory Rack 1. Assembly Instructions 4. For OHDHR and OHDCR (Figure 1): Assemble the LEFT ADJUSTMENT RACK (10) to the LEFT UPRIGHT(A) using four 3/8” X 3.5” HEX SCREWS (11), two 3/8" I.D. WASHERS (12) and four 3/8” NYLOCK NUTS (13).
  • Page 5 OHD Accessory Rack 2. Safety & Warranty It is the sole responsibility of the purchaser of Hammer Strength products to instruct all individuals, whether they are the end user or supervising person- nel on proper usage of the equipment. It is recommended that all users of Hammer Strength exercise equipment be informed of the following information prior to its use. PROPER USAGE Do not use any equipment in any way other than designed or intended by the manufacturer.
  • Page 6 OHD Accessory Rack 2. Safety & Warranty WARRANTY WHAT IS COVERED This Hammer Strength commercial exercise equipment (Accessory Rack) is warranted to be free of all defects in material and workmanship. WHO IS COVERED The manufacturer’s warranty covers the original purchaser or any person receiving the Product as a gift from the original purchaser. WHO PAYS TRANSPORTATION &...
  • Page 7 HOW TO GET PARTS & SERVICE Call Customer Support Services at (800) 351-3737 or (847) 451-0036, Monday through Friday from 8:00 a.m. to 6:00 p.m. Central Standard Time. Have the following information available when calling; name, address and serial number of the Product. Hammer Strength will provide information on how to obtain a replacement part, advice on how and where to ship the Product for service or, if necessary, arrange for on-site service.

  • Page 8: Specifications

    OHD Accessory Rack 3. Specifications General Specifications 1. Equipment Anchoring All machines have holes in the feet, which allow for easy anchoring to the floor. Hammer Strength recommends that all machines be anchored to the floor to minimize the possibility of tipping. 2.

This manual is also suitable for:

Olympic heavy duty accessory rackOhdac
