ST Series
Slope Top Convector
Installation, Operation & Maintenance Instructions
GENERAL
Slope top heaters are designed to mount on the wall at sill height (or lower) and can be positioned directly on the floor. The end of
the unit can be positioned against adjacent sidewall if desired. Units are prewired and are designed for either right hand or left hand
entry for easy connection of supply wiring from bottom, rear, or end, as well as multiple wiring of adjacent heaters from one entry
point.
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAU-
TIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY TO
PERSONS, INCLUDING THE FOLLOWING:
1. Read all instructions before installing or using the heater.
2. A heater has hot and arcing or sparking parts inside. Do not
use in areas where gasoline or flammable liquids are used
or stored.
3. This heater is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. Keep combustible materials,
such as boxes, crates, furniture, pillows, bedding, papers,
clothes, and curtains away from heater.
IMPORTANT INSTRUCTIONS
WARNING
SAVE THESE INSTRUCTIONS
FILE #E37116
!
4. To prevent a possible fire, do not block air intakes or
exhaust in any manner.
5. Do not insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock or
fire, or damage the heater.
6. Serious injury or death could result from electric shock.
Make sure electrical power supply circuit coming to heater
is disconnected at main disconnect or service panel before
installing or servicing this heater.
7. This heater is not for residential or household use.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Marley ST02125
Summary of Contents for Marley ST02125
-
Page 1: Important Instructions
