E5000 Processor specifications

Mechanical/Environmental
Casing
Operating temp
Water ingress
Weight - processor unit only
Dimensions (overall)
Electrical
Operating voltage
Power consumption
Low power standby mode
Protection
Alarm output current
CPUs
RAM
Storage
Conformity
Interfaces
Ethernet
NMEA 2000 (compliant)
Video input
Video output for NSO evo2
(60Hz nominal)
Video output for ECDIS
(60Hz nominal)
USB
SD
NMEA 0183 port baud rate
RS422 port baud rate
Charting support
E5000 Processor specifications |
ABS plastic
-15°C to +55°C
IPx2
1060 grams
281 mm (W) x 232 mm (H) x 65.5 mm (D)
9 - 31.2 V DC
45 W max, 1 W off (power connected to +ve supply)
yes
reverse polarity and temporary over-voltage to 36V
1 A
iMX61 quad core (x2)
DDR3 1GB
16 GB ECDIS / 8 GB NSO evo2
CE, C-Tick, HDMI
3 ports total - 1 & 2 are PoE (RJ45 socket)
1 port on rear (Micro-C male, LEN = 1)
2 ports on rear (BNC female. NTCS or PAL format)
800x600 (SVGA 4:3)
1024x768 (XGA 4:3)
1280x720 (HD 16:9)
1366x768 (WXGA)
1920x1080 (Full HD 16:9)
1920x1200 (WUXGA 16:10)
1280x800 (16:10)
1280x1024 (SXGA 5:4)
1920x1080 (Full HD 16:9)
mass storage (Type A socket)
32GB (Full size SD card socket)
4800, 9600, 19200, & 38400 (via proprietary cable)
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
E5024 ECDIS system: S57 or S63 approved ENC charts
NSO evo2: Refer to NSO evo2 Operator Manual
