CLUB SERIES 45 DEGREE

BACK EXTENSION

ASSEMBLY INSTRUCTIONS
Part # 7199901
1
Revision:10/19/01
Rev A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Club Series 45X and is the answer not in the manual?

Questions and answers

Summary of Contents for Life Fitness Club Series 45X

  • Page 1: Back Extension

    CLUB SERIES 45 DEGREE BACK EXTENSION ASSEMBLY INSTRUCTIONS Part # 7199901 Revision:10/19/01 Rev A.
  • Page 2: Parts List

    PART # DESCRIPTION 72000 FRAME 72006 HIP PAD ADJUST 72012 SUPPORT 72015 FORMED ANGLE 69132 HIP PAD 3202403 3/8 X 2-3/4” BUTTON HEAD 3102904 3/8 X 3” BOLT 3233301 5/16 X 1/2” SHOULDER BOLT NOTE: BOLT LENGTH IS MEASURED FROM THE UNDERSIDE OF THE HEAD OF THE BOLT. PARTS LIST HARDWARE BAG: ACUHB-CS45XPLT...
  • Page 3 7 3/8 X 3” BOLT 3/8” LOW HEIGHT LOCK 10 3/8 X 3-3/4” BOLT 3/8” SAE WASHER 6 3/8 X 2-3/4” BUTTON HEAD BOLT 8 5/16 X 1/2” SHOULDER HEAD BOLT 3/8” BLACK SAE WASHER LOCK WASHER WASHER RH CAP (WHITE/PLATINUM)
  • Page 4 FIGURE 1 STEP 1: • SECURELY assemble the two SUPPORTS (3) to the FRAME (1) using eight RH CAPS (15), four 3/8 X 3-3/4” BOLTS (10), eight 3/8” SAE WASHERS (12), eight 3/8” RH WASHERS (13) and four 3/8” LOW HEIGHT LOCK NUTS (11) as shown in FIGURE 1.
  • Page 5: Spring Pin

    FIGURE 2 SPRING PIN 6 3/8 X 2-3/4” BUTTON HEAD 14 BLACK STEP 2: • Pull back the SPRING PIN on the FRAME (1) and insert the HIP PAD ADJUST (2) as shown in FIGURE 2. • SECURELY assemble the FORMED ANGLE (4) to the FRAME (1) using two 3/8 X 2-3/4” BUTTON HEAD BOLTS (6), two 3/8” BLACK SAE WASHERS (14), two 3/8”...
  • Page 6 FIGURE 3 8 5/16 X 1/2” SHOULDER BOLT STEP 3: • SECURELY assemble one 5/16 X 1/2” SHOULDER BOLT (8) and one 1/4” LOCK WASHER (9) to the HIP PAD ADJUST (2) as shown in FIGURE 3.
  • Page 7 FIGURE 4 3” 3/8 X 3” 7 STEP 4: • SECURELY assemble the two HIP PADS (5) to the HIP PAD ADJUST (2) using two RH CAPS (15), two 3/8 X 3” BOLTS (7) and two 3/8” RH WASHERS (13) as shown in FIGURE 4. (Note the the direction of the hole pattern on pad.)
  • Page 8: Warranty Information

    There is a risk assumed by individuals who use this type of equipment. To minimize risk, please follow these rules: 1. Inspect equipment daily. Tighten all loose connections and replace worn parts immediately. Failure to do so may result in serious injury. 2.
