- Page 1 WT. STACK SHROUD FOR CLASS - H,S PART # 7822601 REV. B VERSION: LFG5/FSFCM1-SHR-101 DATE: 06-15-05 G5/FIT 1.0 CM USER GUIDE WARNING: Read and follow all directions for each step to insure proper assembly of this product.
-
Page 2: Important Safety Information
Life Fitness dealer. Please note: * Thank you for purchasing the Life Fitness Weight Stack Shroud for G5/FIT 1.0 CM. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. -
Page 3: Components List
* 3/4 Wrench * Phillups Screw Driver PA RT NO. DESCRIPTION LEA 7801595 SHROUD, G5/FIT 1.0 CM WEIGHT STA CK LEA 7822495 PTD A SSY , SHROUD BRA CKET TOP LEA 7822595 PTD A SSY , SHROUD BRA CKET BOTTOM... -
Page 4: Assembly
TOP COVER TOP SHROUD REMOVE THIS CABLE ONLY CABLE END ASSEMBLY WEIGHT PLATES FIGURE 1 NOTE: IF SHROUD IS BEING INSTALLED ALONG WITH THE GYM SYSTEM GO TO STEP 3 STEP 1: Disassemble one cable end and remove cable. Remove TOP COVER and TOP SHROUD from machine. Remove WEIGHT PLATES. - Page 5 STEP 2: Remove entire WEIGHT PLATE GUIDE ASSEMBLY AS SHOWN IN FIGURE ABOVE. Discard CAP SCREWS shown above NOTE: YOU WILL NEED TO RE-ASSEMBLE. THEREFORE, IT IS IMPORTANT THAT YOU REMEMBER THE PROPER ORDER OF ALL COMPONENTS AS SHOWN. IF NEED BE REFER TO GYM SYSTEM MANUAL FOR DETAILED ASSEMBLY !! DISCARD CAP SCREWS FIGURE 2...
- Page 6 FIGURE 3 STEP 3: Slide one SHROUD (1) into back of machine and slide forward to make room for WEIGHT PLATE and GUIDE ASSEMBLY. Place BOTTOM SHROUD BRACKET (3) on BASE. Re-install WEIGHT GUIDE ASSY. Including new SHROUD BRACKETS, TOP(2) and BOTTOM (3) as shown in figure above.
- Page 7 TOP SHROUD 3/8 x 3-1/2 WEIGHT PLATES TIGHTEN SECURELY FIGURE 4 STEP 4: Securely assemble TOP SHROUD to gym using two 3/8 X 3-3/4 CAPS SCREWS (5) Re-install CABLE and CABLE END: REFER TO FIG 1 CAREFULLY Slide all WEIGHT PLATES back into position.
- Page 8 TOP COVER FIGURE 5 STEP 5 Place other SHROUD (1) into back of gym as shown above and securely tighten both SHROUDS (1) to TOP SHROUD BRACKET (2) and BOTTOM SHROUD BRACKET (3) using eight 3/8 WASHERS (6) and eight 3/8 X 3/4 CAP SCREWS (4). Place TOP COVER back into position and tighen with screws.
-
Page 9: Maintenance
Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your Life Fitness customer service representative at (800) 328-9714.(Outside of the U.S. and Canada, +1-847-288-3300) * Inspect equipment daily. -
Page 10: Limited Warranty
Life Fitness extends the following LIMITED W ARRANTY to the original owner (proof of purchase required, keep your receipt with this manual) of the Life Fitness product. The W arranty terms apply to IN HOME and LIGHT INSTITUTIONAL USE ONLY. -
Page 11: International Offices
Life Fitness Italia S.R.L. Via Elvas 92 39042 Bressanone Italy Phone: 39 (472) 835-470 Fax: 39 (472) 833-150 Life Fitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LIFE FITNESS www.LifeFitness.com...
