Band Selection - TTI TCB-881 Instruction Manual

9. Band Selection

going to select.The LCD display offers you the band
information.The band chart for each area is as follows.
Press AM/FM button while the band information is blinking or
wait for 5 seconds to complete the selection and go to the
transmit and receive mode.This transceiver has "EC" band
setting when it is shipped out from the factory.
Settings Display
EC Europe 40 Ch FM 4W
E Spain 40 Ch AM/FM 4W
F France 40 Ch FM 4W, 40 Ch AM 1W
Poland 40 Ch AM / FM 4W
PL
(Polish Frequencies : 5KHz)
UK UK 40 Ch FM 4W (British Frequencies)
UE UK 40 Ch FM 4W (British Frequencies)
(EU/UK) + CEPT 40 Ch FM 4W (EC)
Italy 40 Ch AM / FM 4W
I
Italy 34 Ch AM / FM 4W
I2
Germany 80 Ch FM 4W, 12 Ch AM 1W
D
Germany 40 Ch FM 4W, 12 Ch AM 1W
D2
Europe 40 Ch FM 4W, 40 Ch AM 1W
EU
14
Pressing AM/FM button and Scan
button at the same time, turn on the
transceiver. Using the channel
selector, select the band that you are
Band
TCB-881
