900 Series
Cabinet Unit Heaters
Model B
Installation & Maintenance Instructions
Dear Owner,
Congratulations! Thank you for purchasing this new heater manufactured by a division of Marley Engineered
Products. You have made a wise investment selecting the highest quality product in the heating industry.
Please carefully read and follow the installation and maintenance directions shown in this manual. You should
enjoy years of efficient heating comfort with this product from Marley Engineered Products... the industry's
leader in design, manufacturing, quality and service.
Read carefully - These instructions are written to help
you prevent difficulties that might arise during installation
of heaters. Studying the instructions first may save you
considerable time and money later. Observe the follow-
ing procedures and cut your installation time to a mini-
mum.
TO REDUCE RISK OF FIRE AND ELECTRIC SHOCK:
1. Disconnect all power coming to the heater at main
service panel before wiring or servicing.
Note: More than one disconnect may be required.
2. All wiring must be in accordance with national and
local electric codes and the heater must be ground-
ed.
3. Verify the power supply voltage coming to heater
matches the ratings printed on the heater nameplate
before energizing.
4. This heater is hot when in use. To avoid burns, do
not let bare skin touch hot surfaces.
5. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause
SAVE THESE INSTRUCTION SHEETS
WARNING
!
1
... The Employees of
Marley Engineered Products
electric shock, fire, or damage to heater.
6. Do not block air intakes or exhaust in any manner.
Keep combustible materials at least 24" (610 mm)
away from heater. Keep drapes at least 6" (153 mm)
above top of front discharge grille. Do not use
drapes above top discharge units. Do not install
behind doors, furniture, towel rack, or boxes.
7. A heater has hot and arcing (sparking) parts inside.
Do not use in areas where gasoline, paint, or flam-
mable
liquids are used or stored.
8. Use this heater only as described in this manual. Any
other use not recommended by the manufacturer
may cause fire, electric shock, or injury.
9. This heater is not approved for use in corrosive
atmospheres such as marine, green house, or chem-
ical storage areas.
10. FOR DUCT CONNECTED HEATERS, Do not
exceed 0.2" wg. external static pressure and do not
mount heater on end panels.
11. Do not use OPTIONAL 0-100% OUTSIDE AIR
DAMPER with bottom air inlet.

Advertisement

Table of Contents
loading

Summary of Contents for Marley 935

  • Page 1 Installation & Maintenance Instructions Dear Owner, Congratulations! Thank you for purchasing this new heater manufactured by a division of Marley Engineered Products. You have made a wise investment selecting the highest quality product in the heating industry. Please carefully read and follow the installation and maintenance directions shown in this manual. You should enjoy years of efficient heating comfort with this product from Marley Engineered Products...
  • Page 2: Specifications

    Specifications Total Line Amperage (includes motor amps) HEATING Cabinet CAPACITY Length 1 ph 3 ph 1 ph 3 ph 1 ph 1 ph 3 ph 3 ph 3 ph BTU/hr Series (in) CFM* 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz...
  • Page 3 General Information 1. Create on opening in the wall 26-5/8” (676mm) high by the width of the heater plus 1/4” (6.4mm). Example: If the heater 900 Series Cabinet Unit Heaters are designed and UL & cUL was 68 inches long, the opening should measure Listed to be applied as Standard Free Air heaters with both 26-5/8”...
  • Page 4: Ducted Applications

    DUCTED APPLICATIONS WARNING 1. See Figure 3 for duct flange size and location. 2. Duct collars have been factory located (Bottom inlet, Front TO REDUCE RISK OF FIRE AND ELECTRICAL inlet, Top discharge, Front discharge) as ordered. SHOCK: DO NOT USE 0-100% OUTSIDE AIR DAMPER OPTION WITH BOTTOM AIR INLET.
  • Page 5 Downflow Upflow Downflow Upflow Figure 1 Ceiling 5" min. Zero or greater 24" min. 24" min. (127 mm) (610 mm) (610 mm) HEATER: Wall Mounted 24" min. 24" min. 5" min. (610 mm) (610 mm) Zero or greater (127 mm) Floor Upflow (semi-recessed) Downflow (semi-recessed)
  • Page 6: Mounting Dimensions

    Figure 2 Figure 2 MOUNTING DIMENSIONS (889 mm) Including Front Cover 9-7/8 13-1/2 (457 mm) (343 mm) (251 mm) (413 mm) 16-1/4 Heater Back Front Cover 1-23/32", 1-23/64", 1-31/32" 26-3/8 Concentric Knockouts OPTIONAL (670 mm) OUTSIDE AIR Collar 7/8", 1-3/32" (76 mm) 8-7/16 OPTIONAL...
  • Page 7 Figure 3 DUCT COLLARS DIMENSIONS and INSTALLATION DETAILS (124 mm) 9/16 4-7/8 (14 mm) (173 mm) (173 mm) 6-13/16 6-13/16 (543 mm) (103 mm) 2 (51mm) 4-7/8 21-3/8 4-1/16 2 (51mm) (124 mm) Heater Back Heater Back (124 mm) 2 (51mm) 4-1/16 (173 mm) (173 mm)
  • Page 8: Typical Wiring Diagram

    WIRING TO CONVERT 208, 240, 480 & 600 VOLT STOCK 5 & 10 KW HEATERS SEE WARNING STEPS 1, 2 & 3 ON PAGE 1 OF THIS From Three Phase To Single Phase INSTRUCTION SHEET. Figure 4 shows a typical wiring diagram. Remove front cover.
  • Page 9 CIRCUIT BREAKERS ORDER PART NO. 410086+VAR NOTED BELOW CABINET 1 PH LENGTH KW 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ QTY VAR QTY VAR 35 in. 48 in. 58 in. 68 in. 78 in.
  • Page 10 ELEMENTS ORDER PART NO. 1802-2083+VAR NOTED BELOW CABINET 1 PH LENGTH KW 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ QTY VAR QTY VAR 35 in. 48 in. 58 in. 68 in. 78 in.
  • Page 11 REPLACEMENT PARTS LIST (cont.) Basic Model Series Description Filter (Permanent) 2010-7008-006 2010-7008-007 2010-7008-008 2010-7008-006 2010-7008-007 2010-7008-007 Filter (Throw-Away) 2010-7009-006 2010-7009-007 2010-7009-008 2010-7009-006 2010-7009-007 2010-7009-007 Motor 3900-2032-000 3900-2033-000 3900-2033-000 3900-2033-000 3900-2033-000 3900-2032-000 Manual Reset Limit 4520-2017-000 4520-2017-000 4520-2017-000 4520-2017-001 4520-17-002 Auto Reset Limit 4520-2048-000 Power Relay (24V Control)
  • Page 12: Limited Warranty

    Marley authorized service center or the Marley Engineered Products Center, and we will repair or replace, at our option, at no charge to you with return freight paid by Marley. It is agreed that such repair or replacement is the exclusive remedy available from Marley Engineered Products.
