Summary of Contents for Kichler Lighting Canfield Patio 310192
- Page 1 Canfield Patio ® ™ A Kichler Select ceiling fan Kichler ® Lighting 7711 East Pleasant Valley Road P.O. Box 318010 Cleveland, Ohio 44131-8010 Instruction Manual Customer Service 866.558.5706 8:30 AM to 5:00 PM EST, Monday - Friday...
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 10. To avoid personal injury or damage to the 2. -
Page 3: Tools And Materials Required
52" Canfield Patio 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Canopy &... -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building structure. -
Page 5: Hanging The Fan
52" Canfield Patio 5. HANGING THE FAN Ceiling mounting REMEMBER to turn off the power before you bracket begin. Canopy To properly install your ceiling fan, follow the steps below. Canopy cover Step 1. Remove the decorative canopy Fig. 5 bottom cover from the canopy by turning the cover counter clockwise. - Page 6 Step 8. Slip the coupling cover, canopy cover and canopy onto the downrod. Hanger ball Thread the hanger ball onto the downrod, Downrod insert the cross pin through the downrod and tighten. Now tighten the set screw. (Fig. 9) Canopy Step 9.
-
Page 7: Installation Of Safety Support
52" Canfield Patio 6. INSTALLATION OF SAFETY SUPPORT (required for Canadian installation ONLY) A safety support cable is provided to help prevent the ceiling fan from falling, please install it as follows. Hanger bracket Step 1. Attach the provided wood screw and Attach safety cable to ceiling joist with washers to the ceiling joist next to the... -
Page 8: Finishing The Installation
8. FINISHING THE INSTALLATION Step 1. Tuck all the connections neatly into Outlet box the ceiling outlet box. Step 2. Slide the canopy up to the mounting Hanger bracket and place one of the key hole slots bracket over the mounting screw on the mounting Screws bracket. -
Page 9: Installing The Switch Housing
52" Canfield Patio 10. INSTALLING THE SWITCH HOUSE MOUNTING PLATE 1. Loosen the two screws on the mounting ring attached to the motor shaft and "remove" and save the third screw. (Fig. 15) 2. Place the key holes on the mounting plate over the 2 screws previously loosened from the mounting ring, turn mounting plate until it locks in place at the narrow section of the key... - Page 10 12. OPERATING INSTRUCTIONS Turn the power on and check the operation of your ceiling fan. The pull chain controls the 3 speeds of your ceiling fan. 1 pull = High, 2 pulls = Medium, 3 pulls = Low and the 4th pull turns the motor off. Fig.
-
Page 11: Troubleshooting
52" Canfield Patio 13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check that all fuses or circuit breakers are installed or in the ON position. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. Fan sounds noisy.
